SKF Lincoln FlowMaster II Instruction Manual

User and maintenance instructions
Model , series “A”
FlowMaster II rotary driven
hydraulic pump
Date of issue November 
Form number 
Version 

* Indicates change.
Contents
Declaration of Incorporation * . . . . . . 
U.K. Declaration of Incorporation * . . 
Safety *. . . . . . . . . . . . . . . . . . . . . . . . . . 
Usage . . . . . . . . . . . . . . . . . . . . . . . . . . . 
Description. . . . . . . . . . . . . . . . . . . . . . . 
Appropriate use. . . . . . . . . . . . . . . . . . . 
Operation with system controller . . . . 
Specifications . . . . . . . . . . . . . . . . . . . . . 
Dimensions . . . . . . . . . . . . . . . . . . . . . . . 
Installation. . . . . . . . . . . . . . . . . . . . . . . 
Operation . . . . . . . . . . . . . . . . . . . . . . . . 
Fill reservoir . . . . . . . . . . . . . . . . . . . . . 
Maintenance and repair . . . . . . . . . . . . 
General maintenance . . . . . . . . . . . . . . 
System malfunction . . . . . . . . . . . . . . . 
Outlet check service . . . . . . . . . . . . . . . 
Vent valve service . . . . . . . . . . . . . . . . . 
Safety unloader valve. . . . . . . . . . . . . . 
Bare pump assembly . . . . . . . . . . . . . . 
Reservoir cover . . . . . . . . . . . . . . . . . . . . 
Outlet check assembly () . . . . . . . . . . . 
Hydraulic vent valve () . . . . . . . . . . . . 
Cover plug . . . . . . . . . . . . . . . . . . . . . . . . 
Grease level sensor port. . . . . . . . . . . . . 
Troubleshooting . . . . . . . . . . . . . . . . . . . 
Service parts. . . . . . . . . . . . . . . . . . . . . . 
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . 


Declaration of Incorporation * DOCUMENT NUMBER
404692.DoI
Manufacturer name/address:
Lincoln Industrial Corporation
 N. Hanley Road
St. Louis, MO  U.S.A.
TEL: + () - FAX: + () -
Authorized to compile the technical file:
SKF Lubrication Systems Germany GmbH
Heinrich-Hertz-Straße -
 Walldorf, Germany
TEL: + () -
EMAIL: [e-mail] WEBSITE: www.skf.com
This Declaration of Incorporation is issued
under sole responsibility of the
manufacturer. Lincoln Industrial Corporation
hereby declares that the partly completed
machinery stated below:
Name: FlowMaster II
Model number(s): 
Description:
Rotary driven hydraulic pump (series “A”)
Year of CE: 
in its intended use, is in conformity with the
relevant union harmonization legislation:
Machinery Directive //EC
(Article  Partly Completed Machinery)
and conforms to the following harmonized
standards:
EN ISO : 
Hydraulic fluid power - general rules and
safety requirements for systems and their
components
EN ISO : 
Safety of machinery. General principles
for design. Risk assessment and risk
reduction
EN ISO :+A:
Pumps and pump units for liquids -
common safety requirements
EN : 
Liquid pumps. Safety requirements.
Procedure for hydrostatic testing
EN : 
Safety of machinery. Minimum gaps to
avoid crushing of parts of the human body
I, the undersigned of Lincoln Industrial Corporation, do hereby declare that the equipment specified above, in its intended use, conforms to
the requirements of the above EC Directive(s).
___________________________________
Robert Collins
Technical Compliance Manager
St. Louis, MO, U.S.A.
//
The following EHSR (Essential Health and
Safety Requirements) have been applied:
..a – ..b – ..c– .. – .. –
.. - .. – .. – .. – .. – ..
– .. – .. – .. – .. –.. –
... – .. – ..
The manufacturer maintains a technical file
summary sheet containing test reports and
product documentation:
Technical file summary sheet number:
RA-
The partly completed machinery shown
above should not be put into service until the
final machinery into which it is to be
incorporated has been declared in conformity
with the provisions of the directive, where
appropriate.
* Indicates change.


* Indicates change.
U.K. Declaration of Incorporation * DOCUMENT NUMBER
UK404692CA
Manufacturer name/address:
Lincoln Industrial Corporation
 N. Hanley Road
St. Louis, MO  U.S.A.
TEL: + () - FAX: + () -
Authorized to compile the technical file:
SKF (U.K.) Limited
 Canada Close
Banbury, Oxfordshire, OX RT, GBR
EMAIL: [e-mail] WEBSITE: www.skf.com
This U.K. Declaration of Incorporation is
issued under sole responsibility of the
manufacturer. Lincoln Industrial Corporation
hereby declares that the partly completed
machinery stated below:
Name: FlowMaster II
Model number(s): 
Description:
Rotary driven hydraulic pump (series “A”)
Year of CE: 
in its intended use, is in conformity with the
relevant union harmonization legislation:
Supply of Machinery (Safety) Regulations
 ( No. )
along with the following Directive(s) that
were also applied with the above legislation:
EN ISO : 
Hydraulic fluid power - general rules and
safety requirements for systems and their
components
EN ISO : 
Safety of machinery. General principles
for design. Risk assessment and risk
reduction
EN ISO :+A:
Pumps and pump units for liquids -
common safety requirements
EN : 
Liquid pumps. Safety requirements.
Procedure for hydrostatic testing
EN : 
Safety of machinery. Minimum gaps to
avoid crushing of parts of the human body
I, the undersigned of Lincoln Industrial Corporation, hereby declare that the equipment specified above, in its intended use, conforms with the
Essential Health and Safety Requirements of U.K. legislation Supply of Machinery (Safety) Regulations  No.  Annex I, Declaration of
Incorporation by the time of placing it on the market.
___________________________________
Robert Collins
Technical Compliance Manager
St. Louis, MO, U.S.A.
//
The following EHSR (Essential Health and
Safety Requirements) have been applied:
..a – ..b – ..c– .. – .. –
.. - .. – .. – .. – .. – ..
– .. – .. – .. – .. – .. –
... – .. – ..
The manufacturer maintains a technical file
summary sheet containing test reports and
product documentation:
Technical file summary sheet number:
RA-
The partly completed machinery shown
above should not be put into service until the
final machinery into which it is to be
incorporated has been declared in conformity
with the provisions of the directive, where
appropriate.


NOTE
Refer to model  manual 
for all other safety considerations.
Safety *
The assembly must be installed, maintained
and repaired exclusively by persons familiar
with the instructions.
Always disconnect power source
(electricity, air or hydraulic) from the
equipment when it is not being used.
This equipment generates high pressure.
Extreme caution should be used when
operating this equipment as material leaks
from loose or ruptured components can
inject fluid through the skin and into the
body. If any fluid appears to penetrate the
skin, seek attention from a doctor
immediately. Do not treat injury as a simple
cut. Tell attending doctor exactly what type of
fluid was injected.
Any other use not in accordance with
instructions will result in loss of claim for
warranty or liability.
• Do not misuse, over-pressurize, modify
parts, use incompatible chemicals, fluids,
or use worn and/or damaged parts.
• Do not exceed the stated maximum
working pressure of the equipment or of
the lowest rated component in your
system.
• Always read and follow the manufacturer’s
recommendations regarding fluid
compatibility, and the use of protective
clothing and equipment.
• Failure to comply may result in personal
injury and/or damage to equipment.
CAUTION
Do not operate equipment without
wearing personal protective gear.
Wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing pro-
tection used for appropriate conditions
will reduce personal injuries.
Failure to comply may result in light
personal injury.
WARNING
Do not allow any body part
to be trapped by equipment.
Body parts can be crushed
by subassemblies during
operation.
Failure to comply may result in death
or serious physical injury.
WARNING
Do not allow fluid to leak
onto floor when operating
equipment. If spill occurs,
clean any fluid on floor before continuing
operation.
Failure to comply may result in death
or serious personal injury.
WARNING
Do not use this equipment to supply,
transport, or store hazardous
substances and mixtures in accordance
with annex I part - of the CLP
regulation (EG /) or HCS 
CFR . marked with GHS,
GHS and GHS hazard pictograms
shown:
Explanation of signal
words for safety
NOTE
Emphasizes useful hints and
recommendations as well as
information to prevent property damage
and ensure efficient trouble-free
operation.
CAUTION
Indicates a dangerous situation that can
lead to light personal injury if
precautionary measures are ignored.
WARNING
Indicates a dangerous situation that
could lead to death or serious injury if
precautionary measures are ignored.
DANGER
Indicates a dangerous situation that will
lead to death or serious injury if
precautionary measures are ignored.
WARNING
Do not operate equipment
without reading and fully
understanding safety
warnings and instructions.
Failure to follow warnings and
instructions may result in serious injury.
* Indicates change.


Table 
Specifications
Supply inlet hydraulic pressure Maximum   psi (241 bar)
Operating working hydraulic pressure  psi (15 bar)
Maximum output pressure   psi (241 bar)
Hydraulic inlet flow Up to  gal/min (7.6 l/min)
Pump ratio with manifold : at low inlet pressure,
 to  psi (21 to 24 bar) and low inlet flow,
below  gal/min (7.6 l/min); Pump ratio
approaches : ratio at higher inlet pressure
and flow
Ambient operating temperature – to + °F (–40 to +66 °C) *
Operating voltage  V
Hydraulic inlet port SAE 
Tank return port SAE 
Maximum hydraulic fluid temperature  °F (121 °C)
Reservoir capacity  lbs (40.8 kg)
Usage
Description
Model  is a pumping unit designed to
operate a Centro-Matic lubrication system.
Unit includes a vent valve to relieve line
pressure to recharge injectors. FlowMaster II
rotary driven hydraulic pumps include a
pressure reducing valve, flow control valve
and solenoid operated ( V ) “on” and
“off” valve. Pressure reducing and flow con-
trol valves are factory preset and are not
adjustable.
FlowMaster II pump is fully automatic
when using a system controller and a pres-
sure switch. Pump is double acting, dispens-
ing lubricant on both up and down strokes.
This unit is designed to be used with SL-V,
SL-, SL-, SL- and SL- series injec-
tors or a combination of these.
Model  does not include a pressure
gauge.
Appropriate use
• Pump on this unit is exclusively designed
to pump and dispense lubricants using
hydraulic power only.
• Maximum specification ratings should not
be exceeded.
• Any other use not in accordance with
instructions will result in loss of claims for
warranty and liability.
Operation with
system controller
When system controller times out, lube cycle
will initiate. Solenoid is energized to deliver
hydraulic pressure to pump and vent valve.
Pump begins dispensing lubricant through
injectors to bearings.
When all bearings have received lubricant,
pressure rises in system to actuate pressure
switch. When pressure switch actuates, con-
trol is reset to de-energize solenoid valve
cutting off hydraulic oil pressure to pump
and vent valve. Pump stops, pressure vents
and pressure switch de-actuates. Control
begins timing toward next lube event.
WARNING
Do not exceed   psi (241 bar)
maximum supply inlet hydraulic
pressure or   psi (241 bar)
maximum outlet pressure.
Failure to comply may result in death,
personal injury and damage to system
components.
* Indicates change.


A-A
∅ 0.50 in (13 mm)
∅ 15.1 in (384 mm)
∅ 13.8 in (352 mm)
20° 40°
A A
18.86 in
(
479 mm )
37.43 in
(951 mm)
Fig. 
Dimensions


WARNING
Disconnect all hydraulic or electric
power to equipment before performing
maintenance or service.
Failure to comply can cause death
and/or serious personal injury.
Maintenance and
repair
General maintenance
• Keep area around pump clean. Clean off
filling port area prior to filling reservoir.
Clean area around filler after filling as
lubricants will attract dirt.
• Keep lubricants clean and free of dirt
and debris.
System malfunction
• Refer to Troubleshooting (page ) to
determine where to look if problems occur.
• Refer to corresponding sections for
replacement and repair of specific areas.
• Each part is identified with a number
keyed to a matching part on
illustrated views.
• General recommendations of tools
required are also specified in each step.
• Pay particular attention to warning
statements to prevent personal injury and
possible damage to pump components.
Installation
Place unit in approximate location making
sure electric and hydraulic power connec-
tions are accessible.
 Mark center locations of six holes at bot-
tom of reservoir.
 Drill six 1/2in (13 mm) holes. Use of 7/16 in
(10 mm) bolts will offer some flexibility in
securing reservoir to equipment.
 Connect lubricant outlet of pump to
system with suitable hose capable of
  psi (241 bar) working pressure.
 Connect hydraulic inlet with at least
3/8in (9 mm) inner diameter hose capable
of at least   psi (241 bar) operating
pressure.
 Connect hydraulic return to tank connec-
tion line with 3/4in (19 mm) inner diame-
ter hose or pipe.
 On model , both flow rate,
. gal/min (7.6 l/min), and pressure,
 psi (19 bar), are factory set and
non-adjustable.
Operation
Fill reservoir
 Clean area around filling port.
 Remove lower () and upper ()
pipe plugs from side of reservoir.
 Attach appropriate bulk-filling pump to
lower inlet ( in NPT).
 Fill reservoir until grease appears at the
top ( 1/4in NPT) vent high level port.
 Remove bulk filling pump.
 Replace both pipe plugs.
WARNING
Do not over pressurize reservoir
during filling.
Failure to comply may result in death
or serious injury.


Outlet check service
Refer to Troubleshooting (page ) to
determine if outlet check valve () is
cause of failure.
Pump will not build up sufficient lubricant
pressure if outlet check () is fouled
(† Fig.  and Fig. , page ). Foreign mate-
rial may lodge beneath check ball () or
between check disc () and seat () of
bushing assembly. Sealing surfaces of seat
must form a perfect seal.
 Turn off and disconnect hydraulic and
electric power supply to pump
assembly ().
 Standard tools required are bench
mounted vice, set of open end wrenches
ranging from 7/16 to  1/2in, large  in
(600 mm) adjustable wrench and
smaller  in (254 mm) adjustable
wrench.
 Remove hose ().
 Remove outlet check assembly ()
and adapter ().
 Remove adapter from outlet check
assembly.
 Remove outlet connector ()
from outlet check bushing ().
 Remove ball check seat () from outlet
connector ().
 Pull check disk assembly () out of ball
check seat ().
 Remove and discard gaskets ( and ).
 Clean and inspect all check
components (, , , and )
for scoring, damage or any foreign
material.
 Replace any damaged components of
outlet check assembly.
Replace gaskets ( and ).
Reverse above procedure to reassemble.
Torque check assembly to
 ft-lbf (135 Nm).
Vent valve service
Refer to Troubleshooting (page )to
determine if vent valve () is cause of
failure († Fig. , page  and
Fig. IPB , page ).
 Turn off and disconnect hydraulic and
electric power supply to pump assembly.
 Standard tools required are bench
mounted vice, set of open end wrenches
ranging from 7/16 to  1/2in,
large  in (600 mm) adjustable wrench
and smaller  in (254 mm) adjustable
wrench.
 Loosen vent hose (), supply hose ()
and hydraulic hose ().
 Remove bolts () and lock washers ().
 Remove vent valve ().
 Place base of vent valve in vice and
remove connected elbows ( and ).
 Remove hydraulic cylinder ().
 Remove piston and u-cup assembly ()
from cylinder ().
 Remove packing assembly () from
cylinder. If grease leakage is evident from
side of hydraulic cylinder, replace
packing.
 Clean and inspect needle () and valve
seat () for damage by nicks, grooves or
scoring. Replace if damaged.
 Remove valve seat () from valve
body (). Replace valve seat if damaged.
 Remove and replace gasket () under
valve seat ().
Reverse above procedure to re-assemble.
 Needle () and inside diameter of
hydraulic cylinder () should be coated
with oil or grease to assist in assembly.
 Tighten valve seat () into body ()
using  ft.lbf (34 Nm).
 Tighten hydraulic cylinder () onto valve
body () using  ft.lbf (135 Nm).
NOTE
Street elbow () must be facing down.
Elbow () must be rotated
approximately ° toward vent hose ()
to prevent excessive rubbing of hydrau-
lic hose on pump.


1
2
3 4
5
6
7
8
9
10 11
12
13
9
39
40
41
42 43
44
45
Fig. 
Reservoir cover
Fig. 
Outlet check assembly ()
Safety unloader valve
Safety unloader valve () († Fig. 2) is not
serviceable. Replace if malfunction is
apparent. Upon reassembly, tighten to
 ft-lbf (13,5 Nm).
Safety unloader valve () is set to open at
  to   psi (259 to 293 bar) lubricant
pressure. If pressure switch fails to operate
and shut off hydraulic supply to pump, safety
unloader will open at approximately
  psi (275 bar) to relieve lubricant
supply line pressure (safety unloader is
preset and not adjustable).
WARNING
Do not plug outlet of safety unloader.
Plugging safety unloader outlet will
result in pressure build up.
Failure to comply may result in death
or serious personal injury.
WARNING
Do not operate without safety unloader.
Safety unloader ships with pump
assembly, but is not pre-installed.
Safety unloader must be installed
before using pump.
Failure to comply may result in death
or serious personal injury.
Bare pump assembly
Refer to manual  for bare pump
assembly ().


33
46
47
48
49
50
51
52
26
53
54
55
56
57
58
59
60
26
Fig. 
Hydraulic vent valve ()
Fig. 
Cover plug
Fig. 
Grease level sensor port


Troubleshooting
Condition Possible cause Corrective action
Pump does not operate. No hydraulic power to pump. Turn on or connect hydraulic supply to pump.
No pressure:
• Closed supply line shut off valve. Open shut-off valve.
• No power to solenoid valve. Correct electrical fault.
• Faulty solenoid. Replace solenoid.
• Pressure reducing valve is set too low. Reset pressure reducing valve.
• Insufficient hydraulic fluid supply. Check hydraulic supply for proper pressure and flow.
Pressure is inadequate:
• Closed fluid outlet line. Check outlet line and clear obstructions.
• Pump is stalled due to grease back pressure. Check vent valve in system.
Pump is seized or damaged. Dismantle pump and repair defective or seized
component. Refer to manual .
Pump runs excessively. Pump tube malfunction. Refer to manual .
Outlet check damage or contamination. Repair check or remove contamination.
Vent valve damage or contamination. Repair vent valve or remove contamination.
System component leaking. Repair leaks.
Vent valve not receiving proper pressure to keep it closed. Orifice fitting plugged.
Injector bypassing. Repair injectors.
Pump speeds up or runs erratically. Low level of grease or reservoir is empty. Refill reservoir.
Pump piston or checks are worn. Refer to manual .
Pump runs, but output is low. Insufficient hydraulic fluid supply. Check hydraulic supply and adjust flow.
Inlet pressure too low. Increase pressure at pressure control valve.
Faulty inlet or discharge check valve in pump. Replace faulty components.
Refer to manual .
Lubricant leaking from safety
unloader valve.
Pressure of system set too high. Adjust pressure switch setting.
Safety unloader damaged or contaminated. Replace safety unloader.
Lubricant leaking from weep hole in
vent valve.
Vent valve lubricant seal damaged. Replace lubricant seal.


A-A
B-B
A A
B
B
1
2
3 4
5
6
7
8
9
10 11
12
13
14
15
61
16
17
18
19
20
21
22
23
24
25
26
27
28
29 30 31
32
33
34
35
36
37
38
9
6
9
18
Fig. IPB 


) Suggested service replacement component.
) Sold as an assembly. Individual parts not available.
) See  for pump details.
Service parts
Item Description Part Quantity Item Description Part Quantity
Vent hose assembly    Eye bolt  
 High pressure hose assembly    Hex nut (3/8-)  
 Hydraulic hose assembly    Street elbow (3/4NPT × 1/2NPT)  
 Safety unloader assembly  )  Lock washer (5/16 in)  
 Adapter (1/2NPT × 1/4NPT)    Hex head cap screw (5/16- × 3/4in)  
 Plug (1/4in)    Gasket  ) 
Plug (1/2in)    Outlet check bushing  ) ) 
Bare pump assembly  )   Pump check disk assembly  ) ) 
Street elbow (1/4NPT)    Ball check seat  ) 
 Adapter    Check ball  ) 
 Outlet check assembly    Gasket  ) 
 Orifice fitting    Outlet connector  ) 
 Pressure reducing valve    Hydraulic cylinder  
 Extension tube    Piston and seal ) ) 
 Hex head cap screw (1/4- ×  1/4in)    Needle  ) 
 Lock washer (1/4in)    Packing assembly  ) ) 
 Hex head cap screw (3/8- ×  1/4in)    Valve seat  ) 
 Lock washer (3/8in)    Check seat gasket  
 Plug ( 1/4NPT)    Valve body  
 Reservoir    Hex head cap screw (1/2- ×  in)  
 Pipe plug ( in)    Gasket  
 Vent pipe    Lock washer (1/2in)  
 Nut (7/8-)    Hex nut (1/2-)  
 Gasket )    Hex head machine screw (- × 5/8in)  
 Cover Gasket )    Lock washer (#)  
 Drum cover    Cover  
 Elbow, vent tube    Gasket  
 Pump gasket    Manifold assembly ) 
 Adapter elbow  
 Solenoid coil, V  
 Solenoid valve with manual override  
 Street elbow (1/4NPT)  
 Vent valve assembly  


skf.com | lincolnindustrial.com
® SKF, Lincoln, FlowMaster II and Centro-Matic are registered trademarks of the SKF Group.
© SKF Group 
The contents of this publication are the copyright of the publisher and may not be reproduced (even
extracts) unless prior written permission is granted. Every care has been taken to ensure the accuracy
of the information contained in this publication but no liability can be accepted for any loss or damage
whether direct, indirect or consequential arising out of the use of the information contained herein.
November  · Form 404692 Version 3
Warranty
The instructions do not contain any information on the warranty.
This can be found in the General Conditions of Sales, available at:
www.lincolnindustrial.com/technicalservice or www.skf.com/lubrication.

Gebrauchs- und Wartungsanleitung
Modell , serie „A“
Hydraulikpumpe FlowMaster II
mit Umlaufantrieb
Ausgabedatum November 2023
Formularnummer 404692
Version 3

* Kennzeichnet eine Veränderung.
Inhalt
Einbauerklärung * . . . . . . . . . . . . . . . . 3
Sicherheit * . . . . . . . . . . . . . . . . . . . . . . 4
Gebrauch . . . . . . . . . . . . . . . . . . . . . . . . 6
Beschreibung. . . . . . . . . . . . . . . . . . . . . 6
Bestimmungs-gemäße
Verwendung. . . . . . . . . . . . . . . . . . . . . . 6
Betrieb mit Systemsteuergerät. . . . . . 6
Technische Daten . . . . . . . . . . . . . . . . . . 
Abmessungen. . . . . . . . . . . . . . . . . . . . . 
Einbau . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Betrieb . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Tank füllen . . . . . . . . . . . . . . . . . . . . . . . 8
Wartung und Reparatur. . . . . . . . . . . . 8
Allgemeine Wartung. . . . . . . . . . . . . . . 8
Systemstörungen . . . . . . . . . . . . . . . . . 8
Wartung des
Auslassrückschlag-ventils . . . . . . . . . . 9
Wartung des Entlüftungsventils . . . . . 9
Druckbegrenzungs-
ventil. . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Basispumpeneinheit. . . . . . . . . . . . . . . 10
Tankdeckel. . . . . . . . . . . . . . . . . . . . . . . . 
Auslassrückschlagventil-
Baugruppe (11). . . . . . . . . . . . . . . . . . . . 
Hydraulikentlüftungsventil (33) . . . . . . . 
Deckelstopfen . . . . . . . . . . . . . . . . . . . . . 
Fettstandsensor-Anschluss . . . . . . . . . . 
Fehlerbehebung . . . . . . . . . . . . . . . . . . . 
Ersatzteile . . . . . . . . . . . . . . . . . . . . . . . . 
Garantie. . . . . . . . . . . . . . . . . . . . . . . . . . 


* Kennzeichnet eine Veränderung.
Einbauerklärung * DOKUMENTNUMMER
404692.DoI
Name/Anschrift des Herstellers:
Lincoln Industrial Corporation
 N. Hanley Road
St. Louis, MO  U.S.A.
TEL: + () - FAX: + () -
Zur Zusammenstellung der technischen Unterlagen bevollmächtigt:
SKF Lubrication Systems Germany GmbH
Heinrich-Hertz-Straße -
 Walldorf, Deutschland
TEL: + () -
EMAIL: [e-mail] URL: www.skf.com
Diese Einbauerklärung wird in der alleinigen
Verantwortung des Herstellers ausgestellt.
Lincoln Industrial Corporation erklärt
hiermit, dass die unten angegebene
unvollständige Maschine:
Name: FlowMaster II
Bestellnummer(n): 
Beschreibung:
Hydraulikpumpe mit Umlaufantrieb
serie „A“
Jahr der CE-Kennzeichnung: 
bei ihrer bestimmungsgemäßen Verwend-
ung mit der folgenden anwendbaren
EU-Harmonisierungsvorschrift
übereinstimmt:
Maschinenrichtlinie //EC
(Artikel  Verfahren für unvollständige
Maschinen)
und die Bestimmungen der folgenden
Harmonisierungsnormen erfüllt.
EN ISO : 
Fluidtechnik - Allgemeine Regeln und
sicherheitstechnische Anforderungen an
Hydraulikanlagen und deren Bauteile
EN ISO : 
Sicherheit von Maschinen –Allgemeine
Gestaltungsleitsätze. Risikobeurteilung
und Risikominderung
EN ISO :+A:
Pumpen und Pumpenaggregate für
Flüssigkeiten – Allgemeine
sicherheitstechnische Anforderungen
EN : 
Flüssigkeitspumpen –
Sicherheitstechnische Anforderungen.
Prozessverfahren für hydrostatische
Druckprüfung
EN : 
Sicherheit von Maschinen –
Mindestabstände zur Vermeidung des
Quetschens von Körperteilen
Ich, der unterzeichnendeVertreter der Lincoln Industrial Corporation, erkläre hiermit, dass die oben spezifizierte Maschine bei ihrer
bestimmungsgemäßenVerwendung die Anforderungen der oben genannten EU-Richtlinie(n) erfüllt.
___________________________________
Robert Collins
Technical Compliance Manager
St. Louis, MO, U.S.A.
//
Die folgenden grundlegenden Sicherheits-
und Gesundheitsanforderungen (Essential
Health and Safety Requirements, EHSR)
wurden angewandt:
..a – ..b – ..c– .. – .. –
.. - .. – .. – .. – .. – ..
– .. – .. – .. – .. –.. –
... – .. – ..
Der Hersteller führt technische
Konstruktionsunterlagen mit Prüfberichten
und der Produktdokumentation:
Nr. der Zusammenfassung der
technischen Unterlagen:
RA-
Die oben beschriebene unvollständige
Maschine darf erst dann in Betrieb
genommen werden, wenn die endgültige
Maschine, in die sie eingebaut werden soll,
gegebenenfalls als mit den Bestimmungen
dieser Richtlinie konform erklärt wurde.


* Kennzeichnet eine Veränderung.
Sicherheit *
Die Montage darf ausschließlich von
Personen bedient, gewartet und repariert
werden, die mit dieserAnleitung vertraut
sind.
Bei Nichtgebrauch derAusrüstung diese
stets von der Stromquelle (Elektrizität, Luft
oder Hydraulik) trennen.
Dieses Gerät erzeugt einen hohen Druck.
Beim Betrieb des Geräts ist äußerste
Vorsicht geboten. Im Falle einer Leckage
kann aus gelösten oder geborstenen
Komponenten Flüssigkeit auf die Haut oder
in die Augen spritzen. Hautverletzungen
durch eingedrungene Flüssigkeiten
umgehend medizinisch versorgen lassen
und nicht wie eine einfache
Schnittverletzung behandeln. Dem
behandelnden Arzt genaue Angaben über
das Medium machen, das in die Haut
eingedrungen ist.
Jeder nicht mit dieserAnleitung konforme
Gebrauch des Geräts führt zur Nichtigkeit
jeglicher Garantie- und Haftungsansprüche.
• Keine Teile auf eine nicht vom Hersteller
vorgesehene Weise verwenden, mit zu
starkem Druck beaufschlagen oder
verändern; keine nicht kompatiblen
Chemikalien oder Flüssigkeiten oder
abgenutzte und/oder beschädigte Teile
verwenden.
• Die Empfehlungen des Herstellers in
Bezug auf die Kompatibilität der
Flüssigkeit und den Gebrauch von
Schutzkleidung und -ausrüstungen lesen
und jederzeit beachten.
• Bei einem Missachten dieses Hinweises
kann es zu Verletzungen und/oder
Produktschäden kommen.


Sicherheitssignale
HINWEIS
Deren Hinweise enthalten nützliche
Tipps und Empfehlungen sowie
Informationen für einen effizienten und
störungsfreien Betrieb.
VORSICHT
Verweist auf eine Gefahrensituation, die
bei Unterlassung entsprechender
Vorsichtsmaßnahmen zu leichten
Verletzungen oder Sachschäden führen
kann.
WARNUNG
Verweist auf eine Gefahrensituation, die
bei Unterlassung entsprechenderVor-
sichtsmaßnahmen zu schweren oder
leichtenVerletzungen führen kann.
ACHTUNG
Verweist auf eine Gefahrensituation, die
bei Unterlassung entsprechender
Vorsichtsmaßnahmen zu schweren oder
tödlichenVerletzungen führen kann.
WARNUNG
Dieses Gerät erst dann in
Betrieb nehmen, wenn die
Sicherheitswarnungen und
Anleitungen gelesen und
vollständig verstanden wurden.
Ein Missachten derWarnhinweise und
Anleitungen kann zu schweren Verlet-
zungen führen.
VORSICHT
Das Gerät erst nach dem Anlegen einer
persönlichen Schutzausrüstung in
Betrieb nehmen.
Augenschutz tragen. Bei den ent-
sprechenden äußeren Bedingungen
angelegte Schutzausrüstungen wie
Staubmasken, rutschsichere Arbeitss-
chuhe, Helme und Gehörschutz reduz-
ieren dasAuftreten vonVerletzungen.
Nichtbeachtung kann zu leichtenVer-
letzungen führen.
WARNUNG
Achten Sie darauf, dass
keine Körperteile von
Geräten eingeklemmt
werden.
Körperteile können im Betrieb durch
Baugruppen gequetscht werden.
Bei einem Missachten dieses Hinwei-
ses kann es zu schweren oder tödlichen
Verletzungen kommen.
WARNUNG
Achten Sie darauf, dass
keine Flüssigkeit auf den
Boden tropft, wenn Sie
Geräte bedienen. Wenn etwas ver-
schüttet wird, sollten alle Flüssigkeiten
auf dem Boden entfernt werden, bevor
Sie fortfahren.
Ein Missachten dieses Hinweises kann
Verletzungen verursachen.
WARNUNG
Dieses Gerät nicht zur Lieferung, zum
Transport oder zur Lagerung von
gefährlichen Stoffen und Gemischen
verwenden. In diesem Zusammenhang
sind die folgenden Gefahrenpikto-
gramme GHS, GHS und GHS
gemäß Anhang I, Teil -, der CLP-Ver-
ordnung (EG-Verordnung /)
bzw.  CFR . (OSHA HCS) zu
beachten:

