Skil 5885 User manual

SKIL Europe BV - Konijnenberg 60 08/08 2610398693
4825 BD Breda - The Netherlands
CIRCULAR SAW
5885 (F0155885..)
www.skileurope.com
www.skileurope.com
ORIGINAL INSTRUCTIONS . . . . . . . . . . . . . 7
NOTICE ORIGINALE . . . . . . . . . . . . . . . . . 11
ORIGINALBETRIEBSANLEITUNG . . . . . . 16
ORIGINELE GEBRUIKSAANWIJZING. . . . 21
BRUKSANVISNING I ORIGINAL . . . . . . . . 27
ORIGINAL BRUGSANVISNING . . . . . . . . . 31
ORIGINAL DRIFTSINSTRUKS. . . . . . . . . . 36
ALKUPERÄISET OHJEET . . . . . . . . . . . . . 41
MANUAL ORIGINAL . . . . . . . . . . . . . . . . . 45
MANUAL ORIGINAL. . . . . . . . . . . . . . . . . . 50
ISTRUZIONI ORIGINALI . . . . . . . . . . . . . . 55
EREDETI HASZNÁLATI UTASÍTÁS. . . . . . 60
PÒVODNÍM NÁVODEM K POUÎÍVÁNÍ . . . 65
OR‹J‹NAL ‹fiLETME TAL‹MATI . . . . . . . . . 70
INSTRUKCJÑ ORYGINALNÑ. . . . . . . . . . . 75
ОРИГИНАЛНЬОЕ РУКОВОДСТВО
ПО ЭКСПЛУАТАЦИИ . . . . . . . . . . . . . . . . 80
ОРИГІНАЛЬНА ІНСТРУКЦІЯ
З ЕКСПЛУАТАЦІЇ . . . . . . . . . . . . . . . . . . . 86
ΠΡΩΤΟΤΥΠΟ Ο∆ΗΓΙΩΝ ΧΡΗΣΗΣ . . . . . . 91
INSTRUCØIUNI DE FOLOSIRE
ORIGINALE . . . . . . . . . . . . . . . . . . . . . . . . 97
ОРИГИНАЛНО РЪКОВОДСТВО
ЗА ЕКСПЛОАТАЦИЯ . . . . . . . . . . . . . . . 102
PÔVODN¯ NÁVOD NA POUÎITIE . . . . . 108
ORIGINALNE UPUTE ZA RAD . . . . . . . . 113
ORIGINALNO UPUTSTVO ZA RAD . . . . 117
IZVIRNA NAVODILA . . . . . . . . . . . . . . . . 122
ALGUPÄRANE KASUTUSJUHEND . . . . 126
ORI˛INÅLÅ LIETO·ANAS PAMÅC±BA. . 131
ORIGINALI INSTRUKCIJA. . . . . . . . . . . . 136
GB
F
D
NL
S
DK
N
FIN
E
P
I
H
CZ
TR
PL
ME77
RU
UA
GR
RO
BG
SK
HR
SRB
SLO
EST
LV
LT

2
15885
E
D
A
A
HH
F
G
C
B
3
2
7,9 kg
EPTA 01/2003
5000 /min RUBBER
65 mm
45°
235 mm
MAX.
30 mm
230 mm
MIN.
30 mm
Watt
2000
85 mm
90°
110 V = 1700 W

3
K
J
L
3 mm
4
HFG
K
N
M
M
5

4
M
ADEH
P
M
NOT STANDARD
INCLUDED
ADEH
K
6
Q
7

5
0
QF
G
R
SU V T
Ø 34-35 mm
98

6
#
$
X
W
Q
!
Q
F
G
@

7
GB
Circular saw 5885
INTRODUCTION
• This tool is intended for lengthways and crossways
cutting of wood with straight cuts as well as angle cuts
to 45°; with the appropriate saw blades also non-ferrous
metals, light building materials and plastics can be cut
• Read and save this instruction manual 2
TECHNICAL SPECIFICATIONS 1
SAFETY
GENERAL SAFETY INSTRUCTIONS
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or serious
injury. Save all warnings and instructions for future
reference. The term “power tool” in the warnings refers to
your mains-operated (corded) power tool.
1) WORK AREA SAFETY
a) Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive
atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks
which may ignite the dust or fumes.
c) Keep children and bystanders away while operating
a power tool. Distractions can cause you to lose
control.
2) ELECTRICAL SAFETY
a) Power tool plugs must match the outlet.
Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools.
Unmodified plugs and matching outlets will reduce risk
of electric shock.
b) Avoid body contact with earthed or grounded
surfaces such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d) Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
e) When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric
shock.
f) If operating a power tool in a damp location is
unavoidable, use an earth leakage circuit breaker.
Use of an earth leakage circuit breaker reduces the risk
of electric shock.
3) PERSONAL SAFETY
a) Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication.
A moment of inattention while operating power tools
may result in serious personal injury.
b) Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is
in the off-position before connecting to power
source, picking up or carrying the tool. Carrying
power tools with your finger on the switch or energising
power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.
e) Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away
from moving parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g) If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of dust collection
can reduce dust-related hazards.
4) POWER TOOL USE AND CARE
a) Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b) Do not use the power tool if the switch does not turn
it on and off. Any power tool that cannot be controlled
with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source before
making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the power
tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained
users.
e) Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any
other condition that may affect the power tool’s
operation. If damaged, have the power tool repaired
before use. Many accidents are caused by poorly
maintained power tools.

8
f) Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc.,
in accordance with these instructions, taking into
account the working conditions and the work to be
performed. Use of the power tool for operations
different from those intended could result in a
hazardous situation.
5) SERVICE
a) Have your power tool serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the power tool is
maintained.
SAFETY INSTRUCTIONS FOR CIRCULAR SAWS
DANGER
• Keep hands away from cutting area and the
blade; keep your second hand on front handle
(if both hands are holding the saw, they can not be cut
by the blade)
• Do not reach underneath the workpiece (the guard
cannot protect you from the blade below the workpiece)
• Adjust the cutting depth to the thickness of the
workpiece (less than a full tooth of the blade teeth
should be visible below the workpiece)
• Never hold piece being cut in your hands or across
your leg (it is important to support the work properly to
minimise body exposure, blade binding, or loss of
control)
• Hold tool by insulated gripping surfaces when
performing an operation where the cutting tool may
contact hidden wiring or its own cord (contact with a
“live” wire will also make exposed metal parts of the
tool “live” and shock the operator)
• When ripping always use a rip fence or straight edge
guide (this improves the accuracy of cut and reduces
the chance for blade binding)
• Always use blades with correct size and shape of
arbor holes (diamond or round) (blades that do not
match the mounting hardware of the saw will run
eccentrically, causing loss of control)
• Never use damaged or incorrect blade washers or
bolts (the blade washers and bolt were specially
designed for your saw, for optimum performance and
safety of operation)
KICKBACK - CAUSES
• Kickback is a sudden reaction to a pinched, bound or
misaligned saw blade, causing an uncontrolled saw to
lift up and out of the workpiece toward the operator
• When the blade is pinched or bound tightly by the kerf
closing down, the blade stalls and the motor reaction
drives the unit rapidly back toward the operator
• If the blade becomes twisted or misaligned in the cut,
the teeth at the back edge of the blade can dig into the
top surface of the wood causing the blade to climb out
of the kerf and jump back towards operator
KICKBACK - OPERATOR PREVENTION
Kickback is the result of tool misuse and/or incorrect
operating procedures or conditions and can be avoided by
taking proper precautions as given below
• Maintain a firm grip with both hands on the saw and
position your arms to resist kickback forces;
position your body to either side of the blade, but
not in line with the blade (kickback could cause the
saw to jump backwards, but kickback forces can be
controlled by the operator, if proper precautions are
taken)
• When blade is binding, or when interrupting a cut for
any reason, release the trigger and hold the saw
motionless in the material until the blade comes to a
complete stop; never attempt to remove the saw
from the work or pull the saw backwards while the
blade is in motion or kickback may occur (investigate
and take corrective actions to eliminate the cause of
blade binding; avoid cutting nails or screws)
• When restarting a saw in the workpiece, centre the
saw blade in the kerf and check that saw teeth are
not engaged into the material (if saw blade is binding,
it may walk up or kickback from the workpiece as the
saw is restarted)
• Support large panels to minimise the risk of blade
pinching and kickback (large panels tend to sag under
their own weight; supports must be placed under the
panel on both sides, near the line of cut and near the
edge of the panel)
• Do not use a dull or damaged blade (unsharpened or
improperly set blades produce narrow kerf causing
excessive friction, blade binding and kickback)
• Blade depth and bevel adjusting locking levers must
be tight and secure before making cut (if blade
adjustment shifts while cutting, it may cause binding
and kickback)
• Use extra caution when making a plunge cut into
existing walls or other blind areas (the protruding
blade may cut objects that can cause kickback)
WARNING
• Check lower guard for proper closing before each
use
• Do not operate the saw if lower guard does not
move freely and close instantly
• Never clamp or tie the lower guard into the open
position
• If saw is accidentally dropped, lower guard may be
bent; disconnect the plug, raise the lower guard with
the retracting handle and make sure it moves freely and
does not touch the blade or any other part, in all angles
and depths of cut
• Check the operation of the lower guard spring; if the
guard and the spring are not operating properly,
they must be serviced before use (lower guard may
operate sluggishly due to damaged parts, gummy
deposits, or a build-up of debris)

9
• Lower guard should be retracted manually only for
special cuts such as plunge cuts and compound
cuts; raise lower guard by retracting handle and as
soon as blade enters the material, the lower guard
must be released (for all other sawing, the lower guard
should operate automatically)
• Always observe that the lower guard is covering the
blade before placing saw down on bench or floor (an
unprotected, coasting blade will cause the saw to walk
backwards, cutting whatever is in its path; be aware of
the time it takes for the blade to stop after switch is
released)
GENERAL
• Avoid damage that can be caused by screws, nails and
other elements in your workpiece; remove them before
you start working
• Secure the workpiece (a workpiece clamped with
clamping devices or in a vice is held more securely than
by hand)
• Use suitable detectors to find hidden utility lines or
call the local utility company for assistance (contact
with electric lines can lead to fire or electrical shock;
damaging a gas line can result in an explosion;
penetrating a water pipe will cause property damage or
an electrical shock)
• When you put away the tool, switch off the motor and
ensure that all moving parts have come to a complete
standstill
• Use completely unrolled and safe extension cords with
a capacity of 16 Amps (U.K. 13 Amps)
• In case of jamming or electrical or mechanical
malfunction, immediately switch off the tool and
disconnect the plug
• SKIL can assure flawless functioning of the tool only
when the correct accessories are used which can be
obtained from your SKIL dealer
• Use only accessories with an allowable speed matching
at least the highest no-load speed of the tool
• Never use the tool without the original protection guard
system
• This tool should not be used by people under the age of
16 years
• The noise level when working can exceed 85 dB(A);
wear ear protection
• If the cord is damaged or cut through while working, do
not touch the cord, but immediately disconnect the plug
• Never use the tool when cord is damaged; have it
replaced by a qualified person
• Always check that the supply voltage is the same as the
voltage indicated on the nameplate of the tool (tools
with a rating of 230V or 240V can also be connected to
a 220V supply)
• Starting cycles generate brief voltage drops;
interference with other equipment/machines may occur
in case of unfavourable mains system conditions
(malfunctions are not to be expected for system
impedances below 0.36 ohm) - if you need further
clarification, you may contact your local power supply
authority
• This tool is not suitable for wet cutting
• After switching off your circular saw, never stop the
rotation of the saw blade by a lateral force applied
against it
• Never use circular saw blades made of high speed steel
(HSS)
• Never use grinding/cutting discs with this tool
• Do not work materials containing asbestos (asbestos
is considered carcinogenic)
• Dust from material such as paint containing lead, some
wood species, minerals and metal may be harmful
(contact with or inhalation of the dust may cause
allergic reactions and/or respiratory diseases to the
operator or bystanders); wear a dust mask and work
with a dust extraction device when connectable
• Certain kinds of dust are classified as carcinogenic
(such as oak and beech dust) especially in conjunction
with additives for wood conditioning; wear a dust
mask and work with a dust extraction device when
connectable
• Follow the dust-related national requirements for the
materials you want to work with
• Do not attempt to cut extremely small workpieces
• Remove all obstacles on top of as well as underneath
the cutting path before you start cutting
• Do not work overhead with the tool
• Only use a saw table provided with a switch that
prevents restarting of the motor after interruption of
voltage
• Only use a saw table provided with a kerf guide
• Always disconnect plug from power source before
making any adjustment or changing any accessory
WHEN CONNECTING NEW 3-PIN PLUG (U.K. ONLY):
• Do not connect the blue (= neutral) or brown (= live) wire
in the cord of this tool to the earth terminal of the plug
• If for any reason the old plug is cut off the cord of this
tool, it must be disposed of safely and not left
unattended
USE
• Mounting saw blade 3
! disconnect the plug
- take hex key A from storage B
- push spindle-lock button C and hold it while you
remove blade bolt D with blade wrench
! push spindle-lock button C only when tool is at a
standstill
- release spindle-lock button C
- remove flange E
- open lower guard F with lever G and hold it while you
mount saw blade with saw teeth and arrow printed
on saw blade pointing in same direction as arrow on
lower guard
- release lower guard F
- mount flange E
! make sure that clamping surfaces H of flanges
are perfectly clean and face the blade

10
- push spindle-lock button C and hold it while you
tighten blade bolt with hex key 1/8 turn past finger
tight (ensures slippage of saw blade when it
encounters excessive resistance thus reducing motor
overload and saw kickback)
- release spindle-lock button C
• Adjusting cutting depth (0-85 mm) 4
- for an optimal quality cut the saw blade should not
extend more than 3 mm below the workpiece
- loosen lever J
- raise/lower foot K until desired cutting depth is set on
scale using indicator L
- tighten lever J
• Adjusting cutting angle (0-45°) 5
- loosen 2knobs M
- tilt tool until desired cutting angle is set on scale
using indicator N
- tighten 2knobs M
! when bevel cutting, cutting depth does not
correspond with value on cutting depth scale
• 90° Cutting angle check 6
- adjust and tighten foot K to maximum cutting depth 4
- adjust and tighten cutting angle to 0°
- check for 90° angle between the blade and bottom of
foot with a square
- if adjustment is needed, loosen 2knobs M and use
adjustment screw P as illustrated
• Line-of-cut indicator Q 7
- for guiding tool along desired line of cut marked on
the workpiece
- for a straight 0° cut or a 45° bevel cut use the
indicator line concerned
- allows you to choose whether waste material is on
inner or outer side of blade
! the wide part of the foot should rest on the
supported part of the workpiece
! cutting width is determined by width of blade
teeth and not by width of blade body
! always make trial cuts first to verify actual line of
cut
• Electronic soft-start 8
Ensures reaching the maximum speed smoothly without
a sudden impact when tool is switched on
• Dust suction
- connect vacuum cleaner to extension R 9
! never let the vacuum cleaner hose interfere with
the lower guard or the cutting operation
- one may also use a dust bag (SKIL accessory
2610387402)
• Operating the tool 9
- connect plug to power source
- always hold handle S firmly with one hand and
handle T firmly with the other hand
- place tool with front end of foot flat on workpiece
! ensure that the saw teeth are not engaged into
the workpiece
- switch on tool by first pressing knob U (= safety
switch which cannot be locked) and then pulling
trigger V
! the tool should run at full speed before the blade
enters into the workpiece
- lower guard F opens automatically when saw blade
enters the workpiece (open lower guard manually by
using lever G only for special cuts such as plunge
cuts)
- do not force the tool; apply light and continuous
pressure
- after completing the cut switch off tool by releasing
trigger V
! ensure that the blade has come to a complete
standstill, before you lift the tool from the
workpiece
APPLICATION ADVICE
• Always face the good side of the workpiece down to
ensure minimum splintering
• Only use sharp saw blades of the correct type 0
- quality of cut improves by the number of teeth
- carbide tipped blades stay sharp up to 30 times
longer than ordinary blades
• Rip fence W !
- for making exact cuts along a workpiece edge
- can be inserted in either side of foot
Adjusting rip fence
- loosen knob X
- adjust to desired cutting width by using rip fence
scale (use line-of-cut indicator Q as 0-reference)
- tighten knob X
• Plunge cutting @
- set desired cutting depth
- tilt tool forward with line-of-cut indicator Q lined up
with desired line of cut marked on the workpiece
- open lower guard F with lever G
- just before blade enters workpiece, switch on tool
and gradually lower back end of tool using front end
of foot as hinge-point
- gradually move tool downward as well as forward
- as soon as blade enters the material, release lever G
! the tool should run at full speed before the blade
enters into the workpiece
! never pull tool backwards
• Cutting large panels #
- support panel close to the cut either on floor, table or
workbench
! set cutting depth so that you cut through panel
and not through support
- in case rip fence does not allow desired width of cut,
clamp or nail straight piece of wood to workpiece as
a guide, and use the left side of the foot against this
guide
• Vibration level
The vibration emission level stated at the back of this
instruction manual has been measured in accordance
with a standardised test given in EN 60745; it may be
used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned

11
- using the tool for different applications, or with
different or poorly maintainted accessories, may
significantly increase the exposure level
- the times when the tool is switched off or when it is
running but not actually doing the job, may
significantly reduce the exposure level
! protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns
MAINTENANCE / SERVICE
• Always keep tool and cord clean (especially the
ventilation slots)
! disconnect the plug before cleaning
• Clean saw blade immediately after use (especially from
resin and glue)
• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skileurope.com)
ENVIRONMENT
• Do not dispose of electric tools, accessories and
packaging together with household waste material
(only for EU countries)
- in observance of European Directive 2002/96/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol $will remind you of this when the need for
disposing occurs
F
Scie circulaire 5885
INTRODUCTION
• Cet outil est conçu pour effectuer dans le bois des
coupes droites longitudinales et transversales ainsi que
des angles d’onglet jusqu’à 45°; muni de lames de scie
correspondantes, il est capable de scier des matériaux
non-ferroux, des matériaux de construction légers et
des matières plastiques
• Lisez et conservez ce manuel d’instructions 2
SPECIFICATIONS TECHNIQUES 1
SECURITE
INSTRUCTIONS GENERALES DE SECURITE
ATTENTION! Lisez tous les avertissements de
sécurité et toutes les instructions. Ne pas suivre les
avertissements et instructions peut entraîner un choc
électrique, un incendie et/ou de graves blessures sur les
personnes. Conservez tous les avertissements et
toutes les instructions pour pouvoir s’y reporter
ultérieurement. La notion d’”outil électroportatif” dans les
avertissements se rapporte à des outils électriques
raccordés au secteur (avec câble de raccordement).
1) SECURITE DE LA ZONE DE TRAVAIL
a) Maintenez l’endroit de travail propre et bien éclairé.
Un lieu de travail en désordre ou mal éclairé augmente
le risque d’accidents.
b) N’utilisez pas l’outil dans un environnement
présentant des risques d’explosion et où se trouvent
des liquides, des gaz ou poussières inflammables.
Les outils électroportatifs génèrent des étincelles
risquant d’enflammer les poussières ou les vapeurs.
c) Tenez les enfants et autres personnes éloignés
durant l’utilisation de l’outil électroportatif.
En cas d’inattention vous risquez de perdre le contrôle
sur l’outil.
2) SECURITE RELATIVE AU SYSTEME ELECTRIQUE
a) La fiche de secteur de l’outil électroportatif doit être
appropriée à la prise de courant. Ne modifiez en
aucun cas la fiche. N’utilisez pas de fiches
d’adaptateur avec des outils avec mise à la terre.
Les fiches non modifiées et les prises de courant
appropriées réduisent le risque de choc électrique.
b) Evitez le contact physique avec des surfaces mises
à la terre telles que tuyaux, radiateurs, fours et
réfrigérateurs. Il y a un risque élevé de choc électrique
au cas où votre corps serait relié à la terre.
c) N’exposez pas l’outil électroportatif à la pluie ou à
l’humidité. La pénétration d’eau dans un outil
électroportatif augmente le risque d’un choc électrique.
d) N’utilisez pas le câble à d’autres fins que celles
prévues, n’utilisez pas le câble pour porter l’outil ou
pour l’accrocher ou encore pour le débrancher de la
prise de courant. Maintenez le câble éloigné des
sources de chaleur, des parties grasses, des bords
tranchants ou des parties de l’outil en rotation.
Un câble endommagé ou torsadé augmente le risque
d’un choc électrique.
e) Au cas où vous utiliseriez l’outil électroportatif à
l’extérieur, utilisez une rallonge autorisée
homologuée pour les applications extérieures.
L’utilisation d’une rallonge électrique homologuée pour
les applications extérieures réduit le risque d’un choc
électrique.
f) Si l’usage d’un outil dans un emplacement humide
est inévitable, utilisez un disjoncteur de fuite à la
terre. L’utilisation d’un disjoncteur de fuite à la terre
réduit le risque de choc électrique.

✎
142

✎
143

✎
144

145
CE DECLARATION OF CONFORMITY We declare under our sole responsibility that this product is in conformity with the following
standards or standardized documents: EN 60 745, EN 55 014, in accordance with the provisions of the directives 2006/95/EC,
2004/108/EC, 98/37/EC (until Dec. 28, 2009), 2006/42/EC (from Dec. 29, 2009 on).
NOISE/VIBRATION Measured in accordance with EN 60 745 the sound pressure level of this tool is 94 dB(A) and the sound power
level 105 dB(A) (standard deviation: 3 dB), and the vibration 2.9 m/s2(hand-arm method; uncertainty K = 1.5 m/s2).
Technical file at: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE DÉCLARATION DE CONFORMITÉ Nous déclarons sous notre propre responsabilité que ce produit est en conformité avec les
normes ou documents normalisés suivants: EN 60 745, EN 55 014, conforme aux réglementations 2006/95/CE, 2004/108/CE,
98/37/CE (jusqu’au 28.12.2009), 2006/42/CE (à partir du 29.12.2009).
BRUIT/VIBRATION Mesuré selon EN 60 745 le niveau de la pression sonore de cet outil est 94 dB(A) et le niveau de la puissance
sonore 105 dB(A) (déviation standard: 3 dB), et la vibration 2,9 m/s2(méthode main-bras; incertitude K = 1,5 m/s2).
Dossier technique auprès de: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE KONFORMITÄTSERKLÄRUNG Wir erklären in alleiniger Verantwortung, daß dieses Produkt mit den folgenden Normen oder
normativen Dokumenten übereinstimmt: EN 60 745, EN 55 014, gemäß den Bestimmungen der Richtlinien 2006/95/EG,
2004/108/EG, 98/37/EG (bis 28.12.2009), 2006/42/EG (ab 29.12.2009).
GERÄUSCH/VIBRATION Gemessen gemäß EN 60 745 beträgt der Schalldruckpegel dieses Gerätes 94 dB(A) und der Schal-
leistungspegel 105 dB(A) (Standard- abweichung: 3 dB), und die Vibration 2,9 m/s2(Hand-Arm Methode; unsicherheit K = 1,5 m/s2).
Technische Unterlagen bei: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE CONFORMITEITSVERKLARING Wij verklaren, dat dit product voldoet aan de volgende normen of normatieve documenten:
EN 60 745, EN 55 014, overeenkomstig de bepalingen van de richtlijnen 2006/95/EG, 2004/108/EG, 98/37/EG (tot 28-12-2009),
2006/42/EG (vanaf 29-12-2009).
GELUID/VIBRATIE Gemeten volgens EN 60 745 bedraagt het geluidsdrukniveau van deze machine 94 dB(A) en het
geluidsvermogen-niveau 105 dB(A) (standaard deviatie: 3 dB), en de vibratie 2,9 m/s2(hand-arm methode; onzekerheid K = 1,5 m/s2).
Technisch dossier bij: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE KONFORMITETSFÖRKLARING Vi intygar och ansvarar för, att denna produkt överensstämmer med följande norm och
dokument: EN 60 745, EN 55 014, enl. bestämmelser och riktlinjema 2006/95/EG, 2004/108/EG, 98/37/EG (till 28.12.2009),
2006/42/EG (from 29.12.2009).
LJUD/VIBRATION Ljudtrycksnivån som uppmätts enligt EN 60 745 är på denna maskin 94 dB(A) och ljudeffektnivån 105 dB(A)
(standard deviation: 3 dB), och vibration 2,9 m/s2(hand-arm metod; onoggrannhet K = 1,5 m/s2).
Teknisk tillverkningsdokumentation finns hos: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE KONFORMITETSERKLÆRING Vi erklærer under almindeligt ansvar, at dette produkt er i overensstemmelse med følgende
normer eller normative dokumenter: EN 60 745, EN 55 014, i henhold til bestemmelserne i direktiverne 2006/95/EF, 2004/108/EF,
98/37/EF (indtil 28.12.2009), 2006/42/EF (fra 29.12.2009).
STØJ/VIBRATION Måles efter EN 60 745 er lydtrykniveau af dette værktøj 94 dB(A) og lydeffektniveau 105 dB(A) (standard
deviation: 3 dB), og vibrationsniveauet 2,9 m/s2(hånd-arm metoden; usikkerhed K = 1,5 m/s2).
Teknisk dossier hos: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE SAMSVARSERKLÆRING Vi erklærer at det er under vårt ansvar at dette produkt er i samsvar med følgende standarder eller
standard- dokumenter: EN 60 745, EN 55 014, i samsvar med reguleringer 2006/95/EF, 2004/108/EF, 98/37/EF (frem til 28.12.2009),
2006/42/EF (fra 29.12.2009).
STØY/VIBRASJON Målt ifølge EN 60 745 er lydtrykknivået av dette verktøyet 94 dB(A) og lydstyrkenivået 105 dB(A) (standard
deviasjon: 3 dB), og vibrasjonsnivået 2,9 m/s2(hånd-arm metode; usikkerhet K = 1,5 m/s2).
Tekniske underlag hos: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE TODISTUS STANDARDINMUKAISUUDESTA Todistamme täten ja vastaamme yksin siitä, että tämä tuote en allalueteltujen
standardien ja standardoimisasiakirjojen vaatimusten mukainen EN 60 745, EN 55 014, seuraavien sääntöjen mukaisesti
2006/95/EY, 2004/108/EY, 98/37/EY (28.12.2009 asti), 2006/42/EY (29.12.2009 alkaen).
MELU/TÄRINÄ Mitattuna EN 60 745 mukaan työkalun melutaso on 94 dB(A) ja yleensä työkalun äänen voimakkuus on 105 dB(A)
(keskihajonta: 3 dB), ja tärinän voimakkuus 2,9 m/s2(käsi-käsivarsi metodi; epävarmuus K = 1,5 m/s2).
Tekninen tiedosto kohdasta: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CE DECLARACION DE CONFORMIDAD Declaramos bajo nuestra sola responsabilidad que este producto está en conformidad
con las normas o documentos normalizados siguientes: EN 60 745, EN 55 014, de acuerdo con las regulaciones 2006/95/CE,
2004/108/CE, 98/37/CE (hasta el 28.12.2009), 2006/42/CE (a partir del 29.12.2009).
RUIDOS/VIBRACIONES Medido según EN 60 745 el nivel de la presión acústica de esta herramienta se eleva a 94 dB(A) y el nivel de
la potencia acústica 105 dB(A) (desviación estándar: 3 dB), y la vibración a 2,9 m/s2(método brazo-mano; incertidumbre K = 1,5 m/s2).
Expediente técnico en: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
GB
F
D
NL
S
N
FIN
E
08 SKIL Europe BV A. v.d. Kloot
DK

146
08 SKIL Europe BV A. v.d. Kloot
ЗАЯВЛЕНИЕ О СООТВЕТСТВИИ Мы с полной ответственностыо заявляем, что это изделие соответствует следующим
стандартам или станда ртизованным документам: EN 60 745, EN 55 014, в соответсувии с инструкциями 2006/95/EC,
2004/108/EC, 98/37/EC (до 28.12.2009), 2006/42/EC (начиная с 29.12.2009).
ШУМНОСТИ/ВИБРАЦИИ При измерении в соответствии co стандартoм EN 60 745 уровень звукового давления для этого
инструмента составляет 94 дБ (A) и уровeнь звуковой мощности - 105 дБ (A) (стандартное отклонение: 3 dB), и вибрации -
2,9 м/с2(по методу для рук; недостоверность K = 1,5 м/с2).
Техническая документация у: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
RU
CE ВІДПОВІДНІСТЬ Ми заявляємо, що відповідність даного продукту наступним стандартам і регулюючим документам
повністю нашою відповідальністю: EN 60 745, EN 55 014, відповідно до положень директив 2006/95/EG, 2004/108/EG,
98/37/EG до 28.12.2009 p.), 2006/42/EG (після 29.12.2009 p.).
ШУМ/ВІБРАЦІЯ Зміряний відповідно до EN 60 745 рівень тиску звуку даного інструменту 94 дБ(А) i потужність звуку
105 дБ(А) (стандартне відхилення: 3 дБ), i вібрація 2,9 м/с2(ручна методика; похибка K = 1,5 м/с2).
Технічні документи в: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
UA
CE ∆ΗΛΩΣΗ ΣYMBATOTΗΤΑΣ ∆ηλώνουµε υπευθύνως τι το προϊν αυτ είναι κατασκευασµένο σύµφωνα µε τους εξής
κανονισµούς ή κατασκευαστικές συστάσεις: EN 60 745, EN 55 014, κατά τις διατάξεις των κανονισµών της Κοινής Αγοράς
2006/95/EK, 2004/108/EK, 98/37/EK (έως 28.12.2009), 2006/42/EK (απ 29.12.2009).
ΘΟΡYΒΟ/ΚΡΑ∆ΑΣΜΟYΣ Μετρηµένη σύµφωνα µε EN 60 745 η στάθµη ακουστικής πίεσης αυτού του εργαλείου ανέρχεται
σε 94 dB(A) και η στάθµη ηχητικής ισχύoς σε 105 dB(A) (κοινή απκλιση: 3 dB), και ο κραδασµς σε 2,9 m/s2(µεθοδος
χειρς/βραχίονα - ανασφάλεια K = 1,5 m/s2).
Τεχνικς φάκελος απ: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
GR
OÂWIADCZENIE ZGODNOÂCI CE Niniejszym oÊwiadczamy ponoszàc osobistà odpowiedzialnoÊç, ˝e produkt wykonany jest
zgodnie z nast´pujàcymi normami i dokumentami normalizujàcymi: EN 60 745, EN 55 014, z godnie z wytycznymi 2006/95/EU,
2004/108/EU, 98/37/EU (do 28.12.2009), 2006/42/EU (od 29.12.2009).
HA¸ASU/WIBRACJE Pomiarów dokonano zgodnie z normà EN 60 745 ciÊnienie akustyczne narz´dzia wynosi 94 dB(A) zaÊ poziom
mocy akustycznej 105 dB(A) (poziom odchylenie: 3 dB), zaÊ wibracje 2,9 m/s2(metoda d∏oƒ-r´ka; b∏àd pomiaru K = 1,5 m/s2).
Dokumentacja techniczna: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
PL
CE DECLARAÇÃO DE CONFIRMIDADE Declaramos sob nossa exclusiva responsabilidade que este producto cumpre as
seguintes normas ou documentos normativos: EN 60 745, EN 55 014, conforme as disposições das directivas 2006/95/CE,
2004/108/CE, 98/37/CE (até 28.12.2009), 2006/42/CE (a partir de 29.12.2009).
RUÍDO/VIBRAÇÕES Medido segundo EN 60 745 o nível de pressão acústica desta ferramenta é 94 dB(A) e o nível de potência
acústica 105 dB(A) (espaço de erro: 3 dB), e a vibração 2,9 m/s2(método braço-mão; incerteza K = 1,5 m/s2).
Processo técnico em: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
P
CE DICHIARAZIONE DI CONFORMITÀ Dichiaramo, assumendo la piena responsabilità di tale dichiarazione, che il prodotto è
conforme alle seguenti normative e ai relativi documenti: EN 60 745, EN 55 014 in base alle prescrizioni delle direttive 2006/95/EG,
2004/108/EG, 98/37/EG (fino al 28.12.2009), 2006/42/EG (a partire dal 29.12.2009).
RUMOROSITÀ/VIBRAZIONE Misurato in conformità al EN 60 745 il livello di pressione acustica di questo utensile è 94 dB(A) ed il livello
di potenza acustica 105 dB(A) (deviazione standard: 3 dB), e la vibrazione 2,9 m/s2(metodo mano-braccio; incertezza K = 1,5 m/s2).
Fascicolo tecnico presso: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
I
CE MINÖSÉGI TANUSITVANY Teljes felelösségünk tudatában kijelentjük, hogy jelen termék a következö szabványoknak vagy
kötelezö hatósági elöírásoknak megfelel: EN 60 745, EN 55 014, a 2006/95/EK, 2004/108/EK, 98/37/EK (2009.12.28-ig), 2006/42/EK
(2009.12.29-tŒl kezdve) elöírásoknak megfelelöen.
ZAJ/REZGÉS Az EN 60 745 alapján végzett mérések szerint ezen készülék hangnyomás szintje 94 dB(A) a hangteljesítmény szintje
105 dB(A) (normál eltérés: 3 dB), a rezgésszám 2,9 m/s2 (kézre-ható érték; szórás K = 1,5 m/s2).
A mıszaki dokumentáció a következŒ helyen található: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
H
CE STRVZUJÍCÍ PROHLÅ◊ENÍ Potvrzujeme na odpovπdnost, Ωe tento v¥robek odpovídå nåsledujícím normåm nebo normativním
podkladüm: EN 60 745, EN 55 014, podle ustanovení smπrnic 2006/95/ES, 2004/108/ES, 98/37/ES (do 28.12.2009), 2006/42/ES (od
29.12.2009).
HLUÇNOSTI/VIBRACÍ Mπ®eno podle EN 60 745 çiní tlak hlukové vlny tohoto p®ístroje 94 dB(A) a dávka hluçnosti 105 dB(A)
(standardní odchylka: 3 dB), a vibrací 2,9 m/s2(metoda ruka-paΩe; nepfiesnost K = 1,5 m/s2).
Technická dokumentace u: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
CZ
CE STANDARDIZASYON BEYANI Ye¤ane sorumlu olarak, bu ürünün afla¤ıdaki standartlara veya standart belgelerine uygun
oldu¤unu beyan ederiz: EN 60 745, EN 55 014, yönetmeli¤i hükümleri uyarınca 2006/95/EG, 2004/108/EG, 98/37/EG (28.12.2009
tarihine kadar), 2006/42/EG (29.12.2009 tarihinden itibaren).
GÜRÜLTÜ//T‹TREfiIM Ölçülen EN 60 745 göre ses basıncı bu makinanın seviyesi 94 dB(A) ve çal›flma s›ras›ndaki gürültü 105 dB(A)
(standart sapma: 3 dB), ve titreflim 2,9 m/s2(el-kol metodu; tolerans K = 1,5 m/s2).
Teknik belgelerin bulundu¤u merkez: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
TR

147
08 SKIL Europe BV A. v.d. Kloot
DECLARAØIE DE CONFORMITATE CE Declaråm pe proprie råspundere cå acest product este conform cu urmåtoarele standarde
sau documente standardizate: EN 60 745, EN 55 014, în conformitate cu regulile 2006/95/CE, 2004/108/CE, 98/37/CE (pânå la
28.12.2009), 2006/42/CE (începând cu 29.12.2009).
ZGOMOT/VIBRAØII Måsurat în conformitate cu EN 60 745 nivelul de presiune a sunetului generat de acest instrument este de
94 dB(A) iar nivelul de putere a sunetului 105 dB(A) (abaterea standard: 3 dB), iar nivelul vibraøiilor 2,9 m/s2(metoda mînå - braø;
incertitudine K = 1,5 m/s2).
Documentaøie tehnicå la: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
RO
CE ДЕKЛАPAЦИЯ ЗA CБOTВETCTBИE Декларираме на изцяло наша отговорност, че това изделие е съобразено със
следните стандарти или стандартизирани документи: EN 60 745, EN 55 014, в съответствие с нормативната уредба на
2006/95/EG, 2004/108/EG, 98/37/EG (до 28.12.2009), 2006/42/EG (от 29.12.2009).
ШУМ/ВИБPAЦИИ Измерено в съответствие с EN 60 745 нивото на звуково налягане на този инструмент е 94 dB(A) а
нивото на звукова мощност е 105 dB(A) (стандартно отклонение: 3 dB), а вибрациите са 2,9 m/s2(метод ръка-рамо;
неопределеност K = 1,5 m/s2).
Подробни технически описания при: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
BG
CE IZJAVA O USKLA ĐENOSTI Izjavljujemo uz punu odgovornost da je ovaj proizvod usklađen sa slijedeçim normama i
normativnim dokumentima: EN 60 745, EN 55 014, prema odredbama smjernica 2006/95/EG, 2004/108/EG, 98/37/EG (do
28.12.2009), 2006/42/EG (od 29.12.2009).
BUCI/ VIBRACIJAMA Mjereno prema EN 60 745, prag zvuãnog tlaka ovog elektriãnog alata iznosi 94 dB(A) a jakost zvuka
105 dB(A) (standardna devijacija: 3 dB), a vibracija 2,9 m/s2(postupkom na ‰aci-ruci; nesigurnost K = 1,5 m/s2).
Tehniãka dokumentacija se moÏe dobiti kod: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
HR
CE IZJAVA O USKLA ĐENOSTI Pod punom odgovorno‰çu izjavljujemo da je ovaj proizvod usklađen sa sledeçim standardima ili
standardizovanim dokumentima: EN 60 745, EN 55 014, u skladu sa odredbama smernica 2006/95/EG, 2004/108/EG, 98/37/EG (do
28.12.2009), 2006/42/EG (od 29.12.2009).
BUKA/VIBRACIJE Mereno u skladu sa EN 60 745, nivo pritiska zvuka ovog alata iznosi 94 dB(A), a jaãina zvuka 105 dB(A)
(normalno odstupanje: 3 dB), a vibracija 2,9 m/s2(mereno metodom na ‰aci-ruci; nesigurnost K = 1,5 m/s2).
Tehniãka dokumentacija kod: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
SRB
IZJAVA O USTREZNOSTI CE Odgovorno izjavljamo, da je ta izdelek v skladu z naslednjimi standardi ali standardnimi dokumenti:
EN 60 745, EN 55 014, v skladu s predpisi navodil 2006/95/ES, 2004/108/ES, 98/37/ES (do 28.12.2009), 2006/42/ES (od 29.12.2009).
HRUP/VIBRACIJA Izmerjeno v skladu s predpisom EN 60 745 je raven zvoãnega pritiska za to orodje 94 dB(A) in jakosti zvoka
105 dB(A) (standarden odmik: 3 dB), in vibracija 2,9 m/s2 (metoda ‘dlan-roka’; netoãnost K = 1,5 m/s2).
Tehniãna dokumentacija se nahaja pri: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
SLO
CE VASTAVUSDEKLARATSIOON Kinnitame ainuvastutajana, et see toode vastab järgmistele standarditele või
normdokumentidele: EN 60 745, EN 55 014 vastavalt direktiivide 2006/95/EÜ, 2004/108/EÜ, 98/37/EÜ (kuni 28.12.2009),
2006/42/EÜ (alates 29.12.2009) nõuetele.
MÜRA/VIBRATSIOON Vastavalt kooskõlas normiga EN 60 745 läbi viidud mõõtmistele on antud seadme helirõhk 94 dB(A) ja
helitugevus 105 dB(A) (standardkõrvalekalle: 3 dB), ja vibratsioon 2,9 m/s2(käe-randme-meetod; mõõtemääramatus K = 1,5 m/s2).
Tehniline toimik saadaval aadressil: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
EST
CE DEKLARÅCIJA PAR ATBILST±BU STANDARTIEM Mïs ar pilnu atbild¥bu pazi¿ojam, ka ‰is izstrÇdÇjums atbilst standartiem vai
standartizÇcijas dokumentiem EN 60 745, EN 55 014 un ir saska¿Ç ar direkt¥vÇm 2006/95/ES, 2004/108/ES, 98/37/ES (l¥dz
28.12.2009) un 2006/42/ES (no 29.12.2009).
TROKSNIS/VIBRÅCIJA Saska¿Ç ar standartu EN 60 745 noteiktais instrumenta rad¥tÇ trok‰¿a ska¿as spiediena l¥menis ir 94 dB(A)
un ska¿as jaudas l¥menis ir 105 dB (A) (pie tipiskÇs izkliedes: 3 dB), un vibrÇcijas intensitÇte ir 2,9 m/s2(strÇdÇjot rokas reÏ¥mÇ;
izkliede K = 1,5 m/s2).
TehniskÇ lieta no: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
LV
CE ATITIKTIES DEKLARACIJA Mes atsakingai parei‰kiame, kad ‰is gaminys atitinka tokius standartus ir normatyvinius
dokumentus: EN 60 745, EN 55 014 pagal reglament˜ 2006/95/EB, 2004/108/EB, 98/37/EB (iki 2009-12-28), 2006/42/EB
(nuo 2009-12-29) nuostatas.
TRIUK·MINGUMAS/VIBRACIJA ·io prietaiso triuk‰mingumas buvo i‰matuotas pagal EN 60 745 reikalavimus keliamo triuk‰mo
garso slògio lygis siekia 94 dB(A) ir akustinio galingumo lygis 105 dB(A) (standartinis nuokrypis: 3 dB), ir vibracijos pagreitis rankos
pla‰takos srityje tipiniu atveju yra maÏesnis, kaip 2,9 m/s2(paklaida K = 1,5 m/s2).
Techninò byla laikoma: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
LT
CE PREHLÁSENIE O ZHODE Vÿhradne na na√u vlastnú zodpovednos† prehlasujeme, Ωe tento vÿrobok zodpovedá nasledujúcim
normám alebo normovanÿm dokumentom: EN 60 745, EN 55 014, v súlade s predpismi 2006/95/EG, 2004/108/EG, 98/37/EG (do
28.12.2009), 2006/42/EG (od 29.12.2009).
HLUKU/VIBRÁCIÁCH Merané pod¬a EN 60 745 je úroveµ akustického tlaku tohto nástroja 94 dB(A) a úroveµ akustického vÿkonu je
105 dB(A) (√tandardná odch¥lka: 3 dB), a vibrácie sú 2,9 m/s2(metóda ruka - paΩa; nepresnosÈ K = 1,5 m/s2).
Súbor technickej dokumentácie sa nachádzajú na adrese: SKIL Europe BV (PT-SEU/PJE), 4825 BD Breda, NL.
SK
