SkyLink ED-100 User manual

101A083-002
Emergency Dialer
DIAL-ALERT
MODEL: ED-100
www.skylinkhome.com
TM
FEB, 2006.
CUSTOMER SERVICE
17 Sheard Avenue, Brampton,
Ontario, Canada L6Y 1J3
Tel : [phone]
Fax : [phone]
Email : [email protected]
PAT. D410633
6243000B1
©2006 SKYLINK GROUP

–
2
–
SKYLINK TECHNOLOGIES INC.
Your Guide to the
Emergency Dialer
DIAL-ALERT
MODEL: ED-100
TM

–
3
–
TABLE OF CONTENTS
PACKAGE CONTENTS............................................................................................4
...
OVERVIEW.........................................................................................................5
INSTALLATION.......................................................................................................................6
LIGHTSANDSOUNDS.........................................................................................................9
STANDARDPROGRAMMING...................................................................................10-14
-Programthe TimeClock...............................................................................................10
-RecordingaMessage....................................................................................................10
-PlaybackPre-recordedMessage................................................................................11
-StoringTelephoneNumbers.........................................................................................11
- A. Storing telephone numbers in memory
(Sendstheemergency voicemessageonly)......................................11-12
- B. Storing telephone numbers in memory
(Sendsbothemergencyvoicemessageandnumericinformation)........12
- C. Storing telephone numbers in memory
(Sendsthenumericinformationtopageronly)..............................................13
-DeleteaTelephone NumberfromMemory...............................................................13
-To Review or Modify The Pre-programmed Phone Numbers, The
RedialCountand/orTheRepeat Timesof aPhoneNumber...............................14
-Activate the Dial-Alert with the Panic Button on the Keypad...............................14
PANIC TRANSMITTER...............................................................................................15
ADVANCEDPROGRAMMING...................................................................................16-21
-ProgramThe CallingTime...........................................................................................16
-Programming the Pause Period for Pager Access.................................16-17
-Setthetype ofPhoneSystem.....................................................................................17
-Program The ID Code of a Transmitter...........................................................17-18
-DeleteProgrammed PanicTransmitter...................................................................18
-To Erase Panic Transmitters from the Dialer.......................................................18
-To Arm/Disarm the Dialer.....................................................................................18
-Delay Dialing.......................................................................................................19
-UniversalDialTone..............................................................................................19-20
BATTERY MAINTENANCE............................................................................21-22
-Dial-Alert...........................................................................................................................21
-Panic Transmitter.....................................................................................................22
QUICKGUIDE......................................................................................................................23
–
22
–
The Panic Transmitter operates on three 3-volt lithium batteries (CR-1220)
that are installed at the factory. The battery storage life of these lithium
batteries is approximately five years. There are two screws on the back of
the transmitter that hold the top and bottom case together.
To replace the Panic Transmitter batteries:
1. Undo the two screws on the back
of the transmitter.
The back will then come off.
2. Take out all the old batteries using
a small screwdriver or a pen.
3. Place the new batteries in position.
The positive end should be facing
upward as you place the batteries in
the transmitter (see diagram).
4. Close the battery cover and re-
insert two screws.
Note: In order to maintain the battery life,
activate the Panic Transmitter in case of an
emergency only.
PANIC TRANSMITTER BATTERY
+

All materials required for installation are included with this package
1 Dial-Alert (AD-433)
1 Telephone Line
1 antenna (installed)
1 AC adapter
1 9 volt alkaline battery
1 Panic Transmitter (PT-434) includes
Three 3 volt Lithium batteries (installed)
1 Pack of screws and anchors (for Dial-Alert)
Sheet of templates
Double sided tape
Manual
Warranty Card
Quick Guide
–
4
–
PACKAGE CONTENTS
–
21
–
The ED-100 Dial-Alert comes with 4 batteries that at some point you may
have to replace:
One 9 volt alkaline battery for the Dial-Alert
Three 3 volt lithium batteries for the Panic Transmitter
Recommendation: Test your Dial-Alert periodically to ensure that all batteries
are working.
DIAL-ALERT BATTERY
The Dial-Alert comes equipped with a 9V backup alkaline battery in case
the electrical power is interrupted for any reason.
When the dialer backup battery is low, the LOBATT. light goes on.
To replace the dialer backup battery:
1. Open the Dial-Alert case by pressing
down on the two tabs on the top edge
and pull the front forward.
2. Disconnect the old battery.
3. Connect the new battery.
4. Close the Dial-Alert case.
The battery life, (9 volt alkaline battery), is
approximately two years if used only for backup.
Note: If the AC adapter is disconnected while the battery is being replaced,
the pre-recorded message will be erased, and the clock will return to 12:00.
Re-record the emergency voice message and reset the clock. (Refer to page
10).
BATTERY MAINTENANCE

–
5
–
OVERVIEW
The AD-433 Dial-Alert dials as many as 9 pre-programmed telephone numbers
and sends a personalized pre-recorded message. Each telephone number can
be dialed up to 9 times and the person receiving the emergency message can
confirm receipt of that message by pressing the "#" key on their telephone. A
pre-recorded message, maximum 40 seconds in length will be played notifying
the person being called of the emergency.
The Dial-Alert is activated when:
1. The red panic button [O] on the keypad of the Dial-Alert is pressed
2. The button is pressed on the panic transmitter (included in the ED-100 package)
This manual is divided into 4 sections in order to assist in the installation
and programming your Dial-Alert.
1. Installation
2. Lights and Sounds
3. Standard Programming
- Program the time clock
- Record a message
- Playback of pre-recorded message
- Storing telephone numbers in memory for
- emergency voice message only
- both emergency voice message and numeric information
- numeric information only
- Delete a telephone number from memory
- Modify the redial count and repeat times of a telephone number
4. Advanced Programming
- Programming the calling time
- Programming the pause period for pager access
- Select the phone system (regular or PABX phone systems)
- Program transmitters to activate dialer
- Erase programmed transmitters
- To arm / disarm the dialer
- Dialing delay
- Universal Dial Tone
–
20
–
3. Press the [2] key within 5 seconds after pressing the [9] key to turn on the
universal dial tone.
When the universal dial tone is turned off, and no dial tone is detected within 1
minute (after the dialer is activated), the display will show “no LInE” and the
backlit keypad will flash. To return to standby mode (Display shows the time),
press and hold the panic button [O] for 2 seconds.
ADVANCED PROGRAMMING
Turn on the universal dial tone:
1. Press the [L] key, display will show “L”.
2. Press the [9] key, display will show “ L 9 1 ”. The last digit (1) indicates
that the universal dial tone detection is turned off.

–
6
–
INSTALLATION
The Dial-Alert is installed using the screws provided. We have also included
double sided tape, to use for temporary installation while you are positioning
the dialer. Once the dialer is positioned correctly, install it permanently with
screws. We have also included wall anchors and a template to help position
the screws correctly.
How to use the template:
1. Cut and place the appropriate template in the desired position
2. Screw part way into the surface where the holes are marked
3. Unscrew the screws and remove the template
4. Screw the component in place where you started the screws
INSTALLING THE DIAL-ALERT (AD-433)
Position the dialer beside a telephone or near any phone line and within
access of an electrical outlet. However, it is recommended that you hide the
dialer for security purposes. The dialer runs on regular electrical current. It
also contains a 9 volt alkaline backup battery in case power is interrupted
for any reason. A phone line must be connected to the dialer in order for the
dialer to work. Connect the phone lines and AC adapter as shown.
Note: The optional line input is intended for an answering machine, tele-
phone etc. The device connected to the dialer will be disconnected when
the dialer is activated. Therefore it will not affect the operation of the dialer.
There are 3 ways to attach the Dial-Alert on the wall:
1. using double sided tape for temporary use
2. hanging it from the two keyholes on two stationary screws
3. screwing the back onto thewall with four screws.
To mount the Dial-Alert:
1. Open the case.
a) Press the two tabs on top of the
dialer
b) Pull open the front
12V DC AC ADAPTER
OPTIONAL LINE INPUT FOR
PHONE ANSWERING MACHINE / TELEPHONE
TEL LINE IN
LINE
DELAY DIALING
The delay dialing allows the dialer to dial the preset phone numbers after a
specified period of time (between 0 - 75 seconds). This feature allows the
user to deactivate the dialer after it has been triggered. For instance, if the
panic transmitter is pressed accidentally, and the delay dialer is set to '0'
seconds, the dialer will begin dialing immediately. If the delay dialing is set
to anything but "0" seconds, the dialer will not dial immediately, it will start
dialing after the preset delay dialing time. The delay dialing is factory set to
0 seconds.
To set the dialing time delay:
1. Press the [L] key, the display will show “ L ”.
2. Press the [8] key, the display will show “ L 8 1 ”. The last digit is the
current delay dialing setting.
3. Press either 1, 2, 3, 4 or 5 to set the delay dialing time, (refer to the chart
below) 1=0 seconds
2=30 seconds
3=45 seconds
4=60 seconds
5=75 seconds
If the display shows “ L 8 3 ”, the dialer will begin dialing 45 seconds after
the dialer has been activated. During that delay period, you may wish to stop
the dialer from dialing the preset telephone numbers. If so, press and hold the
panic button [O] on the keypad for 2 seconds. If you have successfully aborted
the call, the display will go back to clock mode.
UNIVERSAL DIAL TONE
This feature allows our Dial-Alert to be compatible with all phone systems
world-wide. When the Universal Dial Tone is off, our Dial-Alert needs a dial
tone before it will dial the pre-programmed telephone numbers. However, not
all phone systems and dial tones are the same. For instance, the dial tone
may be different for any phone system that accommodates the voice message
systems or call answer feature. When the Universal Dial Tone is on, our Dial-
Alert will dial no matter what type of dial tone is present.
This Universal Dial Tone is factory set to off. However, you may wish to set
it to on if your phone line accommodates the voice message systems or call
answer feature.
–
19
–
ADVANCED PROGRAMMING

–
7
–
INSTALLATION
3. Thread the AC adapter cord through the top
hole in the back of the unit and plug it into
the AC connector on the circuit board as
shown. The adapter cord must be inserted
through the back of the unit beforeit is
attached to the wall.
4. Insert the 9 volt alkaline battery and rotate
the antenna from the inside of the dialer to
the outside.
5. Attach the unit to the wall. If hanging the
unit, insert two screws using the template
provided. If screwing the back directly to the
wall, take the back plate right off by prying
apart one hinge and unplug the AC adapter
from the circuit board.
6. Using the template, attach the backplate
onto the wall with 2 screws.
7. Mount the dialer on the backplate. Insert
one hinge into the hole, then twist the other
hinge into position.Plug the AC adapter back
into the circuit board.
8. Firmly close the case.
9. Plug the AC adapter into a power outlet. The
red AC PWR light will turn on and the keypad
backlight will flash.
2. Thread the telephone line through the top
hole in the back of the unit and plug it into
the "LINE" jack. Plug the other end of this
line into a telephone jack. If you want to have
an answering machine on the same line as
the dialer, thread the phone line through the
bottom hole in the back of the unit and plug
it into the "PHONE" jack of the dialer. The
phone line(s) must be inserted through
the back of the unit before it is attached
to the wall.
–
18
–
ADVANCED PROGRAMMING
DELETE PROGRAMMED PANIC TRANSMITTER:
Once a panic transmitter is learned, it is stored in memory. In order to delete
any one of the transmitters, first the entire memory must be erased, then re-
learn the panic transmitters you wish to use. You cannot erase only one specific
transmitter, the entire memory must be cleared.
To erase panic transmitters from the dialer:
1. Press the [L] key, the display will show “ L ”.
2. Press the [6] key, the display will show “ L 6 ErASE “.
3. Press the [#] key. If your hear a double beep, all panic transmitters have
been deleted.
TO ARM/DISARM THE DIALER
The dialer can be armed to send messages when the transmitters that are
learned have been activated. You can also disarm the dialer so that it will
not be activated even if any of the learned transmitters are activated. You
may choose to disarm the dialer for whatever reason. The dialer is currently
set to arm mode. We recommend all users arm the dialer all the times.
To arm/disarm the dialer:
1. Press the [L] key, the display will show “ L ”.
2. Press the [7] key, the display will show “ L 7 1 ”. The last digit (1)
indicates the dialer is armed.
3. To disarm the dialer, press the [2] key within 5 seconds after pressing the
[7] key . When the dialer is disabled, the display will read “ L 7 2 ”.
When the dialer is disarmed, the disarm LED light will be on.

–
8
–
Switch Setting
1. Tone/Pulse Switch
This dialer supports both Tone and Pulse
dialing. In order to change the setting, you
need to open the case by pressing the two
tabs on top of the dialer and pull open the front.
The Tone/Pulse switch is located at the upper
left corner of the circuit board (just above
the adapter jack). The switch is set to Tone at
the factory. This setting can be changed by
sliding the switch to the appropriate position.
2. Speaker On/Off Switch
The speaker must be on during programming
and recording the voice message in order to
use the playback feature. For security pur-
poses, the speaker may be turned off after
programming to allow for silent dialing when
the dialer is activated.
The On/Off switch for the speaker is located
on the lower right corner of the circuit board.
The default setting for the speaker is "On".
INSTALLATION
–
17
–
SET THE TYPE OF PHONE SYSTEM
This dialer supports both regular telephone and PABX phone systems.
Selection can be made using the function key. The dialer is currently set for
regular phones.
To select the phone system:
1. Press the [L] key, display will show an “L”.
2. Press the [3] key, display will show “L 3 1 ”, the last digit (1) means
the dialer is set for regular phone.
3. To change the setting of the dialer to PABX systems, press [2].
The display will show “ L 3 2 ” and the system is now set to PABX system.
PROGRAM THE ID CODE OF A TRANSMITTER
Before any additional panic transmitter can activate the Dial-Alert, it must
be learned (programmed) to communicate with the dialer. Once it is learned
and the button on the panic transmitter is pressed, the dialer will begin to
dial the preset telephone numbers and play the pre-recorded message.
To program Skylink’s panic transmitter:
1. Press the [L] key, display will show “L”.
2. Press the [5] key, display will show “ L 5 Id codE ”.
3. Activate the desired panic transmitter within 5 seconds after pressing the
[5] key. Once the panic transmitter is learned to the dialer, the display will
return to clock mode.
4. To ensure that the transmitter has been learned, activate the learned trans-
mitter when the dialer is in the clock mode. If the dialer starts dialing the
preset phone numbers, the transmitter has been learned. To terminate the
dialing, press and hold the Panic Button [O] on the keypad for 2 seconds.
ADVANCED PROGRAMMING

–
16
–
ADVANCED PROGRAMMING
PROGRAM THE CALLING TIME
The calling time is the amount of time the phone will ring until the call is dis-
connected. If the phone is not picked up within this period of time, the dialer
will either call again, (depends on the redial count), or advance to the next phone
number. The calling time is currently set at 60 seconds.
How to program the calling time
1. Press the [L] key, the display will show “ L ”.
2. Press the [1] key, the diplay will show “ L 1 1 ”, the last digit, “ 1 ”, is
the setting of the call time, (in this example, it is currently 30 seconds,
as per chart below). To keep this setting, press the [L] key.
3. To change the calling time, press either 1, 2, 3, 4 or 5 when the diplay
shows “ L 1 1 ” (refer to the chart below)
1=30 seconds
2=45 seconds
3=60 seconds
4=75 seconds
5=90 seconds
If the display shows “ L 1 3 ”, the phone will ring for 60 seconds before
the call is disconnected.
PROGRAMMING THE PAUSE PERIOD FOR PAGER ACCESS
As mentioned before, when storing a telephone number to be sent to pagers,
a pause period will be inserted between the telephone number and the numeric
message. The current setting for this pause period is 5 seconds. This setting
can be changed from 1 to 9 seconds to suit a specific application.
To program the pause period
1. Press the [L] key, the display will show “ L ”.
2. Press the [2] key, the display will show “ L 2 5 ”, the last digit, “ 5 ”,
is the setting of the pause period (in this example, it is currently set at 5
seconds), to keep this setting, press the [L] key.
3. To change the pause period, between 1 to 9 seconds, press ( 1 - 9 ) on
the keypad while the display shows “ L 2 5 ”. If the number 9 is entered,
the pause period between the number dialed and the numeric message
is 9 seconds.
Below is an explaination of the lights and sounds of the Dial-Alert.
LIGHTS
ACPWR light on dialer is being powered by AC adapter.
ACPWR light off dialer is not receiving any AC power.
LOBATT. light off backup battery is connected and working.
LOBATT. light on backup battery is weak, battery needs to be replaced.
DISARM light off the dialer will dial the pre-programmed phone numbers
when activated.
DISARM light on the dialer will not dial any phone numbers when
activated.
Keypad backlight 1.) the dialer has no message in memory.
flashing 2.) dial tone is not detected when the dialer is
activated, check phone line connection.
Keypad backlight If unit is powered by AC adapter or powered by back
up battery, back light stays on for five seconds
when any key on the keypad is pressed.
SOUNDS
Short beep You have pressed a key in the right order.
Two short beep's 1.) When the dialer is turned on for the first time.
2.) When the pre-programmed transmitters/sensors
are deleted from the memory.
Long beep You have made a mistake.
–
9
–
LIGHTS AND SOUNDS

STANDARD PROGRAMMING
When you plug in the dialer for the first time, you will hear a double beep and
all the lights will be on for 2 seconds, the keypad will continue to flash and
the clock will be set to 12:00.
PROGRAM THE TIME CLOCK
1. Press the [L] key, display will show “L”.
2. Press the [4] key, display will show “ L 4 12:00 ”. The first digit of the
time will be flashing. The flashing digit is the number you are currently
changing.
3. Using the keypad, enter the desired number.
The clock is in 24 hour mode. For example, if the display shows
“ L 4 1330 ”, the time is set at 1:30 pm.
To change the time to 8:15 pm, the sequence is (remember that the clock is
in 24 hour mode):
[ L ] , [ 4 ] , [ 2 ] , [ 0 ] , [ 1 ] , [ 5 ]
RECORDING A MESSAGE
Currently the keypad is flashing and will continue to flash until a message
has been recorded. The dialer cannot dial any phone numbers if a message
has not been recorded.
To record a message, press and hold the [R/P] key for 2 seconds then release,
the display will show “rEcord” and a beep is generated which alerts you to begin
recording. The microphone is located beside the speaker. Record all the infor-
mation you would like to be played in case of an emergency. For example:
"This is an emergency voicemessage, my name is John Smith, please send
help, I live at......My phone number is xxx-xxx-xxx" (if you have two phone
lines, give the phone number of the line that is not using.)
This dialer includes a special feature to let the called party terminate the emer-
gency message. By pressing "#" while the message is being played, the Dialer
will stop calling that number, then advance to the next number, if any. We recom-
mend that a short ending be recorded after the emergency message informing
the recipient of this feature (i.e. this message will call you xtimes and repeat
xtimes during each call, to acknowledge and discontinue further calls, press "#").
After you are finished recording the message, (maximum length of 40 seconds),
press and release [R/P] key, display will show “PLAY” and play back the message.
After playing the message, the display will return to clock mode. The keypad
backlight will stop flashing indicating that a message has been recorded.
The sequence to record a message is:
Press and hold [ R/P ] for 2 seconds , [ record message ] , press [ R/P ].
–
10
–
PANIC TRANSMITTER
The Panic Transmitter conveniently fits on any keychain or necklace. It
allows you to activate the Dial-Alert from a distance of approximately 100 feet
from the dialer. The distance will depend on what is between the Panic Trans-
mitter and the dialer. This transmitter is water resistance and shock resistance,
it allows you to carry this transmitter all the time.
Activate the Emergency Dialer with the Panic Transmitter
In an emergency, you can activate the dialer using the
Panic Transmitter. Move the sliding cover and press
the panic button for one second. This will activate the
dialer and it will dial the preset telephone numbers.
Note: Make sure you press down on the transmitter for
one full second or the system may not respond.
–
15
–

–
11
–
STANDARD PROGRAMMING
STORING TELEPHONE NUMBERS
This feature enables the user to program as many as 9 different telephone
numbers. The dialer can send out 2 different messages. One message is the
pre-recorded voice message that you programmed earlier, the other message
sends numeric information to a pager.
There are three different ways that you can send the voice message and the
numeric information:
A. Sends the emergency voice message only.
B. Sends both the emergency voice message and the numeric infomation
(pager reception only).
C. Sends the numeric information only (for pager reception only).
A. Storing telephone numbers in memory (Sends the emergency
voice message only)
1. Press the [MEM] key, the display will show a letter “M” on the upper left corner.
If nothing is entered within 5 seconds, the display will return to the clock mode.
2. Within the first 5 seconds, select a memory location by pressing a key
pad number 1 - 9 to store the telephone number.
3. Enter the telephone number using the keypad. The display will flash as the
numbers are being entered.
4. Press the [MEM] key within 5 seconds after the last digit of the telephone
number is entered. The number is now stored.
5. After the telephone number has been stored, "rEdIAL 3" will appear on the
display. This is the redial count which is the number of times the dialer will
call that telephone number. The dialer is factory set to call each number 3
times. The number of attempts can be changed to dial 1 to 9 times. If you
want to keep the dialer at 3 attempts, press the [MEM] key. To change the
redial count, enter a number from 1 - 9 when display shows “rEdIAL 3” .
6. The display will now show “rEPEAt 3”. This is the repeat count which is
the number of times the message will be repeated during that one call. The
dialer is factory set to repeat the message 3 times. The number of repeats
can be changed from 1 to 9 times. If you want to keep the repeat count to
remain at 3 times, press the [MEM] key. To change the repeat count,
enter a number from 1 - 9 when display shows “rEPEAt 3” .
PLAYBACK PRE-RECORDED MESSAGE
Press and release the [R/P] key, display will show “PLAY” and the dialer will
beep. The message is then played back.
–
14
–
5. The display will now show the current setting of the redial count. If you
want to keep the current redial count, enter the [MEM] key. If you want
to change the setting, enter the desired number, (1 - 9), then press the
[MEM] key.
6. After pressing the [MEM] key, the display will show the current setting
of the repeat times.
7. If you want to keep the current repeat time, enter the [MEM] key. If you
want to change the setting, enter the desired number, (1 - 9), then press
the [MEM] key.
8. The screen will revert back to clock mode.
Activate the Dial-Alert with the Panic button on the keypad
After you programmed all the emergency telephone numbers and the voice
message, you can activate the dialer by pressing the panic button on the
keypad. Once the panic button is pressed, the dialer will start dialing the pre-
programmed emergency phone numbers. You can also activate the dialer
using the Panic Transmitter.
STANDARD PROGRAMMING
1. Press the [MEM] key, display will show an “M” in the upper right corner.
2. Select the memory location of the phone number, (1 - 9)
3. The phone number will be shown on the display.
4. If you want to change the telephone number, enter the new phone number
while the old number is on the screen. This telephone number will be deleted
when a new number is added. Then press the [MEM] key. If you want to
keep the telephone number shown on the screen, press [MEM].
TO REVIEW OR MODIFY THE PRE-PROGRAMMED PHONE NUM-
BERS, THE REDIAL COUNT AND/OR THE REPEAT TIMES OF A
PHONE NUMBER.

STANDARD PROGRAMMING
–
13
–
C. Storing telephone numbers in memory (Sends the numeric
information to pager only)
1. Press the [MEM] key, the display will show a letter “M” on the upper left
corner. If nothing is entered within 5 seconds, the display will return to the
clock mode.
2. Within the first 5 seconds, select a memory location by pressing a keypad
number 1 - 9 to store the telephone number.
3. Enter the telephone number using the keypad. The display will flash as the
telephone is being entered.
7. After the telephone number has been stored, another message will appear
on the display asking for a redial count. The redial count is the number
of times the dialer will call that telephone number. The dialer is factory set
to call the number 3 times. The number of attempts can be changed to dial
1 to 9 times. If you want to keep the redial count at 3 attempts, press the
[MEM] key. To change the redial count, enter a number from 1 - 9 when
display shows "rEdIAL 3".
8. Input the repeat times when the display shows "rEPEAt 3". The repeat
time is the number of times the message will be played for that certain
phone number. The current setting is 3. It can be changed from 1 to 9 using
the keypad. Again, by pressing [MEM] will keep the existing setting.
DELETE A TELEPHONE NUMBER FROM MEMORY
1. Press [MEM] key.
2. Select the memory location (1 - 9) of the phone number you want to delete.
3. The phone number will be shown on the display, if that is the number you
want to delete, press the [R/P] key while the telephone number is on the
display. Once the phone number is deleted, the display will return to clock
mode.
4. Press the [R/P] key to insert a pause period between the telephone number
and the information you want to send. The display will show a “P”. This pause
period is factory set at 5 seconds but can be changed from 1 - 9 seconds.
(Refer to Advanced Programming - programming the pause period for pager
access).
5. Enter the numeric information you want to send out, ( the information that
will be shown on the pager), then press [L]. This will suspend the recorded
message.
6. Press [MEM].
–
12
–
3. Enter the telephone number using the keypad. The display will flash as the
telephone is being entered.
4. Press the [R/P] key to insert a pause period between the telephone
number and the numeric information you want to send. The pause period
is the time you have to wait after the connection has been made to the
paging company and before you can enter the numeric information (i.e.
phone number). The display will show a “P” if a pause period is entered.
This pause period is factory set at 5 seconds but can be changed from
1 - 9 seconds (Refer to Advanced Programming - programming the pause
period for pager access). You may also insert multiple pause periods to
suit your application. Call the paging company to determine how long
the pause period should be.
5. Press [MEM]
6. "rEdIAL 3" will appear on the display. This is the redial count which is
the number of times the dialer will call that telephone number. The dialer
is factory set to call the number 3 times. The number of attempts can
be changed to dial 1 to 9 times. If you want to keep the redial count at 3
attempts, press the [MEM] key. To change the redial count, enter a number
from 1 - 9 when display shows “rEdIAL 3”.
7. The display will now show “rEPEAt 3”. This is the repeat count which is
the number of times the message will be repeated during that one call.
The dialer is factory set to repeat the message 3 times. The number of
repeats can be changed from 1 to 9 times. If you want to keep the repeat
count to remain at 3 times, press the [MEM] key. To change the repeat
count, enter a number from 1 - 9 when display shows “rEPEAt 3”.
STANDARD PROGRAMMING
2. Within the first 5 seconds, select a memory location by pressing a keypad
number 1 - 9 to store the telephone number.
B. Storing telephone numbers in memory(Sends both emergency
voice message and numeric information)
1. Press the [MEM] key, the display will show a letter “M” on the upper left
corner. If nothing is entered within 5 seconds, the display will return to
the clock mode.
7. The dialer is now in standby mode. (Display shows the time).
The sequence to store a telephone number is as follows:
[MEM] , enter memory location (1-9) , enter telephone # , [MEM] , enter
redial # (1-9), enter repeat # (1-9).
