TeleAlarm TA72 User manual

TA72
TA72-UM-EN | V1.0 | 2016.12
en User Manual

THIS PAGE IS LEFT INTENTIONALLY BLANK

TA72 | en 3
TA72_UM_EN_V1.0_2016.12_FINAL © TeleAlarm SA
Table of contents
1 Safety instructions ......................................................... 6
2 Features ........................................................................... 7
3 Scope of delivery ............................................................ 8
4 Product description ........................................................ 9
4.1 Unit description ............................................................................... 9
4.2 Emergency call button .................................................................... 9
4.3 Cancel / Action button (S button) ................................................. 10
4.3.1 Cancel emergency call ................................................................................... 10
4.3.2 Take the first incoming call ............................................................................. 10
4.3.3 Action button: service call ............................................................................... 10
4.3.4 Action button: unit status ................................................................................ 11
4.4 Device indications ........................................................................ 11
4.4.1 Light signals .................................................................................................... 11
4.4.2 Local voice announcements from the unit ...................................................... 12
4.4.3 Error messages .............................................................................................. 13
5 Installation ..................................................................... 14
5.1 Installation recommendations ....................................................... 14
5.2 Placing the TA72 .......................................................................... 14
5.3 Connecting the TA72 .................................................................... 15
5.3.1 PSTN connection ............................................................................................ 15
5.3.2 External telephone connection (option) .......................................................... 16
5.3.3 Ethernet (IP) connection ................................................................................. 17
5.3.4 Power connection ........................................................................................... 18
5.3.5 Perform a test ................................................................................................. 18
5.4 Switch off ...................................................................................... 18

4 en | TA72
© TeleAlarm SA TA72_UM_EN_V1.0_2016.12_FINAL
6 Programming ................................................................. 19
6.1 Programming methods ................................................................. 19
6.2 Special key functions .................................................................... 20
6.2.1 Maintenance button ........................................................................................ 20
6.2.2 Reset the TA72 .............................................................................................. 20
6.2.3 Restore the TA72 to factory settings .............................................................. 20
6.2.4 Enter Service mode ........................................................................................ 21
6.2.5 Exit Service mode ........................................................................................... 21
6.3 Wireless transmitters 1 and 2 pairing ........................................... 22
6.4 Dynamic Host Configuration Protocol (DHCP) ON / OFF and IP
address announcement 22
6.5 Radio Frequency (RF) range test ................................................. 23
7 Appendix ........................................................................ 24
7.1 TA72 technical specifications ....................................................... 24
7.2 Licences ....................................................................................... 25
7.3 Conformity .................................................................................... 26
7.4 Wall mounting ............................................................................... 26
8 Operation ....................................................................... 27
8.1 Emergency call to a monitoring centre ......................................... 27
8.2 Emergency call to a private phone ............................................... 27
8.3 Taking phone calls ........................................................................ 29
8.4 Test instructions ........................................................................... 30
9 Maintenance .................................................................. 31
9.1 Cleaning ....................................................................................... 31
9.2 Device disposal ............................................................................ 31
9.3 Replacing the backup battery ....................................................... 32
9.4 Replacing the wireless transmitter battery .................................... 35
10 Appendix ........................................................................ 36
10.1 TA72 technical specifications ....................................................... 36

TA72 | en 5
TA72_UM_EN_V1.0_2016.12_FINAL © TeleAlarm SA
10.2 Licences ....................................................................................... 37
10.3 Conformity .................................................................................... 38
10.4 Wall mounting ............................................................................... 38

6 en | Safety instructions TA72
© TeleAlarm SA TA72_UM_EN_V1.0_2016.12_FINAL
1 Safety instructions
– Do not install the unit near a heating appliance.
– Do not expose the unit to direct sunlight.
– Do not install in a wet or humid environment.
– Never touch the power adapter with wet hands.
– Do not attempt to open the unit or the power adapter.
– When unplugging the unit from the power outlet, never pull on the power cord but
always grip the power adapter.
– Connect the TA72 only to a professionally installed 230V AC /50 Hz power outlet with a
16 A fuse near the TA72.
– Do not install the TA72 in the proximity of DECT/GSM telephones, TV sets, large metal
objects, microwave appliances or radio telephones. This will impair the reception of
signals from the wireless transmitter.
– Use only original equipment for cables and power supply. Any other power adapter
could damage the unit.
– Use the unit only in the intended country where it has been delivered.
– Electrolytes or gases may be emitted from the battery should it leak under exceptional
circumstances. If this happens, deactivate the unit by isolating it from the network and
power supply. Battery replacement must be carried out by trained service personnel
only.
– Comply with your national regulations, guidelines and requirements for the disposal of
end-of-life electrical equipment and batteries.
– Repairs should only be performed by an authorized service partner.
– Be sure to allow the required space around the device. The TA72 must be easily
accessible.
– The wireless transmitter provided with the TA72 contains a button cell battery. If the
button cell battery is swallowed, it can cause severe internal burns in just 2 hours and
can lead to death. Keep new and used batteries away from children. If the battery
compartment does not close securely, stop using the product and keep it away from
children. If you think batteries might have been swallowed or placed inside any part of
the body, seek immediate medical attention.
Electrostatic discharge
DANGER!
Read through the safety instructions carefully before using the unit for the first time. This is
important for connection, use and safety.
WARNING!
The TA72 contains highly sensitive electronic components. It should be opened only in an
ESD protected environment with respect to the following precautions. Discharge yourself
from electrostatic loads by touching a grounded conductive surface before opening the unit.

TA72 Features | en 7
TA72_UM_EN_V1.0_2016.12_FINAL © TeleAlarm SA
2 Features
The TA72 has been designed to ensure maximum security for persons living in their own
homes or in locations where assistance could be needed. It can be used to send
emergency calls to a monitoring centre or a private phone.
The person requiring assistance activates a call by pressing a button on the TA72 or by
using a wireless transmitter. This action establishes a voice connection between the person
requiring assistance and the call receiver.
The device has two basic operating modes:
1. The TA72 is part of a social alarm system that consists of a monitoring centre that can
be reached at any time and the device itself. Calls are sent to this monitoring centre.
2. The unit is operated as a standalone unit, in which case emergency calls will be sent to
private phones.
The TA72 can be used with up to 10 wireless transmitters.
The TA72 is able to store up to 10 different destination numbers (telephone number or IP
address). When an emergency call is sent and if the call to the first number is not
successful, the TA72 will try the next numbers. If the last number has been dialed
unsuccessfully, the unit starts with the first number again and continues until it either sends
an emergency call successfully. A single programmed number will be tried 12 times. The
maximum number of dial attempts can be set. By default, it is set to 15 attempts. See the
Reference Manual for more information.
CAUTION!
This unit shall be tested weekly. See Section 8.4 Test instructions.

8 en | Scope of delivery TA72
© TeleAlarm SA TA72_UM_EN_V1.0_2016.12_FINAL
3 Scope of delivery
1. TA72 including pre-installed rechargeable backup battery
2. Quick user guide
3. Power supply unit
4. Phone cable (optionally with a country-specific telephone plug) and / or Ethernet cable
5. Necklace or bracelet
6. Wireless transmitter (battery included)
Care
solutions
ENNL
DE NO
FR SV
IT FI
ESDA
Quick Guide Snellegids
KurzanleitungHurtigveiledning
Aide-mémoireSnabbguide
GuidarapidaP
ikaopas
Guía rápidaKvikguide
TA 72
3
12
4
1
6
5
4
3
2
NOTICE!
Additional accessories can be supplied on request.
CAUTION!
To reduce risk of fire and electric shock, replace only with identical components and parts.

TA72 Product description | en 9
TA72_UM_EN_V1.0_2016.12_FINAL © TeleAlarm SA
4 Product description
4.1 Unit description
1. Cancel / Action button
2. Emergency call button
3. Maintenance button
4.2 Emergency call button
If you require help, press the emergency call button to initiate a call.
The call will be answered either by a person at the monitoring centre or a relative or other
individual, according to the programmed destination.
21 3

10 en | Product description TA72
© TeleAlarm SA TA72_UM_EN_V1.0_2016.12_FINAL
4.3 Cancel / Action button (S button)
4.3.1 Cancel emergency call
If you have pressed the emergency call button by mistake, you can cancel the call with the
action button during the pre-alarm time.
Press the action button until the unit announces "stop". Calls cannot be cancelled after the
pre-alarm time.
4.3.2 Take the first incoming call
If your TA72 is delivered to you unprogrammed, this special function allows you to accept
the first incoming call (PSTN connection only).
► Press the action button 3 times within 3 seconds.
If the first incoming call is from your monitoring centre that supports this functionality, the
operator can start a remote programming session. Refer to the Reference Manual.
4.3.3 Action button: service call
The action button can also be used as a service button. If you press the button and hold it
for at least 2 seconds, the unit dials a call number that has been programmed for the
service call and you hear the announcement "service call".

TA72 Product description | en 11
TA72_UM_EN_V1.0_2016.12_FINAL © TeleAlarm SA
4.3.4 Action button: unit status
The action button flashes if there is a malfunction. Press the action button to announce the
status.
4.4 Device indications
4.4.1 Light signals
The TA72 has two indicator lamps that display the status of the unit. The symbols have the
following meanings:
Lamp shines bright
Lamp shines dull
Lamp blinks (0.5 s)
Lamp flashes (0.1 s)
Status Description or action Blue Red
Initialization After power on.
Device not programmed The device will continuously beep 5
times every 10 seconds and the LED will
alternatively blink.
Error Error message is announced once.
Press action button to repeat.
See Section 4.4.3
Standby normal mode
Unit is in standby.
Standby battery operated
Standby mode with the action button set as service button.
Pre-alarm Can be cancelled with action button.
Connection Established connection.

12 en | Product description TA72
© TeleAlarm SA TA72_UM_EN_V1.0_2016.12_FINAL
4.4.2 Local voice announcements from the unit
Speak Speak (indication for the hearing
impaired).
Listen Listen (indication for the hearing
impaired).
Repeated call When a call is repeated.
Call activated If the call is not acknowledged, a new call
will be sent.
Call back waiting time Pressing action button acknowledges the
alarm.
Status Description or action Blue Red
Voice announcement Meaning
"Emergency call" When the emergency call button is pressed.
"Call activated" Connection failed - unit is calling again.
"Stop" The call is cancelled by pressing the action button during
the pre-alarm time.
"Service call" When the action button is pressed, if it is programmed as
a service button or direct call.
"Emergency call cleared" When a repeated call is acknowledged on the unit.
"Call ended" When a call back is acknowledged on the unit.
"Radio button [x]" When a wireless transmitter button is pressed, x being
the number of the transmitter, from 1 to 10.

TA72 Product description | en 13
TA72_UM_EN_V1.0_2016.12_FINAL © TeleAlarm SA
4.4.3 Error messages
Error messages are announced locally by the TA72. When the TA72 is in synthetic speech
disabled mode, error messages are only announced by beeps.
Voice
announcement
Synthetic speech
disabled mode
Meaning and action needed
"Power failure" 1 beep Main power failure.
Check the power connection.
"Line failure" 2 beeps Connection to PSTN or IP network has been
lost. Check the connection.
"Unit battery
empty"
3 beeps The backup battery is empty.
Connect to the main power supply.
"Transmission
failure"
4 beeps Emergency call not sent.
Contact the monitoring centre.
- 5 beeps Device is not operational.
Refer to the Reference Manual.

14 en | Installation TA72
© TeleAlarm SA TA72_UM_EN_V1.0_2016.12_FINAL
5 Installation
5.1 Installation recommendations
– Place the TA72 on a flat and non-slippery surface.
– Do not cover the microphone (right-front side of the unit) and the loudspeaker (top of
the unit).
– Dependent on the configuration of the device, alarms will be send via the telephone line
or IP network.
– The TA72 must be connected with the original power supply.
– To send an alarm, at least one alarm receiver (a monitoring centre or a private phone)
must be programmed.
– The power supply of the TA72 must placed at least 10 cm away from the device.
– The power supply must be plugged into a wall socket in the proximity of the TA72 and
must remain easily accessible at all times.
– Construction materials affect the range of the device. For example, concrete walls with
steel reinforcements hamper the radio signal more than a brick wall.
– Location of the TA72 affects the range of the transmitter. The best place to locate it is a
central room.
5.2 Placing the TA72
Placing on a surface
The TA72 is designed for use at home. Many items of furniture are coated with a variety of
paints, varnishes and plastics. The feet of the TA72 may leave marks on furniture as a
result of chemical processes.
Wall mounting
You can mount the TA72 directly onto a wall.See Section 10.4 Wall mounting, Page 38
CAUTION!
Before starting to install and program the TA72, read the safety instructions carefully.

TA72 Installation | en 15
TA72_UM_EN_V1.0_2016.12_FINAL © TeleAlarm SA
5.3 Connecting the TA72
5.3.1 PSTN connection
1. Insert the plug of the telephone cable into the socket (1) on the TA72. Feed the cord
through the cable channel and through the opening on the back of the unit.
2. Fit the plug of the telephone cable into the socket of your telephone outlet.
1
CAUTION!
Only connect the unit to a telephone outlet that has been correctly installed by your
telephone service provider. The TA72 is designed to be connected to the public telephone
network.

16 en | Installation TA72
© TeleAlarm SA TA72_UM_EN_V1.0_2016.12_FINAL
5.3.2 External telephone connection (option)
1. Insert the plug of the external telephone cable into the socket (2) on the TA72. Feed the
cord through the cable channel and through the opening on the back of the unit.
2. Fit the other end of the external telephone cable into your telephone.
To check whether an emergency call can be sent:
1. Make a phone call as you normally would.
2. When the phone call is in progress, press the emergency call button.
► If the setup is correct, the phone call will be interrupted immediately after the pre-alarm.
2
NOTICE!
In the event of an emergency, the unit must be able to send out an emergency call even if a
phone call is in progress at the time.
CAUTION!
With a private branch exchange (PABX or a digital box) there is no guarantee that a phone
call will be interrupted by the emergency call.

TA72 Installation | en 17
TA72_UM_EN_V1.0_2016.12_FINAL © TeleAlarm SA
5.3.3 Ethernet (IP) connection
1. Insert the plug of the network connection cable into the socket (3) on the TA72. Feed
the cord through the cable channel and through the opening on the back of the unit.
2. According to your installation, fit the other end of the network connection cable into
your router outlet or switch.
3
NOTICE!
Be aware of potential limitations due to network availability. In case of a DSL or cable
equipment, be aware of power failures. Prioritizing an emergency call may not always be
possible.
WARNING!
The TA72 shall be connected only to a device with the auto-negociation procedure enabled
for the Ethernet communication.

18 en | Installation TA72
© TeleAlarm SA TA72_UM_EN_V1.0_2016.12_FINAL
5.3.4 Power connection
1. Insert the plug of the power supply into the socket (4) on the TA72. Feed the cord
through the cable channel and through the opening on the back of the unit.
2. Plug the power adapter into the power outlet.
All the indicator lamps light up for approx. 2 seconds, this is a battery test. The unit enters in
standby mode and can now be programmed (refer to the Reference Manual for more
information on programming).
5.3.5 Perform a test
Once the unit is installed, perform a test immediately by sending an alarm with the wireless
transmitter. See also Section 8.4 Test instructions.
5.4 Switch off
To switch the TA72 off, remove the power plug from the socket (4).
4
NOTICE!
The backup battery will now charge up. The specified standby time is available when the
battery is fully charged, after 16 hours. If the TA72 is stored and disconnected, connect it to
the main power supply at least once every 6 months, to allow the battery to charge.
NOTICE!
If you remove the power plug from your power outlet, the unit announces "power failure".
The unit will switch to battery operation.

TA72 Programming | en 19
TA72_UM_EN_V1.0_2016.12_FINAL © TeleAlarm SA
6 Programming
Before you program the TA72 you must be familiar with all of the unit's functions.
Programming is specifically intended for authorized personnel only.
6.1 Programming methods
Three programming methods are available to program your TA72:
– The Configuration Manager software;
– The Cloud Service Platform;
– A compatible Social Alarm Monitoring Centre.
Please refer to the corresponding documents for more information.
NOTICE!
Correct programming of the TA72 is important for the full function of the unit. Please refer to
the Reference Manual for more information on programming.
NOTICE!
Check the remote programming possibilities with your monitoring centre.

20 en | Programming TA72
© TeleAlarm SA TA72_UM_EN_V1.0_2016.12_FINAL
6.2 Special key functions
6.2.1 Maintenance button
To press the maintenance button, use something long a thin, such as an unfolded paper
clip.
6.2.2 Reset the TA72
1. Press the maintenance button for 0.5 to 2 seconds and then release it.
2. The unit beeps and reboots.
6.2.3 Restore the TA72 to default settings
1. Press the maintenance button for at least 20 seconds.
2. The unit announces: "Setup reset".
The unit is now non-operational. You have to program it with the Configuration Manager or
Cloud Service Platform. Please refer to the Reference Manual for more information on
programming.
Maintenance button
CAUTION!
This function deletes all user settings and restores the default settings.
