Smart power AVR10-120TBF User manual

COMPUTER-GRADE
FILTERING
AVR10-120TBF, AVR15-120TBF, AVR20-120TBF,
AVR20-230TBF Plus, AVR20-240TBF
IMPORTANT - RMA (Return Material Authorization)
If for any reason you need to return the AVR Plus unit to the manufacturer, you should
obtain an RMA (Return Material Authorization) number before returning the unit. To request
an RMA number please call 1-800-772-7633 or visit the website at
www.smartpowersystems.com/rma.htm
1760 Stebbins Drive - Houston, Texas 77043 - Tel:[phone] - Fax:[phone]
E-mail: [email protected] - www.smartpowersystems.com 1-800-882-8285
MEGA CONDITIONERS
The most advanced electronic power conditioner on the market for half the price and a
quarter of the weight of an isolation transformer. The Mega Conditioner offers ultra power
filtration and conditioning of normal and common mode noise which accounts for 90% of
power-related problems experienced by copiers, mailing systems, large format printers and
other office equipment.
UNINTERRUPTIBLE POWER SUPPLIES - UPS SERIES
Smart Power Systems' Uninterruptible Power Supplies (UPS) integrated TBF™ Technology
provide on-line power conditioning.
OTHER POWER PROTECTION PRODUCTS
WARRANTY
$25,000 Connected Equipment Warranty
If the AVR Plus unit fails during the warranty period and this failure allows a surge to pass through
and damage the connected equipment, Smart Power Systems will pay for the repair or replacement
of the connected equipment of the original purchaser. See our website for more details
- www.smartpowersystems.com
USER'S GUIDE
USER'S GUIDE
Thank you for purchasing this AVR Plus. Smart Power
Systems is dedicated to developing and manufacturing the
highest performance power protection and filtration devices
for your electronic equipment. Proper use of this device will
provide the protection needed for your connected equipment.
16000120 Rev.02/14
All AVR Plus units are guaranteed free of defects in material or workmanship for 2 years. See our
website for more details - www.smartpowersystems.com
INSIDE THE BOX
AVR Unit User's Manual CAT.5 Patch Cord
AUTOMATIC VOLTAGE REGUL ATOR
AVR
TRANSFORMER BASED FILTER (TBF™) SERIES
Considered to be one of the most significant developments in the power protection industry.
TBF™ Filters contain innovative technology that combines Surge Suppression and Noise
Isolation which filters the noise on the ground to less than 0.5 Volts (US Patent # 6229682).
Exclusive "POVP" Prolonged Over Voltage Protector (US Patent # 6560086) disconnects the
output power if voltage exceeds 155 volts. Exclusive Smart Technology (US Patent
#5721661) protects microprocessor based equipment against reverse polarity or no ground.
The patented TBF™ filters prevent 90% of the power problems experienced by your POS
system, computer, copier and facsimile machine.
Models:
SmartPower
SYSTEMS
••••••••••••••••
A POWER QUALITY COMPANY
SmartPower
SYSTEMS
••••••••••••••••
A POWER QUALITY COMPANY

SPECIFICATIONS
Output Voltage Regulation (VAC)
Dimensions Inches (mm) DxWxH
Capacity (Amps)
Input Voltage Range (VAC) / 50/60Hz
Net Weight (Lbs./Kgs.)
MODEL
Shipping Weight (Lbs./Kgs.)
AVR15-120TBF
15
Input Plug
Receptacles
5-15P
Two 5-15R
Operating Environment
WARRANTY
<0.5V
<10V
AVR10-120TBF
10
7.9 x 5.4 x 4.5 (200 x 137 x 115)
10 / 4.5
10.75 / 4.9
120±8.5%
120 21%±
Two 5-15R
14.7 / 6.7
16.2 / 7.4
AVR20-120TBF
5-20P
Two 5-20R
20
16.5 / 7.5
18 / 8.2
230±3.9%
Specifications subjects to change without notice.
<5% of input surge voltage
20
18 / 8.2
19.5 / 8.9
6-20P
Two 6-20R
120±6.5%
99-128
Over Voltage Protection -
Disconnects the output
when exceeds: (VAC)
140-145
SYSTEM DESCRIPTION
1. Network Protector (RJ45)
2. Output Receptacles
3. Circuit Breaker
4. Input Power Cord
1
2
3
4
1. Green LED: Normal
Red LED: Fault
2. Buck
3. Boost
FRONT
4. Network protection
5. Output Receptacle (available with 4)
6. Circuit Breaker
7. Input Cord
1
2
3
BUCK
BOOST
1. Green LED: Normal
Red LED: Fault
2. Buck
3. Boost
4. Volt Meter Output
10 Amp
models
15 & 20 Amp
models
REAR
FRONT REAR
5
7
6
4
IMPORTANT SAFETY INSTRUCTIONS
WARNING
SAVE THESE INSTRUCTIONS: This manual contains important instructions that should
be followed during installation and maintenance of the AVR. •Install this unit in a controlled
environment.
CAUTION
INSTALLATION & OPERATION
1. Check in specifications if the AVR unit has the same voltage rating as required.
2. Connect input power cable to wall outlet with correct voltage rating.
3."Power On" LED will turn on. AVR unit is running normal.
4. Connect power cable of the equipment that needs to be protected to AVR's output outlets.
Network
RJ45 Jack/HUB
248-252
AVR20-230TBF Plus
198 252-
ATTENTION
AVR20-230TBF Plus model can be plugged
into a 208V or 240V outlet. It automatically
detects and converts the power voltage
from 208V or 240V to 230V and also
regulates it
FEATURES
This can be used with copiers, office equipment, computers and telecommunication systems.AVR
• Common Mode noise filtering: < 0.5 Volts
• Normal Mode noise filtering: <10 Volts
• Voltage regulation
• Over and under voltage protection
• Site wiring fault indicator
• Ground loop current protection
Risk of electric shock, do not remove cover. For service call Smart Power Systems at 800-772-7633.
•Avoid exposing the AVR Plus to direct sunlight, stoves or any other heat source.
•To prevent overheating, make sure that the ventilation openings of the unit are not covered.
•Keep unit away from moisture and dust.
Notice for AVR20-230TBF Plus models
Spike Transient Let Through Voltage
(Common Mode) (N-G)
Spike Transient Let Through Voltage
(Normal Mode) (L-N)
DAMAGED UNIT ON ARRIVAL
Inspect unit for any damage on arrival . If damage is found, please contact the shipping company to file
insurance claim.
AVR
AVR20-240TBF
13 x 5.5 x 6.6 (330 x 140 x 168)
Temperature: 0-40°C - 0-90% (non condensing)Humidity:
2 Years
240 18%-12%+
240±4%
260-265
18.5 / 8.5
20 / 9.1
1
3
4
2
OUTPUT
CIRCUIT
BREAKER
IN
INPUT
OUT
Wall Outlet
Protect Your Wide Format Printer
