SMARTdesks iGroup Installation guide

TABLES
ASSEMBLY INSTRUCTIONS
www.smartdesks.com
800-770-7042
iGroup® Tables are shaped in right triangles with a curve on the
user side. They are produced to order with this curve on the
right or left side, usually in sets, to produce mirror-image shapes
or radial shapes.
These are Mirror-Image shapes made up of equal
numbers of Lefts and Rights.
These are Radial Shapes
made up of All Lefts or All Rights.
A grouping is arranged, then the casters are
locked to keep the arrangement stable. Plako®
interlocking plates are fixed to the underside
to provide additional connected stability to the
arrangement.
Three legs are attached to each iGroup Table
Element, using 8 hex head/phillips drive 1/4-20
bolts, provided for each leg.
Mesh modesty panels provide wire manage-
ment with hook/loop closures. They hang from
two hooks which are attached with screws.
Legs may be fixed height or adjustable height.
They install the same way. A SnapChase™
wire management sleeve is shown installed on
a rear leg.
© 2014 CBT Supply, Inc. dba SMARTdesks® All rights reserved. SMARTdesks is a registered trademark of CBT Supply, Inc.

Install three legs
Use a Phillips #2 drive or 3/8”hex drive to
install eight 1/2” bolts for each leg.
Install Plako joining plates
Plako clips are used to hold the igroup
table elements together as configured.
The pilot hole pattern is a group of four.
Use four 1-1/8”wood screws per hub to
install using #2 Phillips driver. The clips
interlock to form the joining plate.
© 2014 CBT Supply, Inc. dba SMARTdesks® All rights reserved. SMARTdesks is a registered trademark of CBT Supply, Inc.

Install modesty panel hooks.
Install two hooks for suspending the modesty
panels. Each installs into pilot holes with two
wood screws, each.
Hang the wire management modesty panel on
two hooks.
Press SnapChase™ wire management channel onto the preferred
leg for wire management. SnapChase™ fits any leg and is easily
repositioned.
Modesty panel: steel frame with mesh fabric and hook-
loop closures for wire management.
