SMARTdesks SPX-243030-FDL User manual

Right End Panel (1 ea.)
Front Edge
Smartdesks Model SPX-243030-FDL
Panel List
Note: Separate and stack panels by like types before beginning assembly process.
Fixed Projector & Document Camera Cabinet
1 Top Panel • 1 Back Panel • 1 Left End Panel • 1 Right End Panel
• 1 Bottom Panel • 1 Adjustable Shelf • 1 Storage Door • 1 Toe Kick Panel
SPX-243030-FDL Page 1
Top Panel (1 ea.)
Back Panel (1 ea.)
Toe Kick Panel (1 ea.)
cSmartdesks ltd. 1999
Storage Door (1 ea.) Bottom Panel (1 ea.)
Left End Panel (1 ea.)
Front Edge
Adjustable Shelf (1 ea.)
= Cam Fitting
= Cam Hole
= Screw Hole/Spoon Pin
= RV Fitting
= Grommet/wire access

Smartdesks Model SPX-243030-FDL
The Smartdesk is packaged ready to be assembled. Included is a Master Parts and Panel List showing diagrams of all
parts and hardware required for assembly. Please note, improper installation may void Smartdesk warranty. To install
correctly follow the enclosed instructions. If you need additional assistance or information please contact Technical
Service at 410-922-6005. c Copyright Smartdesks ltd. 1999. All rights reserved.
Hardware Inventory Sheet
1 person is needed to assemble
Smartdesks Storage and Support Components: Fixed Projector& Document Camera Cabinet
Model SPX-243030-MDL
Unpack Parts and Hardware:
Parts and panels will vary according to Smartdesks model. See Parts & Panels List and Hardware
Inventory Sheet. Please verify all parts and quantities prior to assembly. Contact the factory if your
quantities are incomplete. Note: All panels are predrilled ready for assembly.
Tools needed for assembly:
Power drill with #2 Phillips screwdriver bit and regular #2 Phillips screwdriver.
The following diagram shows the contents of the hardware bag.
Contents of Hardware Bag : (quantities for each unit - multiply by number of components)
extra hardware parts packaged to account for possible loss during shipping.
2 ea.- Shelf Spoon Pins
for Adjustable Shelf (rear holes)
2 ea.- Earthquake Pins
for Printer/Storage Shelf
(front holes)
10 ea. - Cam Pins
push through holes in panels.
(Side, Back, and
Bottom Panels)
SPX-243030-FDL Page 2
2 ea. - Hinge Plates
2 ea. - Hinge Plate
Screw Cover Caps
to cover Hinge Plate
Screws
Smartdesks have been designed and tested as an ergonomi-
cally correct and space saving unit. For more information
on this and other Smartdesks products, call 1-800-770-7042
or visit our website at http://www.smartdesks.com
Smartdesks Storage and Support Components:
Fixed Projector & Document Camera Cabinet
Model SPX-243030-MDL

Figure 2
Figure 3
STEP 1 - Top & Side Panel Assembly
In a clean work area lay Top Panel with top facing
down on the floor on cardboard or carpet/packing
quilt. (Fig. 1)
SPX-243030-FDL Page 3
Lift and place Left Side Panel into 90overtical position
with fittings facing in. While holding right panel in ver-
tical position, match RV Fittings to one another and
snap panel into place. Use power drill to tighten the
screw contained in the RV Fitting. (Fig.2) Each RV
Fitting contains a screw to lock the hardware once the
panels have been snapped into place. Warranty is
void if all locking screws have not been tightened.
RV Fittings come preinstalled in panels and are
equally spaced along Top edge. Tighten all remaining
RV Fittings along panel edge. (Fig.3)
Repeat STEP 1 for the installation of the Left Side
Panel.
Figure 1
STEP 2 - Back Panel To Sides Assembly
NOTE: 2 person assembly required for proper fit.
Slide Back Panel into position between two Side
Panels matching the cam fittings to the holes at top. It
is necessary for 2 people to accomplish this assembly.
Vertical panels cannot be left standing unsupported
(Fig.4) Insert top 2 Cam Pins through Left and Right
Side Panels into cam fittings. (Fig. 5) Start at the top
cam of each end panel when inserting Cam Pins and
move down each end panel alternating as Cam Pins
are inserted. Make sure arrows on Cam Pins are facing
out (3 pm clock position).
Figure 5
Figure 4
c Smartdesks ltd. 1999

STEP 3 - Bottom Panel Assembly
NOTE: 1 person assembly is required for proper fit.
The Bottom Panel is not adjustable. Make sure arrows
on cams are facing out. With cabinet laying on its back,
push 2 Cam Pins through one side. Align predrilled hole
on Bottom Panel with Cam Pins that have been pushed
through. Then slide the Bottom Panel into position.
Align holes and Cam Pins. Slide Bottom Panel in place.
(Fig. 9) For opposite side, Bottom Panel is already set
in place. Insert Cam Pins through holes into Bottom
Panel. Tighten only the left side of Cam Fittings
BEFORE mounting the Toe Kick Panel. (Fig. 10)
Figure 8 Smartdesks Storage & Support Component
SPX -302430-FDx/Fxx Unit Back & Side Panels Assembled
Figure 9
Figure 11
Figure 10
SPX-243030-FDL Page 4
c Smartdesks ltd. 1999
STEP 2 - Back Panel To Sides Assembly (cont.)
NOTE: 1 person assembly required for proper fit.
Tighten about 1/4 turn with screwdriver until it locks into
place.(Fig. 6) Repeat this step for remaining Cam Pins.
The Cam Pin is a steel to steel assembly which ensures
heavy duty strength when assembled. (Once Back
Panel is secured to Left and Right Side Panels, the
“shell” of the unit is assembled. (Fig. 7))
Cam pin is
inserted
through
panel into
preinstalled
fitting.
Check to verify that arrow is
pointing perpendicular to pin
when Cam is locked.
Figure 7
Figure 8
Figure 6
While holding Toe Kick Panel with the front facing up,
match RV Fittings to one another and snap the left side
of the Toe Kick Panel into place. Left side of the Toe
Kick Panel is now temporarily mounted. (Fig. 11)
STEP 4 - Toe Kick Assembly
NOTE: 1 person assembly is required for proper fit.

SPX-243030-FDL Page 5
c Smartdesks ltd. 1999
2 sets of predrilled holes in side panels are used for the
Adjustable Shelf. Insert Earthquake Pins. Push 1
Earthquake Pin in front hole of Left and Right Side
Panel. Insert Shelf Spoon Pins. Push 1 Shelf Spoon
Pin in matching level rear holes of Left and Right Side
Panel. (Fig. 14)
Slide Adjustable Shelf
into place and rest on top
of pins. (Fig. 15)
Adjustable Shelf should
be parallel to Top Panel.
STEP 6 - Adjustable Shelf
NOTE: 1 person assembly is required for proper fit.
STEP 5 - Flip SPX Unit 180oto
Upright Position
NOTE: 2 persons required for this step.
Roll SPX unit on its back then to its upright position.
(Fig. 13)
Gently spread the Bottom and Right Side Panels
apart so that the RV Fittings of the right side of the
Toe Kick Panel can be matched and snapped into
place. (Fig. 12) It is necessary to tighten the last 2
Cam Fittings on the bottom and tighten the RV
Fittings on the Toe Kick Panel.
STEP 4 - Toe Kick Assembly (cont.)
NOTE: 1 person assembly is required for proper fit.
Figure 12
Figure 13
Figure 14
Figure 15
Figure 14
STEP 6 - Installation of Storage Door
Lift and place Storage Door to match hinge fittings of
Right Side Panel. Snap hinge fittings together.
(Fig.14) Close Storage Door.
