Smartgen HGM9600 Series User manual

HGM9600 SERIES
(HGM9610/HGM9620)
GENSET CONTROLLER
USER MANUAL

HGM9600 Series Genset Controller User Manual Page 2 of 73
CONTENTS
1OVERVIEW....................................................................................................................................................6
2MODELS COMPARISON..............................................................................................................................7
3PERFORMANCE AND CHARACTERISTICS ................................................................................................8
4SPECIFICATION........................................................................................................................................ 11
5OPERATION .............................................................................................................................................. 12
5.1 INDICATOR LIGHT............................................................................................................................. 12
5.2 KEY FUNCTIONS ............................................................................................................................... 14
5.3 LCD DISPLAY..................................................................................................................................... 15
5.3.1 MAIN DISPLAY........................................................................................................................... 15
5.3.2 USER MENU AND PARAMETERS SETTING ............................................................................. 16
5.4 AUTO START/STOP OPERATION..................................................................................................... 19
5.5 MANUAL START/STOP OPERATION ............................................................................................... 21
5.6 SWITCH CONTROL PROCEDURES ................................................................................................... 21
5.6.1 HGM9620 SWITCH CONTROL PROCEDURES ......................................................................... 21
5.6.2 HGM9610 SWITCH CONTROL PROCEDURES ......................................................................... 22
6PROTECTION ............................................................................................................................................ 24
6.1 WARNINGS ........................................................................................................................................ 24
6.2 SHUTDOWN ALARM ......................................................................................................................... 26
6.3 TRIP AND STOP ALARM ................................................................................................................... 28
6.4 TRIP ALARM ...................................................................................................................................... 28
7WIRINGS CONNECTION........................................................................................................................... 29
8SCOPES AND DEFINITIONS OF PROGRAMMABLE PARAMETERS....................................................... 32
8.1 CONTENTS AND SCOPES OF PARAMETERS .................................................................................. 32
8.2 ENABLE DEFINITION OF AUXILIARY OUTPUT PORTS.................................................................... 41
8.2.1 DEFINED CONTENTS OF AUXILIARY OUTPUT PORTS ........................................................... 41
8.2.2 CUSTOM PERIOD OUTPUT ....................................................................................................... 45
8.2.3 CUSTOM COMBINED OUTPUT ................................................................................................. 45
8.3 DEFINED CONTENTS OF AUXILIARY INPUT PORTS (ALL GND (B-) ACTIVE) ................................ 46
8.4 SELECTION OF SENSORS................................................................................................................. 49
8.5 CONDITIONS OF CRANK DISCONNECT SELECTION ...................................................................... 50
9PARAMETERS SETTING........................................................................................................................... 51
10 SENSORS SETTING ................................................................................................................................ 52
11 COMMISSIONING................................................................................................................................... 53
12 TYPICAL APPLICATION......................................................................................................................... 54
13 INSTALLATION....................................................................................................................................... 56
14 GSM SHORT MESSAGE ALARM AND REMOTE CONTROL ................................................................. 58
14.1 GSM SHORT MESSAGE ALARM..................................................................................................... 58
14.2 GSM SHORT MESSAGE REMOTE CONTROL................................................................................. 58
14.3 CONTROLLER AND GSM MODULE CONNECTION ........................................................................ 59
15 CONNECTIONS OF CONTROLLER WITH J1939 ENGINE .................................................................... 60
15.1 CUMMINS ISB/ISBE ........................................................................................................................ 60
15.2 CUMMINS QSL9 .............................................................................................................................. 60

HGM9600 Series Genset Controller User Manual Page 3 of 73
15.3 CUMMINS QSM11(IMPORT) .......................................................................................................... 61
15.4 CUMMINS QSX15-CM570 .............................................................................................................. 61
15.5 CUMMINS GCS-MODBUS ............................................................................................................... 62
15.6 CUMMINS QSM11........................................................................................................................... 62
15.7 CUMMINS QSZ13............................................................................................................................ 63
15.8 DETROIT DIESEL DDEC III /IV......................................................................................................... 63
15.9 DEUTZ EMR2 ................................................................................................................................... 64
15.10 JOHN DEERE ................................................................................................................................. 64
15.11 MTU MDEC .................................................................................................................................... 64
15.12 MTU ADEC (SMART MODULE)..................................................................................................... 65
15.13 MTU ADEC (SAM MODULE).......................................................................................................... 65
15.14 PERKINS........................................................................................................................................ 66
15.15 SCANIA.......................................................................................................................................... 66
15.16 VOLVO EDC3 ................................................................................................................................. 66
15.17 VOLVO EDC4 ................................................................................................................................. 67
15.18 VOLVO-EMS2 ................................................................................................................................ 67
15.19 YUCHAI.......................................................................................................................................... 68
15.20 WEICHAI ........................................................................................................................................ 68
16 ETHERNET PORT.................................................................................................................................... 69
16.1 ILLUSTRATION................................................................................................................................ 69
16.2 NETWORK CLIENT MODE............................................................................................................... 69
16.3 WEB SERVER MODE........................................................................................................................ 69
16.4 NETWORK CABLE CONNECTION................................................................................................... 70
17 MICRO SD ............................................................................................................................................... 72
18 USB.......................................................................................................................................................... 72
19 FAULT FINDING...................................................................................................................................... 73

HGM9600 Series Genset Controller User Manual Page 4 of 73
Registered trademark
No. 28 Xuemei Street, Zhengzhou, Henan, China
Tel: [phone]
[phone] (overseas)
Fax: [phone]
Web: www.smartgen.com.cn
www.smartgen.cn
Email: [e-mail]
All rights reserved. No part of this publication may be reproduced in any material form (including
photocopying or storing in any medium by electronic means or other) without the written permission of
the copyright holder.
Smartgen reserves the right to change the contents of this document without prior notice.
Table 1 Software Version
Date
Version
Note
2012-03-08
1.0
Original release.
2014-08-27
1.1
Modify the external view and the main display description.
2023-09-19
1.2
Modify the image to be consistent with the indicator.

HGM9600 Series Genset Controller User Manual Page 5 of 73
This manual is suitable for HGM9600 series controller only. (HGM9610/HGM9620)
Clarification of notation used within this publication.
Table 2 Sign Instruction
Sign
Instruction
NOTE
Highlights an essential element of a procedure to ensure correctness.
CAUTION!
Indicates a procedure or practice, which, if not strictly observed, could result in
damage or destruction of equipment.
WARNING!
Indicates error operation may cause death, serious injury and significant property
damage.

HGM9600 Series Genset Controller User Manual Page 6 of 73
1OVERVIEW
HGM9600 series genset controllers are used for genset automation and monitor control system of
single unit to achieve automatic start/stop, data measure, alarm protection and “three remote” (remote
control, remote measuring and remote communication). The controller adopts large liquid crystal
display (LCD) and selectable Chinese, English or other languages interface with easy and reliable
operation.
HGM9600 controller adopts 32-bit micro-processor technology with precision parameters measuring,
fixed value adjustment, time setting and threshold adjusting and etc. The majority of parameters can
be set using front panel and all the parameters can be set using PC (via USB port) and can be adjusted
and monitored with the help of RS485 and ETHERNET ports. Controllers are fitted with Micro SD for
real-time operation data recording for convenient browsing and timely fault detection. It can be widely
used in a number of automatic genset control system with compact structure, simple connections and
high reliability.

HGM9600 Series Genset Controller User Manual Page 7 of 73
2MODELS COMPARISON
Table 3 Model Comparison
Item
HGM
9210
HGM
9220
HGM
9310
HGM
9320
HGM
9410
HGM
9420
HGM
9610
HGM
9620
HGM
9510
HGM
9520
LCD
Dimension
3.7”
4.3”
Pixel
132 x 64
480 x 272
AMF
●
●
●
●
●
BUS monitoring
●
Parallel
connection
●
●
Expansion module
●
●
Input port number
7
7
7
7
7
7
8
8
7
8
Output port
number
8
8
8
8
8
8
8
8
8
8
Sensor number
5
5
5
5
5
5
5
5
5
5
Neutral (earth)
current
●
●
Schedule function
●
●
●
●
●
●
●
●
●
●
ETHERNET
●
●
RS485
●
●
●
●
●
●
●
●
GSM
●
●
●
●
●
●
J1939
●
●
●
●
●
●
USB
●
●
●
●
●
●
●
●
●
●
LINK
●
●
Real-time clock
●
●
●
●
●
●
●
●
●
●
Event log
●
●
●
●
●
●
●
●
●
●
Micro SD card
●
●
NOTE:
(1) Two of the outputs are fixed: start output and fuel output.
(2) HGM96XX’s analog sensors are composed by 3 fixed sensors (temperature, pressure, liquid level) and 2 configurable
sensors.
NOTE: Functions of mentioned herein HGM9210/HGM9220/HGM9310/HGM9320/HGM9410/HGM9420
/HGM9510/HGM9520 controllers can be changed, please check the corresponding user manual for accurate
information.

HGM9600 Series Genset Controller User Manual Page 8 of 73
3PERFORMANCE AND CHARACTERISTICS
HGM9610, used for single automation systems, auto start/stop of the unit performed with the help of
remote signal.
HGM9620, has all functions of HGM9610 as well as mains electric quantity monitoring and
mains/generator automatic transfer control function (AMF), particularly suits for single automation
systems that include mains and generator.
Key characteristics,
♦With ARM-based 32-bit SCM, highly integrated hardware, higher reliability;
♦480x272 LCD with backlight, multilingual interface (including English, Chinese or other languages)
which can be chosen at the site, making commissioning convenient for factory personnel;
♦Improved LCD wear-resistance and scratch resistance due to hard screen acrylic;
♦Silicon panel and pushbuttons for better operation in high-temperature environment;
♦RS485 communication port enabling remote control, remote measuring, remote communication via
ModBus protocol;
♦ETHERNET communication port with multiple monitoring modes;
♦Micro SD port for recording of real-time operation data;
♦Equipped with SMS (Short Message Service) function. When genset is alarming, controller can send
short messages via SMS automatically to setting 5 telephone numbers. Besides, generator status
can be controlled and checked using SMS;
♦Equipped with CANBUS port and can communicate with J1939 genset. Not only can you monitor
frequently-used data (such as water temperature, oil pressure, speed, fuel consumption and so on)
of ECU machine, but also control starting up, shutdown, speed raise and drop via CANBUS port;
♦Suitable for 3-phase 4-wire, 3-phase 3-wire, single phase 2-wire, and 2-phase 3-wire systems with
voltage 120/240V and frequency 50/60Hz;
♦Collect and show 3-phase voltage, current, power parameter and frequency of generator or mains.
Mains Generator
Line voltage (Uab, Ubc, and Uca) Line voltage (Uab, Ubc, and Uca)
Phase voltage (Ua, Ub, and Uc) Phase voltage (Ua, Ub, and Uc)
Phase sequence Phase sequence
Frequency Hz Frequency Hz
Load
Current IA, IB, IC
Each phase and total active power kW
Each phase and total reactive power kvar
Each phase and total apparent power KVA

HGM9600 Series Genset Controller User Manual Page 9 of 73
Each phase and average power factor PF
Accumulate total generator power kWh, kvarh, kVAh
♦For mains, controller has over and under voltage, over and under frequency, loss of phase and phase
sequence wrong detection functions; For generator, controller has over and under voltage, over and
under frequency, loss of phase, phase sequence wrong, over and reverse power, over current
functions;
♦3 fixed analog sensors (temperature, oil pressure and level) are fitted;
♦2 configurable sensors can be set as sensor of temperature, oil pressure or fuel level;
♦Precision measure and display parameters about engine,
Temp. (WT) °C/°F both be displayed
Oil pressure (OP) kPa/Psi/Bar all be displayed
Fuel level (FL) % (unit)
Speed (SPD) r/min (unit)
Voltage of Battery (VB) V (unit)
Voltage of Charger (VD) V (unit)
Hour count (HC) can accumulate to max. 65535 hours.
Start times can accumulate to max. 65535 times.
♦Protection: automatic start/stop of the gen-set, ATS (Auto Transfer Switch) control with perfect fault
indication and protection function;
♦All output ports are relay-out;
♦Parameter setting: parameters can be modified and stored in internal EEPROM memory and cannot
be lost even in case of power outage; most of them can be adjusted via front panel of the controller
and all of them can be modified with PC via USB, RS485 or ETHERNET ports.
♦More kinds of curves of temperature, oil pressure, fuel level can be used directly and users can
define the sensor curves by themselves;
♦Multiple crank disconnect conditions (speed sensor, oil pressure, generator frequency) are optional;
♦Widely power supply range DC(8~35)V, suitable for different starting battery voltage environment;
♦Event log, real-time clock, scheduled start & stop generator (can be set as start genset once a
day/week/month whether with load or not);
♦Can be used on pumping units and as an indicating instrument (indication and alarm are enabled,
relay is inhibited);
♦Accumulative total run time and total electric energy of A and B. Users can reset it as 0 and
re-accumulate the value which make convenience to users to count the total value as their wish;
♦Can control engine heater, cooler and fuel pump;
♦With maintenance function. Actions (warning, shutdown or trip and stop) can be set when

HGM9600 Series Genset Controller User Manual Page 10 of 73
maintenance time out;
♦All parameters use digital adjustment, instead of conventional analog modulation with normal
potentiometer, improving reliability and stability;
♦Waterproof security level IP55 due to rubber seal installed between the controller enclosure and
panel fascia;
♦Metal fixing clips enable perfect performance in high temperature environment;
♦Modular design, anti-flaming ABS enclosure, pluggable connection terminals and embedded
installation way; compact structure with easy mounting.

HGM9600 Series Genset Controller User Manual Page 11 of 73
4SPECIFICATION
Table 4 Technical Parameters
Items
Contents
Operating Voltage
DC8.0V to DC35.0V, Continuous Power Supply
Power Consumption
<4W (standby ≤2W)
Alternator Input Range
3-Phase 4-Wire
3-Phase 3-Wire
Single-Phase 2-Wire
2-Phase 3-Wire
AC15V - AC360V (ph-N)
AC30V - AC620V (ph-ph)
AC15V - AC360V (ph-N)
AC15V - AC360V (ph-N)
Alternator Frequency
50Hz /60Hz
Speed Sensor Voltage
1.0V to 24.0V (RMS)
Speed Sensor Frequency
10,000 Hz (max.)
Start Relay Output
16A DC28V at supply output
Fuel Relay Output
16A DC28V at supply output
Programmable Relay Output (1)
7A DC28V at supply output
Programmable Relay Output (2)
7A DC28V at supply output
Programmable Relay Output (3)
7A DC28V at supply output
Programmable Relay Output (4)
7A AC250V voltage free output
Programmable Relay Output (5)
7A AC250V voltage free output
Programmable Relay Output (6)
7A AC250V voltage free output
Case Dimension
266mm x182mm x45mm
Panel Cutout
214mm x160mm
C.T. Secondary
5A rated
Working Temperature
(-25~+70)°C
Working Humidity
(20~93)%RH
Storage Temperature
(-25~+70)°C
Protection Level
IP55 Gasket
Insulating Intensity
Apply AC2.2kV voltage between high voltage terminal and low
voltage terminal;
The leakage current is not more than 3mA within 1min.
Weight
0.95kg

HGM9600 Series Genset Controller User Manual Page 12 of 73
5OPERATION
5.1 INDICATOR LIGHT
Fig.1 HGM9610 Front Panel
Fig.2 HGM9620 Front Panel

HGM9600 Series Genset Controller User Manual Page 13 of 73
NOTE: Selected light indicators description:
Table 5 Warning and Alarm Indicator
Alarm Type
Warning Indicator
Alarm Indicator
Warning
Slow flashing
Slow flashing
Trip Alarm
Slow flashing
Slow flashing
Shutdown Alarm
Off
Fast flashing
Trip and Stop Alarm
Off
Fast flashing
Running indicator: illuminated from crank disconnect to ETS while off during other periods.
Gen normal indicator: It is light on when generator is normal; flashing when generator state is abnormal;
off when there is no generator power.
Mains normal indicator: It is light on when mains is normal; flashing when mains state is abnormal; off
when there is no mains power.

HGM9600 Series Genset Controller User Manual Page 14 of 73
5.2 KEY FUNCTIONS
Table 6 Key Function Description
Icon
Key
Function Description
Stop
Stop running genset in Auto/Manual mode; Lamp test (press
at least 3 seconds); Reset alarm in stop mode; During stopping
process, press it again to stop genset immediately.
Start
Start genset in Manual mode.
Manual Mode
Press it and controller enters Manual mode.
Auto Mode
Press it and controller enters Auto mode.
Mute/Reset Alarm
Alarming sound off; If there is trip alarm, pressing the button
at least 3 seconds can reset this alarm.
Gen Close/Open
Control gen close/open in manual mode. (unavailable for
HGM9610)
Mains Close/Open
Control mains close/open in manual mode. (unavailable for
HGM9610)
Close
Control close breaker in manual mode. (unavailable for
HGM9620)
Open
Control open breaker in manual mode. (unavailable for
HGM9620)
Up/Increase
1) Screen scroll;
2) Up cursor and increase value in setting menu.
Down/Decrease
1) Screen scroll;
2) Down cursor and decrease value in setting menu.
Left
1) Page scroll;
2) Left move cursor in setting menu.
Right
1) Page scroll;
2) Right move cursor in setting menu.
Set/Confirm
1) Select viewing area;
2) Press it over 3s can enter parameter setting;
3) Confirm setting information.
Exit
1) Return to main menu;
2) Return to previous menu in setting menu.
NOTE: In manual mode, pressing and simultaneously will force generator to crank. Successful
start will not be judged according to crank disconnect conditions, operator will have to crank the starter motor manually;

HGM9600 Series Genset Controller User Manual Page 15 of 73
when operator decides that the engine has fired, he/she should release the button and start output will be deactivated,
safety on delay will start.
CAUTION: Default password is 00318, user can change it in case of others change the advanced parameters setting.
Please clearly remember the password after changing. If you forget it, please contact SmartGen services and send all
information in the controller page of “ABOUT”to us.
5.3 LCD DISPLAY
5.3.1 MAIN DISPLAY
Main screen show pages; use to scroll the pages and to scroll the screen.
★Main Screen, including as below,
Gen: voltage, frequency, current, active power, reactive power
Bus: voltage, frequency
Engine: speed
Some status.
★Status, including as below,
Status of genset, mains, and ATS.
NOTE: HGM9610 has no mains status screen.
★Engine, including as below,
Speed, temperature of engine, engine oil pressure, (fuel) level, configure sensor 1, configure sensor 2,
battery voltage, charger voltage, accumulated run time, accumulated start times.
NOTE: If connected with J1939 engine via CANBUS port, this page also includes: coolant pressure, coolant level, fuel
temperature, fuel pressure, inlet temperature, exhaust temperature, turbo pressure, total fuel consumption and so on.
(Different engine with different parameters)
★Gen, including as below,
Phase voltage, Line voltage, frequency, phase sequence.
★Mains, including as below,
Phase voltage, Line voltage, frequency, phase sequence.
NOTE: HGM9610 has no this page.
★Load, including as below,
Current, each phase and total active power (positive and negative), each phase and total reactive power
(positive and negative), each phase and total apparent power, each phase and average power factor
(positive and negative), accumulated energy (kWh, kvarh, kVAh) and earth current.
NOTE: When only mains switch on indicator lights, count active and inactive power, apparent power, power factor, but
accumulate electric energy. Counting the generator active and reactive power, apparent power, power factor, and accumulate
electric energy under other conditions.

HGM9600 Series Genset Controller User Manual Page 16 of 73
NOTE: Power factor shows as following,
Remark:
P stands for active power
Q stands for reactive power
Table 7 Power Factor Description
NOTE:
1. Input active power, generator or mains supplies electricity to load.
2. Output active power, load supplies electricity to generator or mains.
3. Input reactive power, generator or mains sends reactive power to load.
4. Output reactive power, load sends reactive power to generator or mains.
★Alarm:
NOTE: For ECU alarms and shutdown alarms, if the alarm information is displayed, check engine according to it,
otherwise, please check the manual of engine according to SPN alarm code.
◙Event log
Records all start/stop events (shutdown alarm, trip and shutdown alarm, manual /auto start or stop) and
the real time when alarm occurs.
Others, including,
Time and date, count down time for maintenance (if it is enable), input/output ports status, NET status and
SD status.
◙About, including,
Issue time of software and hardware version, product PD number.
5.3.2 USER MENU AND PARAMETERS SETTING
Press and hold for more than 3 seconds to enter user menu;
★Parameter
After entering the correct password (factory default password is 00318) you can enter parameter
Power factor
Conditions
Active power
Reactive power
Remark
COS>0L
P>0,Q>0
Input
Input
Load is inductive resistance.
COS>0C
P>0,Q<0
Input
Output
Load is capacitance resistance.
COS<0L
P<0,Q>0
Output
Input
Load equals to one under
excitation generator
COS<0C
P<0,Q<0
Output
Output
Load equals to one over
excitation generator.

HGM9600 Series Genset Controller User Manual Page 17 of 73
settings screen.
★Language
Selectable Chinese, English and others (default: Espanol)
★Commissioning
On load, off load or custom commissioning can be chosen. Custom commissioning can configure on
load or not during commissioning, when to commissioning and select the mode after commissioning
(manual mode, auto mode and stop mode).
★Clear users’ accumulation
Can clear total run time A and B, total electric energy A and B.
Parameter setting Including as following,
★Mains settings
★Timer settings
★Engine settings
★Generator settings
★Load settings
★Switch settings
★Analog sensor settings
★Input port settings
★output port settings
★Module settings
★Scheduling and maintenance settings
★GSM settings
Example,
Return
Mains
> Start Delay
> Return Delay
> Preheat Delay
> Cranking Time
> Crank Rest Time
> Safety On Time
> Start Idle Time
> Warming Up Time
> Cooling Time
> Stop Idle Time
> ETS Hold Time
> Wait Stop Time
Form 1:
Use to scroll settings, to enter
settings (form 2), to exit settings menu.
Timers >
Engine
Generator
Load
Switch
Temp. Sensor
OP Sensor
Level Sensor
Config. Sensor 1
Config. Sensor 2

HGM9600 Series Genset Controller User Manual Page 18 of 73
Return
Mains
> Start Delay
Form 2:
Use to scroll settings, to enter
settings (form 3), to return to previous menu.
(form 1).
> Return Delay
> Preheat Delay
> Cranking Time
> Crank Rest Time
> Safety On Time
> Start Idle Time
> Warming Up Time
> Cooling Time
> Stop Idle Time
> ETS Hold Time
> Wait Stop Time
Timers >
Engine
Generator
Load
Switch
Temp. Sensor
OP Sensor
Level Sensor
Config. Sensor 1
Config. Sensor 2
Return
Mains
> Start Delay
> Return Delay
> Preheat Delay
Form 3:
Use to scroll settings, to enter
settings (form 4), to return to previous menu.
(form 1).
Timers >
Engine
Generator
Load
Switch
Temp. Sensor
OP Sensor
Level Sensor
Config. Sensor 1
Config. Sensor 2
> Cranking Time
> Crank Rest Time
> Safety On Time
> Start Idle Time
> Warming Up Time
> Cooling Time
> Stop Idle Time
> ETS Hold Time
> Wait Stop Time
> Start Delay
> Return Delay
> Preheat Delay
00008
Form 4:
Press to enter settings (form 5), to return
to previous menu. (form 6).
>Cranking Time
> Crank Rest Time
> Safety On Time
> Start Idle Time
> Warming Up Time
> Cooling Time
> Stop Idle Time
> ETS Hold Time
> Wait Stop Time

HGM9600 Series Genset Controller User Manual Page 19 of 73
> Start Delay
> Return Delay
> Preheat Delay
00008
Form 5:
Press to change cursor position,
are used for changing cursor value, Confirm
setting (form 4), exit setting (form 4).
>Cranking Time
> Crank Rest Time
> Safety On Time
> Start Idle Time
> Warming Up Time
> Cooling Time
> Stop Idle Time
> ETS Hold Time
> Wait Stop Time
> Start Delay
> Return Delay
> Preheat Delay
00008
Form 6:
are used for changing the setting
contents. Confirm setting (form 4), to
return to previous menu. (form 1).
>Cranking Time
> Crank Rest Time
> Safety On Time
> Start Idle Time
> Warming Up Time
> Cooling Time
> Stop Idle Time
> ETS Hold Time
> Wait For Stop
NOTE: Pressing can exit setting directly during configuration.
5.4 AUTO START/STOP OPERATION
Press , its indicator lights, and controller enters Auto mode.
Starting Sequence,
1. HGM9620: When mains power is abnormal (over and under voltage, over and under frequency, loss of
phase, phase sequence wrong), it enters mains “abnormal delay” and LCD display count down time.
When mains abnormal delay is over, it enters into “start delay”; it also enters this mode when “remote
start on load” is active.
2. HGM9610: Generator enters “start delay” as soon as “remote start on load” is active.
3. Start Delay timer is shown on Status page of LCD.
4. When start delay is over, preheat relay outputs (if this be configured), “preheat start
delay XX s” is shown at the bottom line of LCD.
5. When preheat delay is over, fuel relay outputs 1s and then start relay output; if engine crank fails

HGM9600 Series Genset Controller User Manual Page 20 of 73
during “cranking time”, the fuel relay and start relay deactivated and enter “crank rest time” to wait for
next crank.
6. If engine crank fails within setting times, the controller sends Fail to Start signal and Fail to Start
message appears on LCD alarm page.
7. In case of successful crank attempt, “safety on timer” starts. During this period, low oil pressure, high
water temperature, under speed, charge failure alarms are disabled. As soon as this delay is over,
“start idle delay” is initiated (if configured).
8. During “start idle delay”, under speed, under frequency, under voltage alarms are inhibited. When this
delay is over, “warming up delay” starts (if configured).
9. When “warming up delay” is over, if generator state is normal, its indicator will be illuminated. If
voltage and frequency has reached on-load requirements, the closing relay will be energized,
generator will accept load, generator power indicator will turn on, and generator will enter Normal
Running state; if voltage and frequency are abnormal, the controller will initiate alarm (alarm type will
be displayed on LCD alarm page).
NOTE: In case of “Remote Start (off Load)”, the procedure is the same, except for step NO. 9: the closing relay will NOT
be energized, generator will NOT accept load.
Stopping Sequence:
1. HGM9620: When mains return normal during gen-set running, it enters mains voltage “normal delay”.
When mains normal delay is over, enter “stop delay”; also can be into this mode when “remote start on
load” is inactive.
2. HGM9610: Generator enters “stop delay” as soon as “remote start on load” is inactive.
3. When stop delay is over, close generator relay is un-energized; generator enters into “cooling down
time”. After “transfer rest time”, close mains relay is energized. Generator indicator extinguish while
mains indicator lights.
4. Idle relay is energized as soon as entering “stop idle delay”.
5. If enter “ETS hold delay”, ETS relay is energized. Fuel relay is deactivated and decides whether
generator is stopped or not automatically.
6. Then enter gen-set “Fail to stop time”, auto decides whether generator is stopped or not
automatically.
7. Enter “after stop time” (if configured) as soon as generator stops. Otherwise, controller will send “Fail
to Stop” alarm. (If gen-set stopped successfully after warning of “Fail to Stop”, it will enter “after stop
time” and remove alarm)
8. Enter “generator at rest” as soon as “after stop time” is over.
