Operation Manual
Refrigerant Type Thermo-cooler
HRGC001-A ∗
∗∗
∗ HRGC001-W ∗
∗∗
∗
HRGC002-A ∗
∗∗
∗ HRGC002-W ∗
∗∗
∗
HRGC005-A ∗
∗∗
∗ HRGC005-W ∗
∗∗
∗
SMC Corporation
Keep this manual available whenever necessary.
© 2007 SMC CORPORATIO All Rights Reserved

To users
Thank you for purchasing SMC’s Thermo cooler (hereinafter referred to as “unit”).
For safety and long life of the unit, be sure to read this operation manual (hereinafter referred to as
“manual”) and clearly understand the contents.
• Be sure to read and follow all instructions noted with “Warning” or “Caution” in this manual.
• This manual is intended to explain the installation and operation of the unit. Only the person who
understands basic operation of the unit through this manual or who performs installation and operation
of or has basic knowledge about industrial machines is allowed to work on the unit.
• This manual attached to the unit and its contents will not be a part of contract and accompany
modification or change of existing agreement, commitment or relation.
• It is strictly prohibited to copy this manual entirely or partially for the use by the third party without prior
permission from SMC.
Note This manual is subject to possible change without prior notice.

HRX-OM-L014
Error! Style not defined.
HRGC001-A HRGC002-A HRGC005-A
1
st
edition : Jun. 2007
Contents
Chapter 1 Safety Instructions .............................................................. 1
1.1 Before using unit.........................................................................................................1
1.2 Reading the Manual ....................................................................................................1
1.3 Hazards ........................................................................................................................2
1.3.1 Level of hazards ......................................................................................................................2
1.3.2 Definition of “Serious injury” and “Light injury” ........................................................................2
1.3.3 Types of hazard labels ............................................................................................................3
1.3.4 Locations of Hazard Labels.....................................................................................................4
1.4 Other Labels ................................................................................................................6
1.4.1 Product Label ..........................................................................................................................6
1.5 Safety Measures..........................................................................................................6
1.5.1 Safety Instructions for Use ......................................................................................................6
1.5.2 Personal Protective Equipment...............................................................................................7
1.6 Emergency Measures..................................................................................................8
1.7 Disposal of waste ........................................................................................................9
1.7.1 Recovery of refrigerant and compressor oil ............................................................................9
1.7.2 Discarding the unit...................................................................................................................9
1.8 Material Safety Data Sheet (MSDS) ............................................................................9
Chapter 2 Name and Function of Parts............................................... 1
2.1 HRGC001-A∗
∗∗
∗,HRGC002-A∗
∗∗
∗,HRGC001-W∗
∗∗
∗ and HRGC002-W∗
∗∗
∗.......................................1
2.2 HRGC005-A∗
∗∗
∗ and HRGC005-W∗
∗∗
∗.....................................................................................2
Chapter 3 Transport and Setting Up.................................................... 1
3.1 Transport......................................................................................................................1
3.2 Installation ...................................................................................................................3
3.2.1 Environment ............................................................................................................................3
3.2.2 Location ...................................................................................................................................4
3.2.3 Installation and Maintenance Space .......................................................................................5
3.3 Setting Up ....................................................................................................................6
3.3.1 Installation ...............................................................................................................................6
3.3.2 Electrical wiring .......................................................................................................................7
3.3.3 Piping.....................................................................................................................................10
3.3.4 Supply of recirculating fluid ...................................................................................................12
3.3.5 Reinstallation of the unit ........................................................................................................13
Chapter 4 Starting the Unit .................................................................. 1
4.1 Before Starting. ...........................................................................................................1
4.1.1 Setting up conditions ...............................................................................................................1

HRX-OM-L014
Error! Style not defined.
HRGC001-A HRGC002-A HRGC005-A
1
st
edition : Jun. 2007
4.1.2 Connection of cables .............................................................................................................. 1
4.1.3 Circulating fluid ....................................................................................................................... 1
4.1.4 Facility water piping (only for HRGC00∗-W)........................................................................... 1
4.1.5 Liquid level indicator (for tank)................................................................................................ 1
4.2 Opening of facility water valve (only for HRGC00∗
∗∗
∗-W)............................................. 1
4.3 Preparation for Start ................................................................................................... 2
4.3.1 Power supply .......................................................................................................................... 2
4.3.2 Setting of recirculating fluid temperature ................................................................................ 3
4.3.3 Refill of recirculating fluid........................................................................................................ 4
4.4 Starting and Stopping................................................................................................. 6
4.4.1 Starting the unit....................................................................................................................... 6
4.4.2 Stopping the unit ..................................................................................................................... 6
4.5 Check Items After Starting.......................................................................................... 7
4.6 Adjustment of Recirculating Fluid ............................................................................. 7
Chapter 5 Operation............................................................................. 8
5.1 Operation panel........................................................................................................... 8
Chapter 6 Error Display and Remedy ................................................. 1
6.1 Error Display ...............................................................................................................1
6.2 Remedy for Error ........................................................................................................3
6.3 How to Reset Alarm .................................................................................................... 4
6.3.1 Reset by using [RESET] button.............................................................................................. 4
6.3.2 Reset of pump overload (AL02) and compressor overload (AL03) ........................................ 5
6.4 Other Errors ................................................................................................................7
Chapter 7 Control, Inspection and Cleaning ...................................... 1
7.1 Control of Recirculating Fluid Quality.......................................................................1
7.2 Inspection and Cleaning............................................................................................. 2
7.2.1 Daily check ............................................................................................................................. 2
7.2.2 Monthly check ......................................................................................................................... 3
7.2.3 Inspection every 3 months...................................................................................................... 3
7.2.4 Inspection every 6 months...................................................................................................... 4
7.2.5 Inspection for winter seaon..................................................................................................... 4
7.3 Consumables .............................................................................................................. 5
7.4 Stop for a Long Time ..................................................................................................5
Chapter 8 Documents .......................................................................... 1
8.1 Specifications List ......................................................................................................1
8.2 Outline Dimensions .................................................................................................... 2
8.2.1 HRGC001-A∗ and HRGC002-A∗............................................................................................ 2
8.2.2 HRGC001-W∗ and HRGC002-W∗.......................................................................................... 2
8.2.3 HRGC005-A∗.......................................................................................................................... 3
8.2.4 HRGC005-W∗......................................................................................................................... 3

HRX-OM-L014
Error! Style not defined.
HRGC001-A HRGC002-A HRGC005-A
1
st
edition : Jun. 2007
8.3 Electric Circuit Diagram..............................................................................................4
8.3.1 HRGC001-A∗, HRGC002-A∗, HRGC001-W∗ and HRGC002-W∗........................................4
8.3.2 HRGC005-A∗ and HRGC005-W∗...........................................................................................5
8.4 Flow Chart (HRGC00∗
∗∗
∗-A) ............................................................................................6
8.5 Flow Chart (HRGC00∗
∗∗
∗-W)............................................................................................7
8.6 Applicable Regulations...............................................................................................8
8.7 Daily Check Sheet .......................................................................................................9
Chapter 9 Product Warranty ................................................................ 1

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
HRGC001-A HRGC002-A HRGC005-A Error! Style not defined..Error! Style not defined.
1
st
edition : Jun. 2007
Error! Style not defined.-1
Chapter 1 Safety Instructions
1.1 Before using unit

This chapter is intended to specifically describe the safety related issues
for handling the unit.

The unit is a cooling device using recirculating fluid. SMC does not take
any responsibility for any problems that may arise from using the unit for
other purposes.

This product is for the indoor use and not available outdoor.

This product is not designed for a clean room. It generates dust from the
internal components such as pump and fan motor (for air-cooled type).

The unit is operating at high voltage and contains components which
become hot and rotate. If a component needs to be replaced or repaired,
contact a specific vendor for parts and service.

The operate’s, maintence personnel and other people working nearby the
unit should read and understand the safety related descriptions in this
manual carefully before starting work.

Safety manager is responsible to strictly observe safety standards, but
responsibility in respect to safety standard during daily work resides with
each individual operator and personnel for maintainance.

This manual must be kept available to operator’s whenever necessary..
1.2 Reading the Manual
This manual contains symbols to help identify important actions when
installing, operating or maintain the unit.
• Symbols for important Actions
Read most critical instruction to be considered carefully and ensure well understanding of the
content before operating the unit
This sign stands for actions that must be followed.
This sign stands for prohibited actions.

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
Error! Style not defined.Error! Style not defined. HRGC001-A HRGC002-A HRGC005-A
1
st
edition : Jun. 2007
Error! Style not defined.-2
1.3 Hazards
1.3.1 Level of hazards
The instructions given in this manual aim to assure safe and correct
operation of the unit and to prevent injury of operators or damage to the unit.
These instructions are grouped into three categories, Danger, Warning and
Caution, which indicate the level of hazard, damage and also the degree of
emergency. All texts that contain safety critical matter and should be
carefully observed.
DA GER, WAR I G and CAUTIO signs are in order according to
seriousness (DA GER> WAR I G> CAUTIO ).
1.3.2 Definition of “Serious injury” and “Light injury”
 “Serious injury”
The injury that gives aftereffects including loss of eyesight, burnt, electrical
shock, fracture, poisoning, etc. and requires long-term treatment or
hospitalization.
 “Light injury”
The injury that does not need long term treatment or hospitalization. (Others
excluded from serious injury.)
“
W
ARNING”
Hazard that may cause serious personal injury or death during
operation.
“CAUTION” Hazard that may cause minor personal injury.
“CAUTION without exclamation symbol” Hazard that may cause damage or failure
of the unit, facility, ect.
“
D
ANGER”
Hazard that will cause serious personal injury or death during
operation.

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
HRGC001-A HRGC002-A HRGC005-A Error! Style not defined..Error! Style not defined.
1
st
edition : Jun. 2007
Error! Style not defined.-3
1.3.3 Types of hazard labels
The unit has various potential hazards and they are marked with warning
labels. Be sure the read this section before starting any work on the unit.
 Warning related to electricity
 Warning related to high temperatures
 Warning related to rotating objects
 Warning related to other general dangers
This symbol stands for a possible risk of electric shock.
The unit is operated at high voltage and contains uncovered live
terminals inside.
 DO NOT operate the unit without cover panels fitted
 DO NOT work inside this unit unless you have been trained to do so.

This symbol stands for a possible risk of cutting fingers or hand, or
entanglement by rotating fan.
The unit has a cooling fan that rotates during operation
of the unit. The
fan can start and stop intermittantly and without warning.
 DO NOT operate the unit without cover panels fitted.
This symbol stands for a possible risk of burn or hot surface.
The unit has surfaces that can reach high temperatures during
operation. Even after the power is turned off, there can still be
residual
heat in the unit.
 DO NOT operate the unit without cover panels fitted.
 DO NOT start working inside the unit until the temperature has
decreased sufficiently.
This symbol stands for general danger.
On the unit this symbol has different meanings.
1. Hazards Inside
Hot Surfaces Inside – See Hot Surface symbol
Rotating Fan Inside – See Rotating Fan symbol
Pressurized Sytem Inside – The unit
contains pressurised fluid
systems.
 DO NOT operate the unit without cover panels fitted.
2. Lifting Hazard
Lifting the unit from eyebolts can be dangerous
 DO NOT lift the unit without having read the manual.

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
Error! Style not defined.Error! Style not defined. HRGC001-A HRGC002-A HRGC005-A
1
st
edition : Jun. 2007
Error! Style not defined.-4
1.3.4 Locations of Hazard Labels
There are various warning labels on the unit to show the dangers.
 Sign for warning related to heat
Fig. 1-1 Warning label position (HRGC001-∗ and HRGC002-∗)
Fig. 1-2 Warning label position (HRGC001-∗ and HRGC002-∗)
Front
(Hazards Inside)
Rear
(Hazards Inside)
(only for HRGC00
∗
-A-
∗)

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
HRGC001-A HRGC002-A HRGC005-A Error! Style not defined..Error! Style not defined.
1
st
edition : Jun. 2007
Error! Style not defined.-5
Fig. 1-3 Warning label position (HRGC005-∗)
Fig. 1-4 Warning label position (HRGC005-∗)
Rear
(Hazards Inside)
(only for HRGC005-A
∗
)
Front
(Hazards Inside)
（Hanging warning）
1.3 Hazard

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
Error! Style not defined.Error! Style not defined. HRGC001-A HRGC002-A HRGC005-A
1
st
edition : Jun. 2007
Error! Style not defined.-6
1.4 Other Labels
1.4.1 Product Label
When contacting SMC's sales distributor, inform them of serial number
(SERIAL o.) and model number (MODEL o.) of the unit. They are
described on the product label shown below.
Fig. 1-5 Position of product label
1.5 Safety Measures
1.5.1 Safety Instructions for Use

Read and undestand this manual carefully before using the unit.

Before starting maintenance of the unit, be sure to lock out and tag out
the breaker of user's power supply.

If operating the unit during maintenance, be sure to inform all workers
nearby.

Use only the correct tools and procedure when installing or maintaning
the unit.

Use personal protective equipment where specified (“1.5.2 Personal
Protective Equipment”).

Check all parts and screws are fitted correctly and securely after
maintenance.

Avoid working in a drunken or sick condition, which might cause an
accident.

Do not remove the panels except for the cases permitted in this manual.

Do not remove the panels during operation.
Front
Serial umber (SERIAL o.)
Model umber (MODEL o.）
The type and quantity of freon
(REFRIGERA T)
Follow
the instructions below when using the unit. Failure to follow
might cause an accident and injury.

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
HRGC001-A HRGC002-A HRGC005-A Error! Style not defined..Error! Style not defined.
1
st
edition : Jun. 2007
Error! Style not defined.-7
1.5.2 Personal Protective Equipment
This manual specifies personal protective equipment for each work.
 Transport, Setting up and Removal
 Handling of recirculating fluid
 Operation
Always u
se safety shoes, gloves and head protection when
transporting, installing or removing the unit.
Always use safety shoes, gloves, mask, apron and eye protection
when handling the recirculating fluid.
Always use safety shoes and gloves when operating the unit.

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
Error! Style not defined.Error! Style not defined. HRGC001-A HRGC002-A HRGC005-A
1
st
edition : Jun. 2007
Error! Style not defined.-8
1.6 Emergency Measures
When emergency conditions such as natural disaster, fire and earthquake,
or injury occurs, turn off the power supply. The switch for the power supply
is located at the front of the unit.
Press the switch for the power supply at the front of unit to stop the operation of the unit.
Fig. 1-6 Location of the switch for the power supply
Front
OFF
Even when the power supply is turned off, the power circuit keeps
energized partically unless the user’s power supply is shut off. Be
sure to shut off the breaker of user’s power supply.

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
HRGC001-A HRGC002-A HRGC005-A Error! Style not defined..Error! Style not defined.
1
st
edition : Jun. 2007
Error! Style not defined.-9
1.7 Note for disposal
1.7.1 Recovery of refrigerant and compressor oil
The unit uses freon type refrigerant (HFC) and compressor oil. Comply with
the law and regulation in each region for the disposal of compressor oil. The
type and quantity of freon is described on the product label. (Ref. P1-6)
If these fluids need to be recovered, read and understand the instructions
below carefully. If there is any unclear point, contact an SMC's sales
distributor.
1.7.2 Discarding the unit
When discarding the unit, follow all waste disposal regulations within the
country of disposal.
1.8 Material Safety Data Sheet (MSDS)
If the material safety data sheets of chemicals used in this unit are needed,
contact an SMC's sales distributor.
Any chemicals used by the user must be accompanied by an MSDS.

Only service personnel or qualified people are allowed to open the
cover panels of the unit.

Do not mix the compressor oil with domestic waste for disposal.
Also, the incineration of the waste must only be conducted by
specific facilities that are permitted for that purpose.

Comply
with
the law and regulation in each region for the
disposal
of compressor oil.
 The release of refrigerant in to atmosphere is banned by law.
Recover it with specific equipment and dispose of it correctly.
 Only persons
who has sufficient knowledge and experience about
the unit and its accessories are allowed to recover the refrigerant
and compressor oil.

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
HRGC001-A HRGC002-A HRGC005-A Error! Style not defined.Error! Style not defined.
1
st
edition : Jun. 2007
Error! Style not defined.-1
Chapter 2 Name and Function of Parts
2.1 HRGC001-A∗
∗∗
∗,HRGC002-A∗
∗∗
∗,HRGC001-W∗
∗∗
∗ and HRGC002-W∗
∗∗
∗
Fig. 2-1-1 Port (HRGC001-A∗,HRGC002-A∗)
図 2-1-2 Port (HRGC001-W∗,HRGC002-W∗）
Left
Air vent OUT
Signal cable entry
(Grommet)
Power supply
cable entry
(
G
rommet)
Back
Drain port
Rc1/4
Manual bypass
valve
Recirculating fluid
Supply Rc1/2
Right
Recirculating fluid
Return Rc1/2
Tank level indicator
Operation panel
Control box
（
panel internal）
Tank lid
top Overflow port
Rc1/2
Air vent I Air vent OUT Air vent OUT
Front
Cooling water
outlet Rc1/2
Cooling water
Inlet Rc1/2
Left
Signal cable entry
(Grommet)
Power supply
cable entry
(Grommet)
Back
Drain port
Rc1/4
Manual bypass
valve
Recirculating fluid
Supply Rc1/2
Right
Recirculating fluid
Return Rc1/2
Tank level indicator
Operation panel
Control box
(panel internal)
Tank lid
top
Overflow port
Rc1/2
Front

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
Error! Style not defined.Error! Style not defined. HRGC001-A HRGC002-A HRGC005-A
1
st
edition : Jun. 2007
Error! Style not defined.-2
2.2 HRGC005-A ∗
∗∗
∗ and HRGC005-W ∗
∗∗
∗
Fig. 2-2-1 Port (HRGC005-A)
Fig. 2-2-2 Port (HRGC005-W)
Top
Front Left Right
Tank level indicator
Operation panel
Control box
(panel internal)
Tank lid
Air vent I
Power supply cable entry
(Grommet)
Signal cable entry
(Grommet)
Drain port
Rc1/2
Recirculating fluid
Return Rc1/2
Manual bypass
valve
Recirculating fluid
Supply Rc1/2
Back
Air vent OUT Air vent OUT
Eye bolt M12 (accessory)
Overflow port
Rc1/2
Front
Left
Control box
(panel internal)
Power supply cable entry
(Grommet)
Top
Right
Tank level indicator
Operation panel
Tank lid
Drain port
Rc1/2
Recirculating fluid
Return Rc1/2
Manual bypass
valve
Recirculating fluid
Supply Rc1/2
Eye bolt M12 (accessory)
Overflow port
Rc1/2
Back
Signal cable entry
(Grommet)
Cooling water
outlet Rc1/2
Cooling water
inlet Rc1/2

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
HRGC001-A HRGC002-A HRGC005-A Error! Style not defined.Error! Style not defined.
1
st
edition : Jun. 2007
Error! Style not defined.-1
Chapter 3 Transport and Setting Up
3.1 Transport
The unit is heavy and has potential danger at transport. Also, to prevent
damage and breakage of the unit, be sure to follow these instructions for
transport.

Only person
s
who
have
sufficient knowledge and experience
about the unit and system are allowed to transport and set up the
unit.
 Especially pay attention to personal safety.

If a fork lift is used for transport, check the fork is inserted in place
as specified in Fig. 3-1 “Fork insertion position and hanging
method”. At that time, do not get the fork contact to the caster.
 If eyebolt is used for lifting, ensure all four eyebolts are used.
 Keep hanging angle from each eyebolt 45° to 60
o
with attention to
the postion of the center of gravity.
Never lay down the unit.
The compressor oil leaks out to the refrigerant piping and its amount
decreases, which might cause early compressor failure.

Drain the residual fluid from the piping as much as possible to
prevent any spillage.
 If a fork lift is used for transport, pay attention not to damage the
unit with the forks.

HRX-OM-L014
Error! Style not defined. Error! Style not defined.
Error! Style not defined.Error! Style not defined. HRGC001-A HRGC002-A HRGC005-A
1
st
edition : Jun. 2007
Error! Style not defined.-2
Fig. 3-1 Fork insertion position and hanging method
Fork insertion position Fork insertion position
Fork insertion position Fork insertion position
Hanging position (only for HRGC005-
∗
)
Approx. 60
o
Approx. 60
o
Center of gravity of HRGC005-
∗
