SMC Networks VP Series User manual

3 Port Solenoid Valve/
Residual Pressure Release Valve
with Detection of Main Valve Position
Residual pressure
release valve
Residual pressure
release valve qResidual pressure
release valve q
Residual pressure
release valve w
Residual pressure
release valve w
Safety limit switch
Safety limit
switch
With Detection of
Main Valve Position
The detecting function of the main valve position detects a
mismatch between the input signal and valve operation.
Redundant system can be
constructed easily.
Redundant System
A system in which even if one part fails, the whole system
will fulfill its required function. This is usually achieved by
having dual channels of operation, such as dual valves, dual
wiring, dual guard switches etc.
VP542-X536/VP742-X536
Soft start-up
valve
Safety Standard ISO 13849-1 Certified∗2(Corresponding to Category 2 to 4)
Category 2
Category 3, 4
Dual Residual Pressure Release Valve
VP544-X538/VP744-X538
With Soft Start-up Function
VP544-X555/VP744-X555 (0.7 MPa)
VP544-X585/VP744-X585 (1.0 MPa)
Dual Residual Pressure Release Valve
VG342-X87
When the dual residual pressure release valve is
used, if one of the valves fails to operate, the
other one releases residual pressure.
SeriesVP/VG
CAT.EUS11-111Aa-UK
RoHS
∗1. Refer to page 2 for
compliant products.
∗2. Refer to page 2 for certified products.
®
∗1
New
New

2(A)
3
(
R
)
3
(
R
)
1(P)
P1
P2
Throttle Main valve Valve 1 Valve 2
Soft start-up
valve
Safety limit
switch
Safety limit
switch
Soft start-up
valve
Made by Rockwell Automation Made by OMRON
Soft start-up valve: ON
Valve 1, Valve 2: ON
Output pressure P2
Time
P1
1/2P 1
0
Soft start-up valve: OFF
Valve 1, Valve 2: ON
P 2 reaches half of P 1 , and
then the main valve of the
soft start-up valve turns on.
Start supplying flow ad-
justed air with the throt-
tle by energising valve
1 and valve 2.
Output Pressure (P2) vs Time Graph
The detecting function of the main valve position detects a
mismatch between the input signal and valve operation.
Category 2 Safety function can be accomplished by single channel and is automatically
checked.
Category 3 It has redundancy so there is no loss of safety function with a single failure.
The safety function must be checked before each use. An accumulation of
undetected faults can cause loss of safety function.
Category 4
It has redundancy so there is no loss of safety function with a single failure. The
safety function must be checked before each use. An accumulation of undetected
faults does not affect the safety function. (Higher DC and MTTFd than Category 3.)
Residual pressure release valve
With Detection of Main Valve Position (Category 2)
Input equipment (I): Detection equipment (sensor) of starting event
Logical operation equipment (L): Relay sequence circuit, PLC control program
Output equipment (O):
Solenoid valve, Electromagnetic switch, Output relay
Recommended valve: VP542/742-X536
Input equipment (I1, I2): Detection equipment (sensor) of starting event
Logical operation equipment (L1, L2): Relay sequence circuit, PLC control program
Output equipment (O1, O2):
Solenoid valve, Electromagnetic switch, Output relay
Recommended valve: VP544/744-X538, VG342-X87
Output signal
Monitoring
Output signal
Input signal
I
Input equipment
O
Output equipment
OTE
Output of test result
L
Logical operation
equipment
TE
Testing equipment
When the dual residual pressure release valve is used, if one of the
valves fails to operate, the other one releases residual pressure.
Redundant system can be constructed easily. (Category 3, 4)
Output signal
Output signal
Monitoring
Monitoring
Cross monitoring
Input signal
Input signal
I1
Input equipment
I2
Input equipment
O1
Output equipment
O2
Output equipment
L1
Logical operation
equipment
L2
Logical operation
equipment
With soft start-up function (-X555/X585)
Safety limit switch can be selected.
Safety limit switch
Main valve Rod
VP544-X538
VP542-X536
Residual pressure release valve w
∗This product is component which is a part of a safety system and safety equipment is not guaranteed by this single unit alone.
VP544-X555
VP544-X585
Residual pressure
release valve q
쐌
A function to gradually increase the initial pressure
of the pneumatic system has been added to the dual
residual pressure release valve.
쐌
Fixed orifice and variable throttle are available as a throttle
for adjusting the pressure increase. (Ø 1, Ø 1.5,
Ø 2)
Conduit (VP series only) and
M12 connector (4 pin) types
are available.
M12 connector with 6 pins is
available.
qThe main valve position is detected by transferring the
main valve movement directly to the reed safety limit switch
with the rod.
wLong service life: B10d: 10 million times∗
eThe return spring releases the residual pressure securely
regardless of pressure level.
∗For VP첸-X536/X538/X555, safety limit switch made by OMRON
Highly reliable construction
1
3 Port Solenoid Valve/Residual Pressure Release Valve with Detection of Main Valve Position Series VP/VG
Safety Standard ISO 13849-1 Certified

For details about Safety Standard
ISO 13849-1, refer to “machinery
directive 2006/421EC. Safety
control system standard EN ISO
13849-1” on the SMC website
www.smc.eu.
Series Category Port
size Thread
Flow rate characteristics
C [dm3/(s·bar)]/Q [l/min (ANR)]∗1씮2 (P씮A)
5 10 15 20 25
Residual Pressure
Release Valve
VP542-X536 2
3/8" Rc,
G,
NPT
Residual Pressure
Release Valve
VP742-X536
1/2"
Dual Residual Pressure
Release Valve
VP544-X538
3, 4
3/8" Rc,
G,
NPT
Dual Residual Pressure
Release Valve
VP744-X538
1/2"
Dual Residual Pressure Release
Valve with Soft Start-up Function
VP544-X555/VP544-X585
3/8" Rc,
G,
NPT
Dual Residual Pressure Release
Valve with Soft Start-up Function
VP744-X555/ VP744-X585
1/2"
Dual Residual Pressure
Release Valve
VG342-X87
3/4"
Rc,
G,
NPT
Can be connected to Modular type
F.R.L. units.
Applicable models∗
앫VP544/744-X538
앫VP544/744-X555
앫VP544/744-X585
Page 17
X5
85
u
r
e
∗Only port size 3/4"
8
5
Standards and Enclosure
Series Variations
Dual residual pressure
release valve with soft
start-up function
Filter regulator
(Optional
accessory)
Series
Category
Safety limit switch
manufacturer
Standards
Enclosure
Machinery Directive 2006/42/EC
CE cUL RoHS
Harmonised
standards
EN ISO 13849-1: 2008
EN ISO 13849-2: 2008
EN ISO 4414:
2010
Residual Pressure
Release Valve
VP542/742-X536
2
OMRON Corporation
IP65
Rockwell Automation, Inc.
Dual Residual Pressure
Release Valve
VP544/744-X538
3, 4
OMRON Corporation
IP65
Rockwell Automation, Inc.
Dual Residual Pressure Release Valve
with Soft Start-up Function
VP544/744-X555
VP544/744-X585
3, 4
OMRON Corporation
IP65
Rockwell Automation, Inc.
Dual Residual Pressure
Release Valve
VG342-X87
3, 4
OMRON Corporation ∗
IP40
Rockwell Automation, Inc.
Page 3
Page 3
Page 3
Page 19
∗ These values have been calculated according to ISO 6358 and indicate the flow rate under standard conditions with an inlet pressure of 0.6 MPa (relative pressure)
and a pressure drop of 0.1 MPa
∗Please contact SMC for the
VP542/742-X536.
26.6/
5864
2
5
9.8/2203
8.9/2085
15.1/3637
6.5/1461
10.3/2315
5.2/1157
2
3 Port Solenoid Valve/Residual Pressure Release Valve with Detection of Main Valve Position Series VP/VG
Safety Standard ISO 13849-1 Certified

How to Order
Body
2Body ported
4Base mounted
Voltage
524 V DC
Maximum operating
pressure
X555 0.7 MPa
X585 1.0 MPa
Light/surge voltage suppressor
ZWith light/surge voltage suppressor
Series
5VP500
7VP700
Pilot
Internal pilot
RExternal pilot
Electrical entry
DDIN terminal
YDIN (EN 175301-803) terminal
∗Refer to page 18 for details about type Y.
Port size
Port size VP500 VP700
03 3/8" 앬—
04 1/2" — 앬
Thread
—Rc
FG
NNPT
Safety limit switch/Wiring
—G 1/2 (Made by OMRON)
M
M12 connector (Made by OMRON)
S1 M12 connector
(Made by Rockwell Automation)
With check valve (Only external pilot)
Check
valve
Applicable
tube O.D.
Thread
Rc G NPT
—None — 앬앬앬
AYes Ø 6 앬——
BØ 1/4∗——앬
∗For internal pilot, the symbol is nil.
∗Refer to “Piping for External Pilot Type” on page 4 for
selection of the check valve.
Throttle
—Variable throttle
10 Ø 1 fixed orifice
15
Ø 1.5 fixed orifice
20∗Ø 2 fixed orifice
∗VP700 only
3 Port Solenoid Valve/Residual Pressure Release
Valve with Detection of Main Valve Position
VP-X536, X538, X555, X585
X536
X538
X555
25A–VP첸4 첸첸
–
5DZ1
–
첸첸첸 – 첸첸첸 –
Series Compatible with Secondary Batteries
1
Made to Order
For details about 25A-, please consult SMC.
Secondary battery compatible
Dual residual pressure release valve
Dual residual pressure release
valve with soft start-up function
Residual pressure release valve
VP
VP
4
4
4
25
5
5
D
D
D
5 ZR
R
M
M
M
1
1
1
03
03
03
X536
X538
X555VP
4
4
Z
Z
5
5
How to Order
Note) Electrical entry can be selected only for D type.
Check valve type is available only when the thread
type is Rc.
Safety Standard ISO 13849-1 Certified
Fill in according to How to Order above.
F
F
F
∗Refer to page 2 for
compliant products.
∗
X536
3

Model
VP첸42-X536
VP첸44-X538
VP첸44-X555
VP첸42R-X536
VP첸44R-X538
VP첸44R-X555
VP첸44-X585 VP첸44R-X585
Fluid Air
Type of actuation N.C. (Spring return)
Operation Internal pilot External pilot Internal pilot External pilot
Operating pressure range 0.25 to 0.7 MPa 0.25 to 1.0 MPa
External pilot pressure —
0.25 to 0.7 MPa (Same as operating pressure)
Maximum operating frequency 30 times/minute
Minimum operating frequency 1 time/week
Operating and ambient temperature -10 to 50 °C (No freezing)
Ambient humidity 20 to 90 %RH (No condensation)
Manual override None
Pilot exhaust Individual exhaust
Lubrication Not required
Mounting orientation Unrestricted
Impact/Vibration resistance 150/30 m/s2
Enclosure IP65
Operating environment Indoors
B10d (MTTFd calculation)
10000000 times (for the safety limit switch made by OMRON)
1000000 times (for the safety limit switch made by Rockwell Automation)
1000000 times
Internal Pilot Type
Caution
Valve may not operate properly when air sup-
ply to P port is not adequate and the supply
pressure to the valve is lower than 0.25 MPa,
the minimum operating pressure. Be careful
with insufficient supply pressure.
Piping for External Pilot Type
Caution
The product may not operate when the external pilot
pressure is insufficient due to simultaneous opera-
tion or restricted air piping. In this case, use the
check valve (AKH series) with the external pilot port,
change the piping size or adjust the set pressure to
provide a constant pressure of 0.25 MPa or more.
Valve Specifications
Series
Flow rate characteristics Weight
[g]
1씮2 (P씮A) 2씮3 (A씮R)
C [dm
3
/(s·bar)] bCv Q [l/min (ANR)]
∗
C [dm
3
/(s·bar)] bCv Q [l/min (ANR)]
∗
VP542-X536 8.9 0.16 2.2 2085 8.9 0.20 2.1 2132 350
VP742-X536 15.1 0.21 3.6 3637 15.3 0.22 3.7 3707 590
VP544-X538 6.5 0.08 1.3 1461 6.7 0.10 1.3 1521 930
VP744-X538 10.3 0.08 2.3 2315 9.7 0.08 2.1 2180 1510
VP544-X555
VP544-X585 5.2 0.06 1.1 1157 6.7 0.10 1.3 1521 1105
VP744-X555
VP744-X585 9.8 0.08 2.1 2203 9.7 0.08 2.1 2180 2000
Flow Rate Characteristics / Weight
Electrical entry DIN terminal
Rated voltage 24 V DC
Allowable voltage fluctuation
±10 %
Power consumption 0.45 W
Surge voltage suppressor Varistor
Indicator LED
Manufacturer OMRON Rockwell Automation
Electrical wiring G 1/2, M12 connector M12 connector
Contact resistance 25 mΩor less 50 mΩor less
Min. applicable load 5 V DC, 1 mA (Load resistance) 5 V DC, 5 mA (Load resistance)
Max. voltage 24 V DC
Max. load current 50 mA
Max. load inductance 0.5 H
Insulation voltage 300 V 600 V
Protection against electric shock Class II (EN60947-5-1: 2004)
Solenoid Specifications Safety Limit Switch Specifications
Needle Valve / Flow Rate Characteristics (VP544/744-X555)
600
500
400
300
200
100
00 0.5 1 1.5 2 2.5 3 3.5 4
Number of needle rotations (Turns)
Flow rate [l/min (ANR)]
0.25 MPa
0.7 MPa
Ø 2Ø 1.5Ø 1
0.5 MPa
∗ These values have been calculated according to ISO 6358 and indicate the flow rate under standard
conditions with an inlet pressure of 0.6 MPa (relative pressure) and a pressure drop of 0.1 MPa
4
Safety Standard ISO 13849-1 Certified
3 Port Solenoid Valve/
Residual Pressure Release Valve with Detection of Main Valve Position
VP-X536, X538, X555, X585
VP500/700
X536X538
VG342
X87
Specific Product
Precautions
SymbolsSymbols
Specific Product
Precautions
Optional
Accessories
X555 X585

3(R)
3(R)
1(P) 1(P) 1(P)
1(P) 1(P) 1(P)
XX
X
3(R)1(P)
2(A)
(31)
e
(11)
q
r
(32)
w
(12)
3(R)1(P)
2(A)
(31)
e
(11)
q
r
(32)
w
(12)
3(R)1(P)
2(A)
(31)
e
(11)
q
r
(32)
w
(12)
3(R)
2(A)
(31)
e
(11)
q
r
(32)
w
(12)
(31)
e
(11)
q
r
(32)
w
(12)
(31)
e
(11)
q
r
(32)
w
(12)
3(R)
2(A)
(31)
e
(11)
q
r
(32)
w
(12)
3(R)
2(A)
(31)
e
(11)
q
r
(32)
w
(12)
3(R)
(31)
e
(11)
q
r
(32)
w
(12)
3(R)
(31)
e
(11)
q
r
(32)
w
(12)
3(R)
(31)
e
(11)
q
r
(32)
w
(12)
X
2(A)
3(R)
3(R)
(31)
e
(11)
q
r
(32)
w
(12)
(31)
e
(11)
q
r
(32)
w
(12)
2(A)
3(R)
3(R)
(31)
e
(11)
q
r
(32)
w
(12)
(31)
e
(11)
q
r
(32)
w
(12)
2(A)
XX
Safety limit switch terminal [N.C.]
M12 connector pin number
G 1/2 terminal number
Symbols
Terminal/Pin Numbers (Built-in switch 2N.C.)Symbol
VP544(R)/744(R)-X538
VP544(R)/744(R)-X555
VP544(R)/744(R)-X585
M12 connector
pin number
Wiring specification
q
@
:
.
;
w
e
r
G 1/2
terminal number
Wiring specification
(11)
3231
12
11
(12)
(31)
(32)
VP542(R)/742(R)-X536
Made by
OMRON
Safety limit switch
Internal pilot
Internal pilot
Internal pilot
External pilot
External pilot
External pilot
External pilot/With check valve
External pilot/With check valve
External pilot/With check valve
;
(32)
@
(12)
(31)
.
(11)
:
5
VP-X536, X538, X555, X585

3(R)
3(R)
wqe
ytr
3(R)1(P)
2(A)
wqe
ytr
3(R)
2(A)
wqe
ytr
3(R)
wqe
ytr
3(R)1(P)
2(A)
wqe
ytr
3(R)1(P)
2(A)
XX
XX
wqe
ytr
3(R)
2(A)
wqe
ytr
3(R)
wqe
ytr
3(R)
2(A)
wqe
ytr
3(R)
wqe
ytr
wqe
ytr
1(P)
1(P) 1(P) 1(P)
2(A)
3(R)
3(R)
wqe
ytr
wqe
ytr
1(P)
2(A)
3(R)
3(R)
wqe
ytr
wqe
ytr
1(P)
2(A)
XX
Safety limit switch terminal [N.C.]
M12 connector pin number
Symbols
VP544(R)/744(R)-X538
Pin Numbers (Built-in switch 3N.C.)
M12 connector
pin number
Wiring specification
q
@
:
.
B
=
;
t
w
y
e
r
Internal pilot
Internal pilot
Internal pilot
External pilot
External pilot
External pilot
External pilot/With check valve
External pilot/With check valve
External pilot/With check valve
@:.
B=;
VP542(R)/742(R)-X536
Made by
Rockwell Automation
Safety limit switch
Symbol
VP544(R)/744(R)-X555
VP544(R)/744(R)-X585
6
Safety Standard ISO 13849-1 Certified
3 Port Solenoid Valve/
Residual Pressure Release Valve with Detection of Main Valve Position
VP-X536, X538, X555, X585
VP500/700
X536X538
VG342
X87
Specific Product
Precautions
SymbolsSymbols
Specific Product
Precautions
Optional
Accessories
X555 X585

4.5
A
(Max. 10)
26
3.5 7
32
117.754.9
30.7
45
2 x Ø 4.2
(For mounting)
31
216.1
133.2
22.1
25.2
70.8
63.3
31.5
40
4
216.7
131.7 23.5
8
3/8"
[1(P), 3(R) port]
Vent port
(Ø 6.2)
M12 connector
2 x Ø 4.2
(For mounting)
Safety limit switch (made by Rockwell Automation)
Part number: 440P-CDPB03R6
(31.5)
(Distance between ports)
Applicable cable O.D.
Ø 3.5 to Ø 7
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
3/8"
[2(A) port]
(22.9)
(With check valve)
4.5
(25.7)
A
45
(Max. 10)
26
3.5 7
32
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
312 x Ø 4.2
(For mounting)
201.8
118.9
G 1/2
(14)202.4
117.4
23.5
70.8
63.3
31.5
40
4
Applicable cable O.D.
Ø 3.5 to Ø 7
Safety limit switch (made by OMRON)
Part number: D4N-2B31 (G 1/2)
: D4N-9B31
(M12 connector)
2 x Ø 4.2
(For mounting)
103.454.9
30.7
Vent port
(Ø 6.2)
3/8"
[1(P), 3(R) port]
22.1
(31.5)
(Distance between ports)
3/8"
[2(A) port]
(M12 connector)
(22.9)
(With check valve)
Dimensions
VP542(R)-5D
YZ1-03쏔-쏔-X536
VP542(R)-5D
YZ1-03쏔-M쏔-X536
VP542(R)-5D
YZ1-03쏔-S1쏔-X536
Residual Pressure Release Valve (-X536)
Made by
OMRON
Safety limit switch
Made by
Rockwell Automation
Safety limit switch
.
:
@
;Pin
number
View A
For M12 connector
View A
M12 connector
;
.
:
@
=
B
Pin
number
7
VP-X536

4.5
7.5
44.5
(Max. 10) 224.2
108.4
A
9
40
63
56.5
224.8
128.931 (14)
9.4 38.5
88.8
81.3
107.973.5
42
(34.7)
G 1/2
Ø 5.2
(For mounting)
Applicable cable O.D.
Ø 3.5 to Ø 7
Vent port
(Ø 6.2)
1/2"
[1(P), 3(R) port]
(43)
(Distance between ports)
3.5
20.5
Ø 5.2
(For mounting)
333.5
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
1/2"
[2(A) port]
(22.9)
(With check valve)
(M12 connector)
Safety limit switch (made by OMRON)
Part number: D4N-2B31 (G 1/2)
: D4N-9B31
(M12 connector)
88.8
81.3
Applicable cable O.D.
Ø 3.5 to Ø 7
9.4 38.5
33
4.5
(Max. 10)
7.5
2 x Ø 5.2
(For mounting)
41
A
63
56.5
2 x Ø 5.2
(For mounting)
9
40
73.5
42
Vent port
(Ø 6.2)
1/2"
[1(P), 3(R) port]
(43)
(Distance between ports)
34.2
238.5
143.2
24
8
239.1
143.231
122.2
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
1/2"
[2(A) port]
Safety limit switch (made by Rockwell Automation)
Part number: 440P-CDPB03R6
(22.9)
(With check valve)
M12 connector
Dimensions
VP742(R)-5D
YZ1-04쏔-쏔-X536
VP742(R)-5D
YZ1-04쏔-M쏔-X536
VP742(R)-5D
YZ1-04쏔-S1쏔-X536
Residual Pressure Release Valve (-X536)
View A
For M12 connector
.
:
@
;Pin
number
View A
M12 connector
;
.
:
@
=
B
Pin
number
Made by
OMRON
Safety limit switch
Made by
Rockwell Automation
Safety limit switch
8
Safety Standard ISO 13849-1 Certified
3 Port Solenoid Valve/
Residual Pressure Release Valve with Detection of Main Valve Position
VP-X536
VP500/700
X536X538
VG342
X87
Specific Product
Precautions
SymbolsSymbols
Specific Product
Precautions
Optional
Accessories
X555 X585

11.3
97.3
18
29 33.5
Applicable cable O.D.
Ø 3.5 to Ø 7
28.53/8"
[2(A) port]
17.5
91.5 75.5
547
2 x Ø 5.2
(For mounting)
(Max. 10)
Channel 2
Channel 1
201.8 (14)
(90.4)
34
17.5
57
28.5
79
104.8
Vent port
(Ø 6.2)
A
112 90.4
62.5
29
17.5
28.2
2 x 3/8"
[3(R) port]
(59.7)
G 1/2
3/8"
[1(P) port]
8
(22.9)
(With check valve)
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
Safety limit switch (made by OMRON)
Part number: D4N-2B31 (G 1/2)
: D4N-9B31 (M12 connector)
(M12 connector)
Dimensions
VP544(R)-5D
YZ1-03쏔-쏔-X538
VP544(R)-5D
YZ1-03쏔-M쏔-X538
Dual Residual Pressure Release Valve (-X538)
View A
For M12 connector
.
:
@
;Pin
number
Made by
OMRON
Safety limit switch
9
VP-X538

11.3
97.3
18
29 33.5
Applicable cable O.D.
Ø 3.5 to Ø 7
216.1
91.5 75.5
8
(104.7)
547
2 x Ø 5.2
(For mounting)
(Max. 10)
62.5
29
17.5
59.2
28.2
28.53/8"
[2(A) port]
17.5
Channel 2
Channel 1
34
17.5
3/8"
[1(P) port]
104.7112
57
28.5
79
104.8
Vent port
(Ø 6.2)
A
2 x 3/8"
[3(R) port]
M12 connector
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
Safety limit switch (made by Rockwell Automation)
Part number: 440P-CDPB03R6
(22.9)
(With check valve)
Dimensions
VP544(R)-5D
YZ1-03쏔-S1쏔-X538
Dual Residual Pressure Release Valve (-X538)
View A
M12 connector
;
.
:
@
=
B
Pin
number
Made by
Rockwell Automation
Safety limit switch
10
Safety Standard ISO 13849-1 Certified
3 Port Solenoid Valve/
Residual Pressure Release Valve with Detection of Main Valve Position
VP-X538
VP500/700
X536X538
VG342
X87
Specific Product
Precautions
SymbolsSymbols
Specific Product
Precautions
Optional
Accessories
X555 X585

9.5
(14)(Max. 10)
18
401/2"
[2(A) port]
77.5
36
(70.7)
27.2
18
G 1/2
2 x 1/2"
[3(R) port]
113.5
94.5
224.2
(88.9)
2 x Ø 6.2
(For mounting)
67 6.5
Applicable cable O.D.
Ø 3.5 to Ø 7
117.3
16
21
41.536
99
224.8
88.980
40
(22.9)
(With check valve)
124.8
36
18
1/2"
[1(P) port]
A
Vent port
(Ø 6.2)
Channel 2
Channel 1
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
(
M12 connector)
Safety limit switch (made by OMRON)
Part number: D4N-2B31 (G 1/2)
: D4N-9B31 (M12 connector)
Dimensions
VP744(R)-5D
YZ1-04쏔-쏔-X538
VP744(R)-5D
YZ1-04쏔-M쏔-X538
Dual Residual Pressure Release Valve (-X538)
.
:
@
;Pin
number
View A
For M12 connector
Made by
OMRON
Safety limit switch
11
VP-X538

18
9.5
117.3
16
21
36 41.5
Applicable cable O.D.
Ø 3.5 to Ø 7
Channel 2
Channel 1
77.5
36
70.2
27.2
18
2 x 1/2"
[3(R) port]
113.5
94.5
8238.5
(Max. 10)
(103.2)
6.5672 x Ø 6.2
(For mounting)
1/2"
[2(A) port]
40
99
103.2135.9
80
40
1/2"
[1(P) port]
36
18
124.8
(22.9)
(With check valve)
Vent port
(Ø 6.2)
A
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
Safety limit switch (made by Rockwell Automation)
Part number: 440P-CDPB03R6
M12 connector
Dimensions
VP744(R)-5D
YZ1-04쏔-S1쏔-X538
Dual Residual Pressure Release Valve (-X538)
;
.
:
@
=
B
Pin
number
View A
M12 connector
Made by
Rockwell Automation
Safety limit switch
12
Safety Standard ISO 13849-1 Certified
3 Port Solenoid Valve/
Residual Pressure Release Valve with Detection of Main Valve Position
VP-X538
VP500/700
X536X538
VG342
X87
Specific Product
Precautions
SymbolsSymbols
Specific Product
Precautions
Optional
Accessories
X555 X585

62.5 33.5
Applicable cable O.D.
(Ø 3.5 to Ø 7)
35
15
93.8
90.428.5
(22.9)
(With check valve) 202.4
3/8"
[1(P) port]
(14)
201.8
(Max. 10)
(90.4)
8
125
109
547
(Variable throttle type)
75.5
101.3
96
62.5
2 x 3/8"
[3(R) port]
G 12
56.2
24.2
Vent port
(Ø 6.4)
15.5
15
(15)
28.5
30.5
24.2
15
(15)
3/8"
[2(A) port]
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
2 x Ø 5.2
(For mounting)
(M12 connector)
Vent port
(Ø 6.2)
A
Safety limit switch (made by OMRON)
Part number: D4N-2B31 (G 1/2)
: D4N-9B31 (M12 connector)
Dimensions
VP544(R)-5D
YZ1-03쏔-쏔쏔-X555/X585
VP544(R)-5D
YZ1-03쏔-M쏔쏔-X555/X585
Dual Residual Pressure Release Valve with Soft Start-up Function (-X555/X585)
.
:
@
;Pin
number
View A
For M12 connector
Made by
OMRON
Safety limit switch
13
VP-X555, X585

Vent port
(Ø 6.2)
62.5 33.5
35
8
125
109
75.5
101.3
96
62.5
55.7
24.2
15.5
15
28.5
30.5
24.2
15
(Max. 10)
(22.9)
(With check valve)
(15)
3/8"
[2(A) port]
Safety limit switch (made by Rockwell Automation)
Part number: 440P-CDPB03R6
A
2 x 3/8"
[3(R) port]
M12 connector
Vent port
(Ø 6.4)
2 x Ø 5.2
(For mounting)
(Variable throttle type)
Applicable cable O.D.
(Ø 3.5 to Ø 7)
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve
)
(External pilot port)
3/8"
[1(P) port]
(15)
216.1
(90.4)
8 93.8
15
90.428.5
216.7
Dimensions
VP544(R)-5D
YZ1-03쏔-S1쏔쏔-X555/X585/X585
Dual Residual Pressure Release Valve with Soft Start-up Function (-X555/X585
;
.
:
@
=
B
Pin
number
View A
M12 connector
Made by
Rockwell Automation
Safety limit switch
14
Safety Standard ISO 13849-1 Certified
3 Port Solenoid Valve/
Residual Pressure Release Valve with Detection of Main Valve Position
VP-X555, X585
VP500/700
X536X538
VG342
X87
Specific Product
Precautions
SymbolsSymbols
Specific Product
Precautions
Optional
Accessories
X555 X585

Safety limit switch (made by OMRON)
Part number: D4N-2B31 (G 1/2)
: D4N-9B31 (M12 connector)
2 x Ø 6.2
(For mounting) Applicable cable O.D.
Ø 3.5 to Ø 7
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
2 x 1/2"
[3(R) port]
G 1/2
(M12 connector)
A
9.5
155 136
117.3
18
44.4
77.5 41.5
(Max. 10) 224.2
(88.9)
(14)
224.8
88.940
1/2"
[1(P) port]
Vent port
(Ø 6.2)
99
124.8
27.2
18
36
119
77.5
70.7
27.2
6.567
1/2"
[2(A) port]
40
18
18.5
Vent port
(Ø 6.4)
(22.9)
(With check valve)
(Variable throttle type)
Dimensions Dual Residual Pressure Release Valve with Soft Start-up Function (-X555/X585)
VP744(R)-5D
YZ1-04쏔-쏔쏔-X555/X585
VP744(R)-5D
YZ1-04쏔-M쏔쏔-X555/X585
.
:
@
;Pin
number
View A
For M12 connector
Made by
OMRON
Safety limit switch
15
VP-X555, X585

2 x Ø 6.2
(For mounting) Applicable cable O.D.
Ø 3.5 to Ø 7
Port size: 1/8" (Without check valve)
Applicable tube O.D.: Ø 6, Ø 1/4" (With check valve)
(External pilot port)
117.3
18
44.4
77.5 41.5
1/2"
[2(A) port]
40
18
Safety limit switch (made by Rockwell Automation)
Part number: 440P-CDPB03R6
9.5
155 136
6.567
(Variable throttle type)
2 x 1/2"
[3(R) port]
119
77.5
70.2
27.2
18.5
Vent port
(Ø 6.4)
27.2
18
36
1/2"
[1(P) port]
Vent port
(Ø 6.2)
A
(22.9)
(With check valve)
(Max. 10) 236.4
(86.3)
8
99
124.8
245
86.340
M12 connector
Dimensions
VP744(R)-5D
YZ1-04쏔-S1쏔쏔-X555/X585
Dual Residual Pressure Release Valve with Soft Start-up Function (-X555/X585)
;
.
:
@
=
B
Pin
number
View A
M12 connector
Made by
Rockwell Automation
Safety limit switch
16
Safety Standard ISO 13849-1 Certified
3 Port Solenoid Valve/
Residual Pressure Release Valve with Detection of Main Valve Position
VP-X555, X585
VP500/700
X536X538
VG342
X87
Specific Product
Precautions
SymbolsSymbols
Specific Product
Precautions
Optional
Accessories
X555 X585

B
DA
Centre of
F.R.L.
body
Port size
B
C
A
(Spacer width)
F
H
G
EE
J
K
D
Centre of
F.R.L.
body
Seal
IN OUT IN OUT
(Max. 10)
201.8
82.9
(14)
d
cba
d
ab c
(14) 201.8
(Max. 10)
82.9
VP500/700-X538, X555, X585
Optional Accessories
A piping adapter allows installation/removal of the component
without removing the piping and thus makes maintenance easier.
Note) 쏔in part numbers indicates a pipe thread type.
No indication is necessary for Rc; however,
indicate N for NPT, and F for G.
∗Separate interfaces are required for modular unit.
Piping Adapter: 3/8, 1/2
Part no. Note) Port size ABD
E300-쏔03-A 3/8 31.8 30 30
E400-쏔04-A 1/2 31.8 36 36
Spacer with Bracket
Spacer with Bracket Mounting Position
Part no. ABC D EFGHJK
Y300T-A 4.2 82 41 71.5 35 14 7 19 4 41
Y400T-A 5.2 96 48 86.1 40 18 9 26 5 50
Spacer with bracket
Piping
adapter
Dual residual pressure release valve
with soft start-up function
Model ab c d Note
VP544-5DZ1-03-X538 33.9 57.2 95.7 220.7
AW30-03G-B
Y300T-A
E300-03-A
VP744-5DZ1-04-X538 34.4 75.2 118.7 262.7
AW40-04G-B
Y400T-A
E400-04-A
Model ab c d Note
VP544-5DZ1-03-X555
VP544-5DZ1-03-X585 33.9 57.2 129.2 254.2
AW30-03G-B
Y300T-A
E300-03-A
VP744-5DZ1-04-X555
VP744-5DZ1-04-X585 34.4 75.2 160.2 304.2
AW40-04G-B
Y400T-A
E400-04-A
Dual residual pressure release valve (-X538) Dual residual pressure release valve with soft start-up
function (-X555/X585)
∗Each product is not assembled.
VP544-5DZ1-03-X538 ······· 1 pc.
Filter regulator
AW30-03G-B ····················· 1 pc.
Spacer with bracket
Y300T-A ···························· 3 pcs.
Piping adapter
E300-03-A ························· 2 pcs.
Ordering Example∗
17

VP500/700-X536, X538, X555, X585
Specific Product Precautions
Be sure to read this before handling. Refer to the back cover for Safety Instructions.
For 3/4/5 Port Solenoid Valve Precautions, refer to the Operation Manual on the SMC
website, http://www.smc.eu
How to Use DIN Terminal Connector
Caution
Connection
1. Loosen the holding screw and pull the connector out of the
solenoid valve terminal block.
2. After removing the holding screw, insert a flat blade
screwdriver etc. into the notch on the bottom of the terminal
block and pry it open, separating the terminal block and the
housing.
3. Loosen the screw (slotted screws) in the terminal block. Insert
the lead core wires to the terminals according to the connection
method, and secure the wires by re-tightening the terminal
screw.
4. Secure the cord by fastening the ground nut.
Caution
When making connections, please note that using other than the
supported size (Ø 3.5 to Ø 7) heavy-duty cord will not satisfy IP65
(enclosure) standards. Also, be sure to tighten the ground nut
and holding screw within their specified torque ranges.
Changing the entry direction
After separating the terminal block and housing, the cord entry
can be changed by attaching the housing in the desired direction
(4 directions at 90°intervals).
∗When equipped with a light, be careful not to damage the light
with the cord’s lead wires.
Precautions
Plug in and pull out the connector vertically without tilting to one
side.
Compatible cable
Cord O.D.: Ø 3.5 to Ø 7
(Reference) 0.5 mm2, 2-core or 3-core, equivalent to JIS C 3306
Type “Y”
DIN connector type Y is a DIN connector that confirms to the DIN
pitch 8-mm standard.
• D type DIN connector with 9.4 mm pitch between terminals is
not interchangeable.
• To distinguish from the D type DIN connector, “N” is listed at the
end of voltage symbol.
• Dimensions are completely the same as D type DIN connector.
Voltage symbol
Type D: 24 V
Type Y: 24 VN
Terminal screw
(3 locations)
Tightening torque
0.2 to 0.25 N·m
Grommet
(Rubber)
Washer
Ground nut
Tightening torque
1.65 to 2.5 N·m
Holding screw
Tightening torque
0.4 N·m
Housing
(Position for light
mounting)
Terminal block
Notch
Light/Surge Voltage Suppressor
DIN Terminal
With light (DZ)
(YZ)
Note) Surge voltage suppressor of varistor has residual voltage
corresponding to the protective element and rated voltage;
therefore, protect the controller side from the surge voltage.
Limit Switch Cable
OMRON or Rockwell Automation M12 connector limit switch ca-
ble is available.
M12 Connector Cable (4 Pins) Made by OMRON
M12 Connector Cable (6 Pins) Made by Rockwell Automation
Installation
Use the external pilot type when using VP500/700-X536 or X538
with AV series. Install the AV series to the primary side.
No.1
(–)(+)
No.2
(+)(–)
Varistor
LED
Coil
There is no polarity.
Part number Cable length [mm]
ZS-37-L 300
ZS-37-M 500
ZS-37-N 1000
ZS-37-P 2000
ZS-37-C 5000
Part number Cable length [mm]
VP500-231-1 2000
18
VP500/700
X536X538
VG342
X87
Specific Product
Precautions
SymbolsSymbols
Specific Product
Precautions
Optional
Accessories
X555 X585

∗Refer to page 2 for
compliant products.
∗
M X87VG342 5 ZD 06
How to Order
Voltage
524 V DC
Port size
06 3/4"
10 1"
Electrical entry
DDIN terminal
Pilot
—Internal pilot
RExternal pilot
Light/surge voltage suppressor
ZWith light/surge voltage suppressor
Safety limit switch/Wiring
MM12 connector
(Made by OMRON)
S1 M12 connector
(Made by Rockwell Automation)
Thread
—Rc
FG
NNPT
3 Port Solenoid Valve/Residual Pressure Release
Valve with Detection of Main Valve Position
VG342-X87
Dual residual pressure release valve
R
With check valve (Only external pilot)
Check
valve
Applicable
tube O.D.
Thread
Rc G NPT
—None — 앬앬앬
AYes Ø 8 앬——
BØ 5/16" — — 앬
∗For internal pilot, the symbol is nil.
∗Refer to “Piping for External Pilot Type” on page 20 for
selection of the check valve.
25A–VG342첸
–
5DZ
–
첸첸 – M첸– X87
Series Compatible with Secondary Batteries
1
Made to Order
For details about 25A-, please contact SMC.
Secondary battery compatible
Fill in according to How to Order above.
How to Order
Safety Standard ISO 13849-1 Certified
Note) Electrical entry can be selected only for D type.
Check valve type is available only when the thread
type is Rc.
F
19
