OVERVIEW
The SMC8014-TES Transparent Ethernet Service Cable Modem Gateway allows MSOs the opportunity to
offer “Ethernet over DOCSIS” services to the SMB market at price points well below competitive solutions
from incumbent providers. The SMC8014-TES is a standards based solution giving operators needed flex-
ibility to support multi-vendor L2TPv3 compliant enterprise concentrators.
www.smc.com
SMC8014-TES
EZ Connect™ Transparent Ethernet Service Commercial Cable Modem Gateway
('>=@9<I
(>=@9<I
('>:FGG<I
(>:FGG<I
('&(''
Gf<
:F8O
;JC
N@I<C<JJ
JD:;@8>I8DC<><E;
C)KGc`ebjklee\c\[Fm\i?=:e\knfib
JD:/'(+$K<JJD:/'(+$K<J
JD:/'(+$K<J
JD:/'(+$K<J
?=:
E\knfib
?=:
E\knfib
?=:
E\knfib
?=:
E\knfib
?=:
E\knfib
APPLICATION DIAGRAM
KEY FEATURES
Support Multiple VPN Opportunities Full Featured Operational Support
Branch Office
Teleworker
Cellular Backhaul / PECO Cells
OOB Management for Fiber Customers
User friendly and powerful CLI includes many tools for quick
configuration and troubleshooting
Remote management and provisioning via GUI and CLI
RADIUS, TACACS and TACACS+ login authentication
Flexible Deployment Options Advanced Business Class Features
SOHO / Peer-to-Peer: mesh network of up to four SMC8014-TES
connected sites
Enterprise: SMC8014-TES at multiple sites connect to a hosted
VPN concentrator
Standards based approach (L2TPv3 – RFC 3931) for maximum
interoperability
802.1Q VLAN to segment customer’s traffic
SWITCHES VDSL WIRELESS VOIP STORAGE BROADBAND ADAPTERS
C)KG
Zfee\Zk`fe
C)KGZfee\Zk`fe
Fm\i?=:e\knfib
MGE:feZ\ekiXkfi
:ljkfd\iËjJXk\cc`k\F]]`Z\j
?=:E\knfib
F]]`Z\8 F]]`Z\9 F]]`Z\:
JD:/'(+$K<J JD:/'(+$K<J JD:/'(+$K<J
:ljkfd\ij
DX`eF]]`Z\

COMPATIBILITY
• Platform independent – works with PC or Mac
• DOCSIS 1.1/2.0
• IEEE 802.3, 802.3u
• USB 1.1PORTS
• 4 10/100 BASE-TX MDI/MDIX RJ45 ports
• 1 USB 1.1 Connector Type B
• Cable Interface F type female 75ohm
CABLE MODEM FEATURES
• DOCSIS 2.0 certified
• MEF 9 certified (EPL, EVPL, E-LAN)
• MEF14 certified (EPL, EVPL, E-LAN)
• 64/256QAM auto detection
• Supports maximum DOCSIS transfer rates
• Independent resets for downstream and upstream blocks
• Fragmentation and concatenation enabling Quality of Service
(QoS)
NETWORKING
• IEEE 802.1d compliant bridging
• ARP
• ICMP
• FTP/TFTP
• Telnet
• SSH
• Radius
• TACACS/TACACS+RFC 3931 SNMPv3
• Downloadable config files
• 802.1Q VLAN tagging
SECURITY
• Password protected configuration access
• Multiple User Profiles
• Web based authentication
• Comprehensive Logging
• L2TPv3 VPN Termination
SIGNAL LEVEL
• Downstream
• Single Channel;-15 dBmv ~ +15 dBmv, total: < +30 dBmv
• Upstream
• +8 dBmv ~ +58 dBmv (QPSK), +8 dBmv ~ +55 dBmv (16-QAM)
ERROR CORRECTION
• Downstream: ITU-T J.83 Annex B
• Upstream: DOCSIS upstream FEC with scalable interleaving
OPERATIONAL FREQUENCY
• Downstream: 91-857 MHz
• Upstream: 5-42 MHz
DEMODULATION
• Downstream: 64QAM,256QAM
• Upstream: QPSK,16QAM
OPERATING ENVIRONMENT
• Operating Temp. 0oC to 40oC (32oF to 104oF)
• Storage Temp. -20oC to 70oC (-4oF to 158oF)
• Operating Humidity 10% to 85% Non-Condensing
• Storage Humidity 5% to 90% Non-Condensing
ENCRYPTION
• 56-bit/128-bit DES
CERTIFICATION
• FCC Part 15B Class B
• FCC Part 68
• CE mark EN55024
• FCC Part 15C Class B
• CE Class B
• UL
DIMENSIONS
• 9.4 x 5.4 x 1.4 in
• 23.88 x 13.7 x 3.6 cm
WEIGHT
• .93 lbs
• 420 g
LEDs
• Power, Diag, Cable, Traffic, USB, EthernetPOWER
• 12V/1.25A
WARRANTY
• Limited Lifetime
CONTACT
North America
20 Mason
Irvine, CA 92618
1-800-SMC-4YOU
24/7 Technical Support
Europe/Africa
Fructuos Gelabert 6-8
08970 Sant Joan Despí
Barcelona, Spain
Check www.smc.com for your local country contact information
© 2008 SMC Networks. SMC and the SMC logo are registered trademarks
of SMC Networks in the United States or other countries. Other trademarks
or registered trademarks are the property of their respective owners. Infor-
mation is subject to change without notice. All rights reserved.
9/19/2008
www.smc.com
TECH SPECS - SMC8014-TES
