SMC Networks EZ Networking SMC-EZ108FDT User manual

EZ Switch 10/100 Layer 2 Switch
The SMC EZ Switches provide affordable switching and ease of use
in a compact, new design. These unmanaged switches feature 8, 1 ,
24 10BASE-T/ 100BASE-TX RJ-45 ports, and a slot in the front panel
to accommodate your choice of five different optional fibre uplink
modules for increased flexibility in use. It provides port speeds up to
200Mbps and full-duplex capacity on each of its ports, generating
tremendously enhanced performance.
Offering aggregate bandwidth of 1. , 3.4 or 5.0Gbps the switches
provide a range of key features, including: automatic address
learning, store-and-forward architecture to prevent the propagation
of bad packets throughout the network, half- and full- duplex flow
control to prevent packet loss under heavy loading, and filtering and
forwarding on all ports.
All SMC products are backed by a limited lifetime warranty.
Features and Benefits
High Performance & Functiona ity
•Optional uplink to fibre for distance networking (100FX-SC/ST, MT-RJ single mode,
multimode and VF-45 multi-mode
•1. / 3.4 / 5.0 Gbps aggregate bandwidth
•Filtering and forwarding on all ports
•Automatic address learning
•Store-and-forward architecture prevents propagation of bad packets
•Half- and full-duplex flow control prevents packet loss under heavy loading
•Rackmountable or desktop
F exib e System Management
•Plug-and-Play - no configuration necessary
•Auto-negotiation for automatic selection of speed and operating mode
•At-a-glance LEDs for network and activity monitoring
•Designated uplink port for easy network connection
Compatibi ity
•IEEE 802.3, 802.3u
Product Model No. Description
EZ Switch 10/100 SMC-EZ108FDT Dual speed switch with 8 10BASE-T/100BASE-TX ports
a d 1 slot for fibre upli k
SMC-EZ1016FDT 16-port auto-MDIX 10BASE-T/100BASE-TX switch with
o e expa sio slot
SMC-EZ1024FDT 24-port auto-MDIX 10BASE-T/100BASE-TX switch with
o e expa sio slot
SMCEZ108FMSC 1 Port 100BASE-FX SC Multi-mode Fibre Module
SMCEZ108FSSC 1 Port 100BASE-FX SC Si gle-mode Fibre Module
SMCEZ108FMMT 1 Port 100BASE-FX MT-RJ Multi-mode Fibre Module
SMCEZ108FSMT 1 Port 100BASE-FX MT-RJ Si gle-mode Fibre Module
SMCEZ108FMVF 1 Port 100BASE-FX VF-45 Multi-mode Fibre Module
SMC-EZFMST 1-port 100BASE-FX (multimode; SC + SC-ST
media co verter)
www.smc-europe.com www.smc.com
Data Sheet
EZ Switch™ 10/100
SMC-EZ108FDT, SMC-EZ1016FDT,
SMC-EZ1024FDT

Specifications
Physica Characteristics
Ports
•8/1 /24 - 10/100Mbps RJ-45
•1 - 100Mbps FX SC/ST/MTRJ/VF-45
switch port (optional)
•SMC-EZ101 FDT, SMC-EZ1024FDT
support Auto-MDIX on all ports
IInnppuutt PPoowweerr
•100-240 VAC, 50- 0 Hz 0.3A max
MMaaxxiimmuumm CCuurrrreenntt
•0.5A Max. @ 110V, 0.25A Max. @ 240V
PPoowweerr CCoonnssuummppttiioonn
•9 watts max.
TTeemmppeerraattuurree
•0º- 40ºC (standard operating)
•32ºF - 104ºF
HHuummiiddiittyy
•5% to 95% (non-condensing)
SSttaannddaarrddss CCoommpplliiaannccee
•10BASE-T, 100BASE-TX, 100BASE-FX
LLEEDD IInnddiiccaattoorrss
•Power, link/activity, speed, FDX col.
FFllooww CCoonnttrrooll
•Half-duplex: back pressure
•Full-duplex: IEEE 802.3x optional
AAddddrreessss ttaabbllee
•1K MAC address entries
(SMC-EZ108FDT)
•8K MAC address entries
(SMC-EZ101 FDT,SMC-EZ1024FDT)
SSiizzee ((LL xx WW xx HH))
•SMC-EZ108FDT: 28.0 x 11.5 x 3. cm
•SMC-EZ101 FDT: 33.0 x 17.3 x 4.3 cm
•SMC-EZ1024FDT: 48.0 x 17.3 x 4.3 cm
MMaaxx.. FFiilltteerriinngg RRaattee
•Line speed
MMaaxx.. FFoorrwwaarrddiinngg RRaattee
•Line speed
SSwwiittcchh PPrroocceessssiinngg SScchheemmee
•Store-and-forward
Standards Conformance
Standards Conformance
CCeerrttiiffiiccaattiioonn
•CE Mark
IImmmmuunniittyy
•IEC 1000 - 4 - 2, 3, 4,
EEMMII
•C-Tick, FCC Class A, CISPR Class A,
VCCI Class A
SSaaffeettyy
•CSA + NRTL, TUV/GS
IIEEEEEE NNeettwwoorrkkiinngg SSttaannddaarrddss
•IEEE 802.3 (Ethernet)
•IEEE 802.3u (Fast Ethernet)
