Overview
0101001100100100010010110010101010011010010
SMC105DT
Model Number::
EZ SwitchTM 10/100
5-port Fast Ethernet Switch
Features
•Auto-negotiation of half or full duplex,
and auto-sensing of transmission
speed, on all ports
•Autoconfiguration for MDI/MDI-X
cable connections
•ANSI/IEEE 802.3u compliant
•Store-and-forward support
•“At-a-Glance LEDs”
•Small form factor
•External power supply
•Mountable on metal surfaces
Benefits
•Half and full-duplex flow control prevents packets
from being dropped under heavy loading
•Plug-n-Play ensures ease of implementation and
use. Allows connections to servers, workstations,
hubs or switches to be made with straight-through
cables or cross-over cable
•Standards-based technology ensures interoperability
between various IEEE-based products
•Store-and-forward architecture prevents
propagation of bad packets
•Intuitive status indicators allow for simple switch
and network diagnostics
•Canbeconveniently mounted on a metal surface
with included magnets or positioned on the
desktop
Compatibility
• IEEE 802.3
• IEEE802.3u
• IEEE802.3x
SMC’s EZ Switch™ 10/100 is a palm-sized 5-port
Fast Ethernet switch that delivers dedicated
10/100Mbps links to each attached LAN segment
– all with conventional cabling and adapters.
SMC’s EZ Switch™ 10/100 offers a simple, cost-
effective strategy for integrating Fast Ethernet
into your Ethernet network. Auto-negotiation is
used to select the optimal communication mode
for each connection. With store-and-forward
switching and flow control, maximum data
integrity is always maintained, even under heavy
loading. Easy installation,“At-a-Glance LEDs”, and
its ability to be mounted on any metal surface
make this plug-n-play switch an ideal choice for
smooth Fast Ethernet integration.
Managed &
Unmanaged
Switches
38 Tesla
Irvine, CA 92618
1-800-SMC-4YOU
www.smc.com

SPECIFICATIONS
Product Description
SMC105DT EZSwitch™ 5-port 10/100 Fast Ethernet Switch
0101001100100100010010110010101010011010010
Ports
•510/100 Mbps RJ-45 auto-MDI/MDI-X
LEDs
•Power–one
•Link/ACT–one per port
•100M – one per port
Switching method
•Store-and-forward
MAC Address Table
•4Kentriesper system
Memory Buffer
•1MB
Weight
•0.55lbs
Dimensions
•4.3inx2.8in x 0.75in
Temperature
•Operating: 0ºC to 45ºC (32ºF to 113ºF)
•Storage: -40ºC to 70ºC (-40ºF to 158ºF)
Humidity
•Non-Condensing: 10% to 90%
Power Requirements
•DC 9V, 800mA
Power Consumption
•4Watt
Maximum Current
•0.5A@110VAC
•0.22@240VAC
Standards
•IEEE802.3
•IEEE802.3u
•IEEE802.3x
Certification
•CEMark
Safety
•UL
EMI
•FCCClass B
Warranty
•LimitedLifetime
EZ SwitchTM 10/100
5-port Fast Ethernet Switch
SMC105DT
