OVERVIEW
The SMC8124PL2 provides wire speed 10/100/1000 Gigabit Ethernet switching with built in PoE features
specifi cally designed for SMB workgroup environments. By supporting 802.3af PoE on all 10/100/1000
copper ports it enables easy installation of PoE devices such as IP Phones and IP Cameras. The integrated
combo ports provide SFP’s for where fi ber is required for extended distances. An integrated part of this
switch family is the IP Clustering function. The feature allows customers to group together up to 32 switches
into a single logical group which can be managed using a single IP address. The switch also boasts advanced
Quality of Service features that can reduce the latency of packets through the network, with specifi c traffi c
prioritization improving the delivery of converged data such as voice and high quality video over IP. The 2
combo ports provide either 10/100/1000 or SFP ports. The PoE function allows up to 15.4W maximum per
port. Overall this switch is part of a fl exible switch family which brings PoE and non-PoE switches to the edge
of the network.
www.smc.com
SMC8124PL2
TigerSwitch™ 10/100/1000 Standalone 24-port 10/100/1000 Managed
Layer 2 Switch with PoE including 2 x SFP combo ports
10G FIBER
1G FIBER
10G COPPER
1G COPPER
10/100
PoE
WIRELESS
LEGEND
10G FIBER
1G FIBER
10G COPPER
1G COPPER
10/100
PoE
WIRELESS
LEGEND



















APPLICATION DIAGRAM
POWER TO CONNECT
KEY FEATURES
Highest Performance and Lowest Power Flexible Security Features
As part of SMC commitment to green networking this switch family
is designed around the latest generation switching silicon which
can provide high performance and the low power requirements
such as 38W for the SMC8126L2. Translating into approximately
1.4W per port for the 26 port and 1.3W per port for the 50 port.
Security is critical to next generation networks. This switch family
includes a range of User and Device security functions which
will help protect the network. Secure management interfaces for
protecting device confi guration and secure user access using
802.1x or Private Vlans to prevent unauthorized access.
MultiLink Trunking with LACP IP Clustering
Including the ability to bundle together the front panel ports to
provide higher performing uplinks. Trunk links can be confi gured
manually or using the 802.3ad standard which is supported on this
switch family.
Ease of management is crucial and to help deliver this we have
included IP Clustering. This allows users to group together up to
32 switches as part of a logical cluster. The units can be part of
this switch family or from the SMC61xxL2 family giving added
fl exibility.
SWITCHES VDSL WIRELESS VOIP STORAGE BROADBAND ADAPTERS

PORTS
• 24 10/100/1000BASE-T ports
• 2 SFP transceiver slots
• 1 Console port
NETWORK INTERFACE
• 10/100/1000 BASE-T ports
• SFP Transceiver slots supporting SX, LX
and ZX SFP
• Multimode fiber cable; 62.5/125 or 50/125
microns
• Singlemode fiber cable: 9/125 micron
SWITCHING FABRIC
• 48Gbps
• 35.7Mpps
BUFFER ARCHITECTURE
• 768Kbytes
SWITCHING DATABASE
• 8K MAC address entries
LED
• System: Power
• Port: Link/Act; PoE
TEMPERATURE
• Operating: 0 to 45 °C / 32 to 113 °F
• Storage: -40 to 70 °C / -40 to 158 °F
HUMIDITY
• Operating: 10% to 90% (non-condensing)
WEIGHT
• 4.33Kg
• 9.53lbs
DIMENSIONS
• 44x 32 x 4.3cm
• 17.3 x 12.6 x 1.7 in
AC INPUT
• 100 to 240 V, 50-60 Hz, 3A
POWER SUPPLY
• Internal, auto-ranging transformer: 100 to
240 VAC, 47 to 63Hz
POWER CONSUMPTION
• 45W (Switch)
• 180W (Power over Ethernet)
MAXIMUM CURRENT
• 0.25 A @ 115 VAC
• 0.12 A @ 230 VAC
POWER-OVER-ETHERNET
• Maximum output power per port: 15.4 W
• Output Voltage: 44 - 57 VDC
• Maximum output current per port: 350 mA
MTBF
• 8 Years
SWITCH FEATURES
• Spanning Tree Protocol (802.1D, .1w, 1s)
• Forwarding Mode
• Store-and-forward
• VLAN Support
• Up to 255 groups; port-based or with
802.1Q
• VLAN tagging, GVRP for automatic VLAN
learning
• 802.1v (Protocol based Vlans)
• Private vlan support
• Quality of Service
• Supports 4 levels of priority with flexible
classification and prioritization
• Per port bandwidth management
• MultiLink Trunking (LACP)
• 8 groups of up to 8 ports
• Port Mirroring
• IEEE 802.1x
• L2/L3/L4 access control lists
• TACACS+ client authentication
• HTTPS and SSL
• SSH for Telnet sessions
• Static port security
• Jumbo Frame support (on gigabit ports)
• Dual firmware images
• Multiple configuration files support
MANAGEMENT FEATURES
• In-Band Management
• Telnet, SLIP, Web-based HTTP, or SNMP
manager
• Out-of-Band Management
• RS-232 DB-9 console port
• Software Loading
• TFTP in-band or Xmodem out-of-band
• MIB Support
• MIB II (RFC 1213), Bridging MIB (RFC 1493),
Ethernet-Like MIB (RFC 2665), Bridge MIB
Extensions (RFC 2764), RMON MIB (RFC
1757), RFC 2737, RFC 2742, RFC 2021, RFC
2863, RFC 2618, SMC’s private MIB
STANDARDS
• IEEE802.3 Ethernet, IEEE802.3u
Fast Ethernet
• IEEE802.1D Spanning Tree Protocol and
traffic priorities
• IEEE802.3ab and IEEE802.3z
Gigabit Ethernet
• IEEE802.1p Priority tags
• IEEE802.1Q VLAN
• IEEE802.1ac VLAN tagging
• IEEE802.3ad Link aggregation control
protocol
• IEEE802.1w Rapid Spanning Tree
• IEEE802.1v Protocol Based Vlans
• IEEE802.3af Power over Ethernet
• IEEE 802.3x Flow Control
RMON SUPPORT
• Groups 1,2,3, 9 (Statistics, History,
Alarm, Event)
ISO
• IEC8802.3
COMPLIANCES
• CE Mark
• Emissions
• FCC Class A
• Industry Canada Class A
• EN55022 (CISPR 22) Class A
• EN 61000-3-2/3
• Immunity
• EN 61000-4-2/3/4/5/6/8/11
SAFETY
• UL / CUL (UL 60950-1, CSA 22.2 NO60950-1)
• TUV/GS (EN60950-1)
• CB (IEC60950-1)
• CSA/CUS (CSA 22.2. NO 60950-1 &
UL60950-1)
WARRANTY
• Please check www.smc.com for the warranty
terms in your country/region
SLIDE-IN TRANSCEIVERS
FOR COMBO PORTS
SMC1GSFP-SX
• 1G SX SFP Transceiver, 550M, Multimode fiber
SMC1GSFP-LX
• 1G LX SFP Transceiver, 10Km,
Singlemode Fiber
SMC1GSFP-ZX
• 1G LH SFP Transceiver, 70Km,
Singlemode fiber
