Smeg KICTIS90BL User manual

KICTIS90BL
Libretto di Istruzioni
Instructions Manual
Bedienungsanleitung
Instrukcja Obsugi
Manual de instrucciones
Manual de Instruções
Manuel d’Instructions
Gebruiksaanwijzing
Bruksanvisning
Käyttöohje
Brugsvejledning
Bruksanvisning
  
 

2
2
INDICE
CONSIGLI E SUGGERIMENTI.............................................................................................................................................. 5
CARATTERISTICHE.............................................................................................................................................................. 8
INSTALLAZIONE ................................................................................................................................................................. 10
USO...................................................................................................................................................................................... 13
MANUTENZIONE ................................................................................................................................................................ 14
INDEX
RECOMMENDATIONS AND SUGGESTIONS ................................................................................................................... 17
CHARACTERISTICS ........................................................................................................................................................... 20
INSTALLATION.................................................................................................................................................................... 22
USE...................................................................................................................................................................................... 25
MAINTENANCE................................................................................................................................................................... 26
INHALTSVERZEICHNIS
EMPFEHLUNGEN UND HINWEISE ................................................................................................................................... 29
CHARAKTERISTIKEN......................................................................................................................................................... 32
MONTAGE ........................................................................................................................................................................... 34
BEDIENUNG........................................................................................................................................................................ 37
WARTUNG........................................................................................................................................................................... 38
SPIS TRECI
UWAGI I SUGESTIE............................................................................................................................................................ 41
WACIWOCI TECHNICZNE........................................................................................................................................... 44
INSTALACJA........................................................................................................................................................................ 46
UYTKOWANIE................................................................................................................................................................... 49
KONSERWACJA ................................................................................................................................................................. 50
ÍNDICE
CONSEJOS Y SUGERENCIAS........................................................................................................................................... 53
CARACTERÍSTICAS ........................................................................................................................................................... 56
INSTALACIÓN ..................................................................................................................................................................... 58
USO...................................................................................................................................................................................... 61
MANTENIMIENTO............................................................................................................................................................... 62
ÍNDICE
CONSELHOS E SUGESTÕES............................................................................................................................................ 65
CARACTERÍSTICAS ........................................................................................................................................................... 68
INSTALAÇÃO....................................................................................................................................................................... 70
UTILIZAÇÃO ........................................................................................................................................................................ 73
MANUTENÇÃO.................................................................................................................................................................... 74
IT
EN
DE
PL
ES
PT

3
3
SOMMAIRE
CONSEILS ET SUGGESTIONS.......................................................................................................................................... 77
CARACTERISTIQUES......................................................................................................................................................... 80
INSTALLATION.................................................................................................................................................................... 82
UTILISATION ....................................................................................................................................................................... 85
ENTRETIEN......................................................................................................................................................................... 86
INHOUDSOPGAVE
ADVIEZEN EN SUGGESTIES............................................................................................................................................. 89
EIGENSCHAPPEN .............................................................................................................................................................. 92
INSTALLATIE....................................................................................................................................................................... 94
GEBRUIK ............................................................................................................................................................................. 97
ONDERHOUD...................................................................................................................................................................... 98
INNHOLD
ANBEFALINGER OG FORSLAG ...................................................................................................................................... 101
EGENSKAPER................................................................................................................................................................... 104
INSTALLASJON................................................................................................................................................................. 106
BRUK ................................................................................................................................................................................. 109
VEDLIKEHOLD.................................................................................................................................................................. 110
SISÄLTÖ
OHJEET JA SUOSITUKSET ............................................................................................................................................. 113
MITAT JA OSAT ................................................................................................................................................................ 116
ASENNUS.......................................................................................................................................................................... 118
KÄYTTÖ............................................................................................................................................................................. 121
HUOLTO ............................................................................................................................................................................ 122
INDHOLD
RÅD OG ANVISNINGER ................................................................................................................................................... 125
APPARATBESKRIVELSE ................................................................................................................................................. 128
INSTALLATION.................................................................................................................................................................. 130
BRUG................................................................................................................................................................................. 133
VEDLIGEHOLDELSE ........................................................................................................................................................ 134
INNEHÅLL
REKOMMENDATIONER OCH TIPS................................................................................................................................. 137
EGENSKAPER................................................................................................................................................................... 140
INSTALLATION.................................................................................................................................................................. 142
ANVÄNDING...................................................................................................................................................................... 145
UNDERHÅLL...................................................................................................................................................................... 146
FR
NL
NO
FI
DK
SE

4
4

   ........................................................................................................................................ 149
.......................................................................................................................................................... 152
...................................................................................................................................................................... 154
.............................................................................................................................................................. 157
.................................................................................................................................................................................. 158

  ............................................................................................................................................161
.........................................................................................................................................................164
...........................................................................................................................................................166
...........................................................................................................................................................169
 ..................................................................................................................................................170
RU
SA

EN 1
17
RECOMMENDATIONS AND SUGGESTIONS
The Instructions for Use apply to several versions of this appliance.
Accordingly, you may find descriptions of individual features that do not
apply to your specific appliance.
INSTALLATION
•The manufacturer will not be held liable for any damages resulting from
incorrect or improper installation.
• The minimum safety distance between the cooker top and the extractor hood
is 650 mm (some models can be installed at a lower height, please refer to
the paragraphs on working dimensions and installation).
• Check that the mains voltage corresponds to that indicated on the rating
plate fixed to the inside of the hood.
• For Class I appliances, check that the domestic power supply guarantees
adequate earthing.
Connect the extractor to the exhaust flue through a pipe of minimum
diameter 120 mm. The route of the flue must be as short as possible.
• Do not connect the extractor hood to exhaust ducts
carrying combustion fumes (boilers, fireplaces, etc.).
• If the extractor is used in conjunction with non-electrical
appliances (e.g. gas burning appliances), a sufficient
degree of aeration must be guaranteed in the room in
order to prevent the backflow of exhaust gas. The
kitchen must have an opening communicating directly
with the open air in order to guarantee the entry of clean air. When the
cooker hood is used in conjunction with appliances supplied with energy
other than electric, the negative pressure in the room must not exceed 0,04
mbar to prevent fumes being drawn back into the room by the cooker hood.
• The air must not be discharged into a flue that is used for
exhausting fumes from appliances burning gas or other
fuels (not applicable to appliances that only discharge the
air back into the room).
• In the event of damage to the power cable, it must be
replaced by the manufacturer or by the technical service
department, in order to prevent any risks.
2°

EN 1
18
• If the instructions for installation for the gas hob specify a greater distance
specified above, this has to be taken into account. Regulations concerning
the discharge of air have to be fulfilled.
• Use only screws and small parts in support of the hood.
Warning: Failure to install the screws or fixing device in accordance with
these instructions may result in electrical hazards.
• Connect the hood to the mains through a two-pole switch having a contact
gap of at least 3 mm.
USE
•The extractor hood has been designed exclusively for domestic use to
eliminate kitchen smells.
• Never use the hood for purposes other than for which it has been designed.
• Never leave high naked flames under the hood when it is in operation.
• Adjust the flame intensity to direct it onto the bottom of the pan only, making
sure that it does not engulf the sides.
• Deep fat fryers must be continuously monitored
during use: overheated oil can burst into flames.
• Do not flambè under the range hood; risk of fire.
• This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the hazards
involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.

EN 1
19
•“CAUTION: Accessible parts may become hot when used with cooking
appliances.”
MAINTENANCE
•Switch off or unplug the appliance from the mains supply before carrying out
any maintenance work.
• Clean and/or replace the Filters after the specified time period (Fire hazard).
• The Grease filters must be cleaned every 2 months of operation, or more
frequently for particularly heavy usage, and can be washed in a dishwasher.
• The Activated charcoal filter is not washable and cannot be regenerated,
and must be replaced approximately every 4 months of operation, or more
frequently for particularly heavy usage.
• "Failure to carry out cleaning as indicated will result in a fire hazard".
• Clean the hood using a damp cloth and a neutral liquid detergent.
The symbol on the product or on its packaging indicates that this product
may not be treated as household waste. Instead it shall be handed over to the
applicable collection point for the recycling of electrical and electronic
equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this product,
please contact your local city office, your household waste disposal service or
the shop where you purchased the product.

EN 2
20
CHARACTERISTICS
Dimensions

EN 2
21
Components
Ref. Q.ty Product Components
1 1 Hood Canopy complete with: Controls, Light, Filters
21 Telescopic chimney, made up of:
2.1 1 Upper chimney
2.2 1 Lower chimney
7.1 1 Telescopic frame complete with Suction fan, made up
of:
7.1a 1 Upper frame
7.1b 1 Lower frame
91 Reduction flange ø 150-120 mm
14.1 2 Air Outlet Connector Extension
15 1 Air Outlet Connector
25 Hose clamps (not supplied)
Ref. Q.ty Installation Components
7.3 1 Air Outlet Connector fixing bracket
11 4 Wall plugs ø 10
12c 2 Screws 2.9 x 7.5
12e 4 Screws 2.9 x 12.7
12i 2 Screws 2.9 x 12.7
12f 2 Screws M4 x 13
12g 4 Screws M6 x 80
12h 4 Screws 6 x 70
12q 4 Screws 3.5 x 9.5
21 1 Drilling template
22 8 Washers ø 6.4 – ø 4,5
23 4 Nuts M6
Q.ty Documentation
1 Instruction Manual
12i
12c
12e
12e

EN 2
22
INSTALLATION
Drilling the Ceiling/shelf and fixing the frame
DRILLING THE CEILING/SHELF
• Use a plumb line to mark the centre of the hob on the ceiling/support shelf.
• Place the drilling template 21 provided on the ceiling/support shelf, making sure that the
template is in the correct position by lining up the axes of the template with those of the hob.
• Mark the centres of the holes in the template.
• Drill the holes at the points marked:
• For concrete ceilings, drill for plugs appropriate to the screw size.
• For hollow brick ceilings with wall thickness of 20 mm: drill ø 10 mm(immediately insert
the Dowels 11 supplied).
• For wooden beam ceilings, drill according to the wood screws used.
• For wooden shelf, drill ø 7 mm.
• For the power supply cable feed, drill ø 10 mm.
• For the air outlet (Ducted Version), drill according to the diameter of the external air ex-
haust duct connection.
• Insert two screws of the following type, crossing them and leaving 4-5 mm from the ceiling:
• For concrete ceilings, use the appropriate plugs for the screw size (not provided).
• for Cavity ceiling with inner space, with wall thickness of approx. 20 mm, Screws 12h,
supplied.
• For wooden beam ceilings, use 4 wood screws (not provided).
• For wooden shelf, use 4 screws 12g with washers 22 and nuts 23, provided.

EN 2
23
Fixing the frame
• Loosen the two screws fastening the lower chimney and re-
move this from the lower frame.
• Loosen the two screws fastening the upper chimney and re-
move this from the upper frame.
If you wish to adjust the height of the frame, proceed as follows:
• Unfasten the metric screws joining the two columns, located at
the sides of the frame.
• Adjust the frame to the height required, then refit all the screws
removed as above.
• Insert the upper chimney stack from above, and leave it run-
ning free on the frame.
• Lift up the frame, fit the frame slots onto the screws up to the
slot end positions.
• Tighten the two screws and fasten the other two screws provid-
ed with the hood.
Before tightening the screws completely it is possible to adjust
the frame by turning it. Make sure that the screws do not come
out of their seats in the slotted holes.
• The frame mountings must be secure to withstand the weight
of the hood and any stresses caused by the occasional side
thrust applied to the device.
On completion, check that the base is stable, even if the frame
is subjected to bending.
• In all cases where the ceiling is not strong enough at the sus-
pension point, the installer must provide strengthening using
suitable plates and backing pieces anchored to the structurally
sound parts.
22
11
Connections
DUCTED VERSION AIR EXHAUST SYSTEM
When installing the ducted version, connect the hood to the
chimney using either a flexible or rigid pipe ø 150 or 120 mm,
the choice of which is left to the installer.
• To install a ø 120 mm air exhaust connection, insert the reduc-
er flange 9on the hood body outlet.
• Fix the pipe in position using sufficient pipe clamps (not sup-
plied).
• Remove possible charcoal filters.

EN 2
24
Air outlet – Recirculation Version
• Insert the Connector extensions 14.1 into the side of the Con-
nector 15.
• Insert the Connector 15 into the Support bracket 7.3 and fix it
with the screws.
• Fasten the Support bracket 7.3, fixing it to the upper part with
the Screws.
• Make sure that the Connector extensions outlet 14.1 is in cor-
respondence with the Chimney openings both horizontally and
vertically.
• Join the Connector 15 to the Hood canopy outlet using a rigid
or flexible pipe ø¸150 mm, selection of which is at the discre-
tion of the installation technician.
• Make sure that the Activated charcoal odour filter has been
fitted.
12i
Flue assembly - Mounting the hood body
• Position the upper chimney section and fix the upper part to the
frame using the 2 screws 12e (2,9 x 12,7) provided.
• Similarly, position the lower chimney section and fix the low-
er part to the frame using the 2 screws 12e (2,9 x 12,7) provid-
ed.
Before fixing the hood canopy to the frame:
• Screw the 2 screws 12f half way into the holes provided in the
sides of the bottom of the frame.
• Remove the grease filters from the hood canopy.
• Remove any activated charcoal filters.
• Lift the hood canopy and engage the screws 12f in the slots (A)
as far as they will go.
• Working from below, fix the hood canopy to the frame (B),
using the 4 screws 12q and 4 washers 22 provided, then tighten
all the screws securely.
12e
12e
ELECTRICAL CONNECTION
• Connect the Hood to the Mains Power Supply, inserting a
bipolar switch with a contact aperture of at least 3 mm.
• Remove the Grease filters (see paragraph “Maintenance”) and
make sure that the Power cable (A) has been properly inserted
into the Suction fan socket.
• Fasten the connector B to the free socket at the side of the
suction fan
AB

EN 2
25
USE
Control panel
Button Function Led
A Turns the Motor off. The Leds indicating the Speed of the motor turn off.
B Activates speed one. The Leds indicating Speed one and Motor Off turn on.
C Activates speed two. The Leds indicating Speed two and Motor Off turn on.
D Activates speed three. The Leds indicating Speed three and Motor Off turn on.
E Activates Intensive speed. This speed is timed to run
for 6 minutes. At the end of this time the system will
automatically return to the speed set before.
It is disabled by pressing the Button or turning the
Motor off.
Flashes once a second.
F Starts the 24H function, in which the motor starts at a
speed that allows suction of 100 m3/h for 10 minutes
per hour.
To turn it off press the button again.
The Leds indicating Fspeed and Motor Off turn on.
When the filters alarm is triggered, the alarm can be
reset by pressing and holding this button for
approximately 5 seconds. Led Aflashes three times.
These indications are only visible when the motor is
turned off.
When the procedure terminates, the indication shown previously
turns off:
FFlashing
Indicates the need to change the activated charcoal filters, and
also to wash the metal grease filters. The alarm is triggered after
the Hood has been in operation for 100 working hours.
G Activates Delay mode, causing automatic shutdown
of the Motor and the Lighting system with a 30’
delay.
It is disabled by pressing the button or turning the
motor off.
This mode does not function if Intensive or
24h is active.
Led Gturns on, and the button for the selected speed flashes
every 0.5”
H Turns the lighting system on and off at maximum
intensity. The Lighting Led lights up.
On start-up the board recognises the mains frequency.
Recognition is indicated on the display:
- 50Hz: LED A flashes once
- 60Hz : LED A flashes twice

EN 2
26
MAINTENANCE
Grease filters
CLEANING METAL SELF- SUPPORTING GREASE FILTERS
• The filters must be cleaned every 2 months of operation, or
more frequently for particularly heavy usage, and can be
washed in a dishwasher.
• Remove the filters one at a time holding them up with one
hand and pulling the handle downwards with the other hand at
the same time.
• Wash the filters, taking care not to bend them. Allow them to
dry before refitting.
• When refitting the filters, make sure that the handle is visible
on the outside.
Activated charcoal filter (Recirculation version)
REPLACING THE ACTIVATED CHARCOAL FILTER
• The filter is not washable and cannot be regenerated, and must
be replaced approximately every 4 months of operation, or
more frequently for particularly heavy usage.
• Remove the metal grease filters.
• Remove the saturated activated carbon filter by releasing the
fixing hooks.
• Fit the new filter by hooking it into its seating.
• Refit the metal grease filters.
Lighting unit
• For replacement contact technical support ("To purchase
contact technical support").

EN 2
27

EN 2
28
