BK7000
HighDefinitionVideoscope
OperatingManual

2
GeneralSafetyInformation
Readandunderstandallinstrucons.Failuretofollowallinstruconslisted
belowmayresultinelectricshock,fireand/orseriouspersonalinjury.
WorkAreaSafety
• Keepyourworkareacleanandwelllit.Clueredbenchesanddarkareasmaycause
accidents.
• Donotoperateelectricaldevicesorvideoscopetoolinexplosiveatmospheres,suchasin
thepresenceofflammableliquids,gases,orheavydust.Electricaldevicesorvisual
inspecontoolscreatesparkswhichmayignitethedustorfumes.
• Donotusethevideoscopearoundcorrosivechemicals.
• Keepbystanders,children,andvisitorsawaywhileoperangvisualinspecontool.Donot
letvisitorscontacttheunit.

3

PersonalSafety
• Stayalert,watchwhatyouaredoingandusecommonsense.Donotusevideo
scopewhileredorundertheinfluenceofdrugs,alcohol,ormedicaons.A
momentofinaenonwhileoperangtoolsmayresultinseriouspersonalinjury.
• Donotoverreach.Keepproperfoongandbalanceatallmes.Properfoongandbalance
enablesbeercontrolofthetoolinunexpectedsituaons.
• Usesafetyequipment.Alwaysweareyeprotecon(usersandbystanders).Dustmask,non‐
skidsafetyshoes,hardhat,orhearingproteconmustbeusedforappropriatecondions.
• Useproperaccessories.Donotplacethisproductonanyunstablecartorsurface.
• Theproductmayfallcausingseriousinjurytoapersonorseriousdamagetotheproduct.
Preventobjectandliquidentry.Neverspillliquidofanykindonthevideodisplayunit.
Liquidincreasestheriskofelectricalshockanddamagetotheproduct.
• Donotusethisdeviceforpersonalormedicaluse/inspeconinanyway.
• Theunitisnotshock‐resistant.Donotuseitasahammerordropit.


4
Toreducetheriskofseriousinjury,readtheseprecautionscarefullybeforeusingthebattery
chargerorbattery.
A/CPowerSupply
• DonotprobeA/Cpowersupplywithconducveobjects.Shorngofbaeryterminals
maycausesparks,burnsorelectricalshock.
• DonotuseA/Cpowersupplyifdamaged.AdamagedA/Cpowersupplyincreasesthe
riskofelectricalshock.
• Useanappropriatepowersource.Donotaempttouseastep‐uptransformeroran
enginegenerator.DoingsomaycausedamagetotheA/CpowersupplyoftheBK7000
resulnginelectricalshock,fireorburns.
• DonotallowanythingtocovertheA/Cpowersupplywhileinuse.Propervenlaonis
requiredforcorrectoperaonoftheA/Cpowersupply.Allowaminimumof4”(10cm)
ofclear‐ancearoundthechargerforpropervenlaon.
• UnplugtheA/Cpowersupplywhennotinuse.Reducestheriskofinjurytochildren

5
anduntrainedpersons.
• UnplugtheA/Cpowersupplyfromoutletbeforeaempnganymaintenanceorcleaning.
Reducestheriskofelectricalshock.
• DonotuseA/Cpowersupplyinadamp,wetorexplosiveenvironment.Donotexpose
torain,snowordirt.Contaminantsandmoistureincreasetheriskofelectricalshock.
• DonotopentheA/CpowersupplyorBK7000housings.Haverepairsperformedonlyat
authorizedlocaons.(SeeSnap‐onServiceCenter).
• DonotcarrytheA/Cpowersupplybypowercord.Reducestheriskofelectricalshock.

6
BatterySafety
• ThebaeriesintheBK7000areNOTuserreplace‐able.CallyourServiceCenterifyou
believetheBK7000baeryisinneedofservice.
• ProperlydisposeoftheBK7000.Exposuretohightemperaturescancausethebaeryto
explode,sodonotdisposeofinafire.Somecountrieshaveregulaonsconcerning
baerydisposal.Pleasefollowallapplicableregulaons.
• Chargebaeryintemperaturesabove32degreesF(0degreesC)andbelow113degrees
F(45degreesC).StoreBK7000intemperaturesabove‐4°F(‐20°C)andbelow140°F
(60°C).Storageforalongmeattemperaturesabove95°F(35°C)willreducethe
capacityoftheBK7000.ItisrecommendedtostoretheBK7000at77°F(25°C)to
maximizebaerylife.Propercarewillpreventseriousdamagetothebaery.Improper
careofthebaerymayresultbaeryleakage,electricalshockandburns.


7
BatterySafetycontinued
• IftheBK7000isdamaged,donotplugtheA/Cpowersupplyintoit.Donotaempttocharge.
• NeverdisassembletheBK7000unit.Therearenouser‐serviceablepartsinside.
• DisassemblingtheBK7000maycauseelectricalshockorpersonalinjury.
AvoidcontactwithfluidsleakingfromtheBK7000unit.Fluidsmaycauseburnsorskinirritaon.
Thoroughlyrinsewithwaterincaseofaccidentalcontactwithfluid.Consultdoctoriffluidcomes
intocontactwitheyes.


8
VideoScopeUseandCare
• Usevideoscopeonlyasdirected.Donotoperatetheinspectionunitunlesstheowner’s
manualhasbeenreadandpropertraininghasbeencompleted.
• Donotimmersethehandhelddisplayunitinwater.Storeinadryplace.Suchmeasures
reducetheriskofelectricshockanddamage.Theimagerheadandthecablearewaterresis‐
tantwhentheunitisfullyassembled,butthevideodisplayunit/handleisnot.
• Donotusethecameraifcondensationformsinsidethelens.Letthewaterevaporatebefore
usingagain.
• DonotusetoolifON/OFFswitchisnotproperlyworking.Anytoolthatcannotbecontrolled
withtheswitchisdangerousandmustberepaired.
• Storeidleequipmentoutofthereachofchildrenandotheruntrainedpersons.
Equipmentisdangerousinthehandsofuntrainedusers.
• Maintainthevideoscopewithcare.Properlymaintainedtoolsarelesslikelytocause
injury.

9
• Ifunitisdropped,checkforbreakageofparts,andanyotherconditionsthatmayaffect
thetool’soperation.Ifdamaged,havethetoolser‐vicedbeforeusing.Manyaccidents
arecausedbypoorlymaintainedtools.
• Useonlyaccessoriesthatarerecommendedbythemanufacturerforyourtool.
Accessoriesthatmaybesuitableforonetoolmaybecomehazardouswhenusedon
anothertool.
• DryyourhandsbeforeturningtheunitONorOFF.
• Protectagainstexcessiveheat.Theproductshouldbesituatedawayfromheatsources
suchasradiators,heatregisters,stovesorotherproducts(includingamplifiers)that
produceheat.Donotusetheunitnearmovingmachineryorareaswherethe
temperaturewillexceed140°F(60°C).


10
Service
• Donotaempttotakeanypiecesofthisunitapartunlessdirectedtobythismanual.
• Followinstruconsforchangingaccessories.Accidentsarecausedbypoorlymaintained
equipment.
• Providepropercleaning.Donotuseacetonetocleantheunit.Instead,useisopropanol.
• GentlycleantheLCDwithadrycloth.
• Stopusingtheunitifitstartssmokingoremit‐ngnoxiousfumes.
• Refervideoscopetoqualifiedservicepersonnel
underanyofthefollowingconditions:
– Ifliquidhasbeenspilledorobjectshavefallenintoproduct;
– Ifproductdoesnotoperatenormallybyfollowingtheoperanginstrucons;
– Iftheproducthasbeendroppedordamaged inanyway

11
– Whentheproductexhibitsadisnctchangeinperformance.
Ifyouhaveanyquestionsregardingtheserviceorrepairofthismachine,callorwritetothe
appropriaterepaircenterlocation(see"Snap‐onServiceCenterLocations”).
Technicalquestionscanbedirectedtoourtollfreenumberat1‐877‐765‐7665Mondaythrough
Friday6:30amto5:00pmCentralTime(U.S.customersonly).



12
SpecificSafetyInformation
Readthisoperator'smanualcarefullybeforeusing.Failuretounderstandandfollowthecontentsof
thismanualmayresultinelectricalshock,fireand/orseverepersonalinjury.

FCCStatement
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwo
conditions:
1. Thisdevicemaynotcauseharmfulinterference.
2. Thisdevicemustacceptanyinterferencereceived,includinginterferencethatmaycause
undesiredoperaon.NOTE!Thisequipmenthasbeentestedandfoundtocomplywith
thelimitsforClassAdigitaldevices,pursuanttoPart15oftheFCCrules.Theselimits
aredesignedtoprovidereasonableproteconagainstharmfulinterferenceinaresidenal
installaon.Thisequipmentgeneratesusesandcanradiateradiofrequencyenergyand,
ifnotinstalledandusedinaccordancewiththeinstrucons,maycauseharmful

13
interferencetoradiocommunicaons.However,thereisnoguaranteethatinterference
willnotoccurinaparcularinstallaon.Ifthisequipmentdoescauseharmfulinterference
toradioortelevisionrecepon,whichcanbedeterminedbyturningtheequipmentoffand
on,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing
measures:
– Reorientorrelocatethereceivingantenna.
– Increasetheseparaonbetweentheequipmentandreceiver.
– Consultthedealerforhelp.
UseofshieldedcableisrequiredtocomplywithClassAlimitsinSubpartBofPart15oftheFCCrules.
Donotmakeanychangesormodificationstotheequipment.
ThisdevicecomplieswithPart15oftheFCCRulesandwithIndustryCanadalicense‐exempt
RSSstandard(s).Operationissubjecttothefollowingtwoconditions:(1)Thisdevicemaynot
causeharmfulinterference,and(2)Thisdevicemustacceptanyinterferencereceived,
includingreferencethatmaycauseundesiredoperation.Note:Changesormodificationnot

14
expresslyapprovedbythepartyresponsibleforcompliancecouldvoidtheuser'sauthorityto
operatetheequipment.
ThisClassAdigitaldevicecomplieswithCanadianICES‐003.


15
Video Scope Safety
• Donotplacetoolintoanythingoranywherethatmaycontainaliveelectricalcharge.
• FORWALLS:Forinspecnginsidewalls,besuretoshutoff thecircuitbreakertothe
wholehousebeforeusingthetoolbehindanyofthewalls
• FORPIPES:Ifyoususpectametalpipecouldcontainanelectricalcharge,haveaqualified
electriciancheckthepipebeforeusingthetool.Groundcircuits,insomecases,canbe
returnedtocastironpipesandcausethemtobecharged.
• FORAUTOMOBILES/HEAVYEQUIPMENT/MOTORSPORTS:Besuretheautomobile,heavy
equipmentormotorsportequipmentisnotrunningduringinspecon.Metalandliquid
underthehoodmaybehot.Donotgetoilorgasontheimagerhead.Exposureto
petroleum‐basedsubstanceswilleventuallydegradetheimagerheadcovering.
GENERALUSE:Donotuseanywheretheunitmaycomeintoexposurewithhazardouschemi
cals,
electricalchargesormovingparts.Suchsituaonsmayresultinseriousinjuryordeath.


16

ProductDescription
TheBK7000digitalhighdefinionvideoscopeprovidestrueHDvideothankstoithigh
resoluonimagerpairedwiththehighresoluonLCDscreen.The5”screenmakesany
underthehoodjobeasytosee…TheBK7000featuresacapacivetouchscreendisplay
anddualviewpictureinpictureimager…


17
IncludedwiththeBK7000:
1. BK7000handheldunit
2. 5.5mmDualviewHDPiPimager(aachedtounit)
3. Quickstartguide
4. Powersupplywith4interchangeablepowersourceadapters
5. USB‐CtoUSB‐Apowercord
6. BK7000travelcase


18
Specifications
GettingStarted
Descripon
TheBK7000videoscopedisplayslivecolorvideofromanimagingsensorandlightingsource
connectedtoaflexibledualviewimagercable.Theunitiscapableofcapturingstillimagesandfull‐
motionvideo,alongwithaudio.Itcanbeusedtolookintotightspotsandbeambackreal‐timevideo
toatruehighdefinitioncolorLCD.


19
Specificaons
TotalWeight.....................................2.25lbs(800g)
DISPLAYUNIT:
PowerSupply..................................InternalLi‐IonBattery,3.7V,2600mAh,9.6watt‐hours
Chargetime.....................................1.25hours
ChargerInput...................................5VDC,1.Amp
Length..............................................1.28"(32.5mm)
Width................................................6.75"(171.4mm)
Height...............................................3.77"(100mm)
Built‐inCamera................................1280x720HDFixedfocust
ScreenResolution...........................1280x720withLEDbacklight
5.0"(12.7cm)CapacitiveColorTouchscreenLCD
AudioInput.......................................Built‐inMicrophone
AudioOutput....................................Built‐inSpeaker

20
DISPLAYUNITSpecificaons:

Run‐timeonbattery........................3hours(approximately)
Wirelessinterface...........................Wi‐Fi‐802.11n
Wirelessrange................................50ft(10m)
OperatingTemperature...................32°Fto86°F(0°Cto30°C)
(Batterieswillnotchargeabove113°F(45°C))
StorageTemperature......................‐4°Fto140°F(‐20°Cto60°C)
77°F(25°C)isidealformaximumbatterylife.
RelativeHumidity.............................5%to90%non‐condensing

