Socket CHS Series 7 User manual

Cordless Hand Scanner Series 7
with Bluetooth®Wireless Technology
User’s Guide

11/2008 Document # 6410-00233 R
COPYRIGHT NOTICE
Copyright © 2008 Socket Mobile, Inc. All rights reserved.
Socket, the Socket logo, Battery Friendly, Cordless Hand Scanner
with Bluetooth Wireless Technology, SocketCare, SocketScan,
Mobility Friendly, Connect!Agent, SoMo, and Error Proof
Protocol are trademarks or registered trademarks of Socket
Mobile, Inc. Bluetooth and the Bluetooth logos are registered
trademarks owned by Bluetooth SIG, Inc., U.S.A. and licensed to
Socket Mobile, Inc. All other brand and product names are
trademarks of their respective holders.
The Cordless Hand Scanner includes technology licensed under
United States Patent Numbers 5,902,991, 7,429,000 B1 and
D526,320 S.
Reproduction of the contents of this manual without the
permission of Socket Mobile is expressly prohibited. Please be
aware that the products described in this manual may change
without notice.
Feel free to contact Socket Mobile at:
Socket Mobile, Inc.
39700 Eureka Drive
Newark, CA 94560-4808
USA
Other than the above, Socket Mobile can assume no
responsibility for anything resulting from the application of
information contained in this manual.
Please refrain from any applications of the Socket Mobile
Cordless Hand Scanner that are not described in this manual.
Please refrain from disassembling the Cordless Hand Scanner.
Disassembly of this device will void the product warranty.
You can track new product releases, software updates and
technical bulletins by visiting the Socket Mobile website at:
www.socketmobile.com.

TABLE OF CONTENTS
COPYRIGHT NOTICE 2
1 | INTRODUCTION 6
Scanner Versions 6
About the Software 6
Package Contents 7
System Compatibility Requirements 7
Product Registration 8
SocketCare™ Service Program 8
Accessories 8
Additional Documentation 8
Hardware Features 9
2 | HARDWARE PREPARATION 11
Installing Batteries and Attaching the Tether 11
Assembling the AC Adapter 13
Charging the Scanner 13
3 | SETUP FOR WINDOWS MOBILE 14
STEP 1: Uninstall Other Scanning Software 15
STEP 2: Install SocketScan and Connect!Agent 16
STEP 3: Start SocketScan 19
STEP 4: Configure Scanner Settings 19
STEP 5: Turn on the CHS 21
STEP 6: Connect Device to CHS 21
STEP 7: Start Your Application 23
STEP 8: Scan Data into Your Application 24
Disconnecting 25
Symbology Selector 26
Scanner Settings 27
Scan Demo 28
Connect!Agent Utility 29
Dual Device Support 30
4 | SETUP FOR THE INTERMEC CK30 31
STEP 1: Install Connect!Agent and SocketScan 32
STEP 2: Turn on the CHS 33
STEP 3: Start SocketScan 34
STEP 4: Connect CK30 to CHS 34
STEP 5: Open Your Application 36
STEP 6: Scan Data into Your Application 36
Disconnecting 37
3

Symbology Selector 38
Prefixes/Suffixes 39
Power Settings 40
5 | SETUP FOR WINDOWS XP AND VISTA 41
STEP 1: Uninstall Other Scanning Software 42
STEP 2: Install the Software 42
STEP 3: Turn on the CHS 44
STEP 4: Start Bluetooth on Your Computer 45
STEP 5: Configure Bluetooth Settings 45
STEP 6: Start SocketScan 52
STEP 7: Configure Scanner Settings 52
STEP 8: Connect Computer to CHS 54
STEP 9: Open Your Application 55
STEP 10: Scan Data into Your Application 55
Disconnecting 56
Scanner Settings 57
Advanced Bluetooth Settings 58
Remote Trigger Button 61
Symbology Selector 62
Version Information 63
Dual Device Support 63
6 | SETUP FOR PALM OS 64
STEP 1: Uninstall Other Scanning Software 65
STEP 2: Install SocketScan Software 65
STEP 3: Turn on the CHS 67
STEP 4: Start SocketScan 67
STEP 5: Connect CHS to PDA with Bluetooth 68
STEP 6: Open Your Application 70
STEP 7: Scan Data into Your Application 71
Scanner Settings 72
Symbology Selector 74
Scan Test 75
7 | SETUP FOR RIM BLACKBERRY 76
STEP 1: Install SocketScan Software 77
STEP 2: Turn on the CHS 78
STEP 3: Pair Smartphone with CHS 78
STEP 4: Start SocketScan 79
STEP 5: Connect Smartphone to CHS 79
STEP 6: Open Your Application 79
STEP 7: Scan Data into Your Application 80
Disconnecting 80
Symbology Selector 81
4

5
Scanner Settings 81
CS Bonding 82
Version Information 82
APPENDICES
A SPECIFICATIONS 83
B SAFETY AND USAGE TIPS 87
C BAR CODE LABEL SPECIFICATIONS 90
D ENABLING OR DISABLING SYMBOLOGIES 92
E DECODE ZONE 94
F RESTORING FACTORY DEFAULTS 97
G TROUBLESHOOTING 98
H TECHNICAL SUPPORT 102
LIMITED WARRANTY 103
REGULATORY COMPLIANCE 107

1 | INTRODUCTION
Thank you for purchasing the Socket Cordless Hand Scanner (CHS)
Series 7 with Bluetooth Wireless Technology. The CHS combines
the power of bar code scanning with the convenience of
Bluetooth wireless technology so you can collect bar coded data
without being tied to your mobile or desktop computer. Compact,
lightweight, and ergonomically designed to fit comfortably in a
hand, the CHS is ideal for high volume data collection
applications.
SCANNER VERSIONS
The CHS Series 7 includes three
versions of the scanner.
•The entry-level CHS 7E uses
linear CMOS imaging
technology.
•The mid-level CHS 7M has a
Class 1 laser scanner.
•The performance level CHS 7P
features a Class 2 laser scanner
and a ruggedized construction.
ABOUT THE SOFTWARE
SocketScan™enters scanned data directly into any
Windows, Palm or RIM OS program as if the data were
manually typed. Included is a utility that enables you
to configure Prefix/Suffixes, sounds, and other special
settings for the CHS.
Connect!Agent™software for Windows Mobile automates
Bluetooth by setting up and managing the wireless connection.
ActivePairing™for Windows Mobile, XP and Vista enables you to
connect to a specific host computer by scanning a special bar code.
Error Proof Protocol™ensures reliability of data collection by
confirming in real time that scanned data has reached the host
computer. This minimizes the risk of data loss from a dropped
connection.
6

PACKAGE CONTENTS
•Cordless Hand Scanner with Bluetooth Wireless Technology
•AC charging adapter with international plugs
•2 NiMH rechargeable AAA batteries
•Lanyard with retractable tether
•Software Installation CD
•Booklets with copyright, warranty, and regulatory compliance
SYSTEM COMPATIBILITY REQUIREMENTS
Windows Mobile:
•Any of the following Windows Mobile versions:
−Windows Mobile 2003, 2003SE or 5.0 for Pocket PC/Pocket PC
Phone
−Windows Mobile 6.0 or 6.1 Classic/Professional
•Bluetooth radio
•Either of the following Bluetooth stacks:*
−Broadcom 1.5 or later
−Microsoft Bluetooth stack for Windows Mobile
−Stonestreet One 1.2.4 (Build 1783)
•Software installation requires a Windows-based host PC with
the appropriate synchronization software (available free
from the Microsoft website).
Windows CE.NET: The CHS Series 7 is compatible with the
Intermec CK30 mobile computer.
Windows XP and Windows Vista:
•Windows XP Professional/ Tablet PC (SP1, SP2, SP3) or
Windows Vista Business/Ultimate (SP1)
•Bluetooth radio
•Bluetooth stack from Microsoft, Toshiba or Broadcom
Palm OS:
•Palm OS 5.2 or later
•Bluetooth wireless technology
•Software installation requires Palm Desktop Software on a
host computer.
CHAPTER 1: INTRODUCTION 7

RIM BlackBerry:
•Any of the following devices:
−Curve 83xx
−Pearl 81xx
−Bold 9000
For instructions on using the CHS with a smartphone running
Symbian OS, visit: www.socketmobile.com/support/downloads
For software updates, visit: www.socketmobile.com/support/downloads/
PRODUCT REGISTRATION
Socket highly recommends that all customers register their products.
Registered users receive priority for technical support and can choose
to obtain special offers, upgrades, and new product information.
Register online at: support.socketmobile.com
SOCKETCARE™SERVICE PROGRAM
The SocketCare service program is available for the Cordless
Hand Scanner. For more information, please visit:
www.socketmobile.com/support/socketcare/
ACCESSORIES
Various accessories are available for the CHS, including:
•Charging cradle
•Car charger
•Scanning Companion USB Bluetooth adapter
•Accessory pack with lanyard, pull reel, and batteries
•Mobile Power Pack (available in Americas and Asia Pacific)
For more information, please visit:
www.socketmobile.com/products/accessories/
ADDITIONAL DOCUMENTATION
Socket has also published Quick Start Guides and an Advanced
Programming Guide, which includes information on enabling
special scanning settings (e.g., raw data mode). Download them
online at: www.socketmobile.com/support/downloads/
8

HARDWARE FEATURES
Product Diagram
Status indicator LED
Scanner exit
window
Trigger button
Power button
Battery cover
Stylus tip
Rechargeable Batteries and AC Adapter
Charge the internal batteries by using the included AC adapter.
The adapter rating is 5V, 2A, positive pole center. New, fully
charged batteries last ~19 hours to scan 14,000 bar codes.
WARNING: Charge ONLY NiMH batteries in the CHS. Damage may
result if other battery types are charged. Do not store the CHS
for more than 30 days with the batteries installed.
The red Battery Status LED will not function properly if standard
AAA non-rechargeable batteries are being used.
Besides the included AC adapter, you can also recharge the CHS
by using any of the following:
•Socket charging cradle for the CHS
•Socket car charger
•Socket Mobile Power Pack (available in Americas and Asia
Pacific)
•AC and DC adapters of the Socket SoMo 650 handheld
computer, as well as those of most recent Pocket PCs from
Casio, Fujitsu, HP, and Toshiba
Socket charging accessories are available online at:
www.socketmobile.com/products/accessories
CHAPTER 1: INTRODUCTION 9

Status Indicator LED
LED LED Activity Meaning
1 blink per second Bluetooth radio is on, but not
connected.
Bluetooth
Status
(Blue)
1 blink per 3 seconds Bluetooth connection.
Good Read
(Green)
On Data successfully scanned and
transmitted to host device.
Blinking 20% battery capacity remaining
On 10% battery capacity remaining
Battery
Status
(Red) Off Off or Good Battery status
Status Indicator Beeps
Beep Pattern Meaning
2 beeps (low-high) Power on
2 beeps (high-low) Power off
1 beep
Bluetooth connection to host device has begun
OR data has been successfully scanned and sent
to host device*
2 beeps
(same tone) Bluetooth connection to host device has ended
3 long beeps Cable disconnected from wrist unit
5 beeps CRS has detected an error and reset
*Good scan confirmation beep is enabled only in packet mode (default).
Touch Screen Stylus
The CHS features a stylus tip in the tail of the
CHS that you can use on Pocket PC and other
device touch screens.
WARNING: Do not use the stylus if
damaged. A damaged stylus may scratch
the display screen of your computer.
The stylus does not work with tablets using Active Matrix displays.
10

2 | HARDWARE PREPARATION
INSTALLING BATTERIES AND ATTACHING THE TETHER
1. Use a coin or screwdriver to unlock and remove the battery
cover. Turn the lock underneath the scanner to a horizontal
position.
2. Remove the battery cover.
The Bluetooth Device Address is printed on a label
inside the battery compartment. Note the address to
help identify your CHS if you plan to use it within
range of other CHS devices.
3. If desired, attach the tether. Wrap the string loop around the
inside part of the lock.
CHAPTER 2: HARDWARE PREPARATION 11

4. Install the batteries as indicated by the +/- symbols.
WARNING: Do not install the batteries incorrectly.
Damage may result.
5. Replace the battery cover and turn the lock to a vertical
position to secure it.
6. If desired, attach the tether to a lanyard or belt.
12

ASSEMBLING THE AC ADAPTER
The AC adapter included with the CHS includes four
international plugs. Simply find the correct plug for your region
and slide it into the head of the adapter.
CHARGING THE SCANNER
Use the included AC adapter to charge the Cordless Hand
Scanner. Alternatively, you can use a charging cradle, car
charger, or the Mobile Power Pack (all available separately).
The scanner must be fully charged before its first use. The LED
will emit a solid red light while charging, and turn green when
the batteries are fully charged.
WARNING: Do not attempt to charge alkaline
batteries — this may cause alkaline batteries to
leak and damage the CHS.
The red Battery Status LED will not work properly if
standard AAA alkaline batteries are being used.
To purchase charging accessories, please visit:
www.socketmobile.com/products/accessories/
CHAPTER 2: HARDWARE PREPARATION 13

3 | SETUP FOR WINDOWS MOBILE
This chapter explains how to install and use
the Cordless Hand Scanner (CHS) with the
SoMo 650 or other Bluetooth enabled Pocket
PC or mobile computer running Windows
Mobile.
Before you begin the instructions in this
chapter, make sure you have installed the
batteries (and tether, if desired), and charged
the scanner, as described in Chapter 2,
“Hardware Preparation.”
Setup Summary
STEP 1: Uninstall other scanning software.
STEP 2: Install SocketScan and Connect!Agent.*
STEP 3: Start SocketScan.
STEP 4: Configure scanner settings.
STEP 5: Turn on the CHS.
STEP 6: Connect CHS to host device.
STEP 7: Start your application.
STEP 8: Scan bar codes.
Application Features
Symbology Selector
Scanner Settings
Scan Demo
Connect!Agent Utility
*Note: Software installation is not required for the Socket SoMo
650 handheld computer. However, you may want to update the
software if a more recent version of SocketScan or
Connect!Agent is available.
14

STEP 1: UNINSTALL OTHER SCANNING SOFTWARE
Remove any bar code scanning software already installed on
your device.
Note: The SocketScan software pre-installed on the SoMo 650
cannot be uninstalled but can be upgraded.
OPTION 1: Uninstall Directly from the Pocket PC
1. Make sure the bar code scanning software is not running.
2. Tap Start | Settings. Tap on the System tab or Control
Panel.
3. Tap on the Remove Programs icon.
4. Use the utility to remove the software.
OPTION 2: Uninstall with the ActiveSync
1. Make sure the bar code scanning software is not running.
2. Use ActiveSync and a serial/USB cable or cradle to make an
active connection between your device and a host PC.
3. On the host PC, open Microsoft ActiveSync.
4. Click Tools | Add/Remove Programs.
5. Use the utility to remove the software.
CHAPTER 3: SETUP FOR WINDOWS MOBILE 15

STEP 2: INSTALL SOCKETSCAN AND CONNECT!AGENT
Follow these instructions to install SocketScan and Connect!Agent
software into your Pocket PC. Both are required to use the CHS.
1. Use a serial/USB cable or cradle and the appropriate
synchronization software (ActiveSync or the Windows Mobile
Device Center) to make an active connection between your
device and a host PC.
Synchronization software is available free from the Microsoft
website.
2. Insert the installation CD into your host PC.
3. Use My Computer or Windows Explorer to access your CD-
ROM drive. In the CD, click on SETUP.EXE.
4. The SocketScan Setup Center will appear in your web browser.
Read the first page and click Installation in the left margin.
16

5. In the SocketScan installation page, in the Windows CE
section, click Install In the first paragraph.
6. Your web browser will present a series of dialogs.
Internet Explorer:
•In the File Download –Security Warning dialog, click Run.
•In the second warning dialog, click Run.
•Internet Explorer will download the file.
Firefox:
•In the file opening dialog, click Save File.
•Firefox will download the file.
•In the Downloads list, next to SocketScanCE.exe, click Open.
•In the warning dialog, click OK to continue.
7. The InstallShield Wizard for SocketScan Software will
automatically launch. Follow the wizard to install the software.
CHAPTER 3: SETUP FOR WINDOWS MOBILE 17

8. After installing the software, a dialog on your Pocket PC will
direct you to soft reset. Tap ok.
9. Remove your device from the cable/cradle and perform a soft
reset by pressing the reset button. If you skip this step, some
icons may not appear correctly.
10.Install Connect!Agent by returning to the SocketScan Setup
Center. In the Installation page, scroll down to Connect!Agent
– Mobile Devices section and click on the Connect!Agent
software link there.
IMPORTANT! Both SocketScan and Connect!Agent
software must be installed.
18

STEP 3: START SOCKETSCAN
1. Tap Start | Programs | SocketScan folder | SocketScan.
2. When SocketScan is running a SocketScan icon will appear at
the bottom of the Today screen.
Icon Meaning
No bar code scanner detected
CHS is connected and ready to scan
STEP 4: CONFIGURE SCANNER SETTINGS
1. Tap the SocketScan icon at the bottom of the Today screen.
In the pop-up menu, tap Settings.
2. The Scanner Settings utility will appear. Tap on the CS tab at
the bottom of the screen.
CHAPTER 3: SETUP FOR WINDOWS MOBILE 19

3. Check the box Enable Cordless Scanner support. IMPORTANT!!!
4. Tap on the CS HW tab. Enter the following settings:
•Good Read Indicator: Select how you would like the CHS
to indicate that it has successfully read data.
•Battery Level: When the scanner is connected, a progress
bar displays this advanced feature.
•Disable Auto Power Off mode:
CAUTION: Selecting this option will disable the Auto
Power Off mode and can result in complete
discharge of the CHS batteries. Use with caution.
5. After entering settings, tap ok to save the changes.
20
