SINGLE PHASE DIN RAIL ENERGY METER
COUNTIS M13
MANUAL V1.1

CORPORATE HQ CONTACT:
SOCOMEC SAS, 1-4 RUE DE WESTHOUSE, 67235 BENFELD, FRANCE
http://www.socomec.com
Statement
All rights reserve . Without the written permission of SOCOMEC, the contents of any pages an chapters
in this manual shall not be copie or repro uce or isseminate in any form. Otherwise, all
consequences shall be borne by the violator.
SOCOMEC reserves all legal rights.
SOCOMEC reserve the right to mo ify the pro uct specifications escribe in this manual without prior
notice. Before or ering, please contact our company or local agent for the latest specifications of this
pro uct.

CORPORATE HQ CONTACT:
SOCOMEC SAS, 1-4 RUE DE WESTHOUSE, 67235 BENFELD, FRANCE
http://www.socomec.com
Contents
Part 1 Product overview
1.1 Brief Intro uction --------------------------------------------------------------------------------------------------------------1
1.2 Pro uct characteristics -------------------------------------------------------------------------------------------------------1
1.3 Application ----------------------------------------------------------------------------------------------------------------------1
Part 2 General Specifications
2.1 Specifications-------------------------------------------------------------------------------------------------------------------2
2.2 Accuracy -------------------------------------------------------------------------------------------------------------------------2
2.3 RS485 Communication-------------------------------------------------------------------------------------------------------3
2.4 Environment--------------------------------------------------------------------------------------------------------------------3
2.5 Dimensions---------------------------------------------------------------------------------------------------------------------4
2.6 Wiring Diagram----------------------------------------------------------------------------------------------------------------4
Part 3. Operation Instructions
3.1 Display an Operation-------------------------------------------------------------------------------------------------------5
3.1.1Display -------------------------------------------------------------------------------------------------------------------------5
3.1.2 Button Definition-----------------------------------------------------------------------------------------------------------5
3.2 Measurement-----------------------------------------------------------------------------------------------------------------5
3.3 Setting by button--------------------------------------------------------------------------------------------------------------9
Part 4. Modbus re ister Map-------------------------------------------------------------------------------------------------14

- 1 -
Part 1 Product overview
1.1 Brief Intro uction
COUNTIS M13 energy-meter “with a white back-lighte LCD screen for perfect rea ing” are use to
measure single-phase like resi ential, utility an In ustrial application. The unit measures an isplays
various important electrical parameters; provi e a RS485 communication port for remote rea ing an
monitoring. Bi- irectional energy measurement makes the unit a goo choice for solar PV energy metering.
The compact esign an DIN rail installation provi es an easy an economical solution for your metering
eman .
COUNTIS M13 equippe with 2 channels of pulse output. The pulse constant, pulse wi th an output unit
is configurable. Built-in interfaces provi es RS485 Mo bus RTU outputs, RS485 high-spee communication
supports the highest communication rate of 9600 bps, it is an i eal choice for power energy monitoring.
Configuration is passwor protecte .
1.2 Pro uct characteristics
Measures kWh, Kvarh, KW, Kvar, KVA, PF, Hz, m , V, A, etc.
Bi- irectional measurement IMP & EXP
Two pulse outputs
RS485 Mo bus
100A irect connection
1.3 Application
COUNTIS M13 is a multi-functional single phase energy meter, esigne for power system, public facilities,
in ustrial applications an resi ential power monitoring nee s. It can also be use in AC charging pile,
solar photovoltaic an other occasions. Its complete communication function makes it very suitable for
real-time power monitoring systems.

- 2 -
Part 2 General Specifications
2.1 Specifications
Voltage： Rate Voltage ( Un) : 230V AC
Operational voltage：±20% of Un
Current： Rate Current (Ib)：5A
Max Current (Imax)：100A
Over current withstan : 30 Imax for 0.01s
Operational frequency：Rate ：50/60Hz
Range：45-65 Hz
Insulation capabilities： AC voltage withstan 4KV/1min
Impulse voltage withstan 6kV – 1.2µS waveform
Internal Power Consumption：≤ 2W.
Pulse Output 1：Configurable
Pulse Output 2：Fixe 1000imp/kWh
Display：LCD with backlit
Max rea ing：999999.9 kWh
2.2 Accuracy
Voltage：0.5%
Current：0.5%
Frequency：0.2%
Power Factor：1%
Active Power：1%
Reactive Power：±1%

- 3 -
Apparent power：±1%
Active energy：Class1
Reactive energy：Class2
2.3 RS485 Communication
Bus Type：RS485
Communication Protocol：Mo bus RTU
Bau rate：1200/2400/4800/9600bps
Mo bus A ress：1-247
Bus loa ：64pcs
Communication istance：1000m
Parity：EVEN /ODD/NONE
Data bit：8
Stop bit：1
2.4 Environment
Operating humi ity： ≤90%
Storage humi ity： ≤95%
Operating temperature： -25℃~+55℃
Storage temperature： -40℃~+70℃
Stan ar ： IEC 63052-11/IEC62053-21
Accuracy： Class 1
Installation category： CAT II
Protection against penetration of ust an water: IP51（in oor）
Insulating encase meter of protective class: II
Altitu e： ≤2000m

- 4 -
2.5 Dimensions
Height: 63 mm
Wi th: 36 mm
Length: 99 mm
2.6 Wiring Diagram

- 5 -
Part 3. Operation Instructions
3.1 Display an Operation
3.1.1 Display
When the meter is powere on, the meter will initialize an o self-checking
Display as following:
1
Full screen
2
Software version
3 Mo bus A ress
4 Bau rate
5
Total active energy(kWh)
3.1.2 Button Definition
In measurement mo e: Click the button, the LCD isplay will scroll
the measurements；
In Set mo e: Click the button to Switch the menu of the same level
or increase the number of igits; Long press to get out of set-up
menu an return to the menu of the previous level.
In measurement mo e, Click the button: unlock/lock,
communication setting function; long press to enter setting mo e;
In setting mo e, Click the button to move cursor (The cursor is the
number bit that is flickering in setting state); Long press for the
menu item selection confirmation an parameter mo ification
confirmation.
3.2 Measurement
Click the button, the LCD isplay will scroll the measurements.
Total kWh Import kWhExport kWhResettable kWhTotal KVarhImport KVarhExport kVarh

- 6 -
Resettable kVarh Max. Power Deman Voltage CurrentWVarVAPower factor 
FrequencyPulse ConstantMo bus ID Bau rate  Continuous Running Time
Item Display Description
1 Total kWh
Example:70.00kWh
2 Import kWh
Example: 50.00kWh
3 Export kWh
Example: 20.00kWh
4 Resettable kWh
Example: 2.68kWh
5 Total KVarh
Example: 10.00kVarh
6 Import KVarh
Example: 5.00kVarh

- 7 -
7 Export KVarh
Example: 5.00kVarh
8 Resettable kVArh
Example: 1.49kVarh
9 Max. Power Deman
Example: 6930W
10 Voltage
Example: 229.8V
11 Current
Example: 30.156A
12 Active Power (W)
Example: 4700W
13 Reactive Power (Var)
Example: 1030Var

- 8 -
14 Apparent power
Example: 4811VA
15 Power factor
Example: 1.000
16 Frequency
Example: 49.99Hz
17 Pulse Constant
Example: 1000
18 Mo bus ID
Example: 001
19 Bau rate
Example: 9600
20 Continuous Running Time

- 9 -
3.3 Setting by button
To get into Set-up Mo e, the user nee s to press the “Enter “button for 3 secon .
Below parameters can be set via the buttons.
Item Display Description
1 Setting successfully, it isplays “goo ”
2 Setting faile , it isplays ” err”
3 Passwor : The user shall enter the
passwor to enter the Set-mo e
Default：1000
4 Mo bus ID:
Default： 001
Ranges: 001~247
4-1
Press button to enter the selection
routine. The current setting will be flashing.
Use buttons to choose Mo bus
A ress (001 to 247). Press to
confirm the new ID.

- 10 -
5 Bau Rate
Default: 2400bps
Options: 1200, 2400, 4800, 9600bps.
5-1
Press button to enter the selection
routine. The current setting will be flashing.
Use buttons
to choose Bau rate. Press
to confirm the new Bau rate.
6 Parity
Default: None
Options：None, Even, O
6-1
Press button to enter the selection
routine. The current setting will be flashing.
Use buttons to choose Parity. Press
to confirm the new Parity.
7 Pulse Output 1
Default: kWh
Options ：
kWh / KVarh / Imp. Kwh /
Exp.kWh / Imp.kVarh / Exp.kVarh
7-1
Press button to enter the selection
routine. The current setting will be flashing.
Use buttons to choose Pulse Output.
Press to confirm the Pulse Output.

- 11 -
8 Pulse Constant
Default: 1000
Options: 1000 / 100 / 10 / 1
8-1
Press button to enter the selection
routine. The current setting will be flashing.
Use buttons to choose Pulse Constant.
Press to confirm the Pulse Constant.
9 Pulse Duration
Default: 100mS
Options: 200 / 100 / 60ms
9-1
Press button to enter the selection
routine. The current setting will be flashing.
Use buttons to choose Pulse uration.
Press to confirm the Pulse uration.
10 Demand Inte ration Time
Default: 15 minutes
Options: 0 / 5 / 10 / 15 / 30 / 60
10-1
Press button to enter the selection
routine. The current setting will be flashing.
Use buttons to choose DIT. Press
to confirm the DIT.

- 12 -
11
Automatic Scroll Time Interval
Default: 0 S
Options: 0 ~ 30S
11-1
Press button to enter the
selection routine. The current setting
will be flashing. Use buttons to
choose Automatic Scroll Time Interval.
Press to confirm Automatic Scroll
Time Interval.
12
Backlit lasting time
Default:60mins
Options：0 (off)/5/10/20/30/60
12-1
Press button to enter the
selection routine. The current setting
will be flashing. Use buttons to
choose backlit lasting time. Press
to confirm backlit lasting time.
13
Press button for 3 secon s to
clear

- 13 -
13-1 Clear Max eman of active power
13-2 Clear the resettable energy kWh/kVarh
14 Passwor
Default: 1000
14-1
Press button to enter the
selection routine. The current setting
will be flashing. Use buttons to
enter new passwor . Press to
new passwor .

- 14 -
Part 4．
．．
．Modbus re ister Map
Function co e
04 to rea input parameters
Address
(Re ister)
Input Re ister Parameter Modbus Protocol Start Address Hex
Parameters unit format Hi byte Lo byte
0001 Voltage Volts Float 00 00
0007 Current Amps Float 00 06
0013 Active power Watts Float 00 0C
0019 Apparent power VA Float 00 12
0025 Reactive power VAr Float 00 18
0031 Power factor No Float 00 1E
0071 Frequency Hz Float 00 46
0073 Import active energy kWh Float 00 48
0075 Export active energy kWh Float 00 4A
0077 Import reactive energy kvarh Float 00 4C
0079 Export reactive energy kvarh Float 00 4E
0085 Total system power eman W Float 00 54
0087 Maximum total system power
eman
W Float 00 56
0089 Import system power eman W Float 00 58
0091 Maximum Import system
power eman
W Float 00 5A
0093 Export system power eman W Float 00 5C
0095 Maximum Export system
power eman
W Float 00 5E
0259 current eman Amps Float 01 02
0265 Maximum current eman . Amps Float 01 08
0343 Total active energy kWh Float 01 56
0345 Total reactive energy Kvarh Float 01 58
0385 Resettable total active kWh kwh Float 01 80
0387 Resettable total active kVarh kvarh Float 01 82

- 15 -
Function co e
10 to set hol ing parameter
03 to rea hol ing parameter
Address
Re ister
Holdin Re ister Parameter Modbus Protocol Start
Address Hex
Description
Parameters Format Hi byte Lo byte
0013 Pulse 1 Wi th
Float
00 0C
Write Pulse 1 Wi th in millisecon s: 60,
100 or 200, efault 60ms.
Len th : 4 byte
Data Format : Float
0019 Network Parity Stop
Float
00 12
Write the network port parity/stop bits
for MODBUS Protocol. where: 0 = One
stop bit an no parity,
1 efault.= One stop bit an even parity.
2 = One stop bit an o parity. 3
= Two stop bits an no parity. Requires a
restart to become effective.
Len th : 4 byte
Data Format : Float
0021 Meter ID Float 00 14 Ranges from 1 to 247. Default ID is 1.
Len th : 4 byte
Data Format : Float
0025 Pass wor Float 00 18 Meter Pass wor ( only rea )
Default: 1000.
Len th : 4 byte
Data Format : Float
0029 Bau rate Float 00 1C Write bau rate for MODBUS Protocol,
where:

- 16 -
0 = 2400 bau ( efault)
1 = 4800 bau .
2 = 9600 bau
5=1200 bau .
Len th : 4 byte
Data Format : Float
0087 Pulse 1 output mo e Float 00 56
Write MODBUS Protocol input
parameter for pulse out 1:
0001: Import active energy,
0002: Total active energy ( Imp + exp)
0004: Export active energy, ( efault).
0005: Import reactive energy,
0006:Total reactive energy (Imp+ exp)
0008: Export reactive energy,
Len th : 4 byte
Data Format : Float
61457 Reset historical ata Hex F0 10 00 00: reset eman info
Len th : 2 byte
Data Format : Hex
62721 Deman Perio , Sli ing
time an Time of scroll
isplay an backlit lasting
time
BCD
F5 00
Parameter format：
The first byte is for Deman Perio ,
unit: minute. Options:0~60
(0 means the eman won’t be up ate)
Default: 15
The secon byte is for sli ing time
unit: minute. Options 1~ (Deman
Perio -1) Default: 1
The thir byte is for Time of scroll
isplay. Unit: secon . Options: 0~30.
0 means the scroll isplay function is

- 17 -
close . Without scrolling. Default: 0
The forth byte is for backlit lasting time.
Unit: minute. Options: 0~60.
0 means the backlit is always on.
Default: 60
Len th : 4 byte
Data Format : BCD
63761 Pulse 1 output Hex F9 10 0000:0.001kWh/imp( efault)
0001:0.01kWh/imp
0002:0.1kWh/imp
0003:1kWh/imp
Len th : 2 byte
Data Format : HEX
63776 Measurement mo e Hex F9 20 0001:mo e 1(total = import)
0002:mo e 2 (total = import + export）
( efault)
0003:mo e 3 (total = import - export)
Len th : 2 byte
Data Format : HEX
63792 Continuous Running
Time
Float
F9 30
Continuous Running Time
Len th : 4 byte
Data Format : float
64513 Serial number
Unsigne
int32
FC 00 Serial number ( only read)
Len th : 4 byte
Data Format :Unsigne int32
