SOLAC PRO FOAM User manual

PRO FOAM™
Milk Frother & Chocolate Mixer
SOLAC-USA
Model #SPF500
Designed in Spain.
SOLAC-USA AUTHORIZED SERVICE CENTER
Electra-Craft, Inc.
41 Woodbine Street
Bergenfield, New Jersey 07621-3513
[email protected]
Phone [phone] / Fax [phone]
www.electra-craft.com
Instruction
Booklet

IMPORTANT INSTRUCTIONS
When using electrical appliances, basic precautions should always be followed to reduce the risk of fire,
electric shock, and injury to persons, including the following：
1. Read all instructions before using.
2. In case of emergency, immediately unplug the machine from the power outlet.
3. Check that the voltage indicated on the rating label of the appliance does in fact match that of your electrical
system.
4. This appliance is not intended to for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience, and knowledge, unless they are supervised or instructed concerning
the use of the appliance by a person responsible for their safety. Never leave the appliance unattended during
operation. Keep it out of the reach of children.
5. Do not operate the appliance with a damaged cord or plug or after the appliance malfunctions, has been
dropped or damaged in any manner. Return the appliance to an authorized service facility for examination,
electrical or mechanical adjustment, or repair.
6. Always unplug the appliance when not in use or before cleaning. Allow it to cool before adding or removing
parts, and before cleaning the appliance.
7. To protect against fire, electric shock and personal injury, do not immerse cord, plug or appliance in water or
other liquid. Never clean the appliance or the power cord if they are humid. Avoid touching the appliance with
wet hands.
8. Do not run the cord under carpeting. Do not cover the power cord with throw rugs, runners or similar floor
coverings. Arrange the cord away from high traffic areas to a place where it will not be tripped over.
9. Avoid the use of an extension cord as it may overheat and become a fire hazard. If you must use an extension
cord, it should be rated no less than 1,000 watts. Only use a grounded socket to connect the appliance.
10. Do not place on or near a hot gas or electric burner, or in a heated oven.
11. It is normal for the plug to feel warm to the touch; however, a loose fit between the AC outlet receptacle and
plug may cause overheating and distortion of the plug. Contact a qualified electrician to replace loose or worn
outlets.
12. Use the appliance only as the described in this manual. Any other use or accessory attachments not
recommend by the manufacture may cause fire, electric shock, or injury.
13. Never wash in the dishwasher or immerse the machine into water.
14. Only use the milk frother with the power base provided. Do not use the power base with anything else.
15. Do not operate without milk in the jug. Do not insert any object or fingers into the jug when operating. Do not
overfill the jug. Filling past the maximum levels indicated inside the jug can cause overflowing during operation.
Never touch rotating parts. Risk of injury!
16. This appliance is intended to be used in household(in door) and similar applications such as: staff kitchen
areas in shops, offices and other working environments like farm houses; by clients in hotels, motels. No liability
is accepted for any damage resulting from use for other purposes, faulty operation or amateur repairs.

Quick Start Guide ………………
OPERATING INSTRUCTION………
1. Before The First Use
2. Quick Steps
Whisk
For Forthing Milk
Whisk
For Heating Milk
· Unpack the box with care, remove all the packing materials away from the appliance and keep it for later use;
· Keep the packing material(bag and etc.) away from children for safety;
· Before using the appliance for the rst time, please clean the jug and the accessories as described under the
chapter “Cleaning and maintenance” to remove the dust or production residues;
UHT whole milk is the best choice!
Do not exceed the level marks to avoid over ow.




Level Scale Marks
Whisk without Spring
Milk heating Max. Level
Whisk with Spring:
Milk frothing Max. Level
 Max.:
Max.:
Max
Max
MIN
EXTRA Hot
Chocolate&Milk
Hot
Cappuccino
warm
Protein Powder Cold Frothing


Note: the data in this table were provided by lab in accordance to certain brand milk/Chocolate, local
milk/Chocolate from different countries may be various and get different temperature as well as volume,
you should take these data for reference only, not criteria.
Here are some tips to help you understand better of this device
· Choose the proper whisk and insert it inside the jug;
· Pour desired milk into the jug but not more than the maximum to avoid overflow;
· Press the on/off button to turn the appliance on.
· When Pressed the on/off button within 3 seconds and the unit is turned on, user can press On/Off
button to choose desired heating mode indicated with the LED display .
· The default heating mode is Normal heating.
· Once the heating mode is selected, the flashing LED display turns to a solid light and the selected
heating mode starts.
· The milk frother will switch off automatically .
· The operating can be cancelled by pressing the On/Off button again during working.
· Always use your frother first to froth or heating your milk. While it is operating, prepare your coffee or
chocolate and serve immediately.
· Use whole milk (fat content ≥3.0%) for best result.
· Keep your whisks in a safe place to prevent from missing.
· Default Normal Hot is preferrable for espresso, · EXTRA hot is preferrable for Chocolate mix
· Warm Mode is preferrable for Protein mix.
· Cold Mode is preferrable for cold drinks.
· Always wash the jug after use
3.Function Definition
4. Operating Steps
5. Hints and tips:
Whisk
Whisk+Spring
Paddle
Function Operating Mode Tempera-
ture (°F)
Maximum
Volume
Extra hot milk/ Ultra thick froth
hot milk/ Thick froth
Warm milk/Firm froth
Cold milk/firm froth
Hot Chocolate Mixing
hot milk/ light froth
Warm milk/No froth
Cold Milk/no froth
158~176°F5.3 ounces
5.3 ounces
5.3 ounces
5.3 ounces
10.6 ounces
10.6 ounces
10.6 ounces
10.6 ounces
140~158°F
122~140°F
Room
temperature
158~176°F
140~158°F
122~140°F
Room
temperature

………………… ……… … TIPS FOR EASY DRINKS
With frothed milk With hot milk
Caffe Latte
Latte Macchiato
Instant coffee drinks
Hot Chocolate
Protein powder
CLEANING AND MAINTENANCE ………… …… ………
Unplug from the power before cleaning, remove the lid from the jug.
Never immerse the jug or base into water.
This device is NOT designed for dish-washer.
1/3 Espresso
2/3 frothed milk
Some coco powder
Pour desired frothed milk
into a tall glass
Add espresso carefully
along the rim of the
Make instant coffee
Add frothed milk
inside
add milk first
then add chocolatepowder
1/3 Espresso shot
2/3 heated milk
and stir
add water first
then add protein powder
Cappuccino

1. The jug & base: Clean the jug immediately after each use,flush and clean the wall and bottom
with warm soapy water and use the brush to clean the residue if there is,Never use sharp object such as
metal brush and never use abrasives cleaning agent to clean the surface to avoid scratches. Then dry
with a soft cloth.
2. The lid: Rinse under water directly.
3. The whisks: Remove from the jug and wash with warm water. Dry and store in a safe place in case of missing.
SPECIFICATION
Rated Voltage: 110-120V Rated Frequency: 60Hz
Rated Power: 500W N.W./G.W.: 1.65 pound / 1.94 pound
Capacity：5.3 ounces for Heating and frothing
10.6 ounces heating
Protection Class: I
Product Size: 8.11 x 5.9 x 4.29 inches
TROUBLES SHOOTING
Problems Causes Solutions
Indicator light doesn’t
work or jug doesn’t
work
Plug is not inserted properly Re-insert into the power
Jug and power base not connected properly Remove the jug and place again on the base
No power in the socket Check the electric circuit
Problems with electric elements Repair
Jug ceases to work
after starting operation
Jug temperature is too high Rinse cold water inside the jug to reduce the
temperature
Jug damaged with immersion in water repair
Motor doesn’t work
Jug is not cleaned in time after use, milk
locks the mechanism
Clean and move the shaft sleeve of motor by
hand to loosen it
Motor damage repair
No heating Machine damage repair
Charring
Dosage of milk either too little or too much Use the dosage of milk according to the dial
Jug reused without cleaning Cleaning in time after use
Actual voltage much lower than specified
voltage Use the appropriate voltage
Quality of milk froth not
up to standard
Wrong milk type or temperature
Make sure to use whole or semi-skimmed
milk at refrigerator
temperature (about 6-8 °C)
Wrong whisk used Make sure to use the appropriate whisk
Jug reused without cleaning Make sure the jug is clean
