Solahart Solahart300BLK User manual

Valid for Australia and New Zealand
Solahart300BLK •Solahart305BLK •Solahart310BLK •Solahart315BLK
INSTALLATION AND
OPERATION MANUAL

2 3INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU 2 3
DOCUMENT REVISION 01
This manual is valid for Australia and New Zealand as of October 1st 2018 for Solahart300BLK, Solahart305BLK,
Solahart310BLK, Solahart315BLK solar modules, and replaces all earlier versions.
Technical parameters and the design are subject to change. The data sheets and customer information valid at the point in time
when the relevant module was manufactured apply to the installation, mounting, and maintenance procedures for the respective solar
modules.
With solar modules from to Solahart Industries Pty Ltd.
(hereafter referred to as "Solahart") you can directly
transform the sun’s limitless energy into environmentally-
friendly solar electricity.
In order to ensure the maximum performance of your Solahart
solar modules, please read the following instructions care-
fully and observe all guidelines. Non-compliance may result
in damage and/or physical injury.
This installation and operation manual (hereafter also
referred to as the “Manual”) provides instructions for
the safe installation and operation of crystalline solar
modules.
Ä Please read these instructions carefully before proceeding
with your installation.
ÄPlease retain these instructions for the life of the solar
modules.
Ä Please ensure that this Manual is available to the operator
at all times.
ÄThis Manual should be given to all subsequent owners
or users of the solar modules.
Ä All supplements received from the manufacturer should
be included.
ÄPlease observe all other applicable documents.
ÄIf your questions are not satisfactorily answered
in the manual, please contact your system supplier.
Additional information can be found on our website at
www.solahart.com.au.
Intended Use
This manual is valid for Australia and New Zealand.
These instructions contain information regarding the safe
handling and use of quality crystalline solar modules
from Solahart and for their installation, mounting, wiring,
maintenance and disposal.
Symbols and Labels
The following symbols and labels are used throughout the
Manual for ease of use.
SYMBOL DESCRIPTION
ÄProcedure with one or more steps.
• Lists of items.
Ensure that when carrying out a pro-
cedure, you check the results of said
procedure.
Prohibited.
Beware of possible danger or damage.
Categories:
• Danger: Risk of fatal injury
• Attention: Risk of serious injury
or damage to property
• Note: Risk of damage to product
Safety Regulations
In particular the installer as well as the operator of a
module is responsible for compliance with all applicable
statutory requirements and regulations.
ÄUnless otherwise specied by any laws or regulations,
the following stipulations must be upheld at all times
during the installation, operation, and maintenance of
the solar modules:
• This manual.
• Other applicable stipulations (such as country-specic
regulations for pressure equipment, operational safety,
hazardous goods, and environmental protection).
• Regulations and requirements specic to the system.
• Any applicable laws and requirements, in particular
international, country specic, regional laws and
stipulations governing the planning, installation, and
operation of solar power systems and work on roofs.
• Any valid international, national and regional regulations
governing work with direct current, especially those
applicable to the installation of electrical devices and
systems, and regulations issued by the respective
energy provider governing the parallel operation of
solar power systems.
• Any international, country specic and regional
accident-prevention regulations.
• Other applicable stipulations provided by the relevant
national institutions regarding safety in the installation
and operation of electical items.
Qualied & Skilled Personnel
Both the installer and operator are responsible for
ensuring that installation (including connection to the
grid), maintenance and dismantling are carried out by
trained and qualied specialists with approved training
certicates (issued by a state or federal organisation) for
the respective specialist trade.
In Australia, electrical work may only be performed by a
CEC accredited licensed electrician complying with valid
accident prevention regulations, and regulations of the
local energy provider(s).
In New Zealand, electrical work may only be performed
by a skilled electrician complying with valid accident
prevention regulations, and regulations of the local
energy provider(s).
TABLE OF CONTENTS
1 INTRODUCTION 3
2 PLANNING 5
2.1 Technical specications 5
2.2 Requirements 6
2.3 Mounting options 7
2.4 Electrical layout 9
3 INSTALLATION 10
3.1 Safety and transport 10
3.2 Preparation of installation 12
3.3 Module installation 13
4 ELECTRICAL CONNECTION 14
4.1 Safety 14
4.2 Electrical installation safety 15
4.3 Connection of modules 16
4.4 After installation 17
5 GROUNDING 18
6 FAULTS AND DEFECTS 18
7 DISPOSAL 18
8 MAINTENANCE AND CLEANING 19
1 INTRODUCTION

4 5INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU
For additional information see the relevant datasheet of the module provided at www.solahart.com.au.
PRODUCT LINE Solahart300BLK Solahart305BLK Solahart310BLK Solahart315BLK
Type Q.ANTUM Q.ANTUM Q.ANTUM Q.ANTUM
Area [m²] 1.67 1.67 1.67 1.67
Frame height [mm] 32 32 32 32
Weight [kg] 18.5 18.5 18.5 18.5
Max. system voltage VSYS [V] 1000 1000 1000 1000
Max. reverse current [A] 20 20 20 20
Permissible temperature range –40 °C to +85 °C (–40 °F to +185 °F)
Junction box protection class IP67 with bypass diode
Connector protection class IP68 IP68 IP68 IP68
Fire protection class CCCC
Max. test load push/pull [Pa]15,400 / 4,000 5,400 / 4,000 5,400 / 4,000 5,400 / 4,000
Max. design load push/pull [Pa]13,600 / 2,667 3,600 / 2,667 3,600 / 2,667 3,600 / 2,667
Certicates VDE Quality Tested; CE-compliant; IEC 61215:2016; IEC 61730:2016;
Application Class II
1Test and design load in accordance with IEC 61215:2016, depending on mounting options (see section „2.3 Mounting options“)
Validity
These instructions are only valid for crystalline solar
modules from the company Solahart. Solahart assumes
no liability for damage resulting from failure to observe
these instructions.
ÄPlease observe the wiring and dimensioning of the
system.
Ä The installer of the system is responsible for compliance
with all necessary safety regulations during set-up and
installation.
Solahart assumes no liability on the basis of these
instructions. Solahart is only liable in the context of
contractual agreements or in the context of accepted
guarantees. Solahart accepts no other responsibility for
the functionality and safety of the modules.
ÄPlease observe the instructions for any other sys-
tem components that may be part of the complete
solar power system. It may be necessary to carry out a
structural analysis for the entire project.
Additional information for the Operator
ÄPlease keep this manual for the entire life of the solar
power system.
ÄPlease contact your system supplier for information
concerning the formal requirements for solar power
systems.
ÄPlease be sure to contact the relevant local authorities
and energy providers regarding regulations and permit
requirements prior to installation of the solar power
system.
Other applicable documents
In addition to this Manual following technical information
are relevant:
DOCUMENT TYPE
Product data sheet
Packaging and transport information
1 INTRODUCTION 2.1 Technical specifications
2 PLANNING
Fig. 1: External dimensions (in mm) and components for Solahart300BLK,
Solahart305BLK, Solahart310BLK, Solahart315BLK
EN
DETAIL A16 mm
Junction box
1670 mm
4 × Mounting slots (DETAIL A)
Cable with
connectors
Frame
1000 mm
32 mm
8 × Drainage holes
4 × Grounding points ø 4.5 mm
≥1000 mm
150 mm
8.5 mm
24.5 mm
951 mm
345 mm
980 mm

6 7INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU
Installation Site
Please note the following guidelines that apply to the
installation site:
• The modules have been tested according to IEC 61215.
• Solar modules are not explosion-proof and are not suitable
for use in explosive environments.
Ä Do not operate solar modules near highly ammable gas
and vapors (e.g. gas tanks, gas stations).
ÄDo not install modules in enclosed space.
ÄDo not install modules in locations where they may be
submerged in water (e.g. oodplains).
ÄDo not use modules as a substitute for the normal
roong (e.g. modules are not watertight).
Ä Do not install modules in close proximity to air conditioning
systems.
Ä Do not install modules above 4000 m (13120ft) altitude
above sea level.
ÄIn locations with increased salt content in the air (e.g.
close to the sea) special precautions must be taken
(see “Maintenance”).
Ä Do not bring any chemical substance (e.g. oil, solvent etc.)
into contact with any part of the panel. Only substances,
which are released by Hanwha Q CELLS Australia Pty
Ltd, are allowed to be used during installation, operation
and maintenance.
ÄAny installation of modules on surfaces of water is
prohibited. This includes installations on oating as
well as pile-based platforms. Hanwha Q CELLS Australia
Pty Ltd may extend the coverage of its warranty to such
installations, based on a case by case assessment of
the system design and location. A prior written consent
by the warrantor is required in any case.
The solar modules are designed for the following applica-
tions:
• Operating temperatures from –40 °C to +85 °C
(–40 °F to +185 °F).
• Pull loads up to max. 4000 Pa and push loads up to
max. 5400 Pa (see chapter 2.3 mounting options).
• Installation using a mounting frame for solar modules.
Prevention of Shadowing Effects
Optimal solar irradiationleads to maximum energy output:
ÄFor this reason, install the modules so that they face
the sun.
ÄAvoid shadowing (due to objects such as buildings,
chimneys or trees).
ÄAvoid partial shading (for example through overhead
lines, dirt, snow).
Mounting Structure Requirements
The Modules shall be installed and operated on mounting
frames that comply with any applicable laws and stipula-
tions as well as with the following:
• Conform to the necessary structural requirements.
• Compliant with local snow and wind loads.
• Properly fastened to the ground, the roof, or the façade.
• Forces acting on the module are relayed to the mounting
substructure.
• Ensures sufcient rear ventilation of the module.
• Guarantees long-term stability.
• Avoid the usage of different metals to prevent contact
corrosion.
• Allows for stress-free expansion and contraction due to
temperature uctuations.
Ä Ensure that no mechanical stresses (e.g., caused by vibra -
tions, twisting, or expansion) applied to on the module.
ÄEnsure that the clamps and the mounting frame are
compatible.
Clamp System Requirements
Use customary clamps that satisfy the following require-
ments:
• Clamp width: ≥40 mm.
• Clamp height compliant with a 32 mm frame height.
• Clamp depth: 7-12 mm (applicable for all CL clamping
mounting options at section 2.3 Mounting options).
• Clamps are not in contact with the front glass.
• Clamps do not deform the frame.
• Clamps that satisfy the structural requirements of the
installation site.
• Long-term stable clamps that securely afx the module
to the mounting frame.
Module Orientation Requirements
• Vertical or horizontal installation is permitted.
ÄEnsure that rain and melting snow can run off freely.
No water accumulation.
ÄEnsure that the drainage holes in the frame are not
covered. No sealing.
ÄMaintain the permissible angle of
inclination.
• Minimum angle of inclination: 3°
• Maximum angle of inclination: 75°
75°
3°
2.2 Requirements
2 PLANNING
Fig. 2: Installation options for crystalline Solahart modules. All dimensions are given in mm. Also observe the
allowed static loads and clamping range as specied on the following page.
The illustrated installation options apply for both horizontal and vertical module orientation.
Module Clamp Subconstruction Mounting prole
2.3 Mounting options
2 PLANNING
TYPE OF
INSTALLATION
MODULE POINT MOUNTING SYSTEM LINEAR MOUNTING SYSTEM
INSTALLATION
WITH CLAMPS
Solahart300BLK
Solahart305BLK
Solahart310BLK
Solahart315BLK
HYBRID
CLAMPING
Solahart300BLK
Solahart305BLK
Solahart310BLK
Solahart315BLK
INSTALLATION
ON MOUNTING
POINTS
Solahart300BLK
Solahart305BLK
Solahart310BLK
Solahart315BLK
INSTALLATION
WITH INSERTION
PROFILES
Solahart300BLK
Solahart305BLK
Solahart310BLK
Solahart315BLK NOT PERMITTED
300 - 400
EUROPE
0 - 250
CL5
CL2a
0 - 250
CL2b
0 - 250
0 - 300
CL2a
0 - 300
CL2b
CL2a
0 - 200
CL2b
0 - 200
IP1 IP2
IP1 IP2
IP1 IP2
IP1 IP2
CL2a
0 - 250
CL2b
0 - 250
0 - 300
CL2a
0 - 300
CL2b
CL2a
0 - 200
CL2b
0 - 200
345
274
FB2
EN
4 × Mounting
points
4 × Mounting
points
FB2
EN
345
4 x Mounting
points
274
4 x Mounting
points
FB1
FB1
CL1
0 - 250
250 - 450
450 - 550
0 - 200
200 - 350
350 - 450
EUROPE
ASIA
CL1
CL3 CL4
250 - 450
200 - 350
0 - 300
0 - 300
CL3 CL4
CL4
0 - 200
ROW

8 9INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU
2 PLANNING 2.3 Mounting options
Module Selection
For detailed key electrical data, please refer to the actual
data sheet referring to the relevant Module (available at
www.solahart.com.au).
ÄOnly connect modules of the same type and power
class.
Safety Factor
During normal operation, a module may generate a greater
current and / or higher voltage than that determined under
standardised test conditions. Please use a safety factor of
1.25 for the following:
• Calculating the voltage measurement values (Voc) of
components
• Calculating the current measurement values (ISC) of
conductors
• Sizing of control systems connected to the outlets of
the solar modules
ÄPlease follow the valid national guidelines for the
installation of electrical systems.
ÄPlease refer to the latest revision of AS/NZS 5033
(including all relevant amendments) and the Clean
Energy Council Guidelines (for Australia).
Series Connection
Connection of modules in series is only permitted up to
the maximum system voltage as listed in the applicable
data sheet of all the relevant modules to be installed.
Ä Take into account all possible operating situations and all
relevant technical norms and regulations when designing
the system. It has to be ensured that the maximum
system voltage, including all necessary safety margins,
is not exceeded.
Ä Take the voltage limit of the inverter into account when
determining the maximum number of modules in the
string.
Parallel Connection
Modules may be damaged by the occurrence of reverse
currents (caused by module defects, ground leaks, or
defective insulation).
Ä Ensure that the maximum reverse current load capacity
indicated in the data sheet is met.
In order to limit reverse currents that may occur, we
recommend using the following safety options:
1) Layout with a limited number of parallel connected
strings:
Please refer to the latest revision of AS/NZS 5033
(including all relevant amendments) for parallel string
overcurrent protection requirements.
2) Layout with string fuses:
place fuses for each string of modules at the plus and
minus ends. Use gPV-fuses according to IEC 60269-6.
Observe the maximum permitted number of strings as
indicated in the specications provided by the respective
string fuse manufacturer and the technical guidelines.
NOTE!
When installing different product versions, the lowest
minimum permitted reverse current load capacity applies.
Inverters
Inverters with or without transformers may be used.
2.4 Electrical layout
2 PLANNING
Specications
MODULE TYPE MOUNTING
OPTION
POSITION OF
CLAMPS* [MM]
TEST LOAD
PUSH/PULL**
[PA]
DESIGN LOAD
PUSH/PULL**
[PA]
SAFETY
FACTOR
SOLAHART300BLK
SOLAHART305BLK
SOLAHART310BLK
SOLAHART315BLK
CL1 / CL3 250 - 450
5400/4000 3600/2670
1.5
FB1 / FB2 345
IP1 -
CL1 0 - 250
450 - 550
2400/2400 1600/1600
CL2a (with
rails) /
CL2b (with-
out rails)
0 - 250
CL4 0 - 300
CL5 short side: 0 - 250
long side: 300 - 400 4000/4000 2670/2670
ÄThe below mounting options are only possible under certain conditions.
MODULE TYPE MOUNTING
OPTION
POSITION OF
CLAMPS* [MM]
TEST LOAD
PUSH/PULL***
[PA]
DESIGN LOAD
PUSH/PULL***
[PA]
SAFETY
FACTOR
SOLAHART300BLK
SOLAHART305BLK
SOLAHART310BLK
SOLAHART315BLK
IP2 - 2400/2200 1600/1470
*
**
***
Distance between outer edge of module and middle of the clamp.
Loads according to IEC 61215-2:2016 and UL 1703.
Test procedure according to IEC 61215-2:2016 and UL 1703. Mounting
options do not fulll the requirements of the standards.
ATTENTION
ÄThe loads in the table are related to the mechanical stability of the solar modules. The mechanical stability of the
mounting system including clamps has to be evaluated by the system supplier. The system installer is responsible
for the determination of location-specic load requirements.
ÄEnsure, that the subconstruction does not touch the junction box (even under load). Ensure that the clamps or
insertion proles etc. do not touch the glass (even under load).
ÄEnsure, that the connection cables of the junction box do not run between laminate and mounting rails.
ÄEnsure, minimum support depth of 15 mm on the back side of the module for IP1, IP2, CL2b, CL3, CL4 and CL5.
Ensure minimum support depth of 10 mm on the front side of the module for IP1 and IP2.
Ä CL1 and CL2a with rails: Ensure that module frame is xed directly on the rail of the substructure (no spacer allowed
between the module and substructure).
ÄModule bend under loads. Therefore, sharp objects (e.g. screws) must not be mounted near the module backside.
ÄUse M8 corrosion-proof screws and washers (diameter ≥15.8 mm or ≥0.62 in) for FB1 and FB2 mounting.

10 11INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU 10 11
WARNING! Fire Risk!
ÄDo not install modules indoors.
ÄDo not install modules on moving
objects.
ÄInspect the packaging for damages.
ÄContact the transport company regarding
any damage to the packaging.
ÄFollow any instructions on the packaging.
ÄEnsure that all personnel are aware of
and adhere to accident-prevention and
safety regulations.
ÄWhile working wear clean gloves.
§
GB
§
I
§
D
DANGER! Risk of fatal injury due to electric
shock!
ÄCover the modules with an opaque
material during installation.
ÄLeave modules in their original
packaging until installation.
ÄStore the modules securely in cool
and dry rooms. The packaging is not
weatherproof.
DANGER! Risk of fatal injury due to electric
shock!
ÄDo not install damaged modules.
ÄInform your distributor of any damages
immediately.
3.1 Safety and transport
3 INSTALLATION
NOTE! Module damage may occur!
ÄNever lift or move the module with the
connection cables or junction box.
ÄCarry modules upright and horizontally
as shown.
NOTE! Module damage may occur!
ÄNever step on modules.
ÄDo not subject modules to any
mechanical stress.
ÄDo not allow any objects to fall onto
modules
NOTE! Module damage may occur!
ÄDo not drop modules.
NOTE! Module damage may occur!
ÄOnly make modications to the module
which have been conrmed in writing by
Hanwha Q CELLS Australia Pty Ltd.
confirmation
letter
NOTE! Module damage may occur!
ÄDo not stack modules.
NOTE! Module damage may occur!
ÄDo not install modules near ammable
gas / vapors.
ÄDo not install modules in close proximity
to air conditioning systems.
3.1 Safety and transport
3 INSTALLATION

12 13INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU 1312
DANGER! Risk of fatal injury due to electric
shock!
ÄBlock off the installation zone.
ÄKeep children and unauthorized
individuals away from the solar power
system.
DANGER! Risk of fatal injury due to electric
shock!
ÄEnsure that modules and tools are not
subject to moisture or rain at any time
during installation.
WARNING! Risk of injury due to falling mod-
ules!
ÄSecure modules during installation.
ÄDo not install modules in windy or wet
weather.
DANGER! Risk of fatal injury due to electric
shock!
ÄOnly use dry, insulated tools.
ÄDo not carry out the installation alone.
• Only install undamaged modules and
components.
ÄDo not modify the module (e.g. do not
drill any additional holes).
3.2 Preparation of installation
3 INSTALLATION
ÄMaintain an interval of at least 10 mm
between two modules along the short
side and 5 mm along the long side.
10 mm
5 mm
EU
Option 2:
ÄInstall the module at the 4 mounting
points, see Fig. 2, p. 7.
ÄTighten clamps according to
manufacturer’s instructions.
NOTE! Module damage may occur!
ÄDo not subject modules to mechanical
tension. Max. torsion 10 mm/m.
Option 3:
ÄInstall the module using mounting
proles, seeFig. 2, p. 7.
Option 1:
ÄFasten the module with 4 clamps
in the specied clamping range,
see Fig. 2, p. 7.
ÄTighten clamps according to
manufacturer’s instructions.
3.3 Module installation
3 INSTALLATION

14 15INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU 1514
DANGER!
Risk of fatal injury due to electric shock!
When disconnecting an electric circuit carrying direct
current, electric arcs can occur that may result in
life-threatening injuries.
ÄDo NOT unplug the cable when under load.
ÄDo NOT connect any exposed cable ends.
ÄDo NOT touch the poles at the same time.
A solar module generates electrical current and voltage
even at a low intensity of illumination. Sparks and electric
arcs may result from the separation of a closed circuit.
These can result in life-threatening injuries. The danger
increases when several modules are connected in series.
ÄPlease be aware of that the entire open circuit voltage
is active even at low levels of solar irradiation.
ÄPlease follow the valid national regulations and safety
guidelines for the installation of electrical devices and
systems.
Ä Please make sure to take all necessary safety precautions.
With module or phase voltages of more than 120 V, the
extra-low voltage range is exceeded.
Ä Carry out work on the inverter and the wiring with extreme
caution.
Ä Ensure that the modules are disconnected at the inverter
prior to separation.
ÄBe sure to observe the specied time intervals after
switching off the inverter. High-voltage components
need time to discharge.
DANGER! Risk of fatal injury due to electric
shock!
ÄNever open the junction box.
ÄChange of bypass diodes is only allowed
by qualied and trained personnel in
disconnected and covered state.
DANGER! Risk of fatal injury due to electric
shock!
ÄNever touch live contacts with bare
hands.
ÄDo not touch the poles at the same
time.
ÄCover connectors by suitable protective
caps until installation.
DANGER! Risk of fatal injury due to electric
shock!
ÄInsulate any exposed cable ends.
ÄOnly connect cables with plugs.
DANGER! Risk of fatal injury due to electric
shock!
ÄOnly use dry, insulated tools for electrical
work.
4.1 Safety
4 ELECTRICAL CONNECTION
DANGER! Risk of fatal injury due to electric
shock!
ÄEnsure correct polarity.
DANGER! Risk of fatal injury due to electric
shock!
ÄBe sure to maintain the time intervals as
specied by the inverter manufacturer
between switching off the inverter and
beginning any further work.
DANGER! Risk of fatal injury due to electric
shock!
ÄNever unplug the cable when under load.
1. Switch off the inverter.
OFF
EN
3. Switch off the DC circuit breaker.
ÄDisconnect plugs by the use of
appropriate and qualied tools of
the manufacturer Tyco, Amphenol or
Multicontact.
2. Cover the modules to be disconnected.
4.2 Electrical installation safety
4 ELECTRICAL CONNECTION

16 17INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU 1716
ÄUse solar cables for the connection at
the junction box outlet.
ÄUse the same, inverter-compatible plugs.
ÄUse minimum 4 mm2copper wires
insulated for a minimum of 90 °C for
eld connections.
SOLAR
NOTE! Module damage may occur!
ÄEnsure that the cabling is not under
stress.
ÄEnsure that the cables do not run
between module and subconstruction
(danger of pinch).
ÄDo not connect modules with different
orientations or angles of inclination in
the same string.
ÄEnsure for a tight connection between
the plugs. Plugs click together audibly.
click
EN
DANGER! Risk of fatal injury due to electric
shock!
ÄEnsure that all electrical components are
in a proper, dry, and safe condition.
ÄStandard wiring with a return cable.
Inverter
EN
4.3 Connection of modules
4 ELECTRICAL CONNECTION
ÄEnsure that all necessary safety and
functional tests have been carried out
according to current industry standards.
NOTE! Module damage may occur!
ÄEnsure that the plug connections are
secured away from any water-channelling
surface.
ÄIntegrate the system into the existing
lightening protection system in
accordance with the applicable local
regulations.
WARNING! Fire Risk!
ÄDo not use light concentrators (e.g.
mirrors or lenses).
ÄEnsure that the cabling is not exposed
and/or hanging and is protected from dirt
and moisture.
ÄEnsure that cables are protected from
abrasion, tension, compression and
cutting forces in full accordance with
AS / NZS 3000 and all other relevant
standards.
4.4 After installation
4 ELECTRICAL CONNECTION

18 19INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU INSTALLATION AND OPERATION MANUAL SolahartXXXBLK – AU 19
Protective Grounding
ÄThe modules must be grounded in accordance with
the local statutory regulations.
5 GROUNDING
DANGER!
Risk of fatal injury due to electric shock!
ÄDo not attempt to x any problems yourself (e.g.,
glass cracks, damaged cables).
ÄPlease contact your local Solahart dealer.
6 FAULTS AND DEFECTS
ÄDo not disconnect modules by yourself.
Ä Please contact an installer or your local Solahart dealer.
Ä Dispose of modules in accordance with the local disposal
regulations.
7 DISPOSAL
Solahart solar modules are known for a long operating
life and minimal maintenance effort and expense. Dirt
and grime are usually washed away by rain. If the module
is fully or partially shaded by dirt or debris (e.g., plants,
bird droppings), it needs to be cleaned to prevent a loss
of performance.
Maintenance
Ä The PV system has to be inspected regularly by certied
personnel.
ÄThe time intervals and extent of the inspection can
depend on local circumstances (e.g. salt, ammonia
content in the air, high humidity etc.). The customer/
operator must inform himself about time intervals and
extend of necessary inspections.
Ä Inspections have to be performed especially after extraor-
dinary events (e.g. storm, hail, high snow loads etc.).
ÄDuring the inspections it has to be checked that the
components are secure, undamaged and clean.
Cleaning
WARNING!
Risk of injury due to hot and
live modules!
ÄOnly clean modules that have cooled down.
ÄDo not carry or wear any electrically conductive parts.
WARNING!
Risk of falling due to unsecured
access!
ÄNever access the installation area alone or without
taking adequate security precautions.
ÄPlease commission a trade specialist.
Clean the modules as follows:
NOTE!
Module surface damage may occur!
ÄRemove snow and ice without force (e.g. with a very
soft broom)
ÄDo not scratch off dirt.
Ä Rinse dirt (dust, leaves, etc.) off with lukewarm water or
use an alcohol based glass cleaner. Do not use abrasive
detergents or tensides.
ÄUse a soft cellulose cloth (kitchen roll) or sponge to
carefully wipe off stubborn dirt. Do not use micro eece
wool or cotton cloths.
Isopropyl alcohol (IPA) can be used selectively to remove
stubborn dirt and stains within one hour after emergence.
ÄPlease follow the safety guidelines provided by the IPA
manufacturer.
ÄDo not let IPA run down between the module and the
frame or into the module edges.
ÄFree the substructure from any dirt and
debris (leaves, bird nests, etc.).
ÄRemove dirt with lukewarm water or
alcohol based glass cleaner, a broom, or
a soft cloth.
ÄDo not use tensides, scrapers, or any
high-pressure water cleaning equipment.
NOTE! Module damage may occur!
ÄDo not clean modules with water if there
is a risk of frost.
0°
8 MAINTENANCE AND CLEANING

MANUFACTURER:
HANWHA Q CELLS KOREA CORP.,
#1329 Daegum-ro, Geumwang-Eup, Eumseong-gun, ChungCheongbuk-do, Korea 369-901
LICENSE HOLDER AND IMPORTER:
SOLAHART INDUSTRIES PTY LTD.,
1 Alan St. Rydalmere, NSW 2116, Australia
Subject to change without notice. © Hanwha Q CELLS Installation Manual SolahartXXXBLK_2018-10_Rev01_AU
