SOLAR VISION LX25 User manual

installation ManUal
LX commerciaL soLar Lighting FiXtUre
Solar Vision inc. www.solar-vision.ca [e-mail] T. 1-819-729-0450
Revision 4.0
IMPORTANT NOTES:
• Alwaysinstallthelightingxtureonthepolebeforeinstallingthebattery.
• Thelightingxtureshouldneverbehandledwithbatteryinstalledinside.
• Thebatterycompartmentcontainsa“quickconnector”toconnectthebattery.
STEP 2, 3, 4, 5
STEP 6 STEP 7
Indicator lights
INSTALLATION
1. Usingthesuppliedboltsandhardware,fastenthebatterycom-
partmenttothesolarmoduleasindicatedontheimage#1.Orien-
tationofthebatteryboxiscritical.
2. Installthelightingxtureonapolewithanouterdiameterof:
• 102mm(4in)LX25&LX50(squareorroundsleeve);
• 127mm(5in)LX95(squaresleeveonlyontheLX95);
3. Usetheproperdrillingpattern(4inor5in)attheendofthisdocu-
ment.
4. Slidethelightingxtureontopofthepole;
5. Usethe1/4”-20bolttosecuretheluminairetothepole,thedrilling
patternisattheendofthisdocument;
6. Oncethelightisinplace,openthebatteryboxdoorandinsertthe
battery.
7. Makeaquickconnectionwiththequickconnectcable;
8. Agreenindicatorlightindicatesthattheluminaireisfunctionnal.
9. Closethebatteryboxdoor,theinstallationisnowcomplete.
LEARNING DELAY
Thelightrequiresa24-hourdelaytooperateproperlyaccordingtoit’s
program.
Image #1 (step #1)
P.1/5

installation ManUal
LX commerciaL soLar Lighting FiXtUre
Solar Vision inc. www.solar-vision.ca [e-mail] T. 1-819-729-0450
Revision 4.0
Solar Module
Orientation Period Autonomy losses
South
(≈optimal)
Annual 0%
Summer 0%
Winter 0%
East / West
Annual -17%
Summer -9.8%
Winter -28%
North
Annual -35.8%
Summer -21.6%
Winter -54.8%
ORIENTATION AND AUTONOMY 1.1 INSTALLATION GUIDELINES
Toavoidalossofautonomyandamalfunction:
• Theluminairemustbeinstalledhorizontallyandmustneverbetilted;
• Theluminairemustbeinstalledattheendofthepost;
• The luminaire must be installed in an open space with no trees or
structuresnearby,thiscouldfavoursnowaccumulationandshading;
• Thesolarmodulemustbeideallyorientedtowardsthesouth,other-
wiseseetable“ORIENTATIONANDAUTONOMY”.
Failingtofollowtheserecommendationscanresultinlossofsystemper-
formance.
FACTORSAFFECTINGAUTONOMY:
Lackofsunshine,verylowambienttemperature,snowaccumulationdue
totreesorstructuresnearby,shadingduetonearbytreesorstructures,
solarmoduleorientation(seetable),toomanyunplannedoccupancyde-
tections(road,unusualactivitiesandevents),sunshinebelowthemonthly
averages,timedelaytoohighontheoccupancysensor.
P.2/5

installation ManUal
LX commerciaL soLar Lighting FiXtUre
Solar Vision inc. www.solar-vision.ca [e-mail] T. 1-819-729-0450
Revision 4.0
1.2 STORAGE AND HANDLING:
Ifyouwishtostoretheluminaire,thebatteryneedstoberechargedbeforestoringforaperiodof15daysormore
inordertopreventdamagetothebattery.Theluminairemustbestoredat20°Croomtemperature.
The luminaire should never be manipulated when the battery is inside. Use the quick access door to
remove the battery before handling.
1.3 DEEP DISCHARGE PROTECTION
Thisprotectionsignicantlyincreasesbatterylifespan.Thisprotectionalsopreventspermanentdamagetothe
batterycausedbyverydeepdischargesduringcoldweather.When the battery reaches a 50% state of charge,
the battery is automatically disconnected from the system until it’s state of charge reaches 85% i.e.about
1dayofsunshineinsummerandabout4daysofsunshineinwinter.
1.4 DAY-NIGHT TRANSITION
The xture uses the solar panel to detect day and night periods. The night transition requires a very low
brightnesslevelfor5continuousminutes.Thisconstraintpreventsfalsenighttransitions.Avoidexposingthe
luminairetoanarticiallightsourcethatmaycausesynchronizationerrorsbysimulatingtheday.Ifthexture
operateserratically,makesurethesolarmoduleisnotcoveredwithdebrisorheavysnow.Theluminaireau-
tomaticallycorrectssynchronizationerrorsafter24hours.Theoccupancysensorhasitsownphotocell,which
doesnotactivatewhentheambientbrightnessistoohigh.
P.3/5

4.13
.45 X4
2.00
NOTE: The installation of the solar system must be made using one bolt which passes through the post. Follow this drilling pattern for the position of holes. The hole should be pointing in the direction of the desired lighting orientation.
DIRECTION OF LIGHTING
REV.
DESCRIPTION
DATE
PAR
4
DRAWING PER MODEL
15 SEP 2022
JFOL
3
MOUNTING HOLE
27 JUN 2022
JFOL
2
HOLES SIZE AND POSITION ADJUSTED
13 OCT 2020
JFOL
1
UPDATE OF THE NOTE
26 MAR 2020
JFOL
A A
B B
2 2
1 1
PROJECT:
WEIGHT:
"
THICKNESS
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
VISION SOLAIRE INC ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
VISION SOLAIRE COM IS
PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
DIMENSIONS ARE IN INCHES DEFAULT TOLERANCES: ANGULAR
1°
TWO PLACE DECIMAL
.06"
THREE PLACE DECIMAL
.031"
HOLES
.005"
MATERIAL
FINISH
DRAWN
DATE
NAME
VS
TITLE:
SIZE
A
DWG. NO.
REV
SCALE: 1:5
UNLESS OTHERWISE SPECIFIED:
JFOL
24MAY2019
SHEET 1 OF 1
H44_DRL_LXZX
DO NOT SCALE DRAWING
4IN POST
DRILLING PATTERN FOR
LX & ZX
4
P.4/5
LX25-LX50

.45 x4
6.63 2.50
DIRECTION OF LIGHTING
NOTE: The installation of the lamp on the top of the post requires drilling the post as per the presented drilling pattern. The lamp will be secured using one bolt through the lamp post. The hole should be pointing in the direction of the desired orientation.
REV.
DESCRIPTION
DATE
PAR
4
DRAWING PER MODEL
15 SEP 2022
JFOL
3
SIMPLIFICATION OF THE DRILLING PATTERN
27 JUN 2022
JFOL
2
HOLE SIZE AND POSITION ADJUSTED
13 OCT 2020
JFOL
1
UPDATE OF THE NOTE
26 MAR 2020
JFOL
A A
B B
2 2
1 1
PROJECT:
WEIGHT: 36.54
"
THICKNESS
THE INFORMATION CONTAINED IN THIS
DRAWING IS THE SOLE PROPERTY OF
VISION SOLAIRE INC ANY
REPRODUCTION IN PART OR AS A WHOLE
WITHOUT THE WRITTEN PERMISSION OF
VISION SOLAIRE COM IS
PROHIBITED.
PROPRIETARY AND CONFIDENTIAL
DIMENSIONS ARE IN INCHES DEFAULT TOLERANCES: ANGULAR
1°
TWO PLACE DECIMAL
.06"
THREE PLACE DECIMAL
.031"
HOLES
.005"
MATERIAL
FINISH
DRAWN
DATE
NAME
VS
TITLE:
SIZE
A
DWG. NO.
REV
SCALE: 1:5
UNLESS OTHERWISE SPECIFIED:
JFOL
26 MAR 2020
SHEET 1 OF 1
H55S_DRL_LXZX
DO NOT SCALE DRAWING
5IN POST
DRILLING PATTERN FOR
LX & ZX
4
P.5/5
LX95
