Soleus Air LX-140 User manual

14,000 BTU Portable Air Conditioner
14,200 BTU Heat Pump


Model No. LX-140
3092402


Thank you for choosing a Soleus Air LX-140 Portable Air Conditioner & Heat Pump. This owner’s
manual will provide you with valuable information necessary for the proper care and maintenance of
your new product. Please take a few moments to thoroughly read the instructions and familiarize
yourself with all the operational aspects of your new Soleus Air Portable Air Conditioner with Heat
Pump technology.
For your own records, please attach a copy of your sales receipt to this manual. Also, write the store
name/location, date purchased, and serial number below:
Store Name: ____________________________________________________
Location: ______________________________________________________
Date Purchased: _________________________________________________
Serial Number (located on back of unit): ______________________________
    
%HIRUHLQVWDOOLQJDQGXVLQJ\RXUSRUWDEOHDLUFRQGLWLRQHUSOHDVHUHDGWKLVRZQHU¶VPDQXDOFDUHIXOO\6WRUHWKLV
PDQXDOLQDVDIHSODFHIRUIXWXUHUHIHUHQFH
1) Always place the unit on a level surface.
2) Never use or store gasoline or other flammable vapor or liquid near this unit unless instructed by this manual.
3) Maintain at least 10 inches (25 cm) clearance space around this unit. Do not block or cover air inlet or outlet grilles.
4) The unit must be connected to a correctly grounded power supply.
5) Do not start or stop the unit by inserting or pulling out the power plug.
6) Do not use an adapter plug or extension cord.
7) Do not use the unit in the immediate surroundings of a bath, a shower or a swimming pool.
8) Do not insert anything into the air outlet. Do not obstruct air inlet or outlet grills unless instructed by this manual.
9) Do not let children play near this unit.
10) Always inspect the cord for signs of damage before use. If the power cord is damaged, it must be replaced by the
manufacturer or a qualified service technician.
11) When cleaning the unit, always turn the unit off and unplug the power cord.
12) When the unit is not in use, always remove the venting kit from window.
13) Do Not Mix Old And New Batteries.
Do Not Mix Alkaline, Standard (Carbon - Zinc), Or Rechargeable (Nickel - Cadmium) Batteries
 !!!
"!#!  !!!

$

 
x The cooling capacity is measuredat anambient temperature of DB 86 °F, WB 78 °F.
x Noise level is measured at a distance of 3.28 ft away from the front of the unit, when the unit is in cooling mode.
x Power consumption is measured when the fan runs at the highest speed setting.
x These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
x If the environment temperature is higher than the max operating temperature or lower than the minimum operating temperature,
the air conditioner may not work properly.
  
MODEL LX-140
COOLING CAPACITY 14,000 BTU/H
HEATING CAPACITY 14,200 BTU/H
DEHUMIDIFYING CAPACITY 60 pts/Day
POWER
COOLING 1390W
HEATING 1180W
AIR FLOW VOLUME 225 CFM
POWER SOURCE
115 V~ 60 HZ
12.5 AMP / 11 AMP
COOLING / HEATING
SOUND PRESSURE LEVEL 46 dB(A)
NET WEIGHT 83 Lbs
OPERATING
TEMPERATURE
COOLING 60.8-107.6
HEATING  -89.6
DIMENSIONS ASSEMBLED17.5” W h” h” 
REFRIGERANT R-410A
Portable Air Conditioner
Exhaust Hoses (2)
Hose Adapters (2)
Window Kit Adapter (2)
Remote Control
AAA Batteries (2)
Window Kit - 4 Sliding Panels (1 dual hose panel, 1 single hose panel, 2 extension panels) 81” Length
Air Intake and Outlet Covers (2)
Owner’s Manual
3
23

4
LCDI POWER CORD AND PLUG
This air conditioner is equipped with an LCDI (Leakage Current Detection and Interruption) power cord
and plug as required by US National Electric Code 440.65. This cord consists of a length of shielded flexi-
ble cord with no termination on the load side and a LCDI attachment plug on the line side.
The LCDI power cord and plug will remove the supply source via electrical disconnect (circuit trip) if the
nominal current leakage between the cord shield and either load conductor exceeds a predetermined
value. The cord will remain de-energized until the devise has been manually reset. This is intended to re-
duce the risk of a fire in the power cord or combustible materials nearby. The cord shields are not grounded
and they must be considered a shock hazards if exposed. The cord shield must not be connected to ground
or to any exposed metal.
The test and reset buttons on the LCDI Plug are used to check if the plug is functioning properly. To test:
1. Plug power cord into wall outlet%&'"
2. Press TEST Button, circuit should trip, cutting power to the air conditioner!!#
3. Press RESET button ! ( !!#&'"

If test button is pressed and unit can still be turned on, current leakage has been detected. Do not use the
air conditioner or attempt to reset the LCDI Plug. Contact Soleus Air Customer Service for troubleshooting
recommendations.
WARNING:
1. DO NOT press the TEST button while the air conditioner is operating.
2. The TEST and RESET buttons should not be used as ĀONāand ĀOFFāswitches.
3. The cord and plug are not intended to offer protection to externally connected loads or supply circuits.
4. The cord and plug are intended for indoor use only.

&'"
1RWH<RXUXQLWVSRZHUFRUGDQGSOXJPD\GLIIHUIURPWKHRQHVKRZQ

 




Remote Control Sensor




Evaporator Air Intake
Air Intake Cover/Filter
Remote Control Sensor
Louvers
Casters
5

 
 

 
 








  
  
When the unit is operating as an air conditioner, heater, or dehumidifier, the unit draws in fresh outdoor air and exhausts
hot air (in AC or dehumidifier mode) or cool air (in Heat mode) out of the room to complete the air exchange. When the
unit is operating in fan mode, no outdoor air exchange takes place. The window kit and exhaust hose do not need to be
installed when the unit is used as a fan.
12 ( KHVXSSOLHGZLQGRZNLWFDQEHLQVWDOOHGLQVOLGLQJZLQGRZVDQGVOLGLQJJODVVGRRUVXSWRIWORQJ
DSSUR[LPDWHOHQJWK
   
x Choose a suitable location, near a grounded electrical outlet and suitable window or door. Remove
packaging and locate components.
x Extend both ends of the exhaust hoses approximately 6 inches.
x Screw the window kit adapter onto one end of the exhaust hose clockwise. Screw the hose adapter onto
the other end of the exhaust hose clockwise. Repeat on the other exhaust hose.
x Remove outlet covers from the back of the unit by screwing them counter-clockwise, then lifting up.
x Mount the exhaust hoses onto the back of the unit by locking the hose adapters into place.
6
WindowKit
Adapter

   To quickly and efficiently cool a large area.
7
When using with a sliding door, it is recommended to
place the air outtake hose above the air intake hose



8
1Parts
A) 2 Track Screws
B) 2 Wing Nuts
C1 & C2) 2 Hose Panels, one with Two Exhaust Hose Openings
D) 1 Sliding Track Panel
2. Assembly:
First, take the Track Screws (A) and screw one
into each of the small holes found on the Hose
Panels (C1 & C2).
3. Next, take the Wing Nuts (B) and tighten them
around each of the Track Screws (A). Do not tighten
the Wing Nuts (B) all the way; make sure they are
somewhat loose.
4. Now, place the Sliding Track Panel (D) over
the Track Screw (A) on Hose Panel (C1). 
5. Next, take the other Hose Panel (C2) and connect
it to Hose Panel (C1) by placing the Sliding Track
Panel (D) over the Track Screw (A) on Hose Panel
(C2).
6. The Hose Panels (C1 &C2) should now be
connected using the Sliding Track Panel (D).
7. To complete the assembly, tighten the wing Nuts
(B) installed earlier. The finished Window Kit
should resemble the image seen below.

    
When you want quick spot cooling, install the LX-140 using the single hose window kit installation.


Install only the left exhaust hose over the circular air outlet (this outlet will be on the left side of the unit when
you are facing the back of the unit). Cover the right circular air intake using the exhaust intake cover. After
installing the hose remove the square air intake cover on the back of the unit and install the square air intake
vent with removable/washable filter.


To install the window kit, follow the same directions on page 6 for dual hose installation, but instead of using
the dual hose window kit panel, use the single hose panel pictured below.






 

9

    
  













































CONTROL PANEL
MULTI-COLOR DISPLAY
 
 
 
  
  
      



 
 
 
   
10
TEMPERATURE
TEMPERATURE SCALE CHANGE BUTTON
DEHUMIDIFIER
