Soleus Air WCM1-08E-01 User manual

Electronic Casement Window Air Conditioner
Operating Instructions
Model
WCM1-08E-01
8,000 BTU

2
Thank you for choosing a Soleus Air Air Conditioner. This owner’s manual will provide you with
valuable information necessary for the proper care and maintenance of your new product. Please take
a few moments to thoroughly read the instructions and familiarize yourself with all the operational as-
pects of your new air conditioner.
For your own records, please attach a copy of your sales receipt to this manual. Also, write the store
name/location, date purchased, and serial number below:
Store Name: ____________________________________________________
Location: ______________________________________________________
Date Purchased: _________________________________________________
Serial Number (located on back of unit): ______________________________
IMPORTANT SAFETY INSTRUCTIONS
Before installing and using your air conditioner, please read this owner’s manual carefully. Store this
manual in a safe place for future reference. Your safety and the safety of others is very important to
us. Please pay attention to all safety messages outlined in this owner’s manual.
WARNING: To reduce the risk of fire, electrical shock or injury when using your air conditioner, follow
the following basic precautions:
This is a safety alert symbol.
This symbol alerts you to potential hazards that can harm you or others or even cause
death.
All safety messages will directly follow the safety alert symbol and/or the words
“DANGER” or “WARNING”.
Failure to immediately follow these
instructions may cause serious injury
or even death.
All Safety messages alert you of potential hazards, how to reduce the chance of injury,
and what can happen if instructions are not followed correctly.
 Plug into a grounded 3 prong outlet.
 Do not remove the ground prong.
 Do not use a plug adapter.
 Do not use an extension cord.
 Unplug the air conditioner before servicing
 Use two or more people to move and install the air
conditioner

3
SPECIFICATIONS
 Noise level is measured at a distance of 3.28 ft away from the front of the unit in cooling mode.
 Power consumption is measured when the fan runs at the highest speed setting.
 These specifications are for reference only. For actual data, please refer to the rating label on the back of the
unit.
Model WCM1-08E-01
Power Supply (Ph/V/Hz) 1/115V/60Hz
Dehumidifying Capacity (Pints/Day) 34.8
Rated Cooling Capacity (BTU/hr) 8,000
Cooling Power Input (Watts) 762
Rated Current Cooling (Amperage) 6.5A
EER/C.O.P 10.5 (cooling)
Noise Level dB(A) (High/Low) 53dB(A) / 49 dB(A)
CFM (High/Med/Low) 263/238/206
Power Plug Type NEMA 5-15P
Product Dimensions (W” x H” x D” ) 14.5” x 20.25” x 23.375”
Package Dimensions (W” x H” x D” ) 18.75” x 23.75” x 26.625”
Net/Gross Weight (Lbs) 67.9 lbs. / 80.4 lbs.
Refrigerant R-410A

4
IMPORTANT SAFETY INSTRUCTIONS
These instructions describe installation in a typical wood framed window with a wood SLIDE-BY sash, or installation in a
metal CASEMENT window. Modification may be necessary when installing in windows made differently than those
shown in these instructions.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. Read
product labels for flammability and other warnings.
MEETING ELECTRICAL REQUIREMENTS
OBSERVE ALL LOCAL GOVERNING CODES AND ORDINANCES.
DO NOT, UNDER ANY CIRCUMSTANCES, REMOVE THE POWER SUPPLY CORD GROUNDING PRONG.
NOTE: If codes permit, and a separate grounding wire is used; it is recommended that a qualified electrician determine
that the grounding path is adequate and not interrupted by plastic, non-metallic gaskets, or other insulating ma-
terials.
RECEPTACLE WIRING
Receptacle wiring should be a minimum of 14 gauge. Use copper wire only. It is your responsibility to provide proper and
adequate receptacle wiring, installed by an electrician.
ELECTRICAL REQUIRMENTS
A 115 volt (103.5 minimum, 126.5 maximum), 60 Hertz, AC only, 15 ampere fused electrical supply is required. A time
delay fuse or time delay circuit breaker is also required. A separate circuit, serving only this appliance, MUST be pro-
vided.
WARNING: Electrical Shock and Personal Injury Hazard
 Electrical ground is required on this appliance.
 DO NOT ground to a gas line.
 If a cold water pipe is interrupted by plastic, non-metallic gaskets, or other insulating materials, DO NOT use for
grounding.
 Check with a qualified electrician if you are in doubt as to whether the appliance is properly grounded.
 DO NOT modify the power supply cord plug. If it does not fit the outlet, have the correct outlet installed by a qualified
electrician.
 DO NOT have a fuse in the neutral or grounding circuit. A fuse in the neutral, or grounding circuit could result in an
electrical shock.
 DO NOT use an extension cord with this appliance.
Failure to follow these instructions could result in electrical shock, serious injury or death.
Read all instructions before using this air conditioner

5
IMPORTANT SAFETY INSTRUCTIONS (Continued)
ACCIDENT PREVENTION
To reduce the risk of fire, electrical shock, or injury to persons when using your air conditioner, follow basic precautions,
including the following:
 Be sure the electrical service is adequate for the model you have chosen. This information can be found on the
rating label located on the side of the cabinet or behind the grille.
 If the air conditioner is to be installed in a window, you will probably want to clean both sides of the glass prior to
installation. If the windows is a triple-track type with a screen panel included, remove the screen completely before
installation.
 Be sure the air conditioner has been securely and correctly installed according to the installation instructions
provided with this manual. Save this manual and the installation instructions for future use when removing and
reinstalling the unit.
 When handling the air conditioner, be careful to avoid cuts form sharp metal fins on the front and rear coils.
ELECTRICAL INFORMATION
The complete electrical rating of your new air conditioner is stated on the product rating label located on the unit. Refer
to the ratings on the label when checking electrical requirements.
 Be sure the air conditioner is properly grounded. To minimize shock and fire hazards, proper grounding is important.
The power cord is equipped with a three-prong grounded plug for protection against shock hazards.
 Your air conditioner must be used in a properly grounded wall receptacle. If the wall receptacle you intend to use is
not adequately grounded or protected by a time delay fuse or circuit breaker, a qualified electrician will have to install
the proper receptacle.
 Do not run the air conditioner with a protective cover on the outside of the unit. This could result in mechanical dam-
age within the air conditioner.
 Do not use an extension cord or an adapter plug.
NOTE: The power supply cord on this unit contains a current detection device designed to reduce the risk of fire.
Please refer to the page “LCDI POWER CORD AND PLUG” for details. In the event that the power supply cord is
damaged, it cannot be repaired, it must be replaced with a cord from Soleus Home Comfort.
Read all instructions before using this air conditioner
Power supply cord with 3-prong grounding
plug and current detection device
WARNING: Avoid fire hazard or electronic shock,
DO NOT use an extension cord or an adapter plug.
DO NOT remove any prong from the power cord.
DO NOT
under any circumstances,
cut, remove, or bypass the
grounding prong!!

6
LCDI POWER CORD AND PLUG
This air conditioner is equipped with an LCDI (Leakage Current Detection and Interruption) power cord
and plug as required by US National Electric Code 440.65. This cord consists of a length of shielded flexi-
ble cord with no termination on the load side and a LCDI attachment plug on the line side.
The LCDI power cord and plug will remove the supply source via electrical disconnect (circuit trip) if the
nominal current leakage between the cord shield and either load conductor exceeds a predetermined
value. The cord will remain de-energized until the devise has been manually reset. This is intended to re-
duce the risk of a fire in the power cord or combustible materials nearby. The cord shields are not grounded
and they must be considered a shock hazards if exposed. The cord shield must not be connected to ground
or to any exposed metal.
The test and reset buttons on the LCDI Plug are used to check if the plug is functioning properly. To test:
1. Plug power cord into wall outlet. The LED light will turn on.
2. Press TEST Button, circuit should trip, cutting power to the air conditioner. When this occurs,
3. Press RESET button to restore power to the machine. Once power is restored, the LED light
will turn on again.
If test button is pressed and unit can still be turned on, current leakage has been detected. Do not use the
air conditioner or attempt to reset the LCDI Plug. Contact Soleus Air Customer Service for troubleshooting
recommendations.
WARNING:
1. DO NOT press the TEST button while the air conditioner is operating.
2. The TEST and RESET buttons should not be used as “ON” and “OFF” switches.
3. The cord and plug are not intended to offer protection to externally connected loads or supply circuits.
4. The cord and plug are intended for indoor use only.
LED LIGHT
the LED light will turn off.
Note: Your units power cord and plug may differ from the one shown.

7
Installation Tips
For wood-frame casement windows: It may be necessary to construct a frame, using at least 1-inch
thick wood, with a 15-1/2-inch wide opening.
For brick or cement building construction: It may be necessary to put a wood stool strip under AC,
for mounting purposes.
Tools Required:
 Flat-head screwdriver
 Phillips-head screwdriver
 Carpenter's level
 Tape measure
 Fine tooth saw
 Electric or hand drill
 Knife and scissors
 Pencil
PREPARING FOR INSTALLATION
WARNING: Failure to adhere to the following precautions could result in personal injury and
product damage.
 Because this unit weighs over 80 pounds, it is recommended that you have someone help you when
install your new unit, and that you both use proper lifting techniques.
 Inspect the condition of the window where unit will be installed. Be sure it will support the weight of
the unit.
 This appliance must be installed according to all applicable codes and ordinances.
 Handle AC with care. AVOID sharp metal fins on front and rear coils.

8
PARTS LIST & INSTALLATION
Installation Kit Contents
1. Platform (1)
2. Support brace (1)
3. Adjustment bolt (1)
4. Hex flange nut—1/4” (1)
5. Track seal (1)
6. Side channel seal (1)
7. Foam seal strip/Sash seal
8. Safety bracket (1)
9-11.Screw—2-1/2” (2), or Screw– 1-
3/4” (2) or Screw– 1” (2)
12. Screw–3/4” (6)
13. Screw–3/4” self-threading (7)
14. Window locking bracket (1)
15. Plastic window panel (1)
16. Side channel (2)
17. Screw–3/8” (6)
18. Panel frame/seal assembly (1)
19. Weather Insulation Board (1)
20. Remote Control (1)
Identify Screws
By Length
(25 mm)
1
(44mm)
134
(63mm)
2 1 2
3 8
(10mm)
3 4
(1 9mm)

9
INSTALLING THE UNIT IN A SLIDING WINDOW
1. Attach support brace to platform as shown.
Use adjustment bolt and hex flange nut to complete
assembly. Choose slot and adjustment bolt hole
locations that will create a 45 degree angle between
platform and support brace. Try assembly in the
window to determine if platform will rest properly, and
allow proper slope (3/16-inch lower on outside).
NOTE: If you are planning to use a siding protection
board (see Step 5) on the outside of your
house, hold board in place when testing assembly in
window.
2. Measure, and lightly mark a line 8-11/16 inches
from window jamb.
NOTE: If any sash stop protrudes more than 1
inch from the side window jambs, the 8-11/16-inch
measurement must be increased accordingly.
Screen and storm window frames may also require
adjustments to the measurement.
3. Center platform assembly on the line with inside
platform tab pressed against inside edge of window
track. Using the holes in the platform as a guide,
mark and drill two 9/64-inch diameter holes. Drill
holes in either track or stool.
CAUTION
Property Damage Hazard—Failure to adhere
to the following precautions could result in
damage to window or the air conditioner. Make
sure the wood stool or window track is securely
attached to the building construction. Use
longer screws in sub-framing if necessary.
INSTALLATION

10
INSTALLATION—SLIDING
INSTALLING THE UNIT IN A SLIDING WINDOW (CONT.)
4. Peel off protective backing from track seal. Apply
seal to room side of window track. Center of seal strip
should coincide with the line marked in Step 2. The
two screw holes drilled in Step 3 should be directly
above seal strip in the inner track.
5. Securely attach a siding-protection board to
side of house.
NOTE: Siding-protection board should be long
enough to span 2 wall studs.
6. Place platform assembly, with platform tab
against inside of window track, and attach it to
window jamb. Use appropriate length screws (Items
9-11 in Preparing For Installation).
7. Adjust platform assembly so that outside edge is
3/16-inch lower than inside edge, as shown right.
This ensures proper water drainage from the air
conditioner.
8. Level platform assembly from side-to-side.
Also, make sure window track is level. Use leveling
shims as necessary to ensure unit is level from side-to-
side.
9. Measure height of window opening from top of
platform assembly as shown right. Subtract 20-5/8
inches. Mark this measurement on plastic window
panel, along the longer side. (continued)
