Soleus Air SG-PAC-10E5 User manual

10,000 BTU Portable Air Conditioner
Operating Instructions
Model No. SG-PAC-10E5
Reference No. KY-100E5

Thank you for choosing a Soleus Air Powered by Gree Portable Air Conditioner. This owner’s man-
ual will provide you with valuable information necessary for the proper care and maintenance of your
new product. Please take a few moments to thoroughly read the instructions and familiarize yourself
with all the operational aspects of your new Portable Air Conditioner.
For your own records, please attach a copy of your sales receipt to this manual. Also, write the store
name/location, date purchased, and serial number below:
Store Name: ____________________________________________________
Location: ______________________________________________________
Date Purchased: _________________________________________________
Serial Number (located on back of unit): ______________________________
IMPORTANT INSTRUCTIONS
Before installing and using your portable air conditioner, please read this owner’s manual carefully. Store this
manual in a safe place for future reference.
1) Always place the unit on a level surface.
2) Never use or store gasoline or other flammable vapor or liquid near this unit unless instructed by this manual.
3) Maintain at least 10 inches (25 cm) clearance space around this unit. Do not block or cover air inlet or outlet grilles.
4) The unit must be connected to a correctly grounded power supply.
5) Do not start or stop the unit by inserting or pulling out the power plug.
6) Do not use an adapter plug or extension cord.
7) Do not use the unit in the immediate surroundings of a bath, a shower or a swimming pool.
8) Do not insert anything into the air outlet. Do not obstruct air inlet or outlet grills unless instructed by this manual.
9) Do not let children play near this unit.
10) Always inspect the cord for signs of damage before use. If the power cord is damaged, it must be replaced by the
manufacturer or a qualified service technician.
11) When cleaning the unit, always turn the unit off and unplug the power cord.
2

3
SPECIFICATIONS
• The cooling capacity is measured at an ambient temperature of DB 86 °F, WB 78 °F.
• Noise level is measured at a distance of 3.28 ft away from the front of the unit, when the unit is in cooling mode.
• Power consumption is measured when the fan runs at the highest speed setting.
• These specifications are for reference only. For actual data, please refer to the rating label on the back of the unit.
• If the environment temperature is higher than the max operating temperature or lower than the minimum operating
temperature, the air conditioner may not work properly.
PACKAGE CONTENTS
Portable Air Conditioner
Exhaust Hose (1)
Exhaust Hose Adapter (1)
Window Kit Adapter (1)
Hose Adapter (1)
Remote Control & AAA Batteries (2 batteries)
Window Kit - 3 Sliding Panels (1 single hose panel, 2 extension panels)
Drain Hose Assembly (drain pipe, clamp, hose clip, rubber plug, & screw)
Owner’s Manual
Model Number SG-PAC-10E5
Power Supply (Ph/V/Hz) 1/115/60Hz
Dehumidifying Capacity (Pints/Day) 50.4
Rated Cooling Capacity (BTU/h) 10,000
Rated Heating Capacity (BTU/h) /
Cooling Power Input (Watts) 1070
Heating Power Input (Watts) /
Rated Current Cooling (Amperage) 9.5
Rated Current Heating (Amperage) /
Noise Level db (A) H/L <=56
CFM - H / M / L 195 / 165 / 135
Product Dimensions (W” x H” x D”) 11.75 x 31.75 x 14.75
Product Weight (Lbs) 55
Refrigerant Type R-410A
Refrigerant Charge (Oz) 15
Reference Number KY-100E5

LCDI POWER CORD AND PLUG
This air conditioner is equipped with an LCDI (Leakage Current Detection and Interruption) power cord and
plug as required by US National Electric Code 440.65. This cord consists of a length of shielded flexible cord
with no termination on the load side and a LCDI attachment plug on the line side.
The LCDI power cord and plug will remove the supply source via electrical disconnect (circuit trip) if the
nominal current leakage between the cord shield and either load conductor exceeds a predetermined value.
The cord will remain de-energized until the devise has been manually reset. This is intended to reduce the risk
of a fire in the power cord or combustible materials nearby. The cord shields are not grounded and they must
be considered a shock hazards if exposed. The cord shield must not be connected to ground or to any exposed
metal.
The test and reset buttons on the LCDI Plug are used to check if the plug is functioning properly. To test:
1. Plug power cord into wall outlet
2. Press TEST Button, circuit should trip, cutting power to the air conditioner
3. Press RESET button for use
If a test is performed and the indicator light remains ON, current leakage has been detected. Do not use the air
conditioner or attempt to reset the LCDI Plug. Contact Soleus Air Powered by Gree Customer Service for trou-
bleshooting recommendations.
WARNING:
1. DO NOT press the TEST button while the air conditioner is operating.
2. The TEST and RESET buttons should not be used as “ON” and “OFF” switches.
3. The cord and plug are not intended to offer protection to externally connected loads or supply circuits.
4. The cord and plug are intended for indoor use only.
RESET
TEST
4

PRODUCT DIAGRAM
Control Panel
5
Louvers
Louver Guides
Casters
Power Cord
Filters
Upper Air Intake
Lower Air Intake
Remote Control Holder
Air Exhaust Vent

PARTS & WINDOW KIT ASSEMBLY
PARTS
EXHAUST HOSE & ADAPTERS
ASSEMBLY & INSTALLATION
INSTALLATION
When the unit is operating as an air conditioner or dehumidifier, the window kit and exhaust hose must be installed.
When the unit is operating in fan mode, the window kit and exhaust hose do not need to be installed .
MOUNTING THE EXHAUST HOSE
• Choose a suitable location, near a grounded electrical outlet and suitable window or door. Remove
packaging and locate components.
• Extend both ends of the exhaust hose approximately 6 inches.
• Screw the window kit adapter onto one end of the exhaust hose clockwise. Screw the hose adapter onto
the other end of the exhaust hose clockwise.
• Mount the exhaust hose onto the back of the unit by locking the hose adapters into place.
• For maximum efficiency do not bend the hose as much as possible.
6
Exhaust Hose Adapter
Exhaust Hose
Hose Adapter and
Window Kit Adapter

7
SINGLE HOSE WINDOW KIT INSTALLATION
When installing the exhaust hose, try and keep it as flat as possible. The less angles and bends
in the hose, the better the unit will perform. If bending or an angle is necessary, use single 90°
angles like the pictures above. Multiple bends will decrease performance and efficiency
This installation is OK The is a poor installation
22”
26”

CONTROL PANEL, DISPLAY, & OPERATING INSTRUCTIONS
CONTROL PANEL & LED DISPLAY
CONTROL PANEL OPERATING INSTRUCTIONS
1) Power On and Off - Press the POWER button once to manually turn the unit on. Press the POWER
button once more to turn the unit off.
2) Mode Selection - Press the MODE Button repeatedly to cycle between the different modes: Air Condi-
tioner, Dehumidifier, and Fan only mode. Each press of the MODE button will light up a different icon on
the control panel. The exhaust hose and window kit must be installed when the unit is in Air Conditioner or
Dehumidifier mode. When using the unit as a fan, it is not necessary to keep the exhaust hose and window
kit connected to the unit.
3) Temperature - Select the desired temperature by pressing either - or + key when using the unit in
cooling mode. The digital thermostat will display the set temperature.
4) Louver Direction - This unit has 4-Way directional louvers. Use the louver guides to direct air where
cooling or fanning is needed most.
5) Bucket Full - When the unit cannot evaporate the collected moisture fast enough. The excess water will
collect in a backup water tank located inside the unit. The bucket full icon will light up if this occurs
REMOTE RECEIVER
MODE BUTTON TEMP SELECT BUTTONS POWER BUTTON
8
BUCKET FULL LIGHT
COOL MODE LIGHT DRY MODE LIGHT
FAN MODE LIGHT
LED DISPLAY

9
1) Power On and Off - Press the ON/OFF (POWER) button once to manually turn the unit on. Press the Power button once
more to turn the unit off. When you manually power the unit on and off by pressing the ON/OFF button, the preset timer will
be cancelled.
2) Mode Selection - Press the MODE Button repeatedly to cycle between the different modes: Auto, Air Conditioner, Dehu-
midifier, and Fan only mode. Once a mode is selected, an arrow will light up on the LCD display next to the selected MODE
label on the remote. Auto mode automatically chooses the air conditioner, dehumidifier, or fan mode based on the current room
temperature.
3) Fan Speed - Press the FAN speed button to cycle through low, medium, and high fan speeds. The small fan icons will light up
depending on which speed is selected. The more fan icons light up, the higher the speed. The fan icons are located on the LCD
display next to the SPEED label.
4) Temperature Setting - When the unit is in Air Conditioner mode you can select your desired temperature. Press the TEMP
SELECT buttons (+or -) to select your desired temperature setting. The temperature on the LCD display on the remote control
will increase or decrease accordingly. Hold the +/- buttons for two seconds to rapidly increase or decrease the temperature.
REMOTE CONTROL OPERATING INSTRUCTIONS
MODE BUTTON
TEMP SELECT BUTTONS
POWER BUTTON
SWING BUTTON
(Not Available on SG-PAC-10E5)
TIMER BUTTON
FAN BUTTON
SLEEP BUTTON
LCD DISPLAY and
MODE LABELS
NOTE: Heat mode is not available
on the SG-PAC-10E5
NOTE: HEAT MODE IS
NOT AVAILABLE

5) Auto-on Timer: When the air conditioner is off, it can be set to automatically turn on in 30 minutes to 24 hours at the previous
set mode and fan setting. To set the Auto-on Timer, press the TIMER button on the unit or remote control. Each touch of the +/-
buttons on the remote will change the timer setting in 30 minute increments (.5 hours). The T-ON and H lights will blink while
the Auto-on Timer is being set. Once the timer is set, press the TIMER button once more to save the setting. Press the ON/OFF
button to cancel the timer.
Auto-off Timer: When the air conditioner is on, it can be set to automatically turn off in 30 minutes to 24 hours. To set the
Auto-off Timer, press the TIMER button on the remote control. Each touch of the +/- buttons on the remote will change the
timer setting in 30 minute (.5 hour) intervals. The T-OFF and H lights will blink while setting. To cancel the timer, press the
ON/OFF button. Once the timer is set, press the TIMER button once more to save the setting. Press the ON/OFF button to
cancel the timer.
6) Sleep Mode - Press the SLEEP mode button to engage SLEEP mode. Sleep mode automatically reduces the
set temperature by 2°F after one hour and 4°F after two hours. This feature limits compressor usage and
enhances energy savings while you are sleeping.
7) Auto Mode - When AUTO mode is selected the air conditioner will automatically choose the operating
mode base on the current room temperature. When the room is below 68°F the air conditioner will
automatically fan the room to circulate air. When the room temperature is between 68°F-73°F the air
conditioner will operate in Fan mode if it was previously selected or dehumidifier mode (if another mode
was used previously) to remove humidity from the air as well as some cooling to help lower the room
temperature. When the room temperature is between 74°F-79°F the air conditioner will always operate in
dehumidifier mode. When the room temperature rises above 79°F, the unit will operate in air conditioner
mode to maximize cooling. Auto mode uses pre-determined settings to keep you comfortable by choosing
the most energy efficient mode based on the temperature of the room.
10
REMOTE CONTROL OPERATING INSTRUCTIONS (Cont.)
