SolidRF M5U01 User manual

MobileBoost 4G
Cellular Signal Booster
M5U01
www.SolidRFCanada.com 1

Connect the world
Features
•Greatly reduces dropped calls, extends signal range, and increases data rates
•Allows multiple mobile devices to be used simultaneously
•Oscillation (or interference) detection and automatic shutdown with auto reset
•Overload protection circuit – protects cell towers from being overloaded
•Amplifies signals both to and from the cell tower
•Maximum 3 watts(EIRP) output power
•Works on all generations of 2G,3G and 4G
•Power control logic ensures maximum gain is within cellular standards
•Reduces radiation and extends battery life – up to 2 hours additional talk time in weak signal areas.
Package Contents
Booster
25502001-M5U01
Inside Antenna
ANT070101
Outside Antenna
ANT060301
Power Adapter
ADP0201
www.SolidRFCanada.com 2

Installation
1.How it work
Step 1: The powerful outside antenna captures a voice and
data signal, and transfer it to the booster;
Step 2: The booster receives the signal, amplifies it and re-
broadcasts it by inside antenna.
Step 3: Your mobile devices get a better signal, never expe-
rience dropped calls or slow data speed.
2. Step by step installation
Step 1: mount the outside antenna
a. Choose right position
•30cm away from any other metallic objects;
•50cm away from any windows;
b. Mount the antenna: it must be mounted vertically on
top of the car;
c. Set the outside antenna cable into the car
•Carefully pull down the door seal, run the cable into
the car under the seal;
•Run the cable reach the location where you plan to
place the booster;
•Push the seal back into place carefully.
Step 2: mount the inside antenna
a. Choose right position
•20cm away from any other metallic objects;
•50cm away from any windows;
•The position on the right hand of the drive’s seat is re-
commended;
b. Mount the inside antenna:
•Peel off the plastic on the back of the antenna;
•Under it is the 3M sticker, place the antenna onto the
position selected;
Step 3: arrange the booster
a. Choose position
•Under the assistant’s seat, or trunk of the car;
•It is free from excessive heat, direct sunlight and mois-
ture
b. Connect the outside antenna’s connector to the “outs-
ide” labeled port of the booster;
c. Connect the inside antenna’s connector to the “inside”
labeled port of the booster;
1
www.SolidRFCanada.com 3
Vertically mount
Step 4: power on the booster
a. Plug the power adapter to the car 12V DC lighter;
b. Attach the cord of the adapter to the booster;
c. Switch on the adapter by press the button of the ada-
pter, a blue light will be seen show it is working;
Inside antenna Outside antenna
Adapter cord

Cautions & Spec. 2
Note1: Some of the 12V DC lighter power sources
will not shut down when the vehicle is turned off.
Please switch off the adapter when you leave the
car, in case the battery of the vehicle is used up.
Note2: Don’t cover the booster body with anythi-
ng, in case the power dissipation make the booster
too high temperature. Booster will shut down wh-
en the temperature is too high itself.
Technical specification
www.SolidRFCanada.com 4
Note3: Use only the power supply provided by So-
lidRF, any other products non-approved by SolidRF
or self-made power cable may damage the booster.
Note4: Troubleshooting
•Properly: The lights on the front panel indicate
the condition of the booster. Every time the bo-
oster is powered on, all of the lights will be light
on in green color for around 2 seconds and then
lights off, this means the booster pass the self
check and in good condition;
•Wrong condition: If any of the lights flashing in
green light, than means the isolation between
the outside antenna and inside antenna is lower
than it should be, and self oscillate occurred.
You must switch off the booster and check the
outside antenna and inside antenna immediately.
Make sure you have followed this installation re-
commended, and check every thing carefully. If
you can’t fix the problem please contact the te-
chnician or our distributor.
RF Exposure: The manufacturer’s rated output power of this equipment is for single carrier operation. For si
tuations when multiple carrier signals are present, the rating would have to be reduced by 3.5 dB, especially
where the output is reradiated and can cause interference to adjacent band users. This power reduction is t
o be by means of input power or gain reduction and not by an attenuating at the output of the device.
Frequency
(MHz)
LTE (band 12) LTE (band 13) Cellular ( band5) PCS (band 25/2) AWS (band 4)
Uplink 698-716 776-787 824-849 1850-1910 1710-1755
Downlink 728-746 746-757 869-894 1930-1990 2110-2155
Gain Uplink 45±2 45±2 45±2 47±2 47±2
Downlink 48±2 48±2 48±2 50±2 50±2
Output power 26±2dBm(Uplink)/0±2dBm(Downlink)
Noise figure <5dB
In-band Flatness <8dB
Weight 0.7Kg
VSWR ≦2.0
Gain adjustment 20dB
Impedance 50 ohm
Operating temperature -5°~60°
Current ≦1.5A(6V DC)
Dimension(mm) 155*125*25
