Soltech SOLPORT 7W User manual

01
SOLPORT
Wall Pack Lights
7W 15W
Installation Manual
SOLTECH Designs and Manufactures
Advanced, Solar-Powered
LED Technology.

02 03
01 Introduction 02 Specification
Thank you for purchasing SOLPORT Urban Lighting Products.
Important
Please read these instructions before installation to ensure optimum results
and longevity of your lights. The solar panel should be charged in full
sunlight for 8 to 9 hours before initial first use to provide optimum results.
Features
• Adjust solar panel angle to maximize sunlight & allow snow to slide off
• The hinged LED module with solar panel is adjustable to aim light at
a target
• The solar panel blocks most glare for observer eye comfort
• Easy anti-theft installation
• Advanced new Li-ion battery lasts 500 charging-discharging cycles
• 3 operating modes that are programmable via remote control or
on fixture
• Long life battery lasts 3 nights with a one-day charge
• The easiest way to bring lighting to walls on any commercial building
• Integrates the solar panel, battery, sensor, and light fixture into
one small form factor
Notice & Warning
1. The SOLPORT will provide optimal usage where there is
enough sunshine.
2. Please note the lighting time depends on sunshine duration
and weather.
3. The lamp will light up automatically at dusk.
4. Built-in intelligent IC is with over-charge, over-discharge
and over-voltage protection.
5. The lamp is equipped with an internal battery pack, which is
replaceable. If needed, please contact for correct new battery pack.
6. If the battery is taken out and put back in or replaced with new
batteries, please allow the solar panel to receive maximum sunshine
to activate the lamp.
7. Non-professionsals please do not disassemble the lamp.
8. Please do not dispose the battery with household garbage to
avoid explosion.
Please Note
During continuous rainy or cloudy days, run time may be reduced as
the battery will not be fully charged.
Specifications
LED Nominal Power
Solar Panel
Lithium Ion Battery
CCT
Lumen Output@4000K
Beam Angle
CRI
Product Size
SOLPORT 15W
15W
Mono-Crystalline 10V 7.3W
40WH 7.4V 5.4AH
1,500
> 70
10.2 X 12.2 X 5.1 Inches
80° X 100°
4,000K & 5,000K
3 Operating Modes
120° / 16–26 ft
PC & Aluminum
100 lm/W
7hrs (1000W/m2)
2–3 Days
-5 °F to 113 °F
32 °F to 149°F
IP65
70° Adjustable
SOLPORT 7W
7W
Mono-Crystalline 10V 3.7W
40WH 3.7V 5.4AH
700
> 70
7.4 X 9.1 X 3.9 Inches
80° X 100°
4,000K & 5,000K
3 Operating Modes
120° / 16–26 ft
PC & Aluminum
100 lm/W
7hrs (1000W/m2)
2–3 Days
-5 °F to 113 °F
32 °F to 149°F
IP65
70° Adjustable
Waterproof Rate
Solar Panel Angle
Casting
Efficiency@4000K
* Charging Time
Run Time (@Full Power)
Operation Mode
PIR Sensor Angle / Distance
* Operating Temperature
* Charging Temperature
* The temperature can impact the battery’s charging and normal operation. * The solar charge time data is base on 77 degree F ambient temperature with the
panel pointed directly at the solar radiation. The standard radiation value is 1000W/m2.
SOLPORT 7W SOLPORT 15W
9.1 inches 12.2 inches
7.4 inches
10.2 inches
3.9 inches
5.1 inches

04 05
03 Installation
WALL MOUNT
01 02
Drill 4 holes of ø8mm with
depth 60–65mm on the wall.
Use screwdriver to secure the
mounting plate on the wall
with screws.
03
Aim the light in the desired
direction and slide it down to
lock it.
Secure the screw into the side
of the mouting plate.

06 07
04 Remote Control
1. On / Off
On / Off With memory of previous mode before shut off.
3. Full Bright & Dim
The light will automatically turn on to full brightness when motion
is detected within a range of 24 ft. It will turn off after 20 seconds
when there is no motion detected. The bottom portion of the light
will turn on automatically when the upper light turns off and will
then turn off once motion is detected.
4.Full Bright & Off
The light will turn on to full brightness when motion is detected
within a range of 24 ft. Once no motion is detected for 20 seconds,
the light will turn off. The bottom portion of the light will not turn
on in this mode.
ON/OFF Constant
Lighting Mode
Full
Bright & Dim
Full
Bright & Off
2. Constant Lighting Mode
The light will automatically turn on at dusk and remain at 50%
brightness when the motion sensor is disabled. After 5 hours or
when the battery capacity is below 30%, the light will switch to
Mode 3.
WHEN SWITCHING TO A DIFFERENT OPERATING MODE, THE LAMP WILL
FLASH ONCE TO INDICATE THAT THE OPERATING MODE HAS SWITCHED
SUCCESSFULLY.
Please press any button on the lamp first to activate the lamp
and remote control.
IR Remote Control
Control distance: ≤ 12 Meters
120º 120º
120º
120º120º

08 09
Alaska
25° N
15°
30°
45°
60°
19° N
21° N
26° N
20° N
27° N
28° N
29° N
30° N
31° N
32° N
33° N
34° N
35° N
36° N
37° N
38° N
39° N
40° N
41° N
42° N
43° N
44° N
45° N
46° N
47° N
48° N
60° N
49° N
Washington
Oregon
California
Nevada
Arizona
Utah
New Mexico
Kansas
Colorado
Oklahoma
Texas
North Dakota
South Dakota
Nebraska
Idaho
Montana
Wyoming
61° N
62° N
63° N
64° N
65° N
70° N
66° N
67° N
68° N
69° N
Hawaii
Minnesota
The solar charge in a battery pack won’t last forever. The off–grid system
relies on stored solar energy for autonomy. Angling your solar panels
properly can boost the power intake of your solar lighting system. You
want to angle your solar panels at a tilt based on the area’s latitude.
Tip
You can increase the tilt 15° in the winter or decrease 15° in the summer.
In this way you can get the maximum sunlight to recharge the battrey.
Strong sunlight Normal sunlight Less sunlight
Key
The area will dictate the installation of the fixtures and will sometimes
prevent the lights from facing south. But that’s okay! Panels facing West
& East won’t get as much light as Southern facing panels, but will still
collect a good amount of sunlight. A North facing panel also works, but
it will take longer to charge than any other direction. This would mean
that the solar charge will be less optimal if installations are facing North.
0°
15°
15°
45°
60°
45°
Arkansas
Louisiana
Mississippi
Alabama Georgia
South
Carolina
North
Carolina
Virginia
West
Virginia
Kentucky
Illinois
Wisconsin
Iowa
Missouri
Michigan
Indiana
Ohio
Pennsylvania
New York Massachusetts
Rhode Island
Connecticut
New Jersey
Delaware
Maryland
Tennessee
Florida
World Wide Panel Angles
Best Facing Direction of Solar Panel
Best
Worst
OKOK
New Hampshire
Vermont Maine
30°
30°
05 Panel Angle

010 011
06 Luminous Distribution
SOLPORT 15W
07 Warranty
SOLPORT is covered by a 3 year limited warranty. SOLTECH
urban light warrants to the original purchaser that this
product is free from defects in materials and workmanship
for the period of 3 years from date of purchase. To obtain
warranty service please contact your local distributor or sales
rep for further instruction.
IESViewerv2.99n
A.Legotin(C)2004
0
100
200
300
400
Type CLamp=1 434.6 lm
Max=460.3 cd/klm
Power=16 W
Multiplier=1.4346
Degrees=0
Point 0x0x0 m
m
SOLTECH Designs
and Manufactures
Advanced,
Solar-Powered
LED Technology.

012
Copyright©2022–2023 SOLTECH LLC,
All Rights Reserved.
SOLTECH LLC reserves the right to update all
product data sheets at any time. Consult SOLTECH
marketing specialists for publication updates at
[email protected]
1460 Park Avenue.
Emeryville, CA 94608 USA
www.soltechlighting.com
