Soltech SFC8000HP User manual

1
SFC8000HP User’s Manual_V1.0.0.6

2
SFC8000HP User’s Manual_V1.0.0.6
CONTENTS
1. Introduction...........................................................................................10
1.1 Product introduction.................................................................................................................................. 10
1.2 Product sepcification ................................................................................................................................. 11
1.3 Contents .......................................................................................................................................................... 19
2. Exterior...................................................................................................20
2.1 Size..................................................................................................................................................................... 20
2.2 Front panel..................................................................................................................................................... 20
2.3 LED condition................................................................................................................................................ 21
2.4 Connect power input................................................................................................................................. 22
2.5 Connecting I/O port .................................................................................................................................. 23
3. Installation of bracket...........................................................................24
4. Installation of product ..........................................................................26
4.1 Installation of SFC8000HP....................................................................................................................... 26
4.2 Installation of SFP module...................................................................................................................... 27
4.3 Connecting optical cable......................................................................................................................... 28
4.4 Removing transceiver module .............................................................................................................. 28
5. Web managedment system...................................................................30
5.1 Web login ....................................................................................................................................................... 30

3
SFC8000HP User’s Manual_V1.0.0.6
5.2 Web screen configuration....................................................................................................................... 31
5.3 System .............................................................................................................................................................. 32
5.3.1 Information........................................................................................................................................ 33
5.3.1.1 Information Configuration............................................................................................. 33
5.3.1.2 Information status............................................................................................................. 34
5.3.2 IP Configuration .............................................................................................................................. 36
5.3.2.1 IP Configuration ................................................................................................................. 36
5.3.2.2 DHCP Configuration......................................................................................................... 37
5.3.2.3 IP Status ................................................................................................................................. 38
5.3.3 Time ...................................................................................................................................................... 39
5.3.3.1 System Time......................................................................................................................... 39
5.3.3.2 NTP........................................................................................................................................... 41
5.3.3.3 Time Zone Configuration............................................................................................... 42
5.3.4 Syslog................................................................................................................................................... 43
5.3.3.4.1 Syslog Configuration .................................................................................................... 43
5.3.3.4.2 Syslog Status.................................................................................................................... 44
5.3.3.4.3 Detailed Log ..................................................................................................................... 46
5.3.5 Security................................................................................................................................................ 47
5.3.5.1 Users ........................................................................................................................................ 47
5.3.5.2 Privilege Levels.................................................................................................................... 49

4
SFC8000HP User’s Manual_V1.0.0.6
5.3.5.3 SSH ........................................................................................................................................... 50
5.3.5.4 HTTPS...................................................................................................................................... 51
5.3.5.5 Access Management ........................................................................................................ 52
5.3.5.6 Auth Method ....................................................................................................................... 55
5.3.5.7 AAA .......................................................................................................................................... 56
5.3.5.8 NAS .......................................................................................................................................... 67
5.3.5.9 Port Security......................................................................................................................... 76
5.3.6. Green Ethernet................................................................................................................................ 80
5.3.6.1 LED............................................................................................................................................ 80
5.3.6.2 Port Power Savings........................................................................................................... 81
5.3.7 PoE......................................................................................................................................................... 84
5.3.7.1 Configuration....................................................................................................................... 84
5.3.7.2 Schedule................................................................................................................................. 85
5.3.7.3 Status....................................................................................................................................... 86
5.3.8 Digital I/O........................................................................................................................................... 88
5.4 MAC Table...................................................................................................................................................... 91
5.4.1 configuration .................................................................................................................................... 92
5.4.2 Status.................................................................................................................................................... 93
5.5 Ports .................................................................................................................................................................. 95
5.5.1 Configuration.................................................................................................................................... 96

5
SFC8000HP User’s Manual_V1.0.0.6
5.5.2 Status.................................................................................................................................................... 98
5.5.2.1 Port State............................................................................................................................... 98
5.5.2.2 SFP Moudule Information............................................................................................100
5.5.2.3 Traffic Overview................................................................................................................101
5.5.3.4 Detailed Statistics ............................................................................................................102
5.5.3 Mirroring...........................................................................................................................................104
5.5.4 Loop protection.............................................................................................................................106
5.5.4.1 Configuration.....................................................................................................................106
5.6.4.2 Status.....................................................................................................................................107
5.5.5 Limit Control...................................................................................................................................108
5.5.6 ACL......................................................................................................................................................111
5.5.6.1 Configuration.....................................................................................................................112
5.5.6.2 Status.....................................................................................................................................117
5.6 VLANs .............................................................................................................................................................119
5.6.1 Configuration..................................................................................................................................120
5.6.1.1 VLAN Membership..........................................................................................................120
5.6.1.2 Ports.......................................................................................................................................121
5.6.1.3 Private VLANs....................................................................................................................124
5.6.1.4 VCL .........................................................................................................................................126
5.6.1.5 Voice VLAN.........................................................................................................................133

6
SFC8000HP User’s Manual_V1.0.0.6
5.6.2 Status..................................................................................................................................................137
5.6.2.1 VLAN Membership..........................................................................................................137
5.6.2.2 VLAN Port ...........................................................................................................................138
5.6.2.3 VCL .........................................................................................................................................139
5.7 QoS ..................................................................................................................................................................140
5.7.1 Configuration..................................................................................................................................140
5.7.1.1 Port Classification ............................................................................................................141
5.7.1.2 Port Policing.......................................................................................................................143
5.7.1.3 Queue Policing .................................................................................................................144
5.7.1.4 Port Scheduler...................................................................................................................145
5.7.1.5 Port Shaping ......................................................................................................................148
5.7.1.6 Port Tag Remarking........................................................................................................151
5.7.1.7 Port DSCP............................................................................................................................152
5.7.1.8 DSCP-Based QoS .............................................................................................................154
5.7.1.9 DSCP Translation..............................................................................................................156
5.7.1.10 DSCP Classification.......................................................................................................157
5.7.1.11 QoS Control List ............................................................................................................159
5.7.1.12 Storm Control .................................................................................................................160
5.7.2 Status..................................................................................................................................................161
5.7.2.1 QoS Statistics.....................................................................................................................161

7
SFC8000HP User’s Manual_V1.0.0.6
5.7.2.2 QCL Status ..........................................................................................................................162
5.8 Protocol..........................................................................................................................................................164
5.8.1 Ring Protocols................................................................................................................................165
5.8.1.1 S-RING ..................................................................................................................................165
5.8.1.2 Spanning Tree ...................................................................................................................166
5.8.1.3 ERPS .......................................................................................................................................182
5.8.2 Aggregation ....................................................................................................................................203
5.8.2.1 Static......................................................................................................................................203
5.8.2.2 LACP.......................................................................................................................................205
5.8.3 IPMC ...................................................................................................................................................209
5.8.3.1 IGMP Snooping ................................................................................................................209
5.8.3.2 MLD Snooping..................................................................................................................216
5.8.3.3 MVR .......................................................................................................................................224
5.8.4 SNMP .................................................................................................................................................228
5.8.4.1 System...................................................................................................................................228
5.8.4.2 Trap ........................................................................................................................................230
5.8.4.3 Communities......................................................................................................................235
5.8.4.4 Users ......................................................................................................................................237
5.8.4.5 Groups ..................................................................................................................................239
5.8.4.6 Views......................................................................................................................................240

8
SFC8000HP User’s Manual_V1.0.0.6
5.8.4.7 Access....................................................................................................................................241
5.8.5 RMON ................................................................................................................................................243
5.8.5.1 Configuration.....................................................................................................................243
5.8.5.2 Status.....................................................................................................................................249
5.8.6 Discovery Protocols .....................................................................................................................255
5.8.6.1 LLDP.......................................................................................................................................255
5.8.6.2 UPnP ......................................................................................................................................273
5.8.7 Inspection.........................................................................................................................................274
5.8.7.1 DHCP .....................................................................................................................................274
5.8.7.2 IP Source Guard ...............................................................................................................281
5.8.7.3 ARP Inspection..................................................................................................................285
5.8.7.4 sFlow......................................................................................................................................291
5.9 Diagnostics ...................................................................................................................................................296
5.9.1 Ping(IPv4, IPv6) ..............................................................................................................................296
5.9.2 VeriPHY..............................................................................................................................................298
5.10 Maintenance..............................................................................................................................................300
5.10.1 Restart Device..............................................................................................................................300
5.10.2 Factory Defaults..........................................................................................................................301
5.10.3 Software..........................................................................................................................................302
5.10.3.1 Upload................................................................................................................................302

9
SFC8000HP User’s Manual_V1.0.0.6
5.10.3.2 Image Select....................................................................................................................302
5.10.4 Configuration ...............................................................................................................................304
5.10.4.1 Save .....................................................................................................................................304
5.10.4.2 Upload................................................................................................................................304
6. Consol setting(Telnet, SSH)................................................................305
7. Scan manager.......................................................................................309
8. Maintenance Inspection......................................................................309
8.1 surveillance center Maintenance........................................................................................................311
8.2 ethernet switch maintenance ..............................................................................................................312
8.3 Actions for ring construction failures ..............................................................................................313

10
SFC8000HP User’s Manual_V1.0.0.6
1. INTRODUCTION
1.1 PRODUCT INTRODUCTION
SFC8000HP is a Managed Industrial Gigabit Ethernet Switch which has 8 RJ-45
10/100/1000Mbps ports, 2 100M/1000M/2.5GBase-SX/LX SFP slots and non-blocking wire-
speed function.
Gigabit Ethernet Switch can transmit a huge data through 20Gbps internal Switch fabric into
backbone or high-power servers in security topology.
SFC8000HP can find 8K MAC address, provides wired Packet transmit function without any
packet loss. Its high throughput of data provides convenience to users when upgrade to
Gigabit network. It also supports Carrier Ethernet and guarantee high safety of transmitting
data.
1
Introduction

11
SFC8000HP User’s Manual_V1.0.0.6
1.2 PRODUCT SEPCIFICATION
○Physical Port
⬧8port 10/100/1000M Base-T
⬧2port SFP slots Port 9 and Port 10
⬧Reset button for system management
○Generic Features
⬧Comply with IEEE802.3, 10Base-T, IEEE 802.3u, 100Base-TX, IEEE 802.3ab,
1000Base-T,
⬧IEEE 802.3z, 100/1000Base-SX/LX, Ethernet standard
⬧Auto-MDI/MDI-X detection on each RJ-45 port

12
SFC8000HP User’s Manual_V1.0.0.6
⬧Prevents packet loss with back pressure (half-duplex) and 802.3x PAUSE
frame flow control (Full-duplex)
⬧8K MAC address table, automatic source address learning and ageing
⬧20Gbps Switch fabric, non-blocking Switch architecture
⬧Up to 10K Bytes Jumbo frame support at all speed (10/100/1000 Mbps)
○layer2-Switching
⬧Support port-based and 802.1q VLAN function, up to 64VLAN groups
⬧802.1w Rapid-Spanning Tree protocol support
⬧Link Aggregation support static mode and LACP (802.3ad) - up to
4 Trunk groups, each trunk for up to maximum 8 ports
⬧IGMP Snooping - multicast filtering
○Quality of Service
⬧8 QoS classes per port
⬧Traffic class assignment based on 802.1p tag, or DSCP field
⬧Multicast and Broadcast Storm Control as well as Flooding Control
○Security
⬧Port Mirroring support for dedicated port monitoring
⬧802.1X port-Base access control, RADIUS Server Authentication
⬧Static MAC Address assign destination MAC address at specifies port
○Management
⬧Remote Web management interface

13
SFC8000HP User’s Manual_V1.0.0.6
⬧Firmware upgrade through web interface
⬧Cable Diagnostics technology
⬧Support SNMPv1 with RFC-1213/1573-Interface group, Ethernet MIB
⬧SNMP Trap
○Power over Ethernet
⬧Complies with IEEE 802.3af / IEEE 802.3at Power over Ethernet End-Span
PSE
⬧Up to 8 IEEE 802.af devices powered
⬧Up to 4 IEEE 802.at devices powered
⬧Support af PoE Power up to 15.4 Watts for each PoE ports
⬧Support at PoE power up to 30 Watts for each PoE ports
⬧Auto detect powered device (PD)
⬧Circuit protection prevent power interference between ports
⬧PoE Management
* IEEE 802.3af and IEEE 802.3at mode switch control
* PoE power usage threshold control
* Total PoE usage threshold control
* Per port PoE function enable/disable
* PD classification detection

14
SFC8000HP User’s Manual_V1.0.0.6
PRODUCT SPECIFICATION
Hardware Specification
Copper ports
8-Port 10/100/1000 Base-T Auto MDI/MDI-X
SFP Slots
2-Port 100M/1000M/2.5G Base-SX/LX
Switch architecture
Store-and-Forward
Switch backbone
20Gbps
Switch throughput
14.8Mpps
MAC Address Table
8K entries
Data Buffer
512KB On-chip frame buffer
Flow Control
Back pressure for half duplex, IEEE 802.3x Pause Frame for full
duplex
Dimension
61 x 110 x 157(W*D*H) Unit: mm
Power Requirement
54~56V DC
Power Consumption
10 Watts maximum
Reset Button
< 2sec : No Action

15
SFC8000HP User’s Manual_V1.0.0.6
< 10sec : Default Reset (keep ip address)
> 10sec : Factory Reset (reset ip address to default ip)
Alarm Contact
1 relay output with current carrying capacity of 12~24VDC @ 1A
Digital Input
1 input with the same ground, but electrically isolated
from the electronics.
Max. input current: 10 mA
Layer 2 Functions
Management Interface
Web Browser, SNMPv1, v2c, v3 monitor and SNMP Trap
Port configuration
-Port disable/enable. Auto-negotiation 10/100/1000Mbps full
and half duplex mode selection
-Flow Control disable / enable
VLAN
Port-Based / 802.1Q Tagged Based VLAN, Up to 255 VLAN groups
Q-in-Q tunneling
Private VLAN Edge (PVE)
MAC-based VLAN
Protocol-based VLAN
Voice VLAN
MVR (Multicast VLAN Registration)
Up to 255 VLAN groups, out of 4096 VLAN ID

16
SFC8000HP User’s Manual_V1.0.0.6
Link Aggregation
IEEE 802.3ad LACP / Static Trunk
Supports 5 groups of 8-Port trunk support
QoS
4 Priority Queue and traffic classification based on 802.1p priority,
DSCP field in IP packet
IGMP/MLD snooping
IGMP (v1/v2/v3) Snooping, up to 255 multicast Groups
MLD (v1/v2) Snooping, up to 255 multicast Groups
Access Control List
IP-Based ACL / MAC-Based ACL
Up to 123 entries
Bandwidth Control
Per port bandwidth control
Ingress : 500Kb ~ 1000Mbps
Egress: 500Kb ~ 1000Mbps
Port Mirror
One to Multi-port and the monitor mode is RX
SNMP MIBs
RFC-1213 MIB-II
IF-MIB
RFC-1493 Bridge MIB
RFC-1643 Ethernet MIB
RFC-2863 Interface MIB
RFC-2665 Ether-Like MIB

17
SFC8000HP User’s Manual_V1.0.0.6
RFC-2819 RMON MIB (Group 1,2,3,9)
RFC-2737 Entity MIB
RFC-2618 RADIUS Client MIB
RFC-2933 IGMP-STD_MIB
RFC3411 SNMP-Frameworks-MIB
IEEE 802.1X PAE
LLDP
MAU_MIB
Carrier Ethernet
ERPS
Standards Conformance
Network Standards
IEEE 802.3 10Base-T Ethernet
IEEE 802.3u 100Base-TX/100Base-FX Fast Ethernet
IEEE 802.3z Gigabit Ethernet (SX/LX)
IEEE 802.3ab Gigabit 1000T
IEEE 802.3x Flow Control and Back pressure
IEEE 802.3ad Port trunk with LACP
IEEE 802.1D Spanning tree protocol
IEEE 802.1w Rapid Spanning Tree protocol
IEEE 802.1s Multiple spanning tree protocol

18
SFC8000HP User’s Manual_V1.0.0.6
IEEE 802.1p Class of service
IEEE 802.1Q VLAN Tagging
IEEE 802.1x Port Authentication Network Control
IEEE 802.1ab LLDP
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 1112 IGMP version 1
RFC 2236 IGMP version 2
Operating Temperature
-40~80°C
Storage Temperature
-45~85°C
Operating Humidity
5% to 90%, relative humidity, non-condensing
Storage Humidity
5% to 95%, relative humidity, non-condensing
Power over Ethernet
PoE Standard
IEEE 802.3af POE / PSE
IEEE 802.3at POE / PSE

19
SFC8000HP User’s Manual_V1.0.0.6
PoE Power Supply Type
End-Span
PoE Power output
Per port 52V DC, 600mA
Max. 30 Watts
PoE Power Budget
250W
Max. number of Class 4 PD
8
1.3 CONTENTS
⚫Managed Industrial Gigabit Ethernet Switch X 1
⚫User Manual CD X 1
⚫Wall Mount bracket, DIN-Rail Mount bracket, Screw
SFC8000HP Manual CD

20
SFC8000HP User’s Manual_V1.0.0.6
Wall Mount bracket, DIN-Rail Mount bracket, Screw
Note : Please re-package all of contents.
2. EXTERIOR
2.1 SIZE
SFC8000HP’s size is 61mm(W) X 110mm(D) X 157mm(H).
2.2 FRONT PANEL
2
Exterior
