Sonance Navigator K2 User manual

Sonance
Navigator K2
Touchscreen Keypad

Navigator K2 keypad
III
FEDERAL COMMUNICATIONS COMMISSION NOTICE
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
© 2002 All rights reserved.
Sonance is a registered trademark of Dana Innovations,

Navigator K2 keypad
IV
IMPORTANT SAFETY INSTRUCTIONS
Read Instructions -All the safety and operating instructions should be read before the
appliance is operated.
Retain Instructions -The safety and operating instructions should be retained for future
reference.
Heed Warnings -All warnings on the unit and in the operating instructions should be
adhered to.
Follow Instructions -All operating and use instructions should be followed.
Heat -The unit should be situated away from heat sources such as radiators, heat registers,
stoves, or other appliances (including amplifiers) that produce heat.
Power Sources -The unit should be connected to a power supply only of the type described
in the operating instructions or as marked on the appliance.
Water and Moisture -The unit should not be used near water -for example, near a
bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool,
and the like.
Object and Liquid Entry -Care should be taken so that objects do not fall and liquids are
not spilled into the enclosure through openings.
Cleaning -The unit should be cleaned only as recommended by the manufacturer.
Servicing -Do not attempt any service beyond that described in the operating instructions.
Refer all other service needs to qualified service personnel.
Damage Requiring Service -The unit should be serviced by qualified service personnel
when:
•Objects have fallen or liquid has been spilled into the unit.
•The unit has been exposed to rain.
•The unit does not appear to operate normally or exhibits a marked change in
performance.
•The unit has been dropped or the enclosure damaged.
WARNING !
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THE UNIT TO RAIN OR
MOISTURE. NO USER SERVICEABLE PARTS INSIDE.

Navigator K2 keypad
V
LIMITED WARRANTY AND DISCLAIMER
If, within five (5) years from the date shown on the bill of sales, the unit fails due to a
defect in workmanship or materials, Sonance will, at its option and at no charge to the
purchaser, repair or replace the components of such unit which proves to be defective.
For this warranty to be effective, the bill of sale must show that the unit was purchased
from an authorized Sonance retailer. This warranty shall apply exclusively to the original
purchaser and shall not apply to units purchased for industrial or commercial use.
Furthermore, this warranty shall not apply if:
1. Damage to the unit was caused by accident, abuse, or misuse;
2. The unit was modified, or repaired by unauthorized personnel; or
3. The unit was not used as outlined in the operating instructions
Exclusions and Limitations
The warranty set forth above is in lieu of all other warranties; express or implied, of
merchantability, fitness for a particular purpose, or otherwise. The warranty is limited to
Sonance products registered herein and specifically excludes any damage to any
associated equipment, which may result for any reason from use with this product.
Sonance shall, in no event, be liable to incidental or consequential damages arising from
any breach of this warranty or otherwise. This warranty gives you specific legal rights,
and you may have other rights, which vary from state to state.
If your Navigator K2 keypad needs service, please contact Sonance by telephone, fax, or E-
mail for return information (See Chapter 9). Please do not return products to Sonance
without return authorization.
All rights are reserved. No part of this document may be photocopied, reproduced, or
translated without the prior written notice of Sonance.
The information contained in this document is subject to change without notice. Sonance
shall not be liable for errors contained herein or for consequential damages in connection
with the furnishing, performance, or use of this material.
Microsoft and Windows are registered trademarks of Microsoft Corporation. Other brands
and their products are trademarks or registered trademarks of their respective holders.
Sonance Navigator and the Sonance logo are registered trademarks of Sonance.

Navigator K2 keypad
VI
Table of Contents
Federal Communications Commission Notice.........................................................................III
IMPORTANT Safety INSTRUCTIONS.....................................................................................IV
Limited Warranty and Disclaimer ............................................................................................V
Table of Contents VI
Chapter 1. Welcome 1
Note........................................................................................................................................1
Unpacking and Inspection.......................................................................................................1
Product Contents....................................................................................................................2
Software Requirements...........................................................................................................2
Chapter 2. Introduction 3
Features.................................................................................................................................3
Important Notes ......................................................................................................................4
Cleaning..................................................................................................................................5
Keypad Reference..................................................................................................................5
The Touchscreen Display........................................................................................................6
The Control Panel Page..........................................................................................................6
Chapter 3. Navigator K2 ManagerSoftware 11
Installing Navigator K2 Manager............................................................................................11
Programming Overview.........................................................................................................11
Navigator K2 Manager Screen..............................................................................................12
Touchscreen Grid.................................................................................................................13
Design Hints .........................................................................................................................13
Getting Help..........................................................................................................................14
Chapter 4. Navigator K2 Manager Basics 15
How to Add a Page ...............................................................................................................15
How to Delete a Page...........................................................................................................15
How to Add Buttons...............................................................................................................16
How to Delete Buttons ..........................................................................................................16
How to Add Text to Buttons...................................................................................................17
How to Place a Bitmap..........................................................................................................18
How to Add Commands to Buttons ........................................................................................20
How to Delete Commands from Buttons................................................................................22
How to Link Pages................................................................................................................22
How to Remove Page Links..................................................................................................23
How to Save a File ...............................................................................................................23
How to Open an Existing File ................................................................................................23
How to Preview your File......................................................................................................24
How to Setup Communications..............................................................................................25
How to Send a File to the Navigator K2 ................................................................................26
Chapter 5. Navigator K2 Manager Advanced Features 28
How to Rename a Page........................................................................................................28
How to Duplicate a Page.......................................................................................................28
How to insert a frame............................................................................................................28
How to delete a frame...........................................................................................................28
How to Merge Pages ............................................................................................................29
How to Use the PageWizard.................................................................................................30
How to Change Button Styles................................................................................................30

Navigator K2 keypad
VII
How to Select Buttons...........................................................................................................31
How to Cut or Copy Buttons..................................................................................................31
How to Paste Buttons ...........................................................................................................31
How to Move a Button...........................................................................................................32
How to Resize a Button.........................................................................................................32
How to Place a Custom Button..............................................................................................32
How to Use the Macro Editor................................................................................................34
How to Delete a Macro.........................................................................................................40
How to Edit an IR Command in a Macro................................................................................40
How to Use the Channel Macro Wizard.................................................................................41
How to Create a New Scrolling List.......................................................................................43
How to Edit a Scrolling List ...................................................................................................45
How to Edit the Device properties.........................................................................................46
How to Edit Button Properties...............................................................................................54
How to Edit the Properties of Multiple Buttons.......................................................................57
How to Use the “IR Code Search & Replace” Feature...........................................................58
How to Print System Configuration Reports ..........................................................................58
How to Check Memory Usage...............................................................................................59
How to Create a “Self-Downloading .EXE”............................................................................59
How to Use the “Send” Command .........................................................................................60
How to Update the Firmware.................................................................................................60
Chapter 6. Image Editors 62
The Difference Between Custom Buttons and Bitmaps..........................................................62
Button Bitmap Editor Screen.................................................................................................63
Custom Button Editor Screen................................................................................................64
Toolbar .................................................................................................................................65
Tool Palette ..........................................................................................................................67
Up Image-Down Image Tool (Custom Button Editor Only):.....................................................69
New Bitmap Size Dialog Box (Button Bitmap Editor Only):.....................................................70
Chapter 7. IR Library Manager 72
Master and User Command Libraries....................................................................................72
IR Library Manager Screen...................................................................................................72
Toolbar .................................................................................................................................73
Remote Function Window.....................................................................................................74
Creating, Editing and Assigning IR Codes to Remote Files....................................................76
Chapter 8. Troubleshooting 79
Communication Problems......................................................................................................79
Macro Problems....................................................................................................................80
IR Problems ..........................................................................................................................81
Chapter 9. Service and Support 83
Updates and New Products...................................................................................................83
Contacting Sonance..............................................................................................................83
Sonance Technical Support ..................................................................................................83
Shipment of Navigator K2 KEYPAD for Service....................................................................85
Specifications 87
Appendix 90
Index 96

Navigator K2 keypad
VIII

Chapter 1 • Welcome
1
Chapter 1. Welcome
Congratulations on your purchase of the Sonance Navigator® K2 touchscreen
keypad. The Navigator K2 combines the power and flexibility of a graphic LCD
touchscreen with the convenience and familiarity of real buttons.
Navigator K2 takes complete control of the home’s audio/video, lighting, and other
systems, replacing all other user interfaces. It features an intuitive, easy to read LCD
that can display custom buttons, text, graphics, and symbols. In addition to the
backlit display, 11 “hard” keypad buttons allow easy access to frequently used
functions.
Programming is easy and convenient thanks to the advanced Windows® based
software.
NOTE
The Navigator K2 and Navigator K2 Manager software are compatible with infrared
(IR) commands with carrier frequencies between 15kHz and 460kHz, as well as
those commands that do not use a carrier (the built-in infrared receiver is only
compatible with carrier frequencies between 20kHz and 120kHz). This covers the
vast majority of remote controls available to date
Despite every effort to make the Navigator K2 universal system controller work with
all IR systems, some IR-controlled products are unable to be controlled by the
Navigator K2 due to incompatible frequencies or non-standard IR formats. The
Navigator K2 cannot reproduce non-IR formats such as RF and ultrasonic.
UNPACKING AND INSPECTION
After unpacking your new Navigator K2 keypad, save all of the packing materials, in
case you ever have to ship the unit.
Thoroughly inspect the Navigator K2 and packing materials for signs of damage.
Report any damage to the carrier immediately. Report any equipment malfunctions
to Sonance.

Navigator K2 keypad
2
PRODUCT CONTENTS
Contents within the box include the following items:
•Sonance Navigator K2 keypad
•White colored wall plate
•Serial cable for programming
•Getting started card
•Wall cut-out template
•Two spare self retention tabs
SOFTWARE REQUIREMENTS
Sonance Navigator K2 Manager software minimum system
requirements:
•Windows® 98, Windows ME, Windows 2000, Windows XP, or
higher operating system
•IBM or compatible PC with 486DX2/66Mhz or higher
processor
•16 Megabytes (MB) of RAM
•8 Megabytes of free disk space for minimum installation
(16 MB recommended)
•A mouse or other pointing device is required
•S-VGA monitor (256 colors minimum)
•Open RS-232 serial port
•Optional printer for printing setup reports

Chapter 2 • Introduction
3
Chapter 2. Introduction
The Navigator K2 is a programmable touchscreen keypad that is designed to provide
wired control of audio/video and other electronic systems. The Navigator K2 is a
stand-alone controller that can be thought of as a universal remote control that is
permanently installed on a wall. Like other “universal” or “learning” remote
controls, the Navigator K2 allows you to consolidate the functions of many
independent infrared remote controls into one unit. The Navigator K2 also
incorporates a unique programmable user interface, allowing it to provide a simple,
intuitive, and customized interface for any system. Before using the Navigator K2,
please read and follow all instructions in this manual.
FEATURES
The Navigator K2 provides superior quality and reliability as well as these specific
features:
•A replacement for all of your system’s remote controls. The Navigator K2 can
reproduce all of the commands of almost any infrared remote control.
•A programmable graphic display. The Navigator K2 uses powerful
Windowsbased software that makes it easy to place buttons, text, graphics,
and symbols anywhere on the display.
•A backlit LCD with digital matrix touchscreen. When you want to perform a
command, simply touch the display where that command is displayed. The
touchscreen never needs calibrating.
•Real buttons. The Navigator K2 has 11 backlit “hard” keypad buttons that
allow easy access to frequently used functions. The six source buttons can be
re-labeled using a separate membrane keypad kit (Sonance part number
91949)
•A macro function. This feature allows the Navigator K2 to perform a series of
commands by pressing a single button. For example, you can create a macro
called “Movie” that turns on the TV, sets the correct channel, turns on the
VCR, dims the lights, and starts playing a movie.
•Automatic power on and off. The Navigator K2 powers itself down whenever
it is not used for a pre-set amount of time. Touching any area of the display
or a hard button will turn it on again.
•Industry standard IR output port. The Navigator K2 can be wired into
standard IR repeater systems.
•Power status feedback. The Navigator K2 can be connected to the power
status trigger output or a switched outlet (via a plug-in power adapter) of
audio controllers or receivers to indicate system power status using the bi-

Navigator K2 keypad
4
color LED’s behind the keypad’s “OFF” button. The color of these LED’s can
also be changed manually by issuing a command within a macro.
•Relay Control output. The Navigator K2 can be connected to a speaker relay
module (Sonance part number 91550) for muting individual rooms or zones.
This can also be used to control other relay controlled products.
•Keypad sync bus. Individual K2 keypads can be tied together so that the
display, power status, and mute status changes on all keypads when a
change occurs on any one of them. In other words, each of the K2 keypads
that are tied together will track the changes made to any of the other
keypads.
•A serial port for communication with the Navigator K2 Manager
programming software.
•Non-volatile flash memory. The Navigator K2 will not lose any programmed
data when the power is removed.
•Easy installation. The K2 fits inside many standard double-gang electrical
boxes for installation in new construction. It also has a self-contained
mounting system for retrofit applications.
•Five-year parts and labor warranty.
IMPORTANT NOTES
Please read these important notes about the Navigator K2:
•The Navigator K2 should be placed in an area where it is around normal room
temperature (between 60°F to 90°F). If the temperature is too hot, the display
appears dim. If the temperature is too cold, the display appears dark and
may respond slowly.
•Do not use sharp objects on the touchscreen. It is designed to operate with a
touch of your finger.
•Do not let the Navigator K2 get wet. It should not be handled with wet hands
or be placed in an area where it could get wet.
•Do not subject the Navigator K2 to smoke, dust, or vibrations. The display
may be damaged from excessive shock or vibration.
•Use only a power supply that is provided by Sonance.Using the wrong type
of power supply may result in product failure or other damage.

Chapter 2 • Introduction
5
•Do not disassemble the unit. The Navigator K2 contains high voltage circuits
that may cause injury if contacted.
CLEANING
Occasional cleaning may be required, depending on use.
To clean your Navigator K2:
1. Remove the power from the Navigator K2.
2. Lightly dampen a lint-free cloth with water or mild detergent and wipe the
touchscreen, keypad, and outer surfaces.
KEYPAD REFERENCE
KEYPAD SYNC AUX STATUS GND PWRSTATUS IRDATA GND +12VDC
Part Number 91975
RS-485 RELAY CTRL
Sonance Navigator K2
Front
Back
Power Off Hard
Button with
Programmable
Power Status
Indicator Volume and
Channel Hard
Buttons
IR Receiver
Window
Touchscreen
Display
Configurable
Source Hard
Buttons
Removable Connector
for Keypad Power and
Input/Output Functions
RS-485
Network Port
NOTE: The
RS-485 port
is not active
at this time.

Navigator K2 keypad
6
THE TOUCHSCREEN DISPLAY
The Navigator K2 touchscreen display is organized as a series of pages and frames. A
page can consist of up to 12 frames of information having one frame displayed on
the screen at a time.
Normally each frame on a page contains objects (buttons, text, graphics, and
symbols) that are related in some way. For instance, they may all display
information necessary for controlling a particular DVD player.
By default, the Navigator K2 has one Main Menu page. This is the first page that is
displayed when power is applied to the K2. It is programmed at the factory to
display a sample page with a graphic of the Sonance logo on it.
A page is normally created for each device or system to be controlled. Each of these
pages is then attached to one of the “hard” source buttons on the K2. Also, any page
can contain a button(s) that will display any other page when selected. The K2 will
support 63 pages plus the Main Menu page.
THE CONTROL PANEL PAGE
The Control Panel page can be displayed by pressing and holding both frame
arrows for at least 5 seconds.
You can also access the Control Panel page by assigning a “Control Panel” page link
to a button using the Navigator K2 Manager software.
The Control Panel consists of the following two frames:
To change frames, press the frame Left or frame Rightbuttons on the
bottom of the touchscreen. To return to your Navigator K2 program, press the OFF
button.

Chapter 2 • Introduction
7
IR RECEIVER
This button displays a window that allows you to enable or disable the
infrared receiver. The infrared receiver is used to relay commands from a
wireless infrared remote control near the K2 back to the device being
controlled. The default setting for this feature is off. It is recommended
that this feature be turned off if not needed. Electronic and light noise in the
room where the K2 is installed can interfere with the IR commands. The
Signal bar at the top of the window shows you what the IR receiver is
detecting –it turns dark in response to infrared energy that is present. Press
the OK button in the window to close.
BEEPER
This button displays a window that allows you to turn the audible beep on
or off. The beeper provides feedback that a button was pressed. Press the OK
button in the window to close.
TIME OUT
This button displays a window that allows you to adjust the amount of time
the unit waits before power down after the last button press. The time is
variable from 1 second to 60 seconds (default is 10 seconds). Press the
arrows to the left or right of the Time Out setting to adjust the time. Press
the OK button in the window to close. The backlight level during power
down can be adjusted from a medium backlight level to completely off to
minimize power consumption on the system.

Navigator K2 keypad
8
BACKLIGHT LEVEL
This button displays a window that allows you to set the backlight
brightness level of the K2. There are independent settings for the K2’s
Normal operating mode (when it is awake) and the Power Down mode
(when it is asleep). The four brightness choices are High, Medium, Low, and
Off. For the Power Down mode you can also select the Display Off option if
you want the display to show no information while the K2 is asleep. The
High brightness setting is not allowed in the Power Down mode. Press the
OK button in the window to close.
CHANGE PASSCODE
This button displays a window that allows you to set the passcode that is
used to limit access to the Clear All function on the control panel page as
well as the Secured function that is available on all buttons.
When you press the Change Passcode button, the screen will prompt you to
enter the old passcode on the touchscreen followed by the Enter key.
(The default code is 0000).

Chapter 2 • Introduction
9
Now enter a new four-digit passcode, then press Enter.
You will be prompted to enter the new four-digit passcode again for
confirmation, then press Enter.
When new code is entered successfully, the Code Changed window
will pop up to let you know you have changed the passcode.
Do not forget the passcode!

Navigator K2 keypad
10
CLEAR ALL
This button displays a window that will allow you to erase the current
program in the Navigator K2 keypad. When the button is pressed, you will be
prompted to enter the current passcode. If the proper code is entered, the
entire program in the Navigator K2 will be erased.
Warning! This will erase the complete program in the Navigator K2 with no
way to restore it, except by reloading the program from the Navigator K2
Manager software!
If you inadvertently press the CLEAR ALL button, simply press the ENTER
button without entering the passcode and you will be returned to the
Control Panel page.
Note! All control panel settings are available through the “Edit Device
Properties” window in the edit pull down menu (see chapter 5). Control
panel settings are also reset with every file load so be sure the device
properties are set correctly in each of your files.

Chapter 3 • Navigator K2 Manager Software
11
Chapter 3. Navigator K2 ManagerSoftware
Navigator K2 Manager allows you to create the entire graphical interface for a
Sonance Navigator K2 keypad on your computer. Once the interface has been
created, it is downloaded to the Navigator K2 using the included programming cable.
Existing programming can also be extracted, modified, and re-sent to any Navigator
K2 keypad.
Software updates are available for download at no cost at www.sonance.com.
INSTALLING NAVIGATOR K2 MANAGER
For installation from the internet:
1. Using your Web browser, go to the following URL: www.sonance.com
2. When the Web page opens, locate the K2 page under Electronics. Follow
the directions to download the Navigator K2 Manager.
3. Follow the on-screen instructions.
For installation from a CD-ROM:
1. Close any open programs.
2. Place the Navigator K2 Manager compact disc into the CD-ROM drive.
3. If the installation doesn’t appear automatically, click Start and choose
Run, type d:\setup\setup.exe (For d, type the letter for your CD-ROM
drive). Click OK.
4. Follow the on-screen instructions.
PROGRAMMING OVERVIEW
Here is an overview of the process of programming a Navigator K2 from scratch.
Instructions on carrying out these tasks can be found in chapters 4 and 5.
1. Create a new page and add buttons for each source component in a
system.
2. Use the Assign Page tool to link source buttons to their respective source
component pages.
3. Assign infrared codes and other commands to buttons using the Infrared
Library.
4. Create macros using the Macro Editor (if needed).

Navigator K2 keypad
12
5. Check the Device Properties.
6. Save the file.
7. Send the file to the Navigator K2 using the communications commands.
NAVIGATOR K2 MANAGER SCREEN
Menu Bar
Toolbar
Page List
Tool Palette
Source
Hard Buttons
Touchscreen
grid Design Window
Frame Left and
Right arrows
Library Browser
Common Functions
Hard Buttons
