Paradox 1640 User manual

Icon LCD Keypad
(1640)
User Guide
1640-EU02.fm Page -3 Wednesday, May 18, 2005 3:10 PM

1640-EU02.fm Page -2 Wednesday, May 18, 2005 3:10 PM

Table of Contents
Introduction........................................................1
Legend................................................................... 1
Basic Operation.................................................2
Action Keys............................................................ 2
Keypad Indicator Lights......................................... 3
On-screen Icons .................................................... 4
Auditory Feedback................................................. 6
Arming & Disarming..........................................7
Exit Delay .............................................................. 7
Disarming & Deactivating an Alarm....................... 7
Alarm Memory Display .......................................... 8
Regular Arming...................................................... 8
Stay Arming........................................................... 9
Instant Arming ....................................................... 9
Force Arming....................................................... 10
Manual Bypass Programming ............................. 11
One-Touch Arming.............................................. 12
Keyswitch Arming................................................ 14
Timed Auto-Arming.............................................. 14
“No Movement” Auto Arming............................... 15
Fire Alarms.......................................................... 15
Additional Features.........................................19
Programming Chime Zones................................. 19
1640-EU02.fm Page -1 Wednesday, May 18, 2005 3:10 PM

Keypad Muting .....................................................19
Panic Alarms........................................................20
Program Time ......................................................21
Quick Function Keys ............................................21
Keypad Settings...................................................22
Partitioning ...........................................................22
Testing & Maintenance.........................................23
Programming Access Codes......................... 24
System Master Code (Default: 123456)...............24
Master Codes.......................................................24
Duress Code ........................................................25
Programming Access Codes................................25
Trouble List..................................................... 27
System Checklist............................................ 31
1640-EU02.fm Page 0 Wednesday, May 18, 2005 3:10 PM

1640 Icon LCD Keypad 1
1.0 Introduction
The 1640 Icon LCD Keypad allows you to easily access your
security system's functions and provide you with an easy-to-
understand display of your security system's alarm and
operational status.
All the actions performed in your security system will be
executed and displayed through the keypad. Your security
system uses advanced technology which will provide you
with reliable security protection and powerful features that are
easy to use.
Since you will communicate your instructions to the system
through your keypad, please read this manual carefully and
have your installer explain basic system operation.
1.1 Legend
= Indicates a warning.
= Indicates a note or reminder.
[Number] =
Indicates information that must be entered on
the keypad.
1640-EU02.fm Page 1 Wednesday, May 18, 2005 3:10 PM

2 User Guide
2.0 Basic Operation
This section will provide an overview of the 1640’s
functionality. This includes the use of action keys, indicator
lights and visual feedback.
Many of the features in your system must be enabled by
the installer. If the feature is not programmed, the keypad
will emit a rejection beep and the action will be cancelled.
2.1 Action Keys
The 1640 has action keys with which you can access its
various functions as shown in Table 1.
Table 1: Action Keys
Name Key Description
Stay Arm Refer to Stay Arming on page 9 and
Instant Arming on page 9.
Force Arm Refer to Force Arming on page 10.
Function Key 1 Press and hold to activate devices (i.e.
garage door) or reset smoke detectors.
Speak to your installer for more details.
Function Key 2 Reserved for future use.
Zone Bypass Refer to Manual Bypass Programming
on page 11.
1640-EU02.fm Page 2 Wednesday, May 18, 2005 3:10 PM

1640 Icon LCD Keypad 3
2.2 Keypad Indicator Lights
The state of each light on the 1640 keypad represents a
specific condition in your system as shown in Table 2.
Table 2: Indicator Lights
Events in
Memory Refer to Alarm Memory Display on page 8.
System
Trouble Refer to Trouble List on page 27.
N/A Reserved for future use.
LED Name Status Description
AC Light ON
OFF Power on Power off
Status Light Green ON All zones closed
Green OFF Zone(s) open or in
tamper
Green flash Exit delay
Name Key Description
1640-EU02.fm Page 3 Wednesday, May 18, 2005 3:10 PM

4 User Guide
2.3 On-screen Icons
The icons on the keypad’s screen communicate your
system’s status as outlined in Table 3.
Table 3: Icon Display
Status Light Red ON Area(s) armed
Red OFF Area(s) disarmed
Red slow flash Stay or instant armed
Red fast flash System in alarm
Red and yellow
flash alternately Communication bus fault
Icon(s) Description
Indicates numbers corresponding to zones
or option numbers. Numbers will illuminate
to indicate that a zone is opened or when in
trouble view mode will indicate the trouble.
Indicates which areas are Force Armed.
Refer to Force Arming on page 10.
Indicates which areas are Regular Armed.
Refer to Arming & Disarming on page 7.
LED Name Status Description
1640-EU02.fm Page 4 Wednesday, May 18, 2005 3:10 PM

1640 Icon LCD Keypad 5
Indicates which areas are Instant Armed.
Refer to Instant Arming on page 9.
Indicates which areas are Stay Armed.
Refer to Stay Arming on page 9.
Indicates the numerical values for the time,
sections, section data, options and codes.
Indicates which zone is in Chime Mode.
Refer to Programming Chime Zones on
page 19.
Indicates zones in tamper. Refer to Arming
& Disarming on page 7.
Indicates zones that are in Fire Alarm.
Refer to Fire Alarms on page 15
Indicates system troubles. Refer to Trouble
List on page 27.
Indicates bypassed zones. Refer to Manual
Bypass Programming on page 11.
Indicates alarms stored in memory. Refer to
Alarm Memory Display on page 8.
Icon(s) Description
1640-EU02.fm Page 5 Wednesday, May 18, 2005 3:10 PM

6 User Guide
2.4 Auditory Feedback
When you enter information on the keypad, it will guide you
with beep tones. You should be familiar with these:
Confirmation Beep: When an operation (i.e. arming/
disarming) is successfully entered on the keypad or when the
system switches to a new status/mode, the keypad produces
an intermittent beep tone (“BEEP-BEEP-BEEP-BEEP”).
Rejection Beep: When the system reverts to previous status
or when an operation is incorrectly entered on the keypad, it
will emit a continuous beep tone (“BEEEEEEEEP”).
1640-EU02.fm Page 6 Wednesday, May 18, 2005 3:10 PM

1640 Icon LCD Keypad 7
3.0 Arming & Disarming
Take full advantage of your Spectra system by familiarizing
yourself with all of the arming methods.
If your system is not partitioned (see Partitioning on
page 22), everything is considered as belonging to area 1.
3.1 Exit Delay
After entering a valid arming sequence, an Exit Delay Timer
will provide you with enough time to exit the protected area
before the system arms. The keypad may beep during the
Exit Delay and the icon will flash with the number of the
partition in exit delay.
3.2 Disarming & Deactivating an Alarm
To disarm an armed system or an alarm, enter your access
code. An entry point, like the front door, will be programmed
with one of two Entry Delay Timers. When an entry point is
opened, the keypad will beep until you disarm the system.
Your alarm system will not generate an alarm until this timer
elapses. To disarm alarms generated by a Delayed Fire
Zone, please refer to Fire Alarms on page 15.
How Do I Disarm an Alarm?
Enter your [ACCESS CODE].
1640-EU02.fm Page 7 Wednesday, May 18, 2005 3:10 PM

8 User Guide
3.3 Alarm Memory Display
All zones where alarms have occurred will be stored in
memory. The system will erase the contents of the Alarm
Memory every time the system is armed.
3.4 Regular Arming
This method will arm all the zones in the selected area.
Regular Arming can also be activated using Auto-Arming
(see page 14), a Keyswitch (see page 14), or One-Touch
Arming (see page 12).
How Do I View the Alarm Menu?
1. Press the key.
2. The icon will flash and the corresponding number of
zones that were in alarm the last time the system was
armed will illuminate.
3. Press the or key to exit.
How Do I Regular Arm?
1. Close all zones in the desired area.
2. Enter your [ACCESS CODE].
3. If required, press the key corresponding to the desired
area, [1] or [2].For both areas, press the other key after
the confirmation beep.
1640-EU02.fm Page 8 Wednesday, May 18, 2005 3:10 PM

1640 Icon LCD Keypad 9
3.5 Stay Arming
This method allows you to remain in the protected area while
partially arming the system. Stay Zones are zones that are
bypassed when Stay Arming. For example, when you go to
sleep at night, doors and windows can be armed without
arming other zones like motion detectors.
Stay Arming can also be activated using Auto-Arming
(see page 14), a Keyswitch (see page 14) or One-Touch
Arming (see page 12).
3.6 Instant Arming
Instant Arming is similar to Stay Arming. Instant Arming
partially arms your system and enables you to remain in the
perimeter after the system is armed. However, Instant Arming
ignores any Entry or Exit Delays Therefore, any armed zone
that is breached will immediately generate an alarm.
How Do I Stay Arm?
1. Close all zones in the desired area (except Stay Zones).
2. Press the key.
3. Enter your [ACCESS CODE].
4. If required, press the key corresponding to the desired
area, [1] or [2].For both areas, press the other key after
the confirmation beep.
1640-EU02.fm Page 9 Wednesday, May 18, 2005 3:10 PM

10 User Guide
3.7 Force Arming
During Force Arming, any open zones are temporarily
“deactivated” so you can rapidly arm the system without
waiting for all of the zones in the system to close. When the
zone closes, the system will then arm those zones. Force
Arming is commonly used when a motion detector is
protecting the area occupied by a keypad.
Force Arming can also be activated by using One-Touch
Force Arming (see page 13).
How Do I Instant Arm?
1. Stay Arm the system as outlined in Stay Arming on
page 9.
2. During the Exit Delay press and hold the key for 3
seconds.
How Do I Force Arm?
1. Close zones in the desired area (except Force Zones).
2. Press the key.
3. Enter your [ACCESS CODE].
4. If required, press the key corresponding to the desired
area, [1] or [2].For both areas, press the other key after
the confirmation beep.
1640-EU02.fm Page 10 Wednesday, May 18, 2005 3:10 PM

1640 Icon LCD Keypad 11
3.8 Manual Bypass Programming
Manual Bypass Programming allows you to program the
alarm system to ignore (deactivate) specified zones the next
time the system is armed. For example, you may wish to
bypass certain zones when workers are renovating part of
your establishment. Once the system is disarmed, the bypass
entries are erased.
Can also be activated by using One-Touch Bypass
Programming (see page 13).
3.8.1 Bypass Recall Feature
After disarming the system, the bypass entries are erased.
The Bypass Recall Feature reinstates the previous bypass
How Do I Bypass Zones?
1. Press the key.
2. Enter your [ACCESS CODE]. The icon flashes.
3. If required, select the area whose zones you wish to
bypass by pressing the [1] or [2] key.
4. Enter the desired two-digit zone number (i.e. zone 3 =
03) or use the [U]or [V]buttons to scroll to the desired
zone and press the key. Repeat to unbypass the
zone. If the zone number illuminates, the zone is
bypassed. If the zone number is extinguished, the zone
is unbypassed.
5. Repeat step 4 until all desired zones are bypassed.
6. Press the key to exit. The icon will illuminate.
1640-EU02.fm Page 11 Wednesday, May 18, 2005 3:10 PM

12 User Guide
entries saved in memory. This eliminates the need to
manually reprogram the bypass entries every time you arm
the system.
3.9 One-Touch Arming
One-Touch Arming allows you to arm the system without
using an access code. These features must be enabled by
your installer.
3.9.1 One-Touch Regular Arming
Press and hold the key for 3 seconds to arm all zones in
the area. You can use this feature to allow specific individuals
like service personnel (i.e. cleaners) to arm without giving
them access to any other alarm system operations. For
details on Regular Arming, refer to Regular Arming on
page 8.
3.9.2 One-Touch Stay Arming
Press and hold the key for 3 seconds to stay arm. For
details on Stay Arming, refer to Stay Arming on page 9.
How Do I Recall Bypass Entries?
1. Press the key.
2. Enter your [ACCESS CODE].
3. Select an area.
4. Press the key.
5. Press the to exit.
1640-EU02.fm Page 12 Wednesday, May 18, 2005 3:10 PM

1640 Icon LCD Keypad 13
3.9.3 Exit and Stay Arm
With the system already Stay armed, press and hold the
key for 3 seconds to start the Exit Delay (see page 7). You
can now leave the premises. When the Exit Delay elapses,
the system will return to Stay Arming.
3.9.4 Exit and Regular Arm
With the system is already Stay armed, press and hold the
key for 3 seconds to start the Exit Delay (see page 7).
You can now leave the premises. When the Exit Delay
elapses, the system will switch to Regular Arming (see
page 8).
3.9.5 Exit and Force Arm
With the system is already stay armed, press and hold the
key for 3 seconds to start the Exit Delay (see page 7). You
can now leave the premises. When the Exit Delay elapses, the
system will switch to Force Arming (see page 10).
3.9.6 One-Touch Force Arming
Press and hold the key for 3 seconds to bypass any open
Force Zones. For details on Force Arming, refer to page 10.
3.9.7 One-Touch Bypass Programming
Press and hold the key for 3 seconds to access Bypass
Programming Mode (see page 11).
1640-EU02.fm Page 13 Wednesday, May 18, 2005 3:10 PM

14 User Guide
3.10 Keyswitch Arming
A keyswitch can be used to arm and disarm the system. A
keyswitch is programmed to Stay Arm (see page 9) or
Regular Arm (see page 8). A keyswitch can function as a
Maintained or Momentary keyswitch.
To arm the system using a Maintained Keyswitch, set the
keyswitch to the ON position. To disarm the system set the
keyswitch to the OFF position.
To arm the system using a Momentary Keyswitch, set the
keyswitch to the ON position then turn it back to the OFF
position. Repeating this sequence will disarm the system.
3.11 Timed Auto-Arming
You can program the time at which your alarm system will
automatically arm itself everyday.
How do I Program the Auto-Arm Timer?
1. Press the key.
2. Enter your [MASTER CODE].
3. Enter [101] for area 1 or [102] for area 2.
4. Enter the desired [TIME]. Note: Your installer will have set
the time as either International (24hr) or U.S. (12hr)
format.
5. Select [1] for a.m. or [2] for p.m. time format. Refer
Program Time on page 21 for details concerning time
formats.
1640-EU02.fm Page 14 Wednesday, May 18, 2005 3:10 PM

1640 Icon LCD Keypad 15
A 60-second Exit Delay (see page 7) will start before the
system arms. Auto-Arming can be cancelled by entering
your access code.
3.12 “No Movement” Auto Arming
Your panel can be programmed to arm the system and/or
send a report if no zone activity occurs for a pre-programmed
amount of time. This is useful when supervising an individual
with chronic health problems or who lives alone.
3.13 Fire Alarms
Upon a fire alarm, the bell/siren will emit three “squawks” at 2
second intervals until silenced or reset by entering a valid
access code. If the zone is a Delayed Fire Zone, there is a
delay before the system contacts the monitoring station. This
will prevent unnecessary reporting of false alarms. If there is
no fire condition, contact your monitoring station immediately
to avoid an unnecessary response.
What Do I Do if a Delayed Fire Zone Was Activated?
1. Press the key within 30 seconds of the alarm.
2. Try to correct the problem.
3. If the problem persists, the alarm will sound again. Press
the key again.
This instructs the system to delay reporting the fire alarm to
the monitoring station (see Figure 3.1 on page 16).
1640-EU02.fm Page 15 Wednesday, May 18, 2005 3:10 PM

16 User Guide
Figure 3.1: Delayed Fire Zone Event Sequence
1640-EU02.fm Page 16 Wednesday, May 18, 2005 3:10 PM
