THE LEADER IN ARCHITECTURAL AUDIO™
IN-WALL KEYPAD

Navigator K2
SONANCE'S NAVIGATOR K2 In-wall keypad makes controlling audio, video and other electronics
throughout the home so easy that any member of the family can use it. The Navigator K2
features an elegant combination of hard keys and an LCD touch screen for intuitive control.
The hard keys provide tactile feedback (power, volume up/down, channel up/down) and have
customizable source & genre buttons for flexible applications, while the LCD touch screen
changes to bring up only the relevant control buttons on the screen for each source selected.
The high contrast, high resolution LCD touch panel provides excellent off-axis and
direct sunlight viewing, making it easy to see what’s on the screen at all times.
What’s more,the Navigator K2 can control virtually anything that is IR-based –
motorized drapes and screens, IR-based security and lighting, and of course
whole house audio systems. And the K2 features a wide-band IR receiver for
use with hand-held remote controls.
Easy to Program:
The Navigator K2 is remarkably easy to program, thanks to the very intuitive and robust PC-based
K2 Program Manager software. The software contains a very extensive IR library so installers can
just drag and drop the devices in each system, then save a custom-configured system to program
multiple Navigator K2 in-wall keypads. The K2 Program Manager software also features a drag
and drop library for bitmap images, further allowing the installer to custom configure the system
to fit each customer’s needs. You can even enter in CD artist and title information
for display on the LCD touch screen. The installer can also utilize the software to
program in and save macros with up to 64 commands and selectable time delays
from .1 to 10 seconds. Visit www.sonance.com to download the K2 Program
Manager software for free.
Easy to Install:
At only 1.83 inches, the Navigator K2 is an attractive solution for almost any wall
thickness, including new construction and European standards. It also has
self-mounting toggle feet for easy in-wall installation. The attractive white bezel
cover (included) mounts and stays there without screws thanks to strong magnets.
Additional colors in Black, Ivory and Almond can be purchased separately to match décor.
Multiple Navigator K2 in-wall keypads may be used in an installation and will automatically
synchronize with each other, thanks to the sync I/O port, making it easy for the user and
installer to see what source is playing on a distributed audio system throughout the house.
The Navigator K2 is the ideal choice for controlling whole house audio/video system.
It also integrates well with the Sonance Navigator Harbor and Sonamp 1230 amplifier.

Navigator K2 Key benefits:
• Intuitive and simple to operate.
• High contrast LCD touch screen.
• Turns on music, lights, and more with a single press of a key.
The elegant combination of hard keys and an LCD touch screen makes the Navigator K2 one of the most intuitive, easy-to-use in-wall control devices on the market.
Press the “Tuner” button and
the LCD touch screen will bring
up a list of favorite stations for
easy selection. Press the
“DVD” button, and the DVD
control buttons appear on the
touch screen.
Sonance Navigator Harbor – the central brains of your system.
The Sonance Navigator Harbor is a high performance multi-zone controller. Designed for use
with the Navigator K2 in-wall keypad, the Navigator Harbor feeds up to six audio/video sources
to six rooms, enabling listeners in the living room to watch a DVD movie while a CD plays in the
kitchen. It can also easily expand to handle up to 30 zones by linking duplicate RCA input jacks.
Individual Navigator K2 in-wall keypads in each room allow for easy selection of the source in
each zone. The Navigator K2 features a local IR flasher output for each zone, allowing for
independent zone/source equipment control, as well as six common IR flasher inputs for
shared source equipment.
Add a Sonance Sonamp®1230 or 1250MKII to complete your system!
No whole house audio/video system would be complete without a high
quality 12-channel amplifier, and Sonance delivers once again. Choose a
Sonamp 1230 (12 x 30 watts/channel) or Sonamp 1250MKII (12 x 50
watts/channel) to complete your system. Both amplifiers
reliably deliver power to each zone of your system.

NAVIGATOR K2
SPECIFICATIONS
SONANCE • 212 AVENIDA FABRICANTE • SAN CLEMENTE, CA 92672-7531 • TEL: [phone] • 949-492-7777 • FAX: [phone] • 949-361-5151
©2002 SONANCE. ALL RIGHTS RESERVED. SONAMP IS A REGISTERED TRADEMARK OF SONANCE. 33-2989 12/02
ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
TAKE THE TOUR AT WWW.SONANCE.COM
Navigator K2 In-wall Keypad
Navigator K2 In-wall keypad
with LCD touch screen
Navigator Harbor
Multi-Zone A/V Controller
High contrast, high viewing angle 64 x 128
pixel, black & white LCD touch screen with
white LED backlighting
• Six interchangeable hard source buttons
• Built-in IR receiver
• One IR Output (200mA)
• One half-duplex RS485 port
(RJ-45 connection for future
upgradability, not active at this time).
• One power sense input
• One speaker relay trigger output
• One speaker relay status input
• One keypad sync I/O port for keeping
multiple keypads synchronized to the
same page/source
• K2 Program Manager intuitive & robust
PC software for programming and
configuration
• Includes toggles, programming cable,
and white bezel (Additional faceplates in
Black, Ivory, and Almond colors sold
separately).
• Overall Dimensions (W x H x D): 4.5” x
4.5” x 1.83” (114mm x 114mm x 46.5mm)
• In-wall Dimensions (W x H x D): 3.66” x
3.23” x 1.83” (93mm x 82mm x 46.5mm)
•Inputs: Audio – 6 gold RCA, 6 looping jacks
47k; Video-6 gold RCA, 6 buffered looping
jacks 75Ohms; IR/Keypad- 5 position
removable connector; Paging-3.5mm mono
mini-plug with variable level control; OPTO
isolated 5-24VDC trigger Input
•Outputs: Audio-6 stereo RCA 600Ohms;
Video-6 composite RCA 75Ohms; 6 com
mon IR, 6 zone, 1 linking (3.5mm mono
mini-plug for all IR outputs)
• Frequency Response: 20Hz-20kHz +/-0.5dB
• Input Dynamic Range: 90dB
• Volume Control Range: 68dB
• THD: Less than 0.02% 20Hz-20kHz
• Signal to Noise Ration: less than -98dB
(A weighted)
• Preamp Gain: +12dB at maximum volume
• Maximum Signal Output: 9V RMS into
10kOhms load
• Dimensions (W x H x D): 16-3⁄4” x 5-5/8” x
12-5/8” (425mm x 143mm x 321mm)
• Weight: 20 lbs (9 kg)
• Also available in rack mount version
Sonamp 1230
12 Channel Amplifier Sonamp 1250MKII
12 Channel Amplifier
• All Channels Driven Power Output: 30
Watts per channel @ 8Ohms; 45 Watts per
channel @ 4Ohms
• Total Harmonic Distortion: 0.03% 20Hz-
20kHz @ 8Ohms; 0.10% 20Hz-20kHz @
4Ohms (45 WRMS)
• I.M. Distortion (SMPTE 4:1) @ 8Ohms:
0.01% @ 30 Watts
• Signal to Noise Ratio: -100dB below rated
output (A-weighted)
• Input Sensitivity: 700 millivolt for 30 watts
RMS @ 8Ohms
• Input Impedance: 20kOhms
• Power Consumption: 1400 Watts,
maximum 4Ohms full power
• Fuse: 10A AG
• Dimensions (W x H x D): 16-3/4" x 5-5/8" x
14-1/4" (425mm x 143mm x 362mm)
• Weight: 38 lbs (17 kg)
•Also available in rack mount version
• All Channels Driven Power Output: 50
Watts per ch x 12 @ 8 Ohms; 75 Watts per
ch x 12 @ 4 Ohms; 100 Watts per ch x 6 @
8 Ohms bridged.
• Dynamic Headroom: +1.9dB x 12 @ 8
Ohms; +1.8dB x 12 @ 4 Ohms; +3.5dB x 6
@ 8 Ohms bridged
• Total Harmonic Distortion: 0.03% 20Hz-
20kHz @ 8 Ohms, 50 Watts; 0.06% 20Hz-
20kHz @ 4 Ohms, 75 Watts; THD less than
0.01% @ 1 kHz 4 Ohms, 75 Watts
• I.M. Distortion (SMPTE 4:1) @ 8 Ohms:
0.01% @ 50 Watts, 8 Ohms
• Signal to Noise Ratio: -100dB below rated
output (A-weighted)
• Input Sensitivity: 700 millivolts for 50 Watts
RMS @ 8 Ohms
• Input Impedance: 20kOhms
• Power Consumption: 1800 Watts maximum
@ 4 Ohms, full power; 10 Watts standby
• Fuse: 15A MDA, 250V
• Dimensions (W x H x D): 16-3/4" x 9-1/2" x
16-1/2" (425mm x 243mm x 420mm)
• Weight: 55 lbs (25 kg)
•Also available in rack mount version
Use the Sonance Navigator Harbor and the Sonamp®1230, or Sonamp 1250MKII
for seamless integration with the Navigator K2.
Sonance Navigator K2 system hook up
diagram for a sample whole house system!
Additional wall plate colors are also
available in: Almond, Black, and Ivory!
Navigator Harbor
Sonamp 1230
