Sony TA-VE110 User manual
SERVICE MANUAL
MICROFILM
TA-VE110
AEP Model
UK Model
STEREO AV AMPLIFIER
SPECIFICATIONS
Amplifier section
Power output
Surround mode (DIN 1 kHz)
Front:
25 W+25 W/8 ohms
Center:
25 W/8 ohms
(only in the PRO LOGIC
and C, STUDIO modes)
Rear:
10 W+10 W/8 ohms
Frequency VIDEO 1+2, TV, AUX:
response 20 Hz-20 kHz ± 2 dB
Audio section
Inputs Sensitivity Impedance
VIDEO1, 150mV 50kilohms
VIDEO2,
TV, AUX
Outputs VIDEO 1 REC:
Voltage: 150 mV,
Impedance: 470 ohms
REAR, MIX:
Voltage: 1 V
Impedance: 1 kilohms
BASS BOOST +7 dB at 60 Hz
General
Power
requirements 220-230 V AC, 50/60 Hz
Power
consumption 110 W
Dimensions 430 ×95 ×280 mm
(17 ×3 3/4 ×11 1/8 inches)
Mass (Approx.) 4.6 kg
(10 lb 2 oz)
Supplied
accessories Remote controller
(remote) (1)
Size AA (R6) batteries (2)
Scart adaptor (1)
Design and specifications are subject to
change without notice.
