SERVICE MANUAL
US Model
Canadian Model
XM-DS1600P5
MONAURAL POWER AMPLIFIER
Other Specifications
Circuit system Class D Technology
Pulse power supply
Inputs RCA pin jacks
High level input connector
Outputs Speaker terminals
Through out pin jacks
Suitable speaker impedance
2 – 8 Ω
Maximum outputs 1,000 W (at 4 Ω)
1,600 W (at 2 Ω)
Rated outputs (supply voltage at 14.4V)
500 W (20 – 300 Hz, 0.2% THD, at 4 Ω)
900 W (20 – 300 Hz, 0.6% THD, at 2 Ω)
Frequency response 5 – 300 Hz ( dB)
Harmonic distortion 0.06% or less (at 100 Hz, 4 Ω)
Input level adjustment range
0.3 – 6.0 V (RCA pin jacks)
1.2 – 12.0 V (High level input)
Sub-sonic filter 15 Hz, –12 dB/oct
Low-pass filter 50 – 300 Hz, –12 dB/oct
Low boost 0 – 10 dB (40 Hz)
Power requirements 12 V DC car battery
(negative ground)
Power supply voltage 10.5 – 16 V
Current drain at rated output : 90 A (at 2 Ω)
Remote input : 2 mA
Dimensions Approx. 347 ×57 ×339 mm
(13 3/4 ×2 1/4 ×13 3/8 in.) (w/h/d) not incl.
projecting parts and controls
Mass Approx. 3.8 kg (8 lb. 6 oz.) not incl. accessories
Supplied accessories Mounting screws (5)
High level input cord (1)
Protection cap (1)
4P modularcable (1)
Remote level controller (1)
Screws (2)
Design and specifications are subject to change without
notice.
SPECIFICATIONS
AUDIO POWER SPECIFICATIONS (US MODEL)
POWER OUTPUTAND TOTAL HARMONIC DISTORTION
500 watts minimum continuous average power into 4 ohms,
20 Hz to 300 Hz with no more than 0.2% total harmonic
distortion per Car Audio Ad Hoc Committee standards.
+0.5
–3
Notes on Chip Component Replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Ver 1.0 2003. 12
Sony Corporation
e Vehicle Company
Published by Sony Engineering Corporation
9-961-619-01
2003L04-1
© 2003. 12

2
TABLE OF CONTENTS
1. GENERAL
Location and Function of Controls.......................................... 3
Connections ............................................................................. 4
2. DISASSEMBLY
2-1. Bottom Plate ........................................................................ 6
2-2. Main Board Section ............................................................. 7
2-3. Disassembly and Assembly of Ornamental Plate ................ 7
2-4. Main Board .......................................................................... 8
2-5. LED Board ........................................................................... 8
3. DIAGRAMS
3-1. IC Block Diagrams .............................................................. 9
3-2. Printed Wiring Boards –Main Section (1/2)– .................... 10
3-3. Printed Wiring Boards –Main Section (2/2)– .................... 11
3-4. Schematic Diagram –Main Section (1/2)– ........................ 12
3-5. Schematic Diagram –Main Section (2/2)– ........................ 13
4. EXPLODED VIEWS
4-1. Heat Sink (Main) Section .................................................. 15
4-2. Main Board Section ........................................................... 16
5. ELECTRICAL PARTS LIST......................................... 17
XM-DS1600P5
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMESSCHÉMATIQUES ETLALISTE DES PIÈCES SONT
CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT. NE
REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY
DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL OU
DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.

3
XM-DS1600P5
SECTION 1
GENERAL This section is extracted
from instruction manual.

4
XM-DS1600P5

5
XM-DS1600P5

6
XM-DS1600P5 SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. BOTTOM PLATE
Note : This set can be disassemble according to the following sequence.
2-1. BOTTOM PLATE
(Page 6)
2-2. MAIN BOARD SECTION
(Page 7)
2-5. LED BOARD
(Page 8)
SET
2-4. MAIN BOARD
(Page 8) 2-3. DISASSMBLY AND ASSEMBLY
OF ORNAMENTAL PLATE
(Page 7)
4 bottom plat
e
5 insulating sheet
2 three screws
(+P 3
x 6)
3 five screws
(+P 3
x 6)
1 screw
(+P 3
x 6)

7
XM-DS1600P5
2-3. DISASSEMBLY AND ASSEMBLY OF ORNAMENTAL PLATE
2-2. MAIN BOARD SECTION
heat sink (main)
6 CNT2
5 MAIN board section
2 three screws
(+BTP 3
x 14)
3 three screws
(+BTP 3
x 14)
4 three screws
(+BTP 3 x 14
)
1 screw
(+P 3 x 8)
heat sink (main)
At disassembly:
At assembly:
ornamental plate
cut
welding
heat sink (main)
ornamental plate

8
XM-DS1600P5
2-4. MAIN BOARD
2-5. LED BOARD
3 panel (front)
4 MAIN board
2 two screws
(+P 3
x 8)
1 screw
(+P 3
x 8)
2 LED board heat sink (main)
1 screw
(+P 3
x 6)

99
XM-DS1600P5
3-1. IC BLOCK DIAGRAMS
IC6 TL494CN
SECTION 3
DIAGRAMS
•A: B+ Line.
•B: B– Line.
•Total current is measured with no-signal condition.
•Powervoltageisdc14.4Vandfedwithregulateddcpower
supply from +12V and REM terminals.
•Voltage is dc with respect to ground under no-signal
condition.
•Voltages are taken with aVOM(Inputimpedance10MΩ).
Voltage variations may be noted due to normal produc-
tion tolerances.
•Waveforms are taken with a oscilloscope.
Voltage variations may be noted due to normal produc-
tion tolerances.
•Circled numbers refer to waveforms.
•Signal path.
F:AUDIO
for printed wiring boards:
Note:
•X: parts extracted from the component side.
•: Pattern from the side which enables seeing.
(The other layer’s patterns are not indicated.)
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS
AND SCHEMATIC DIAGRAMS.
(In addition to this, the necessary note is
printed in each block.)
for schematic diagram:
Note:
•All capacitors are in µF unless otherwise noted. pF: µµF
50 WV or less are not indicated except for electrolytics
and tantalums.
•All resistors are in Ωand 1/4W or less unless otherwise
specified.
•%: indicates tolerance.
•2: nonflammable resistor.
Caution:
Pattern face side: Parts on thepatternfaceside seenfrom the
(Side B) pattern face are indicated.
Parts face side: Parts on the parts face side seen from the
(Side A) parts face are indicated.
Note:
The components identi-
fied by mark 0or dotted
linewithmark0arecriti-
cal for safety.
Replace only with part
number specified.
Note:
Lescomposantsidentifiéspar
une marque 0sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
IC10 SSM2018TP
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
V1
BAL
VG
GND
MODE
VC
V-
COMP3
+I1 1-G
G
V+
IG
-I1
COMP1
+IN
-IN
COMP2
GAIN
CORE
OSC
REF 5V
ERROR
ERROR
0.1V
16 15 14 13 12 11 10 9
1 2 3 4 5 6 7 8
NON INV VREF VCC C2 E1 E2 OUT
+IN
-IN
COMP EN
CT
RT
C1
GND
TIME

10 10
XM-DS1600P5
3-2. PRINTED WIRING BOARDS — MAIN SECTION (1/2) — • Refer to page 9 for Common Note on Printed Wiring Boards.
1
A
B
C
D
E
F
G
H
I
J
2345678910111213
MAIN BOARD (SIDE A)
1
8
4
5
1
8
4
5
1
8
4
5
1
8
4
5
1
8
4
5
5
4
8
1
17
814
BCE
BCE
BCE BCE BCE
BCE
BCE
BCEBCE
ECB
BCE
BCE
BCE
BCE
ECB
BCE
BCE
ECB
BCE
BCE
BCE
BCE
1-861-422-
11
(11)
LED BOARD
(SIDE A)
1-861-423-
11
(11)
(POWER)
(PROTECTOR)
POWER/PROTECTOR
GR
VOLUME
BOARD
(SIDE A)
VOLUME ASSY
11
(11)
1-861-424-
R302 R48 R47
C32
R66
R128
R88
R74 R75 R76
C33
R77 R67
C31
R80
R170
R97
R79 R69 R68
R104
R85
R103
R106
R152
D26
R150
R87
R82
C38
R54
C35
R81 R17 R18
CF1 R19
C49
R112
R113 R213
R129
R127 R131
R62R61
C56
C55
R108
R171
C44
R64
R65
R92
C42
C37
C18
C19
R91
Q9 Q8 Q7
Q44
Q16
Q42
Q45
Q5
Q6
D23
Q14
Q15
Q37
D11
D9
Q35
Q43 Q10
Q17
Q48 D3
Q39
Q13
Q36
Q34
Q11
R72
C43
R180
R183
R162
R149 R84
R164
R157
R158
R1
C20
R132
C7
R130
R173
LED3
LED2
R172
R175
R105
C48
R159
R25
R23
IC2
IC5
IC4
IC9
IC7
IC8
IC1
R24
R50
R43
R51
R52
R126
R125
R53
R174
R15
C14
R60
C15
R59
C16
R16
C10
R12 R13
R29
RV2
R27
R28
R109 R110
R111
R211
R117
R119
R215 R115
R116
R114
R118
R14
R5
CV2
RV1
CV6
R58
RV3
RG20
RG19
RG18
RG17
RG16
RG15
RG14
RG13
RV4
CV7
RV5
RV6
C9
R26
C24
R169
RS4
C8
R123
R134
R56R57
RS3
R20
RS5
C21
R2
R3R4
RS2RS1
C26C25
C2C23
C12
R8
C1
C13
R11
R10
R156
C28
C50 C53
R7 C27
R6
R136
C30
C51 C52
R163 C 2 9
RC4
RC3
RC1
RC2
C54
R96
C36
R55
R160
CF9
R71
C22
R70
C6 R78
R86
C34
R166
CF10
R98 R83
R161 R184
R154
R99
R73
C5
R90
R202
R102
R46
R45
THR3
THR1
R120
R107
R135
R182
R181
R151
R155
D3 H-7
D9 E-4
D11 F-4
D23 G-6
D26 G-7
IC1 G-4
IC2 F-4
IC4 E-3
IC5 F-4
IC7 H-7
IC8 F-5
IC9 F-4
LED2 G-12
LED3 G-12
Q5 F-6
Q6 F-7
Q7 G-7
Q8 G-8
Q9 G-8
Q10 G-4
Q11 G-5
Q13 I-9
Q14 G-6
Q15 G-6
Q16 G-7
Q17 G-5
Q34 G-5
Q35 G-5
Q36 G-6
Q37 F-3
Q39 G-6
Q42 G-7
Q43 G-5
Q44 G-7
Q45 G-7
Q48 H-7
• Semiconductor
Location (Side A)
Ref.No. Location

11 11
XM-DS1600P5
3-3. PRINTED WIRING BOARDS — MAIN SECTION (2/2) — • Refer to page 9 for Common Note on Printed Wiring Boards.
1
A
B
C
D
E
F
G
H
I
J
2345678910111213
-1 -2
3
4
1
2
-1 -2
-1 -2
-3
L
-4
R
-1
L
-2
R
-1
-2 -4
-3
40A 40A 40A
C B E
C B E
B C E B C E
B C E
B C E
B C E
B C E
B C E
B C E
C B EC B EC B EC B E
C B E
-4 -2
-3 -1
RL
OUTPUT
(THROUGH)
INPUT
HIGH LEVEL INPUT
34
21
4
31
3
12
B C E
B C E
9
8
16
1
9
8
16
1
1-861-422-
11
(11)
B C E
G D S G D S G D S G D S
GD S
G D S
G D S
G D S
SD G
SD G
SD G
SD G
S D G
S D G
S D G
S D G
S D G
S D G
S D G
S D G
MAIN BOARD (SIDE B)
1-861-423- 11
(11)
LED BOARD
(SIDE B)
VOLUME
BOARD
(SIDE B)
1
3
11
(11)
31
42
(LEVEL)
1-861-424-
VOLUME ASSY
LEVEL
CONTROL
CNT3
LEVEL
LOW
BOOST
(40Hz)
LPF
SUBSONIC
FILTER
ON
OFF
ORG
BLK
YEL
REM
+12VGND
SPEAKER OUT
(L+R) (L+R)
YEL
BLK
ORG
MC11
MC3
MC12
R93
MC15
PT1
MC26
MC16
MC27
MC28
MC19
ZD6
ZD5
D16
D15
D12
ZD3
ZD4
ZD2
ZD1
D13
D2
CS4
MC5
MC4
MC6
MC7
C17
MC21
BD1 BD2 BD3 BD4 BD5 BD6
MC22
MC24 MC23 MC30
MC29
MC17
MC20
MC18
MC31
CS3
MC9
EC9
Q3Q4Q2Q1
EC28
EC29
LF2
R122
R124
R139
R137
RG12
RG11
RG10
RG9
RG8
R121
R148
R147
R146
R145
R144
R143
RG7
RG6
RJ1
RJ2
RG5
RG4
RG3
RG2
RG1
RJ3
THR2
PTC2
PTC1
MC10
D8
MC25
FET20 FET19 FET17 FET16 FET13
FET14
FET18 FET15
D21
D19
D20 D22
FET9
FET10
FET11
FET12
FET8
FET7
FET6
FET5
FET4
FET3
FET2
FET1
VR1
CNT3
VR3
VR2
SW1
JK1
LF3
T1
IC6
EC31
EC32 EC33
EC40 EC39
EC38
EC37 EC30
EC14
EC16
EC21 EC20
EC17
EC13
EC52
EC51
EC53
EC7
EC8
EC6
EC11
EC50
EC5
EC55
EC54
EC1
EC2
EC56
EC10EC4EC3
EC61
EC12
EC58
R101
CNT1
Q20
EC15
EC25 EC24
EC23 EC22
EC27 EC26
Q29Q25
Q22
Q18
Q19
Q23 Q27
Q31
Q30
Q21
Q47 Q46
IC10
FUSE1 FUSE2 FUSE3
TER1
Q12
CNT2
CON01
CNT03
EXVR01
D2 F-7
D8 E-4
D12 E-7
D13 E-7
D15 F-5
D16 F-4
D19 A-8
D20 B-8
D21 B-8
D22 B-9
FET1 H-10
FET2 G-10
FET3 G-10
FET4 F-10
FET5 F-10
FET6 E-10
FET7 E-10
FET8 D-11
FET9 C-10
FET10 C-10
FET11 C-10
FET12 B-9
FET13 A-6
FET14 B-6
FET15 B-6
FET16 B-5
FET17 B-5
FET18 C-4
FET19 C-4
FET20 C-3
IC6 F-7
IC10 D-3
PTC1 G-7
PTC2 F-6
Q1 G-5
Q2 G-5
Q3 F-5
Q4 F-5
Q12 I-9
Q18 E-3
Q19 E-4
Q20 E-7
Q21 D-4
Q22 E-3
Q23 D-4
Q25 D-3
Q27 D-4
Q29 D-3
Q30 E-4
Q31 D-4
Q46 F-8
Q47 F-7
ZD1 G-5
ZD2 G-5
ZD3 F-5
ZD4 F-5
ZD5 F-6
ZD6 H-8
• Semiconductor
Location (Side B)
Ref.No. Location

12 12
XM-DS1600P5
3-4. SCHEMATIC DIAGRAM — MAIN SECTION (1/2) — • Refer to page 9 for Common Note on Schematic Diagram and IC Block Diagrams.
IC B/D
D15
D16
Q5
Q6
Q7
Q8
Q9
Q11
Q16
Q39
Q42Q43
Q44
ZD1
ZD2
ZD3
ZD4
CNT1
MC3
MC4
MC5
MC6
MC7
EC3
EC4
EC5
EC6
EC7
EC8
EC12
EC56
EC53
R55
R54
R180R181
R64
R78
R79
R68
R74
R75
R152 R150
R84
R77
R155
R4
R3
R20 R23
R24 R25 R5
R169
R29
R12 R14
R15
R16 R174 R52
R50
R43
R51
R53
R60
R59
R57
R62
R61
R17
R18
R73
R80
R106
EC9
EC10
EC11
EC50
EC51
EC52
R28
R8
EC28
EC29
R26
R183
R10
R11
C51 C52 C50 C53
C12
C43C38C54
MC10
C14
C15
C31
C17
EC1
EC54
R1
R156
EC55
EC2
R157
R2
C28
C27
C30
C29
R159
R158
R13
D11
MC9
C16
D3
R154R81
R182
C6
R67
IC1(1/2)
IC1(2/2)
IC9(2/2)
IC2(1/2)
IC2(2/2)
VR3
RS2
RS1
VR1
VR2
IC4(2/2) IC4(1/2)
Q3
Q4
Q1
Q2
CNT2
Q14
Q15
D23
JK1
Q37
Q45
IC7
R65
R88
RJ3
THR3THR2THR1
IC5(2/2) IC5(1/2)
R163
R6
R164
R7
C1
C13
C2
C23
C21
C20
C9
C10
R136
LED2
R87
R96
R76
R184
R171R170 ZD6
R103
R104
R97 MC19
R27
MC31
SW1
CS4CS3
RV2
RV1
RV3
RV4
CV7
CV6
CV2
RV5
RV6
C26 C24
C35 C36
R149
R82
D26
R99
R161
R162
R160
R69 C5
R66
LED3
CON01
C25 RS3
RS4
IC9(1/2) RS5
IC10
EXVR01
CNT03 CNT3
R85
Q48
R70
(Page 13)

13 13
XM-DS1600P5
3-5. SCHEMATIC DIAGRAM — MAIN SECTION (2/2) — • Refer to page 9 for Common Note on Schematic Diagram and IC Block Diagrams.
IC B/D
IC6
D2
D12
D13
Q13
Q17
Q20
Q22
Q31
Q35
Q36
FET1 FET2 FET3 FET4 FET5 FET6
FET7 FET8 FET9 FET10 FET11 FET12
FET13
FET14
FET15
FET16
FET17
FET18
FET19
FET20
Q23
Q25
Q27
Q29
MC11
MC15
MC20
MC21
MC22
MC23
MC24
MC25
MC26
MC27
MC28
EC14
EC61
R101
R91
R90
R56
R110
R134
R131
R105
R166R86
R71
D22
D21
D20
D19
C42
C19
C37
R48
R46
C32
R58
R117
CF1
R114
R115 R215 R112
R19
R118
RG1 RG2 RG3 RG4
RG7 RG8 RG9 RG10 RG11 RG12
RG6
RG5
R83
C34
D9
R111 R211
C18
MC12
R102
R202
R302
C8 R123
R72
ZD5
EC13
R132
R143 R144 R145 R146 R147 R148
EC27
EC26
EC25
EC24
EC23
EC22
CF9 CF10
IC8
R109
PTC2
PTC1
LF2
RC3
RC4
BD1
BD2
BD3
BD4
BD5
BD6
RC2
RC1
Q10
Q34
Q12
TER1
FUSE1
FUSE2
FUSE3
MC18
RJ2
RJ1
PT1
T1
EC30
EC37
EC31
EC38
EC32
EC39
EC33
EC40
R92
LF3
Q18
Q19
Q21
R113
R121
R116
R122
EC16
EC17
EC21
EC20
C48
R172
EC58 R173
MC30
R98
MC29
C22
MC16
MC17
R137
R45
R47
EC15
C33
R119
D8
R108
R128
C7 R139
R124
R213
R93
Q30 C44
C55
R151
R125
C56 R107
R120
R129
R127
R126
R135
R175
RG13
RG14 RG15 RG16
RG17
RG18 RG19 RG20
C49
R130
Q46
Q47
RJ3
(Page 12)
• Waveform
IC6 5
11V/DIV, 5µsec/DIV
15µsec
3.4Vp-p

14 14
XM-DS1600P5
MEMO

15
XM-DS1600P5
•Color Indication of Appearance Parts
Example :
KNOB, BALANCE (WHITE) ... (RED)
Parts Color Cabinet’s Color
•Accessories are given in the last of this parts list.
RR
NOTE:
•The mechanical parts with no reference
number in the exploded views are not supplied.
•Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
SECTION 4
EXPLODED VIEWS
Ref. No. Part No. Description RemarkRef. No. Part No. Description Remark
4-1. HEAT SINK (MAIN) SECTION
13-253-053-11 PLATE, ORNAMENTAL
23-253-052-01 HEAT SINK (MAIN)
33-253-054-01 PLATE, LIGHT GUIDE
43-253-056-01 PANEL (REAR)
0FUSE1 1-533-743-11 FUSE (BLADE TYPE) (AUTO FUSE) (40A)
0FUSE2 1-533-743-11 FUSE (BLADE TYPE) (AUTO FUSE) (40A)
0FUSE3 1-533-743-11 FUSE (BLADE TYPE) (AUTO FUSE) (40A)
#1 7-685-645-79 SCREW +P 3X6 TYPE2 NON-SLIT
#2 7-685-549-19 SCREW +BTP 3X14 TYPE2 N-S
#3 7-685-646-79 SCREW +P 3X8 TYPE2 NON-SLIT
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
1
2
3
4
#1
#1
#2
not supplied
not supplied
(LED board)
#2
#2
#1 #3
#1
FUSE2
FUSE3
FUSE1

16
XM-DS1600P5
4-2. MAIN BOARD SECTION
Ref. No. Part No. Description RemarkRef. No. Part No. Description Remark
51 3-265-722-01 PANEL (FRONT)
52 A-3283-641-A MAIN BOARD, COMPLETE
53 3-253-061-01 HEAT SINK (SUB)
54 3-253-062-01 PLATE, RETAINER
55 3-225-183-11 SCREW (+PSW.TT.3XL)
56 3-912-431-01 SCREW (+–P)
57 3-912-432-01 SCREW (+–B)
58 3-253-537-01 SCREW (M5X11)
59 3-253-063-01 SHEET (TR), INSULATING
#1 7-685-645-79 SCREW +P 3X6 TYPE2 NON-SLIT
#3 7-685-646-79 SCREW +P 3X8 TYPE2 NON-SLIT
51
52
53
53
59
59
59
53
54
54
54
55
55 55
56
57
58
#3 #1
#1
#1
#3

17
XM-DS1600P5
SECTION 5
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
•Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
•RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
•Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
•SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
•CAPACITORS
uF : µF
•COILS
uH : µH
LED BOARD
**********
< DIODE >
LED2 8-719-060-99 LED SML-210MT-T86 (POWER/PROTECTOR
(POWER))
LED3 8-719-066-99 LED SML-210VT-T86 (POWER/PROTECTOR
(PROTECTOR))
*************************************************************
A-3283-641-A MAIN BOARD, COMPLETE
*********************
3-225-183-11 SCREW (+PSW.TT.3XL)
3-253-537-01 SCREW (M5X11)
3-253-061-01 HEAT SINK (SUB)
3-253-062-01 PLATE, RETAINER
3-253-063-01 SHEET (TR), INSULATING
3-912-431-01 SCREW (+–P)
3-912-432-01 SCREW (+–B)
7-685-645-79 SCREW +P 3X6 TYPE2 NON-SLIT
7-685-646-79 SCREW +P 3X8 TYPE2 NON-SLIT
< FERRITE BEAD >
BD1 1-410-396-41 INDUCTOR, FERRITE BEAD 0.45uH
BD2 1-410-396-41 INDUCTOR, FERRITE BEAD 0.45uH
BD3 1-410-396-41 INDUCTOR, FERRITE BEAD 0.45uH
BD4 1-410-396-41 INDUCTOR, FERRITE BEAD 0.45uH
BD5 1-410-396-41 INDUCTOR, FERRITE BEAD 0.45uH
BD6 1-410-396-41 INDUCTOR, FERRITE BEAD 0.45uH
< CAPACITOR >
C1 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C2 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C5 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C6 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C7 1-125-838-11 CERAMIC CHIP 2.2uF 10% 6.3V
C8 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C9 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C10 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C12 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C13 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C14 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C15 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C16 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C17 1-117-219-11 CERAMIC 68PF 5% 1KV
C18 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C19 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C20 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C21 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C22 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C23 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C24 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C25 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C26 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C27 1-164-346-11 CERAMIC CHIP 1uF 16V
C28 1-164-346-11 CERAMIC CHIP 1uF 16V
C29 1-164-346-11 CERAMIC CHIP 1uF 16V
C30 1-164-346-11 CERAMIC CHIP 1uF 16V
C31 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C32 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C33 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C34 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C35 1-100-743-11 CERAMIC CHIP 2.2uF 10% 16V
C36 1-100-743-11 CERAMIC CHIP 2.2uF 10% 16V
C37 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C38 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C42 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C43 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C44 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C48 1-163-019-00 CERAMIC CHIP 0.0068uF 10% 50V
C49 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C50 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C51 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C52 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C53 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C54 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C55 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
C56 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
CF1 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
CF9 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
CF10 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
*CNT1 1-691-785-11 PIN, CONNECTOR (PC BOARD) 4P
(HIGH LEVEL INPUT)
< JACK >
CNT3 1-818-341-11 JACK, MODULAR 4P (LEVEL CONTROL)
LED MAIN
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.

18
XM-DS1600P5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
< CAPACITOR >
CS3 1-137-379-11 FILM 0.33uF 5% 50V
CS4 1-130-497-00 FILM 0.15uF 5% 50V
CV2 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
CV6 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
CV7 1-127-573-11 CERAMIC CHIP 1uF 10% 16V
< DIODE >
D2 8-719-110-72 DIODE RD30ES-B2
D3 8-719-820-05 DIODE 1SS181
D8 8-719-160-29 DIODE RD6.2F-B2
D9 8-719-800-76 DIODE 1SS226
D11 8-719-800-76 DIODE 1SS226
D12 8-719-987-67 DIODE 11EFS2
D13 8-719-987-67 DIODE 11EFS2
D15 8-719-987-67 DIODE 11EFS2
D16 8-719-987-67 DIODE 11EFS2
D19 8-719-076-60 DIODE FCH20A15
D20 8-719-076-61 DIODE FRH20A15
D21 8-719-076-60 DIODE FCH20A15
D22 8-719-076-61 DIODE FRH20A15
D23 8-719-801-78 DIODE 1SS184
D26 6-500-086-01 DIODE RLS4148TE-11
< CAPACITOR >
EC1 1-128-582-11 ELECT 10uF 20% 63V
EC2 1-128-582-11 ELECT 10uF 20% 63V
EC3 1-126-965-11 ELECT 22uF 20% 50V
EC4 1-126-965-11 ELECT 22uF 20% 50V
EC5 1-126-965-11 ELECT 22uF 20% 50V
EC6 1-126-965-11 ELECT 22uF 20% 50V
EC7 1-126-965-11 ELECT 22uF 20% 50V
EC8 1-126-965-11 ELECT 22uF 20% 50V
EC9 1-104-666-11 ELECT 220uF 20% 25V
EC10 1-104-666-11 ELECT 220uF 20% 25V
EC11 1-128-582-11 ELECT 10uF 20% 63V
EC12 1-126-965-11 ELECT 22uF 20% 50V
EC13 1-126-965-11 ELECT 22uF 20% 50V
EC14 1-128-149-11 ELECT 100uF 20% 160V
EC15 1-128-339-11 ELECT 2200uF 20% 16V
EC16 1-107-947-11 ELECT 220uF 20% 160V
EC17 1-107-947-11 ELECT 220uF 20% 160V
EC20 1-107-947-11 ELECT 220uF 20% 160V
EC21 1-107-947-11 ELECT 220uF 20% 160V
EC22 1-115-814-11 ELECT 0.001F 20% 35V
EC23 1-115-814-11 ELECT 0.001F 20% 35V
EC24 1-115-814-11 ELECT 0.001F 20% 35V
EC25 1-115-814-11 ELECT 0.001F 20% 35V
EC26 1-115-814-11 ELECT 0.001F 20% 35V
EC27 1-115-814-11 ELECT 0.001F 20% 35V
EC28 1-126-951-11 ELECT 470uF 20% 35V
EC29 1-126-951-11 ELECT 470uF 20% 35V
EC30 1-100-587-11 ELECT 1000uF 20% 100V
EC31 1-100-587-11 ELECT 1000uF 20% 100V
EC32 1-100-587-11 ELECT 1000uF 20% 100V
EC33 1-100-587-11 ELECT 1000uF 20% 100V
EC37 1-100-587-11 ELECT 1000uF 20% 100V
EC38 1-100-587-11 ELECT 1000uF 20% 100V
EC39 1-100-587-11 ELECT 1000uF 20% 100V
EC40 1-100-587-11 ELECT 1000uF 20% 100V
EC50 1-126-934-11 ELECT 220uF 20% 16V
EC51 1-126-965-11 ELECT 22uF 20% 50V
EC52 1-126-965-11 ELECT 22uF 20% 50V
EC53 1-126-963-11 ELECT 4.7uF 20% 50V
EC54 1-128-582-11 ELECT 10uF 20% 63V
EC55 1-128-582-11 ELECT 10uF 20% 63V
EC56 1-104-665-11 ELECT 100uF 20% 25V
EC58 1-104-665-11 ELECT 100uF 20% 25V
EC61 1-126-966-11 ELECT 33uF 20% 16V
< TRANSISTOR >
FET1 8-729-056-77 FET RFP70N06
FET2 8-729-056-77 FET RFP70N06
FET3 8-729-056-77 FET RFP70N06
FET4 8-729-056-77 FET RFP70N06
FET5 8-729-056-77 FET RFP70N06
FET6 8-729-056-77 FET RFP70N06
FET7 8-729-056-77 FET RFP70N06
FET8 8-729-056-77 FET RFP70N06
FET9 8-729-056-77 FET RFP70N06
FET10 8-729-056-77 FET RFP70N06
FET11 8-729-056-77 FET RFP70N06
FET12 8-729-056-77 FET RFP70N06
FET13 8-729-056-78 FET SSP45N20A
FET14 8-729-056-78 FET SSP45N20A
FET15 8-729-056-78 FET SSP45N20A
FET16 8-729-056-78 FET SSP45N20A
FET17 8-729-056-78 FET SSP45N20A
FET18 8-729-056-78 FET SSP45N20A
FET19 8-729-056-78 FET SSP45N20A
FET20 8-729-056-78 FET SSP45N20A
< IC >
IC1 8-759-394-81 IC NJM4559M-TE2
IC2 8-759-394-81 IC NJM4559M-TE2
IC4 8-759-394-81 IC NJM4559M-TE2
IC5 8-759-700-94 IC NJM5532M
IC6 8-759-904-94 IC TL494CN
IC7 8-759-085-67 IC LM339NS
IC8 8-759-980-04 IC LM311PS
IC9 8-759-394-81 IC NJM4559M-TE2
IC10 6-705-814-01 IC SSM2018TP
< JACK >
JK1 1-779-078-41 JACK, PIN 4P (INPUT,OUTPUT (THROUGH))
< COIL >
LF2 1-424-885-11 COIL, CHOKE 230uH
LF3 1-424-884-11 COIL, CHOKE 11.3uH
< CAPACITOR >
MC3 1-137-401-11 MYLAR 0.22uF 5% 100V
MC4 1-137-401-11 MYLAR 0.22uF 5% 100V
MC5 1-130-777-00 MYLAR 0.1uF 5% 100V
MC6 1-137-401-11 MYLAR 0.22uF 5% 100V
MC7 1-130-777-00 MYLAR 0.1uF 5% 100V
MAIN

19
XM-DS1600P5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
MC9 1-130-777-00 MYLAR 0.1uF 5% 100V
MC10 1-130-777-00 MYLAR 0.1uF 5% 100V
MC11 1-137-401-11 MYLAR 0.22uF 5% 100V
MC12 1-137-391-11 MYLAR 0.0047uF 5% 100V
MC15 1-137-350-11 MYLAR 0.015uF 5% 100V
MC16 1-130-777-00 MYLAR 0.1uF 5% 100V
MC17 1-130-777-00 MYLAR 0.1uF 5% 100V
MC18 1-136-175-00 FILM 0.68uF 5% 50V
MC19 1-137-351-11 FILM 0.022uF 5% 100V
MC20 1-137-352-11 MYLAR 0.033uF 5% 100V
MC21 1-137-401-11 MYLAR 0.22uF 5% 100V
MC22 1-137-401-11 MYLAR 0.22uF 5% 100V
MC23 1-137-401-11 MYLAR 0.22uF 5% 100V
MC24 1-137-401-11 MYLAR 0.22uF 5% 100V
MC25 1-130-777-00 MYLAR 0.1uF 5% 100V
MC26 1-107-357-11 MYLAR 0.47uF 5% 100V
MC27 1-104-987-11 MYLAR 0.001uF 5% 100V
MC28 1-104-987-11 MYLAR 0.001uF 5% 100V
MC29 1-136-177-00 MYLAR 1uF 5% 50V
MC30 1-161-772-11 CERAMIC 0.1uF 10% 25V
MC31 1-102-074-00 CERAMIC 0.001uF 10% 50V
< TRANSFORMER >
PT1 1-439-759-12 TRANSFORMER, DC-DC CONVERTER
< PHOTO COUPLER >
PTC1 8-719-902-56 PHOTO COUPLER PC817
PTC2 8-719-902-56 PHOTO COUPLER PC817
< TRANSISTOR >
Q1 8-729-931-36 TRANSISTOR MPSA42
Q2 8-729-056-82 TRANSISTOR MPSA92
Q3 8-729-931-36 TRANSISTOR MPSA42
Q4 8-729-056-82 TRANSISTOR MPSA92
Q5 8-729-034-50 TRANSISTOR KTA1504
Q6 8-729-034-50 TRANSISTOR KTA1504
Q7 8-729-034-51 TRANSISTOR KTC3875
Q8 8-729-034-51 TRANSISTOR KTC3875
Q9 8-729-034-51 TRANSISTOR KTC3875
Q10 8-729-034-51 TRANSISTOR KTC3875
Q11 8-729-034-50 TRANSISTOR KTA1504
Q12 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q13 8-729-034-51 TRANSISTOR KTC3875
Q14 8-729-034-51 TRANSISTOR KTC3875
Q15 8-729-034-51 TRANSISTOR KTC3875
Q16 8-729-034-51 TRANSISTOR KTC3875
Q17 8-729-034-51 TRANSISTOR KTC3875
Q18 6-550-660-01 TRANSISTOR KTC3206
Q19 6-550-660-01 TRANSISTOR KTC3206
Q20 8-729-056-82 TRANSISTOR MPSA92
Q21 6-550-247-01 TRANSISTOR KTA1659A
Q22 8-729-056-79 TRANSISTOR 2N5401
Q23 8-729-053-87 TRANSISTOR KTC4370A
Q25 6-550-247-01 TRANSISTOR KTA1659A
Q27 8-729-053-87 TRANSISTOR KTC4370A
Q29 6-550-247-01 TRANSISTOR KTA1659A
Q30 8-729-053-87 TRANSISTOR KTC4370A
Q31 8-729-056-79 TRANSISTOR 2N5401
Q34 8-729-038-53 TRANSISTOR KRA101S
Q35 8-729-034-50 TRANSISTOR KTA1504
Q36 8-729-034-51 TRANSISTOR KTC3875
Q37 8-729-034-51 TRANSISTOR KTC3875
Q39 8-729-034-50 TRANSISTOR KTA1504
Q42 8-729-034-51 TRANSISTOR KTC3875
Q43 8-729-034-51 TRANSISTOR KTC3875
Q44 8-729-034-50 TRANSISTOR KTA1504
Q45 8-729-034-51 TRANSISTOR KTC3875
Q46 6-550-660-01 TRANSISTOR KTC3206-O
Q47 6-550-660-01 TRANSISTOR KTC3206-O
Q48 8-729-034-50 TRANSISTOR KTA1504
< RESISTOR >
R1 1-216-081-00 METAL CHIP 22K 5% 1/10W
R2 1-216-081-00 METAL CHIP 22K 5% 1/10W
R3 1-216-073-00 METAL CHIP 10K 5% 1/10W
R4 1-216-073-00 METAL CHIP 10K 5% 1/10W
R5 1-216-049-11 METAL CHIP 1K 5% 1/10W
R6 1-216-093-11 RES-CHIP 68K 5% 1/10W
R7 1-216-093-11 RES-CHIP 68K 5% 1/10W
R8 1-216-049-11 METAL CHIP 1K 5% 1/10W
R10 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R11 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R12 1-216-089-00 METAL CHIP 47K 5% 1/10W
R13 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R14 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R15 1-216-045-00 METAL CHIP 680 5% 1/10W
R16 1-216-081-00 METAL CHIP 22K 5% 1/10W
R17 1-216-049-11 METAL CHIP 1K 5% 1/10W
R18 1-216-049-11 METAL CHIP 1K 5% 1/10W
R19 1-216-105-11 METAL CHIP 220K 5% 1/10W
R20 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R23 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R24 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R25 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R26 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R27 1-216-083-00 METAL CHIP 27K 5% 1/10W
R28 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R29 1-216-049-11 METAL CHIP 1K 5% 1/10W
R43 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R45 1-216-190-00 RES-CHIP 470 5% 1/8W
R46 1-216-222-00 RES-CHIP 10K 5% 1/8W
R47 1-216-190-00 RES-CHIP 470 5% 1/8W
R48 1-216-222-00 RES-CHIP 10K 5% 1/8W
R50 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R51 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R52 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R53 1-216-049-11 METAL CHIP 1K 5% 1/10W
R54 1-216-073-00 METAL CHIP 10K 5% 1/10W
R55 1-216-073-00 METAL CHIP 10K 5% 1/10W
R56 1-216-021-00 METAL CHIP 68 5% 1/10W
R57 1-216-077-00 METAL CHIP 15K 5% 1/10W
R58 1-216-198-00 METAL CHIP 1K 5% 1/8W
R59 1-216-037-00 METAL CHIP 330 5% 1/10W
R60 1-216-075-00 METAL CHIP 12K 5% 1/10W
R61 1-216-049-11 METAL CHIP 1K 5% 1/10W

20
XM-DS1600P5
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
R62 1-216-049-11 METAL CHIP 1K 5% 1/10W
R64 1-216-073-00 METAL CHIP 10K 5% 1/10W
R65 1-208-529-61 RES-CHIP 62K 2% 1/10W
R66 1-216-089-00 METAL CHIP 47K 5% 1/10W
R67 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R68 1-216-089-00 METAL CHIP 47K 5% 1/10W
R69 1-216-119-00 METAL CHIP 820K 5% 1/10W
R70 1-216-081-00 METAL CHIP 22K 5% 1/10W
R71 1-216-073-00 METAL CHIP 10K 5% 1/10W
R72 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R73 1-216-089-00 METAL CHIP 47K 5% 1/10W
R74 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R75 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R76 1-216-049-11 METAL CHIP 1K 5% 1/10W
R77 1-216-073-00 METAL CHIP 10K 5% 1/10W
R78 1-216-063-00 METAL CHIP 3.9K 5% 1/10W
R79 1-216-073-00 METAL CHIP 10K 5% 1/10W
R80 1-216-073-00 METAL CHIP 10K 5% 1/10W
R81 1-216-089-00 METAL CHIP 47K 5% 1/10W
R82 1-216-073-00 METAL CHIP 10K 5% 1/10W
R83 1-216-198-00 METAL CHIP 1K 5% 1/8W
R84 1-216-049-11 METAL CHIP 1K 5% 1/10W
R85 1-208-775-11 METAL CHIP 510 0.5% 1/10W
R86 1-216-073-00 METAL CHIP 10K 5% 1/10W
R87 1-216-073-00 METAL CHIP 10K 5% 1/10W
R88 1-208-813-11 RES-CHIP 20K 2% 1/10W
R90 1-216-073-00 METAL CHIP 10K 5% 1/10W
R91 1-216-073-00 METAL CHIP 10K 5% 1/10W
R92 1-208-789-11 RES-CHIP 2K 2% 1/10W
R93 1-260-180-91 CARBON 5.1K 5% 1/2W
R96 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R97 1-216-035-00 METAL CHIP 270 5% 1/10W
R98 1-216-222-00 RES-CHIP 10K 5% 1/8W
R99 1-216-025-00 METAL CHIP 100 5% 1/10W
R101 1-215-880-11 METAL OXIDE 10 5% 2W F
R102 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R103 1-216-037-00 METAL CHIP 330 5% 1/10W
R104 1-216-045-00 METAL CHIP 680 5% 1/10W
R105 1-216-089-00 METAL CHIP 47K 5% 1/10W
R106 1-216-043-00 METAL CHIP 560 5% 1/10W
R107 1-216-073-00 METAL CHIP 10K 5% 1/10W
R108 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R109 1-216-648-11 METAL CHIP 3K 2% 1/10W
R110 1-216-009-00 METAL CHIP 22 5% 1/10W
R111 1-216-166-00 RES-CHIP 47 5% 1/8W
R112 1-216-246-00 RES-CHIP 100K 5% 1/8W
R113 1-208-473-11 RES-CHIP 300 2% 1/8W
R114 1-216-190-00 RES-CHIP 470 5% 1/8W
R115 1-216-196-00 RES-CHIP 820 5% 1/8W
R116 1-216-198-00 METAL CHIP 1K 5% 1/8W
R117 1-216-222-00 METAL CHIP 10K 5% 1/8W
R118 1-216-198-00 METAL CHIP 1K 5% 1/8W
R119 1-216-194-00 METAL CHIP 680 5% 1/8W
R120 1-216-089-00 METAL CHIP 47K 5% 1/10W
R121 1-260-094-11 CARBON 390 5% 1/2W
R122 1-260-094-11 CARBON 390 5% 1/2W
R123 1-216-097-00 METAL CHIP 100K 5% 1/10W
R124 1-215-897-11 METAL OXIDE 6.8K 5% 2W F
R125 1-216-049-11 METAL CHIP 1K 5% 1/10W
R126 1-216-081-00 METAL CHIP 22K 5% 1/10W
R127 1-216-073-00 METAL CHIP 10K 5% 1/10W
R128 1-216-073-00 METAL CHIP 10K 5% 1/10W
R129 1-216-091-00 METAL CHIP 56K 5% 1/10W
R130 1-216-049-11 METAL CHIP 1K 5% 1/10W
R131 1-216-107-00 METAL CHIP 270K 5% 1/10W
R132 1-216-049-11 METAL CHIP 1K 5% 1/10W
R134 1-216-073-00 METAL CHIP 10K 5% 1/10W
R135 1-216-089-00 METAL CHIP 47K 5% 1/10W
R136 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R137 1-215-899-11 METAL OXIDE 15K 5% 2W F
R139 1-215-897-11 METAL OXIDE 6.8K 5% 2W F
R143 1-207-612-00 WIREWOUND 0.1 10% 3W F
R144 1-207-612-00 WIREWOUND 0.1 10% 3W F
R145 1-207-612-00 WIREWOUND 0.1 10% 3W F
R146 1-207-612-00 WIREWOUND 0.1 10% 3W F
R147 1-207-612-00 WIREWOUND 0.1 10% 3W F
R148 1-207-612-00 WIREWOUND 0.1 10% 3W F
R149 1-216-073-00 METAL CHIP 10K 5% 1/10W
R150 1-216-049-11 METAL CHIP 1K 5% 1/10W
R151 1-216-073-00 METAL CHIP 10K 5% 1/10W
R152 1-216-049-11 METAL CHIP 1K 5% 1/10W
R154 1-216-081-00 METAL CHIP 22K 5% 1/10W
R155 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R156 1-216-081-00 METAL CHIP 22K 5% 1/10W
R157 1-216-081-00 METAL CHIP 22K 5% 1/10W
R158 1-216-073-00 METAL CHIP 10K 5% 1/10W
R159 1-216-073-00 METAL CHIP 10K 5% 1/10W
R160 1-216-049-11 METAL CHIP 1K 5% 1/10W
R161 1-216-073-00 METAL CHIP 10K 5% 1/10W
R162 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R163 1-216-093-11 RES-CHIP 68K 5% 1/10W
R164 1-216-093-11 RES-CHIP 68K 5% 1/10W
R166 1-216-073-00 METAL CHIP 10K 5% 1/10W
R169 1-216-029-00 METAL CHIP 150 5% 1/10W
R170 1-216-073-00 METAL CHIP 10K 5% 1/10W
R171 1-216-073-00 METAL CHIP 10K 5% 1/10W
R172 1-216-121-00 METAL CHIP 1M 5% 1/10W
R173 1-216-113-00 METAL CHIP 470K 5% 1/10W
R174 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R175 1-216-081-00 METAL CHIP 22K 5% 1/10W
R180 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R181 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R182 1-216-081-00 METAL CHIP 22K 5% 1/10W
R183 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R184 1-216-073-00 METAL CHIP 10K 5% 1/10W
R202 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
R211 1-216-164-00 RES-CHIP 39 5% 1/8W
R213 1-208-473-11 RES-CHIP 300 2% 1/8W
R215 1-216-200-11 RES-CHIP 1.2K 5% 1/8W
R302 1-216-206-00 RES-CHIP 2.2K 5% 1/8W
RC1 1-216-238-00 RES-CHIP 47K 5% 1/8W
RC2 1-216-238-00 RES-CHIP 47K 5% 1/8W
RC3 1-216-238-00 RES-CHIP 47K 5% 1/8W
RC4 1-216-238-00 RES-CHIP 47K 5% 1/8W
RG1 1-247-807-31 CARBON 100 5% 1/4W
RG2 1-247-807-31 CARBON 100 5% 1/4W
