Sony WM-FS555 - S2 SPORTS WALKMAN User manual

3-239-205-41(1)
Radio
Cassette Player
Sony Corporation ©2002 Print d in Malaysia
WM-FS555
Operating Instructions
（背面）
A
B
C
DE
FM
HOLD
VOLUME*
TUNING+/–
x
Y
Belt clip
PRESET +/–
AM
RADIO OFF
M
n**
F
MENU
SET
ENTER
m
MENU
SET
ENTER
Rubber cap
Air outlet
i
* There is a tactile dot beside VOLUME on the main unit to
show the direction to turn up the volume.
**The button has a tactile dot.
English
Preparations
To use the hand strap
Holding the Walkman in a hand A
1Pass the strap through the handle of the
Walkman.
2Pass one side of the strap through the ladder
lock of the other side.
3Put your hand between the Walkman and
the strap, then adjust the length of the strap
and fix it. Slot the excess strap into the
handle of the Walkman.
Placing the Walkman on a belt
1Pass the strap through the handle described
above in steps 1 and 2.
2Tighten the strap at the ladder lock, then
slot the excess strap into the handle of the
Walkman. B
3Put the belt clip on a belt.
To insert a battery C
1Unfasten the buckle.
2Open the cassette lid.
3Release the catch to open the battery
compartment lid and insert one R6 (size
AA) dry battery with correct polarity.
When to replace the battery D
Replace the battery with the new one when “ ”
flashes in the display.
To replace the battery
1Release the catch to open the battery
compartment lid.
2Pull the ribbon up slowly and replace the
battery with new one.
Playing a Tape
1Unfasten the buckle.
2Open the cassette lid and place a cassette.
3Press MENU repeatedly to set the cursor to
TAPE in the display. Then press SET to
select the tape type. F
No message: normal (TYPE I)
METAL: High-position (TYPE II) or metal
(TYPE IV)
4Press N.
Adjust the volume with VOLUME.
To increase the volume, turn VOLUME
counterclockwise.
To Press
Stop playback* x
Wind rapidly** Mor m
* Playback will switch automatically to the opposite side
when the tape reaches the end of the side.
**If you leave the Walkman after the tape has been
wound or rewound, the battery will be consumed
rapidly. Be sure to press x.
Note
•Do not open the cassette lid while the tape is running.
To select the tape direction
Switch Yto select the desired direction.
Listening to the Radio
1If the HOLD function is on, turn the HOLD
switch in the opposite direction of the arrow
to unlock the controls.
Make sure that the tape has stopped
completely.
2Press FM or AM to select the desired band
and to turn on the radio.
3Press TUNING +/– to tune in to the desired
station. Hold down TUNING +/– for a few
seconds to scan for stations.
To turn off the radio
Press RADIO OFF.
To improve the broadcast reception
•For FM: Extend the headphones/earphones cord
(antenna). If the reception is still not good, press
MENU repeatedly to set the cursor in the display to
FM MODE. Then press SET to switch between
“LOCAL” and none (DX), or “MONO (monaural)”
and none (stereo) for best reception. E, F
•For AM: Reorient the unit itself.
Presetting Radio Stations
You can preset up to 40 radio stations — For Canada
and Central/South America: 30 for FM and 10 for
AM. For other countries: 35 for FM and 5 for AM
Presetting Automatically Scanned
Stations
1Press FM or AM.
2Press ENTER for more than 3 seconds.
Preset number 1 will flash in the display
and the Walkman starts scanning the
stations from the lower frequencies and
stops for about 3 seconds when a station is
received.
3If you wish to preset the received station,
press ENTER while the preset number is
flashing.
The received station is preset on preset
number 1 and the unit starts scanning for
the next receivable station.
4Repeat Step 3 until all receivable stations are
preset.
To stop scanning
Press RADIO OFF. The radio is turned off at the
same time.
Notes
•If stations are already stored, the newly preset stations
replace the old ones when the above procedure is
completed.
•If stations cannot be preset automatically, preset
stations manually.
Presetting Stations Manually
1Press FM or AM.
2Press ENTER.
The frequency digits and a preset number
flash in the display.
3While the frequency digits and the preset
number are flashing, tune in to a station you
wish to store using TUNING +/–, and select
a preset number using PRESET +/–.
4While the frequency digits and the preset
number are flashing, press ENTER.
Notes
•If you cannot complete step 3 or 4 while the
indications are flashing, repeat from step 2.
•If a station is already stored, the new station replaces
the old one.
To cancel the stored station
Follow the procedure above and in step 3, press and
hold TUNING +/– until “- - - -” is displayed and
select the preset number you want to cancel using
PRESET +/–. Press ENTER while “- - - -” is flashing.
Playing the preset radio stations
1Press FM or AM.
2Press PRESET +/–.
Using Other Functions
Locking the controls
Turn the HOLD switch to the direction of the arrow
to lock the controls.
The hold function only locks the radio operation
buttons, MENU button and SET button.
Emphasizing bass sound F
Press MENU repeatedly to set the cursor to MB in
the display. Then, press SET to turn MB (mega bass)
on. With each press, the indications change as
follows.
MB (mega bass) : emphasizes bass sound
No message: off (normal)
Notes
•If the sound is distorted with the mode “MB”, turn
down the volume or select normal mode.
•Bass emphasis may not show great effect if the volume
is turned up too high.
Protecting Your Hearing — AVLS
(Automatic Volume Limiter System)
F
Press MENU repeatedly to set the cursor to AVLS in
the display. Then press SET to show “AVLS”.
The maximum volume is kept down to protect your
ears.
“WALKMAN” is a trad mark of Sony Corporation.
Printed using VOC (Volatile Organic Compound)-free
vegetable oil based ink.
Precautions
On battery
• Do not carry dry batteries with coins or other metallic objects.
It can generate heat if the positive and negative terminals of the
batteries are accidentally contacted by a metallic object.
• When you are not going to use the Walkman for a long time,
remove the battery to avoid any damage caused by battery
leakage and subsequent corrosion.
On handling
• Do not leave the unit in a location near heat sources, or in a
place subject to direct sunlight, excessive dust or sand,
moisture, rain, mechanical shock, or in a car with its windows
closed.
• Do not use cassettes longer than 90 minutes except for long
continuous playback.
• The LCD display may become hard to see or slow down when
using the unit at high temperatures (above 40°C/104°F) or at
low temperatures (below 0°C/32°F). At room temperature, the
display will return to its normal operating condition.
• If the unit has not been used for a long time, set it in the
playback mode to warm it up for a few minutes before you
start using again.
On water resistance
• Before opening or closing the lid, be sure to wipe off water,
dust or sand on the exterior of the Walkman. (The Walkman is
not water-resistant with the lid open.)
• Since water in the headphones/earphones jack may cause rust,
cover it with the attached rubber cap when the headphones/
earphones are not in use.
• Since the Walkman is airtight, you may not be able to open the
lid because of sudden change in air pressure inside the
Walkman, which happens after being transported on a plane or
moving from a warm place to a cold place. To open the lid see
“Troubleshooting”.
• The supplied headphones/earphones are not meant to be
immersed in water or come in continuous contact with water. If
they are accidentally dropped into water or get wet, dry them
with a soft cloth. Never use an electric hair dryer.
• If the Walkman or the headphones/earphones are immersed in
salt water, be sure to wash them in non-running fresh water.
Never wash them under running water, and never use soap or
detergent.
• Any sand or dust on the rubber packing will prevent the lid
from closing tightly, and water may leak in. Brush off the dust
once in a while.
• We recommend the packing to be changed every year.
Replacement packing is available at an authorized Sony Service
Facility.
On headphones/earphones
Road safety
Do not use headphones/earphones while driving, cycling, or
operating any motorized vehicle. It may create a traffic hazard
and is illegal in some areas. It can also be potentially dangerous
to play your headphones/earphones at high volume while
walking, especially at pedestrian crossings.
You should exercise extreme caution or discontinue use in
potentially hazardous situations.
Preventing hearing damage
Do not use headphones/earphones at high volume. Hearing
experts advise against continuous, loud and extended play. If you
experience a ringing in your ears, reduce volume or discontinue
use.
Caring for others
Keep the volume to a moderate level. This will allow you to hear
outside sounds and to be considerate to the people around you.
On maintenance
• To clean the tape head and path, Use the cleaning cassette
CHK-1W/C-1KW (not supplied) every 10 hours of use.
Use only the recommended cleaning cassette.
• To clean the exterior, use a soft cloth slightly moistened in
water. Do not use alcohol, benzine or thinner.
• Clean the headphones/earphones plugs periodically.
Troubleshooting
The display shows incorrect information.
• The battery is weak. Replace the battery with a new one.
The display and the operation are not normal.
• Remove the battery for 30 seconds or more, and then insert it
again. If this does not solve the problem, remove the battery
and leave the unit without battery for 30 minutes or more, and
then insert it again. In this case, preset the stations again, since
the preset stations are erased from the memory.
The cassette lid cannot be opened.
• Open the rubber cap, then open the cassette lid. When the
cassette lid opens, remember to close the rubber cap to prevent
intrusion of water.
The sound is distorted.
• Set the Y switch firmly to the correct position.
Specifications
• Frequency range
FM: 87.5 - 108 MHz
AM: 530 - 1 710 kHz (North, Central and South America)
531 - 1 602 kHz (Other countries)
• Power requirements
1.5 V DC battery R6 (size AA) ×1
• Dimensions (w/h/d)
Approx. 102.3 ×117.5 ×47.3 mm, including projecting parts and
controls
• Mass
Approx. 219 g (main unit only)
• Supplied accessories
Stereo headphones or earphones (1)
Hand strap with belt clip (1)
Design and specifications are subject to change without notice.
Battery life (approximate hours) (JEITA*)
Tape Radio
playback reception
Sony alkaline LR6 (SG)** 32 50
Sony R6P (SR) 9 15
* Measured value by the standard of JEITA (Japan Electronics
and Information Technology Industries Association). (Using a
Sony HF series cassette tape)
**When using a Sony LR6 (SG) “STAMINA” alkaline dry battery
(produced in Japan).
Note
•The battery life may be shorter depending on the
operating condition, the surrounding temperature and
battery type.

A
B
C
DE
FM
HOLD
VOLUME*
TUNING+/–
x
Y
皮帶夾
PRESET +/–
AM
RADIO OFF
M
n**
F
MENU
SET
ENTER
m
MENU
SET
ENTER
橡皮罩
排氣口
i
*在主機上 VOLUME 旁邊有一個觸感圓點，表示轉大音量的方
向。
** 按鈕有觸感圓點。
中文
準備使用
要用手帶時
用手拿著 Walkman A
1將手帶穿過Walkman的手柄。
2將手帶的一端穿過另一端的梯鎖。
3把手放在Walkman和手帶中間，適當地調整好
手帶的長度。把多餘長度的手帶塞入Walkman
的手柄。
把 Walkman 掛在皮帶上
1如上面步驟1和2所述，將手帶穿過手柄。
2將手帶繫緊於梯鎖，然後將多餘的手帶塞入
Walkman的手柄。B
3將皮帶夾掛在皮帶上。
要裝電池時C
1鬆開扣環。
2打開磁帶槽蓋。
3釋放卡抓打開電池座蓋，裝入一個R6（AA，3
號）電池，令對準確極性。
何時更換電池D
當顯示器中閃爍著“ ”時，即請更換一個新電
池。
要更換電池時
1釋放卡抓以打開電池座蓋。
2慢慢地拉出絲帶並更換新電池。
播放磁帶
1鬆開扣環。
2打開磁帶座蓋並裝入磁帶。
3重複按MENU把顯示器中的游標設定於TAPE。
然後按SET 以選擇磁帶型。F
無留言：標準（TYPE I）
METAL：高位（TYPE II）或金屬帶（TYPE IV）
4按N。
用VOLUME 調整音量。
要加大音量時，請逆時針方向旋轉VOLUME 。
要請按
停止播放*x
快繞** M或m
*當磁帶繞到了終端時，將自動地切換到反面。
**在磁帶已繞完或重繞完時，您如果放置著Walkman不
理，電池將會消耗得很快。一定請按x。
註
•當磁帶正在運轉中，是不可打開磁帶座蓋的。
要選擇磁帶方向時
開關Y以選擇所要的方向。
聽收音機
1如果打開著HOLD功能，則請把HOLD開關推向
相反於箭頭所指的方向以解鎖控制器。
確認磁帶是否完全停住。
2按FM 或 AM 以選擇所要波段並打開收音機電
源。
3按TUNING +/–以調入所要電台。按住TUNING
+/–幾秒以掃描電台。
要關掉收音機時
請按RADIO OFF 。
要改善接收廣播狀況時
•FM: 請伸開耳機導線（也當天線用）。如果仍不能改
善接收狀況，即請重複按MENU 把顯示器中的游標設
定於FM MODE 。然後按 SET 以便在“LOCAL”和皆非
(DX)，或“MONO（單耳聲）”和皆非（立體聲）之間
切換用以找出最佳的接收狀況。E，F
•AM: 調整機器本身的方位。
預設電台
最多能預設40個電台—加拿大和中南美洲：30
個FM電台和10個AM電台。其他國家：35個FM電台和
5個AM 電台。
自動預設所掃描電台
1按FM或AM。
2按ENTER 3 秒以上。
顯示器中將閃爍著預設號1，Walkman即從較
低頻率開始掃描電台而在接收到電台時，將停
止掃描大約3 秒。
3您如果要預設接收到的電台時，則請在閃爍著
該預設號當中按ENTER 。
所接收的電台即被預設在預設號1上面，然後
機器再開始掃描次一個能接收的電台。
4重複步驟3 至預設好所有能接收的電台。
要停止掃描時
按RADIO OFF 。收音機即關掉電源。
註
•如果已存儲有電台，當作了上述操作程序後，則新預設
的電台將置換掉舊存有的電台。
•如果不能自動預設電台，即請用手動預設電台。
手動預設電台
1按FM或AM。
2按ENTER 。
顯示器中將閃爍著頻率數和預設號。
3當頻率數和預設號閃爍中，用TUNING +/–調
入想要存儲的電台，並用PRESET +/–選擇預
設號。
4在頻率數和預設號閃爍中，按ENTER 。
註
•如果您不能在閃爍著指示燈中完成步驟3或4的操作，就
請再從步驟2 重新開始做。
•如果已存儲有電台，則新預設的電台將取代舊存的電
台。
要取消所存儲的電台時
請按照上面步驟3所述方法按住TUNING +/–至顯
示了“- - - -”並用PRESET +/–選擇要取消的預設號。
在閃爍著“- - - -”當中按 ENTER。
播放預設電台
1按FM或AM。
2按PRESET +/–。
使用其他功能
鎖定控制器
把HOLD 開關轉至箭頭方向以鎖定控制器。
保留功能只鎖定收音機的操作按鈕，MENU按鈕和
SET按鈕。
加強低音F
重複按MENU，把顯示器中的游標設定於MB。然後
按SET 打開MB（mega bass)。每按了按鈕，指示將改
變如下。
MB（mega bass）：加強低音
無留言：關掉（正常）
註
•“MB”模式時如果聲音失真，即請轉低音量或選正常模
式。
•音量過大時，低音的加強效果可能不顯著。
保護聽覺—AVLS（自動音量限制系統）F
重複按MENU，把顯示器中的游標設定於AVLS。然
後按SET以顯示“AVLS”。
即能限制最大的音量以保護您的耳朵聽覺。
使用前須注意
電池須知
•不要把乾電池和硬幣或其他金屬小件放在一起攜帶。因為電池的
正負極如果同時與金屬小件接觸而通電，將產生熱。
•當長期間不要用Walkman時，請取出電池以免因電池漏液而腐蝕
損壞機器。
處理須知
•別把機器放在靠近熱源或會直接照射到陽光，多沙塵或潮濕，會
淋到雨，有機械衝擊的地方，或放在關閉著門窗的汽車裡。
•除非要作長時間的連續播放，否則請別使用超過90 分鐘長的磁
帶。
•在高溫（40℃以上）或低溫（0℃以下）環境中使用機器時，液晶
顯示器可能變成較難看清。但如果放在室溫中，顯示器便可恢復
正常的功能。
•機器如果長期放置沒用，請打開使成播放模式並等數分鐘之後再
開始使用機器。
耐水須知
•要打開或關上蓋子之前，一定要擦乾Walkman外面的水分，塵埃
或沙粒。（當打開著機蓋時，Walkman是不耐水的。）
•頭戴耳機耳機插孔中如果留有水分，可能引起生鏽。不用頭戴
耳機耳機時，請蓋上附有的橡皮罩。
•Walkman是完全密封的。當Walkman內部氣壓發生變化時，您可能
會打不開蓋子。例如容易發生在飛行中的飛機裡或從溫暖處搬到
寒冷處。此時，要打開蓋子，請參看“故障排除”。
•附帶的頭戴耳機耳機並不能浸水或連續接觸著水分。如果不慎
掉進水裡，或弄潮濕了，即請用軟布擦乾。切勿吹風機吹乾。
•Walkman或頭戴耳機耳機如果浸了鹽水，即請用非流動的淡水
洗淨。不可用流動的淡水洗，也不可使用肥皂或洗滌劑。
•橡皮襯墊上如果沾有沙塵，將會妨礙關閉時的密封性。因此，可
能會漏水。每次都請刷乾淨其上面的塵埃。
•襯墊最好能每年更換一次。更換用襯墊，可在指定的Sony服務中
心買到。
頭戴耳機耳機須知
路上安全
在駕車，騎單車或操作任何機動車輛時，請勿使用頭戴耳機耳
機。因為可能會引起交通事故，某些地區甚至有法律禁止使用。步
行中，尤其是在橫渡馬路時，如果用大音量使用頭戴耳機耳機也
會有潛在性危險的。
在有潛在危險的地方，必須特別注意或暫停使用。
預防損傷聽覺
別用太大音量聽頭戴耳機耳機。聽覺專家勸告避免連續，大聲地
使用耳機。您的耳朵若有耳鳴經驗，便須減小音量或不連續使用耳
機。
其他顧慮
保持適當的音量聽耳機。這不但可以同時聽到您周圍的動靜，還可
顧慮到周圍人們的安寧。
保養須知
•要清潔磁頭和走帶路徑時，請利用清潔用磁帶CHK-1W/C-1KW（並
未提供）在每使用過機器10個小時清潔一次。限使用推獎的清潔
磁帶。
•要清潔機殼時，請用軟布輕蘸濕水分擦拭。不可使用酒精，汽油
或稀釋溶劑。
•定期清潔頭戴耳機耳機插頭。
故障排除
顯示器顯示錯誤的資訊。
•電池變弱了。請更換新的電池。
顯示器和操作不正常。
•取出一下電池，等30秒或以上時間之後，再把它裝上。這仍然不
能解決問題時，請再取出電池而讓沒裝電池的機器放置30分鐘或
以上的時間之後再裝入電池。此時，請再預設一下電台。因為存
儲器中的預設電台已被清除。
不能打開機蓋。
•請打開橡皮罩，然後再打開機蓋。機蓋開著時，請記著要關上橡
皮罩以防侵水。
聲音失真。
•請把Y開關穩當設定於正確的位置。
規格
•頻率範圍
FM：87.5 ∼ 108MHz
AM：530 ∼1 710kHz（北美，中美和南美）
531∼1 602kHz（其他國家）
•電源
1.5V DC電池 R6（AA ， 3 號）×1
•尺寸（寬高縱深）
大約102.3 × 117.5 × 47.3mm ，含突出部分和控制器
•質量
大約219g（主機為限）
•隨機附件
立體聲耳機（1）
皮帶夾（1）
設計和規格有所變更時，恕不另行奉告。
電池使用時間（大約時數） (JEITA*)
播放磁帶 聽收音機
Sony鹼性電池 LR6（SG）** 32 50
Sony R6P（SR） 9 15
*按JEITA（Japan Electronics and Information Technology
Industries Association）標準測定的值（使用Sony HF系列磁
帶）。
**當使用Sony LR6(SG)“STAMINA”鹼性乾電池（日本製）時。
註
•根據操作條件，環境溫度和電池類型，電池使用時間可
能會縮短一些。
