Wireless stereo headset
Instruction Manual
CECHYA-0086 7020227

WARNING
To prevent possible hearing damage, do not listen at high volume levels for long
periods.

Precautions
Carefully read the information in this instruction manual and on the package before
using this product. Also read the instructions for the PlayStation®3 system. Retain all
documentation for future reference.
Safety
ˎObserve all warnings, precautions and instructions.
ˎCHOKING HAZARD - Contains small parts. Keep out of the reach of small
children.
Use and handling
ˎStop using the system immediately if you begin to feel tired or if you experience
discomfort or pain in your head while operating the wireless stereo headset. If the
condition persists, consult a doctor.
ˎThe vibration function of the wireless stereo headset can aggravate injuries. Do not
use the vibration function if you have any ailment or injury to the bones, joints or
muscles of your head.
ˎAvoid prolonged use of the wireless stereo headset. Take a break at about 30-minute
intervals.
ˎPermanent hearing loss may occur if the headset is used at high volume. Set the
volume to a safe level.
Over time, increasingly loud audio may start to sound normal but can actually be
damaging to your hearing.
If you experience ringing in your ears or muffled speech, stop listening and have
your hearing checked.
The louder the volume, the sooner your hearing could be affected. To protect your
hearing:
ˋLimit the amount of time you use the headset at high volume.
ˋAvoid raising the volume to block out noisy surroundings.
ˋLower the volume if you can’t hear people speaking near you.
ˎIf you feel that the headset is irritating your skin, stop using it immediately.
ˎDo not expose the headset to high temperatures, high humidity or direct sunlight.
ˎDo not put heavy objects on the headset.
ˎDo not allow liquid or small particles to get into the headset.
ˎDo not throw or drop the headset or subject it to strong physical shock.
ˎDo not place any rubber or vinyl materials on the headset exterior for an extended
period of time.
ˎUse a soft, dry cloth to clean the headset. Do not use solvents or other chemicals. Do
not wipe with a chemically treated cleaning cloth.
ˎDo not disassemble or insert anything into the headset because this may cause
damage to the internal components or cause injury to you.

ˎObserve all signs and instructions that require an electrical device or radio product
to be switched off in designated areas, such as gas/refuelling stations, hospitals,
blasting areas, potentially explosive atmospheres or aircraft.
ˎThe battery used in this device may present a risk of fire or chemical burn if
mistreated. Do not disassemble, heat above 60°C, or incinerate.
NOTE:
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
ˋReorient or relocate the receiving antenna.
ˋIncrease the distance between the equipment and receiver.
ˋConnect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
ˋConsult the dealer or an experienced radio/TV technician for help.
Part names and functions
Front
Headband
Slide the headband to adjust the fit to
your head.
VSS (Virtual Surround Sound)
ON/OFF button
Press and hold for more than one second:
Turns the virtual surround sound effect
on and off. By default the VSS is on.
MIXER slider
Adjusts the relative volume of chat and
game audio.
POWER switch
Status indicator
L marking
Microphone
Keep the right speaker away from the
microphone on the left side to prevent
audio feedback (howling sound).

Rear
BassImpact™ slider
BassImpact™ converts low frequency bass
sounds into pulses around the earpads.
To completely turn off BassImpact™, slide
the BassImpact™ slider to the OFF
position until it clicks.
VOLUME slider
Adjusts the volume of the
headset.
MIC MUTE button
ˎPress to switch MIC MUTE on and off.
ˎHold down the MIC MUTE button
until a beep is heard: Switch the
volume of the sidetone between high
and middle, or off.
Sidetone is a feature that allows you to
hear your own voice from the headset.
For this model, you cannot adjust the
volume of the sidetone on the PS3™
system’s screen.
When MIC MUTE is on, the sidetone
is turned off.
MODE button
R marking
Bottom
USB connector
Connect to a supported USB device to
charge the headset. (Type A - mini-B
USB cable sold separately.)
Audio input/output jack
When the included audio cable is
connected to the headset for use with
mobile devices, the wireless function is
turned off.

Wireless adaptor
IN (audio input) jack
Reset button
Status indicator
Using the headset with the PS3™ system
Compatible with PS3™ system software version 4.20 or later. Only one
headset at a time can be used with the PS3™ system.
1 Insert the wireless adaptor in the USB connector.
2 Slide the POWER switch on the headset to ON.
Status display
When the headset is used with a PS3™ system, the following status
information is displayed in the upper right corner of the screen:
Displayed when [Stereo Headset Audio Extension] is set to [On] *
Displayed when Virtual Surround sound is enabled
Displays volume level
Displayed when the microphone is turned off
Displays battery charge level
*Stereo Headset Audio Extension is a system setting that controls the type of audio
output to the wireless stereo headset. It is available only when the wireless adaptor
is inserted.

Audio Output Selection
With the wireless stereo headset you can listen to PS3™ system audio,
including music, videos and games, in Virtual Surround Sound.
ˋYou can listen to both game audio and chat audio simultaneously.
Use the MIXER slider to adjust the relative volume of game audio vs.
chat audio.
ˋYou can change the audio output to the headset so that you can hear
only chat audio.
To change the audio output, and enable/disable the VSS (Virtual Surround
Sound) ON/OFF button and MIXER slider, select (Settings)
(Accessory Settings) [Stereo Headset Audio Extension].
Stereo Headset
Audio Extension
Audio Output to
headset
VSS (Virtual
Surround Sound)
ON/OFF button
MIXER slider
On All audio Enabled Enabled
Off Chat audio only Disabled Disabled
Listen to TV audio wirelessly
You can wirelessly listen to audio from your TV using the headset. If you
connect your TV’s audio output (headphone jack) and the wireless
adaptor using the audio cable (included with this product), the audio will
be switched.
Audio cable

Hints
ˎThe headset can be used with any television or monitor with a
headphone jack.
ˎThe audio from the USB audio source is not output when the included
audio cable is connected to the wireless adaptor. When you want to hear
audio from the USB audio source, remove the audio cable from the
wireless adaptor.
ˎWireless adaptor needs to be connected to a powered USB port such as a
PS3™ system or television USB port (if available).
Using the headset with a PC
You can use the headset with a PC (with Windows® or Mac OS) that has a
USB connector. Insert the wireless adaptor into a USB connector on the
PC you want to use and then turn on the headset.
For further instructions about use of the headset with Windows® or Mac
OS, visit eu.playstation.com/ps3/support.
Hints
ˎThe headset is not guaranteed to work with every PC that has a USB
connector.
ˎThe VSS (Virtual Surround Sound) ON/OFF button and MIXER slider
can be used only when the headset is connected to a PS3™ system.
Using with a portable device
You can use the included audio cable to connect the headset to the
headphone jack of portable devices such as the PlayStation®Vita system,
allowing you to listen to audio and use the voice chat feature.

Notes
ˎWhen the included audio cable is connected to the headset, the VSS
(Virtual Surround Sound) ON/OFF button and the MIXER slider
cannot be used.
ˎOutput volume varies depending on the portable device that is
connected. Adjust volume accordingly.
ˎYou can use the included stereo audio cable to connect the headset to
your mobile device to listen to audio content and talk on the phone.
ˋIf you are unable to hear audio content using the cable with your
mobile device, turn the headset power off to enable functionality.
ˋYour device may require a standard stereo audio cable (sold
separately) to listen to audio content using the headset. Note that
standard audio cables do not support voice communication.
ˋThis product is not compatible with all mobile devices. Some features
may not work on all mobile devices. For further information on
mobile device compatibility, visit eu.playstation.com/ps3/support
Charging the Headset
When remaining battery level is low, the status indicator flashes red and a
beep is heard. Charge the battery by connecting the headset to a
supported USB device such as a PC. While the battery is charging, the
status indicator lights up red. The status indicator light turns off when the
battery is fully charged.
Hints
ˎYou can check the remaining battery charge on the PS3™ system screen.
ˎYou might not be able to charge the battery if the USB device or the USB
hub does not provide enough power for charging. Try connecting the
headset to a different USB device or a different USB connector on the
device.
ˎCharging takes approximately 3.5 hours when starting with no battery
charge left.
ˎWhen the remaining battery charge is low, the headset beeps while it is
connected and receiving an audio signal.
ˎIt is recommended that you charge the battery in an environment with a
temperature of 10 °C to 30 °C. Charging in other environments might
not be as effective.
ˎIf you do not plan to use the wireless stereo headset for an extended
period of time, it is recommended that you fully charge it at least once a
year to help maintain battery functionality.

Status indicator display
Headset
Indicator
colour
Flashing pattern Headset status
Blue Solid In use
Flashing once repeatedly Pairing mode
Flashing twice repeatedly Connection standby mode
Red Solid Charging
Purple Solid Microphone input off
Light green Solid Analog audio input (output)
Orange Solid System software update in
progress
Wireless adaptor
Indicator
colour
Flashing pattern Headset status
Blue/Light
green *
Solid In use
Flashing once repeatedly Pairing mode
Flashing twice repeatedly Connection standby mode
* When the included audio cable is connected to the wireless adaptor.
