Ver 1.0 2001.02
CFM-S1
SERVICE MANUAL
RADIO CASSETTE-CORDER
SPECIFICATIONS
E Model
9-873-068-11
2001B0200-1
© 2001.2
Sony Corporation
Audio Entertainment Group
General Engineering Dept.
Model Name Using Similar Machanism NEW
Tape Transport Mechanism Type MF-M20-117
• Frequency range
FM: Saudi Arabia: 87.6 - 107 MHz
Other models: 87.6 - 108 MHz
MW: 530 - 1 605 kHz
SW1: 2.3 - 7 MHz
SW2: 7 - 22 MHz
• Aerials FM/SW: Telescopic aerial
MW: Built-in ferrite bar aerial
• Recording system 2-track 1 channel mono
• Frequency response 80 - 8 000 Hz
• Speaker Full range: 12 cm (4 3/4inches) dia., 6Ω, cone
type (1)
• Outputs Earphones jack
For 8 Ωimpedance earphones
• Maximum power output 1.4 W
• Power requirements 110 - 120, 220 - 240 V AC
selectable, 50/60 Hz
6 V DC, 4 R20 (size D) batteries
• Power consumption AC 8 W
• Battery life
FM recording: Sony R20P: approx. 18 h
Sony alkaline LR20: approx. 50 h
Tape playback: Sony R20P: approx. 12 h
Sony alkaline LR20: approx. 30 h
• Dimensions Approx. 287 X147 X110 mm (w/h/d)
(11 3/8X5 7/8X4 4/8inches) (incl. projecting parts)
• Mass (incl. batteries) Approx. 2 kg (4 lb. 7 oz)
• Supplied accessory Mains lead (1)
Design and specifications are subject to change without
notice.

2
CFM-S1
TABLE OF CONTENTS
Specifications ........................................................................... 1
1. GENERAL
Location and Function of Controls .................................... 2
2. DISASSEMBLY
2-1. Cabinet (Front) ASSY, “Cabi, rear” ........................... 3
2-2. MD ASSY ................................................................... 3
2-3. Record/Playback Head (HRP101),
Reel/Capstan Motor (M101),Belt ............................... 3
2-4. Jack Board, Main Board, Fine Tune Board ................ 4
2-5. Battery Terminal Board, Power Board, ...................... 4
2-6. Note on Instalation ...................................................... 5
2-7. Dial Pointer Setting .................................................... 5
3. TEST MODE
3-1. Mechanical Adjustments ............................................. 6
3-2. Electrical Adjustments ................................................ 6
6. DIAGRAMS ...................................................................... 9
4-1. Block Diagrams ........................................................ 10
4-2. Printed Wiring Boards .............................................. 11
4-3. Schematic Diagrams -Main Section (1/2) - ............. 12
4-4. Schematic Diagrams -Main Section (2/2) - ............. 13
5. EXPLODED VIEWS
5-1. Front Cabinet Section ............................................... 16
5-2. Rear Cabinet Section ................................................ 17
5-3. Mechanism Deck Section-1(MF-M20-117) ............. 18
5-4. Mechanism Deck Section-2(MF-M20-117) ............. 19
6. ELECTRICAL PARTS LIST ........................................ 20
SECTION 1
GENERAL
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK !OR DOTTED LINE WITH
MARK !ONTHE SCHEMATIC DIAGRAMS AND IN THE PARTS LIST
ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY.
TUNING
PAUSE STOP/EJECT FF REW PLAY REC
BAND
VOLUMEOPR/BATT
MIC
FINE TUNINGFUNCTION
@DPB
This section is extracted from
instruction manual.
Location and Function of Controls

3
CFM-S1
1
2
Screws
+ BVTP 3X10
Chassis(B)
MD ASSY
pointer
Cabi, rear
SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. CABINET (FRONT) ASSY, “CABI, REAR”
2-2. MD ASSY
• The equipment can be removed using the following procedure.
Set
Cabinet (front) ASSY
Cabi, rear Jack board, Main board,
Fine tune board
Battery terminal board, Power board
MD ASSY
Record/playback head (HRP101),
Reel/capstan motor (M101), Belt
3
1
4
Remove solder (two places)
2
Screws + BVTP 3X14
2
Screws + BVTP 3X1
4
Lid, BATT
Cabinet(front) ASSY
Cabi, rear
2-3. RECORD/PLAYBACK HEAD (HRP101),
REEL/CAPSTAN MOTOR (M101), BELT
1Screws Tapping+B
MD ASSY
4Record/playback
head (HRP101) 7Reel/capstan
motor (M101
)
3Screws
+ PTT 2X 5
6Screws + P2X 5
8Belt
5Lug (T), plate
2Guide, tape

4
CFM-S1
2-4. JACK BOARD, MAIN BOARD, FINE TUNE BOARD
2-5. BATTERY TERMINAL BOARD, POWER BOARD
8
6
3
3
3
Chassis(A)
Main board
7
Screws + BVTP 3X10
2
Screw +BVTP 3X10
5
Claw
Cabi, rear
Fine tune board
1
Knob(FT)
1
Knob(band)
1
Knob(function)
1
Knob(vol)
1
Knob(sound)
4
Screw +BVTP 3X10
Jack board
1
Knob(tune)
Bracket(PWB)
6
2
4 Remove Solde
r
Cabi, rear
Power board
3 Remove solder
Battery terminal board
5 Screws + BVTP 3X10
1 Claw

5
CFM-S1
2-6. NOTE ON INSTALATION
To jack board
Power board (CN901)
Fine tune board (KH2
)
Main board (KH1)
Main board (KH101)
Main board (KH102)
To battery terminal board
To speaker
(SP1)
MIC (ECM101) Power board (KH901)
2-7. DIAL POINTER SETTING
Dress the lead wires as shown in figure.
1Turn the knob(tune)
fully counterclockwise.
2Fit the pointer to the
chassis(B).
5Set the left side of the
pointer to the convex
portion (a) on the
chassis(B).
Pointer
Chassis(A)
Chassis(B)
Chassis(B)
6
6
3
6Hold the left side of pointer,
then insert the gear section
of pointer to groove of chassis(A).
7Bracket(P)
4Screw + BVTP 3X14
Pointer
Chassis(B)
Pointer
(a)

6
CFM-S1
TAPE RECORDER SECTION
FUNOTION switch : TAPE (RADIO OFF)
SOUND switch : OFF
VOLUME : MIN
Standard Output Level
Output terminal Earphone Speaker
load impedance 8Ω6Ω
output signal level 0.25V (–10dB) 0.775V (0dB)
Test Tape
Type Signal Used for
WS-48A 3kHz, 0dB Tape Speed Adjustment
Record/Playback Head Azimuth Adjustment
Procedure :
1.Playback Mode
2.Rotate the screw to adjust level meter reading to the maximum.
Note : Adjust to the maximum peak though there may be two or
three peakes
3.After the adjustment, lock the adjustment screws with suitable
locking compound.
Adjustment Location :
SECTION 3
TEST MODE
3-1. MECHANICAL ADJUSTMENTS
PRECAUTION
1.Clean the following parts with a denatured-alcohol-moistened
swab :
record/playback head pinch roller
erase head rubber belts
capstan
2.Demagnetize the record/playback head with a head demagnetizer.
(Do not bring the head demagnetizer close to the erase head.)
3.Do not use a magnetized screwdriver for the adjustments.
4.After the adjustments, apply suitable locking compound to the
parts adjusted.
5. The adjustments should be performed with the rated power sup
ply voltage unless otherwise noted.
Torque Measurement
Forward CQ-102C
Forward
CQ-102C
Back Tension
Fast Forward CQ-201B
Rewind CQ-201B
Tape Tension Measurement
Torque Meter Meter Reading
Torque Torque Meter Meter Reading
1.77 to 5.88 mN•m
(18 to 60 g•cm)
(0.25 to 0.83 oz•inch)
0.01 to 0.49 mN•m
(1 to 5 g•cm)
(0.014 to 0.069 oz•inch)
4.42 to 9.31 mN•m
(45 to 95 g•cm)
(0.63 to 1.31 oz•inch)
4.42 to 9.31 mN•m
(45 to 95 g•cm)
(0.63 to 1.31 oz•inch)
3-2. ELECTRICAL ADJUSTMENTS
CQ-403A more than 100g
(more than 3.53 oz)
0dB=0.775V
Head azimuth adjustent screw
set
test tape
P-4-A100
(10kHz, -10dB) 8
Ω
level meter
J101 (Earphone jack
)
+

7
CFM-S1
SW Section
BAND switch : SW1, SW2
FINE TUNING control : mechanical center
FM Section
Function switch : FM
Volume : MIN
Tape Speed Adjustment
Procedure :
Mode : Playback
Adjustment Value :3,000Hz
Standard Value :2,990 to 3,010Hz
set
test tape
WS-48B
(3kHz, 0dB) 8Ω
digital frequenc
y
counter
J101 (Earphone jack)
+
Frequency difference between the beginning and the end of the tape
should be within 1.0% (30Hz).
Adjustment Location :
tape speed adjustment
control inside motor
AM RF signal
generator
30% amplitude modulation by 400Hz
signal.
Output level : as low as possible
Put the lead-wire
antenna close to
the set.
set
8Ω
+
J101 (Earphone jack)
level mete
r
AM RF signal
generator
30% amplitude
modulation by 400Hz signal
output level : as low as possible
telescopi
c
antenna
terminal
12pF
set
8Ω
+
J101 (Earphone jack)
level mete
r
FM RF signal
generator
22.5kHz frequency deviation by
400Hz signal.
Output level : as low as possible
telescopi
c
antenna
terminal
0.01 F
µ
TUNER SECTION
MW Section
Function switch : MW
Volume : MIN
set
8Ω
+
J101 (Earphone jack)
level mete
r
0dB=1µV

8
CFM-S1
• Repeat the procedures in each adjustment several times, and the
frequency coverage and tracking adjustments should be finally
done by the trimmer capacitors.
AM(MW/SW) IF ADJUSTMENT
Adjust for a maximum reading on level meter.
T1 455kHz
MW FREQUENCY COVERAGE ADJUSTMENT
Adjust for a maximum reading on level meter.
L4 520kHz <516kHz>
CT4 1,680kHz <1,630kHz>
MW TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L3 600kHz
CT3 1,400kHz
SW1 FREQUENCY COVERAGE ADJUSTMENT
Adjust for a maximum reading on level meter.
L7 2.2MHz
CT7 7.3MHz
SW1 TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L6 2.2MHz
CT6 7.3MHz
SW2 FREQUENCY COVERAGE ADJUSTMENT
Adjust for a maximum reading on level meter.
L9 6.8MHz
CT9 22.5MHz
SW2 TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L8 6.8MHz
CT8 22.5MHz
FM FREQUENCY COVERAGE ADJUSTMENT
Adjust for a maximum reading on level meter.
L2 86.50MHz <87.35MHz>
CT2 109.50MHz <107.80MHz>
FM TRACKING ADJUSTMENT
Adjust for a maximum reading on level meter.
L1 86.50MHz <87.35MHz>
CT1 109.50MHz <107.80MHz>
< > : Saudi Arabia model
[MAIN BOARD]
(Component side)
CT1 : FM Tracking Adjustment
CT3 : MW Tracking Adjustment
CT6 : SW1 Tracking Adjustment
L6 : SW1 Tracking Adjustment
L3: MW Tracking Adjustment
T1 : AM (MW/SW) IF Adjustmen
t
L5 : FM IF Adjustment
L2 : FM Frequency
Coverage Adjustment
CT4: MW Frequency
Coverage Adjustment
CT2 : FM Frequency
Coverage Adjustment
L4 : MW Frequency
Coverage Adjustment
CT7 : SW1 Frequency
Coverage Adjustment
L7 : SW1 Frequency
Coverage Adjustment
CT8 : SW2 Tracking Adjustment
L8 : SW2 Tracking Adjustment
CT9 : SW2 Frequency
Coverage Adjustment
L9 : SW2 Frequency
Coverage Adjustment
L1 : FM Tracking Adjustment
Adjustment Location : MAIN board (Component side)
FM IF ADJUSTMENT
Adjust for a maximum reading on level meter.
L5 10.7MHz

9999
CFM-S1
• Circuit Board Location.
SECTION 4
DIAGRAMS
Battery terminal board
Jack board
Main board
Power board
Fine tune boar
d

1010
CFM-S1
4-1. BLOCK DIAGRAMS
• Signal path.
F: FM
E: PB
a: REC

1111
CFM-S1
4-2. PRINTED WIRING BOARDS
D1 B-9
D2 B-9
D3 C-9
D4 C-9
D101 C-6
D102 E-2
D103 C-6
D104 C-6
D140 D-5
D141 D-5
D901 F-4
D902 F-4
IC1 B-7
IC101 C-3
Q1 C-9
Q101 C-6
Q102 C-6
Q103 C-5
Q105 C-4
Q106 C-5
Q140 D-5
Ref. No. Location
zSemiconductor
Location
Note:
•X: parts extracted from the component side.
•: Pattern on the side which is seen.
•f: internal component.
IC1
R9
R8
C29
C25
C23
C22
C21
JC3
C20
JC8
JC7
C8
C7
C10
C9
JC2
JC1
C2 C3
C16
C17
R5
C1
R2
C15
JC4
JC5
JC6
JC9
JC10
JC11 JC12
JC13
JC14
JC15
JC16
JC17
JC18
JC19
JC20
JC21
JC22
JC24 JC23
C130
R109
R101
R105
R107
KH101
R130
R131
C106
R102
R103
R104
R110
R114
R116
KH103
KH102
C101
C103
C105
C108
C109
C113
C114
C115
C116
C118
C120
C141
C142 C143
C145
R140
R141
R142
R143
R144
R145
R146
R147
R149
R150
R151 R152
R153
C148
C132
Q140
Q106
C14
C13
C122
C123
C5
R112
D1
D2
D3
D4
L1
L2
L4
L5
L6
L8
L7
L9
T1
T1
CF1
-1 -2
CF2
Q1
R4
CNP1
CT7
CT9
CT8
CT6
C18
C19
C28
JW1
JW2
R108
IC101
CNP101
S103
R106
D101
D103
D104
Q101
Q102
S101
R4
Q103
C131
JW106
JW107
JW4
JW103
JW104
JW105
R111
R113
C102
C104
C107
C110
C111
C112
C117
C121
C140
C144
C146
R148
C147
C149
C150
R154
R155
Q105
JW112
JW111
JW110
JW109
JW113
D140
D141
JW3
KH1
C24
C31
C11
C12
C6
CNP102
JW108
C119
S1 1-8
-1-2
-4 -3
-6 -5
-8 -7
E C B
E
C
B
S102
(REC/PB)
HRP101
REC/PB
HEAD
HE101
ERASE
HEAD
CV1-1
CV1-4
CV1-2
CV1-3
CT1-2
CT1-3
CT1-1
CT1-4
M901
REEL/CAPSTAN
MOTOR
S106
(TAPE POWR) M
MAIN
BOARD
POWER
BOARD
JACK
BOARD
BATTERY
TERMINAL BOARD
FINE TUNE
BOARD
B C E
SP1
SPEAKER
L3
MW
BAR
ANTENNA
ANT1
FM
TELESCOPIC ANTENNA
DRY BATTERY
SIZE "D"
(IEC DESIGNATION R20)
4PCS, 6V
ECM101
MIC
1
5
10
15
20
25
30
16
B C E
E
C
B
S1
BAND
FM
SW1
SW2
MW
F901
D901
D902
C903
C901
C902
CNP901
KH901
T901
POWER TRANSFORMER
C26
R7
R6 RV1
C27
JW101
JW102
KH2
R115
KH104 41
R117
D102
R118
11
(11)
1-681-387-
11
(11)
1-680-392-
11
(11)
1-680-391-
11
(11)
1-680-393-
11
(11)
1-680-390-
S101
FUNCTION
TAPE
(RADIO OFF)
RADIO
R
j
S103
SOUND
OFF
ON
R
OPR/BATT
J101
v
EA
MODEL
-1 -2
RV101
VOLUME
RV1
FINE
TUNING
J901
- AC IN
S901
VOLTAGE
SELECTOR
220-240V
110-10V
R
23 4 5 6 7 89 10
A
1
B
C
D
E
F
G
H

1212
CFM-S1
zRefer to page 14 for Notes. z Refer to page 15 for IC Block Diagrams.
4-3. SCHEMATIC DIAGRAM – MAIN SECTION (1/2) –

1313
CFM-S1
4-4. SCHEMATIC DIAGRAM – MAIN SECTION (2/2) – zRefer to page 14 for Notes. z Refer to page 15 for IC Block Diagrams.

14
CFM-S1
14
• All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or
less are not indicated except for electrolytics and tantalums.
• All resistors are in Ωand 1/4 W or less unless otherwise specified.
•f: internal component.
Note: The components identified by mark 0or dotted line with
mark 0are critical for safety.
Replace only with part number specified.
•A: B+ Line.
•H: adjustment for repair.
• Power voltage is dc 6V and fed with regulated dc power supply
from external power voltage jack.
• Voltages are dc with respect to ground under no-signal (detuned)
conditions.
• Voltages are dc with respect to ground in playback mode.
no mark : FM
( ) : SW1, SW2, MW (RADIO SECTION), PLAY (TAPE
SECTION)
< > : MIC REC
[ ] : RADIO REC
• Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production toler-
ances.
• Signal path.
F: FM
E: PB
a: REC
•Abbreviation
EA : Saudi Arabia
UAE : United Arab Emirates
Note on schematic Diagram: MAIN SECTION (1/2), (2/2)

15
CFM-S1
• IC BLOCK DIAGRAMS
IC1 TA2132AF
IC101 MM1315BD
16 15 14 13
FM
OSC
FM RF
OUT AM/FM
SW
AM RF
IN 12 11 10 9
QUAD
AFC DET OUT
AM
OSC
16 15 14 13
FM/AM FM
OSC AM
OSC
FM
OSC
FM RF
OUT AM/FM
SW
AM RF
IN 12 11 10 9
AFC DET OUT
AM
OSC
AM
DET
FM
DET
FM
MIX AM MIX AGC
1234
AGC
RF
GND MIX
OUT
FM RF
IN
5 678
GND
FM IF
IN AM IF
IN
VCC
AM
RF
FM RF
AF
BUFF
FM
IF AM
IF
TAPE/AUX REC/PLAY MIX/ECM NC REC POWER ON/OFF AUX-IN LPF ALC DEL P.VCC P.VCC POWER GND PBTL2 POP DEL
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
B+
B+
B+
B+
B+
B+
B+
B+
B+
B+
B+
B+
B+
B+
MIC-IN
POWER GND
POWER IN
LIN-OUT
RIPPLE
FILTER
RIPPLE
FILTER
SIG VCC
SIG-GND
BIAS
VBIAS
TAPE EQ
TAPE NF
HEAD-IN(–)
HEAD-IN(+)
MIC N.F
BTL1
21
2223
24
25
26
27
28
2930
235
4678910
1
17
1819
20
11 12 13 14 15
16

16
CFM-S1
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
SECTION 5
EXPLODED VIEWS
NOTE :
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “ * ”are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference
number in the exploded views are not
supplied.
• Hardware (# mark) list and accessories and
packing materials are given in the last of this
parts list.
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
5-1. FRONT CABINET SECTION
#2 #2
#2
#1
#1
#1
ECM101
SP1
4
5
1
2
3
6
1 3-226-090-01 LID, CASSETTE
2 X-3380-354-1 CABINET FRONT SUB ASSY
3 3-226-062-01 SPRING (CAS)
4 3-922-112-31 DAMPER
5 3-226-056-01 LID, BATT
6 X-3380-400-1 WINDOW SUB ASSY(E,UAE)
6 X-3380-568-1 WINDOW SUB ASSY(EA)
ECM101 1-542-118-11 MICROPHONE, ELECTRET CONDENSER
SP1 1-529-973-11 SPEAKER
• Abbreviation
EA : Saudi Arabia
UAE : United Arab Emirates

CFM-S1
17
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
5-2. REAR CABINET SECTION
#2
L3
#2
#2
#2
#2
#2
#5
#4
#2
#2
#2
#6
81
ANT1
80
53
51
55
61
62
54
82
63
64
65
66
61
67
6
8
69
56
57
58
59
60
74
75
84 85
73
52
79
76
83
77
72
70
71
51 3-226-046-01 POINTER
52 3-226-041-01 BRACKET (PWB)
*53 3-226-040-01 CHASSIS (B)
*54 1-680-392-11 BATTERY TERMINAL BOARD
55 3-226-052-01 BUTTON (PAUSE)
56 3-226-051-01 BUTTON (STOP)
57 3-226-050-01 BUTTON (FF)
58 3-226-049-01 BUTTON (REW)
59 3-226-048-01 BUTTON (PLAY)
60 X-3380-353-1 BUTTON (REC) SUB ASSY
61 3-226-057-01 ARM (L)
62 3-226-096-01 HANDLE (P)
63 3-226-094-01 KNOB (SOUND)
64 3-226-054-01 KNOB (VOL)
65 3-226-093-01 KNOB (FUNCTION)
66 3-226-092-01 KNOB (BAND)
67 3-226-065-01 TERMINAL, BATT (+-)
68 3-226-064-01 TERMINAL, BATT (-)
69 3-226-038-01 CABI, REAR (E,EA)
69 3-226-038-11 CABI, REAR (UAE)
70 3-226-055-01 KNOB (TUNE)
71 3-226-091-01 KNOB (FT)
*72 1-681-387-11 POWER BOARD
73 3-226-060-01 TERMINAL, ANT
74 3-226-043-01 GEAR (VC)
*75 A-3323-677-A MAIN BOARD, COMPLETE (EA)
*75 A-3323-679-A MAIN BOARD, COMPLETE (E,UAE)
76 3-226-045-01 SHAFT (T)
77 3-226-063-01 SPRING (TUNE)
79 3-226-042-01 BRACKET (P)
80 3-226-044-01 GEAR (INTERVAL)
81 3-226-039-01 CHASSIS (A)
*82 1-680-391-11 JACK BOARD
*83 1-680-393-11 FINE TUNE BOARD
84 3-229-772-01 HOLDER (ANT)
85 3-229-784-01 CUSHION (V)
ANT1 1-501-820-11 ANTENNA, TELESCOPIC
L3 1-754-171-11 ANTENNA,FERRITEROD(MW)(MWTRACKING)

18
CFM-S1
5-3. MECHANISM DECK SECTION-1
(MF-M20-117)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
101 3-933-010-01 SPRING (S/P), TORSION
102 3-933-025-01 SPRING (P), TORSION
103 3-040-857-01 LEVER (P)
104 3-933-024-01 ROLLER, PINCH
105 3-933-019-01 SPRING (F/R), TORSION
106 3-933-028-01 SPRING (FWD), TORSION
107 3-933-016-01 GEAR (S REEL)
*108 3-933-023-11 SLIDER (REC)
109 3-933-022-01 BASE, HEAD
*110 3-933-017-11 SLIDER (REW)
*111 3-933-018-11 SLIDER (FF)
*112 3-933-009-11 SLIDER (STOP)
*113 3-933-008-11 SLIDER (PAUSE)
114 3-933-004-01 CLAW, REEL
*115 3-933-021-01 SLIDER (FRP)
*116 3-933-006-01 SLIDER (EJECT)
117 3-934-833-01 SPRING (FRP)
118 3-022-794-02 SPRING (BT)
119 3-933-007-01 PLATE, LOCK
*120 3-009-076-01 CHASSIS (HEAD)
121 3-010-625-01 GUIDE, TAPE
122 3-342-917-01 SCREW (IT3-C), TAPPING, + B
123 3-936-265-01 LUG (T), PLATE
124 4-936-201-01 SPRING, COMPRESSION
HE101 1-500-680-11 HEAD, MAGNETIC (ERASE)
HRP101 1-500-679-11 HEAD,MAGNETIC(RECORD/PLAYBACK)
HE101
HRP101
101
102
103 104
105 106
107
108
112
110
111
123
109
124
120
121
122
113
114
115
116
117
118
119
#3 #3

CFM-S1
19
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
5-4. MECHANISM DECK SECTION-2
(MF-M20-117)
151 3-933-029-01 LEVER, ERASING PREVENTION
152 3-933-182-01 SPRING, CASSETTE
153 3-932-995-01 GEAR (MID)
154 X-3371-667-1 CLUTCH ASSY
155 3-932-997-01 GEAR (CAM)
*156 3-932-999-01 SLIDER (SW)
157 3-932-998-01 SPRING (GROUND), TORSION
158 3-009-648-01 LEVER (S.OFF)
159 3-009-650-02 SPRING (K), COMPRESSION
160 X-3373-572-1 REEL ASSY (N), T
161 3-933-020-11 BELT
162 X-3377-877-2 FLYWHEEL ASSY
163 3-932-993-01 CHASSIS, OUTSERT
164 3-343-358-01 RING, RETAINING
165 3-223-156-01 SPRING (CAM), COMPRESSION
166 3-934-336-01 BEARING
167 3-939-383-02 SPRING, COMPRESSION
168 3-936-438-01 LEVER (K)
M101 A-3052-373-A MOTOR ASSY (REEL/CAPSTAN) (INCLUDING
PULLEY)
S106 1-692-302-11 SWITCH, LEAF (TAPE POWER)
M101
S106
151
152
153
154
155
156
157
158
159
160
168
161
162
163
164
165
166
167
#6

20
CFM-S1
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example :
uA.... : µA.... , uPA.... : µPA....
uPB.... : µPB.... , uPC.... : µPC....
uPD.... : µPD....
• CAPACITORS
uF : µF
• COILS
uH : µH
• Abbreviation
EA : Saudi Arabia
UAE : United Arab Emirates
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
*1-680-392-11 BATTERY TERMINAL BOARD
***********************
**********************************************************************
*1-680-393-11 FINE TUNE BOARD
***************
<CAPACITOR>
C26 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C27 1-126-961-11 ELECT 2.2uF 20% 50V
<CABLE HOLDER>
*KH2 1-565-384-11 HOLDER, CABLE 3P
<RESISTOR>
R6 1-216-821-11 METAL CHIP 1K 5% 1/16W
R7 1-216-821-11 METAL CHIP 1K 5% 1/16W
<VARIABLE RESISTOR>
RV1 1-223-693-11 RES, VAR, CARBON 100K (FINE TUNING)
************************************************************
*1-680-391-11 JACK BOARD
***********
<DIODE>
D102 8-719-059-97 LED L-34HD (OPR/BATT)
<JACK>
J101 1-563-330-11 JACK (@)
<CABLE HOLDER>
*KH104 1-568-134-21 HOLDER, CABLE 6P
<RESISTOR>
R115 1-216-809-11 METAL CHIP 100 5% 1/16W
R117 1-216-819-11 METAL CHIP 680 5% 1/16W
R118 1-249-393-11 CARBON 10 5% 1/4W F
************************************************************
*A-3323-677-A MAIN BOARD, COMPLETE (EA)
*A-3323-679-A MAIN BOARD, COMPLETE (E,UAE)
******************************
3-229-772-01 HOLDER (ANT)
3-229-784-01 CUSHION (V)
7-685-647-79 SCREW +BVTP3X10 TYPE2 N-S
<CAPACITOR>
C1 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C3 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C5 1-162-199-31 CERAMIC 10PF 5% 50V
(E,UAE)
C5 1-162-275-21 CERAMIC 22PF 5% 50V(EA)
C6 1-162-199-31 CERAMIC 10PF 5% 50V
(E,UAE)
C6 1-162-264-21 CERAMIC 5.6PF 5% 50V (EA)
C7 1-162-907-11 CERAMIC CHIP 2PF 0.25PF 50V
(E,UAE)
C8 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C9 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C10 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C11 1-162-192-31 CERAMIC 2.7PF 10% 50V
C12 1-162-199-31 CERAMIC 10PF 5% 50V
C13 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C14 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C15 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C16 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C17 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C18 1-126-963-11 ELECT 4.7uF 20% 50V
C19 1-104-665-11 ELECT 100uF 20% 10V
C20 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C21 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C22 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C23 1-162-198-31 CERAMIC 8.2PF 10% 50V
C24 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C25 1-162-196-31 CERAMIC 5.6PF 10% 50V
C28 1-126-961-11 ELECT 2.2uF 20% 50V
C29 1-104-665-11 ELECT 100uF 20% 10V
C30 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C31 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V(EA)
C32 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C101 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C102 1-126-961-11 ELECT 2.2uF 20% 50V
BATTERY TERMINAL
JACKFINE TUNE MAIN
