Sony HCD-DZ20 User manual

SERVICE MANUAL
Sony Corporation
Home Audio Division
Published by SonyTechno Create Corporation
AEP Model
UK Model
E Model
DVD RECEIVER
9-887-568-03
2007F16-1
© 2007.06
Ver. 1.2 2007.06
HCD-DZ20
HCD-DZ20 is the amplifier, DVD/CD and
tuner section in DAV-DZ20.
SPECIFICATIONS
Model Name Using Similar Mechanism HCD-DZ230
Mechanism Type CDM85-DVBU102
Optical Pick-up Name KHM-313CAA
Thissystem incorporateswith Dolby*Digital andDolby ProLogic (II)adaptive
matrix surround decoder and the DTS** Digital Surround System.
*Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic”, and the double-D symbol are trademarks of Dolby
Laboratories.
** Manufactured under license from DTS, Inc.
“DTS” and “DTS Digital Surround” are registered trademarks of DTS, Inc.
Amplifier section
Stereo mode (rated) 50 W + 50 W (at 3 ohms,
1 kHz, 1 % THD)
Surround mode (reference) RMS output power
FL/FR/C/SL/SR*: 67 watts
(per channel at 3 ohms,
1 kHz, 10 % THD)
Subwoofer*: 65 watts (at 3
ohms, 80 Hz, 10 % THD)
*Depending on the sound field settings and the source,
there may be no sound output.
Inputs (Analog)
TV (AUDIO IN)(AEP, UK models)
Sensitivity: 450/250 mV
DVD system
Laser Semiconductor laser
(DVD: λ= 650 nm)
(CD: λ= 790 nm)
Emission duration:
continuous
Signal format system
Tuner section
System PLL quartz-locked digital
synthesizer
FM tuner section
Tuning range 87.5-108.0 MHz (50 kHz
step)
Antenna (aerial) FM wire antenna (aerial)
Antenna (aerial) terminals 75 ohms, unbalanced
Intermediate frequency 10.7 MHz
AM tuner section
Tuning range
Mexican and Latin American models:
530 – 1,710 kHz (with the
interval set at 10 kHz)
531 – 1,710 kHz (with the
interval set at 9 kHz)
European, Russian and Middle Eastern models:
531 – 1,602 kHz (with the
interval set at 9 kHz)
TV/VIDEO (AUDIO IN)(Except AEP, UK models)
Sensitivity: 450/250 mV
Mexican and Latin American models:
NTSC
Other models: NTSC/PAL
Other models: 531 – 1,602 kHz (with the
interval set at 9 kHz)
530 – 1,610 kHz (with the
interval set at 10 kHz)
Antenna (aerial) AM loop antenna (aerial)
Intermediate frequency 450 kHz
Video section
Outputs
AEP, UK models: VIDEO: 1 Vp-p 75 ohms
R/G/B: 0.7 Vp-p 75 ohms
Dimensions (approx.) 430×67×310 mm (w/h/d)
incl. projecting parts
Mass (approx.) 3.2 kg
Design and specifications are subject to change
without notice.
Except AEP, UK models: VIDEO: 1 Vp-p 75 ohms
S VIDEO:
Y: 1 Vp-p 75 ohms
C: 0.286 Vp-p 75 ohms
COMPONENT:
Y: 1 Vp-p 75 ohms
P
B
/C
B
, P
R
/C
R
: 0.7 Vp-p
75 ohms
General
Power requirements
Mexican models: 120 V AC, 60 Hz
Latin American models: 110 - 240 V AC, 50/60 Hz
Other models: 220 - 240 V AC, 50/60 Hz
Argentine models: 220 - 240 V AC, 50/60 Hz
Power consumption On: 80 W
Standby: 0.3 W (at the
Power Saving mode)
w
w
w
.
x
i
a
o
y
u
1
6
3
.
c
o
m
Q
Q
3
7
6
3
1
5
1
5
0
9
9
2
8
9
4
2
9
8
T
E
L
1
3
9
4
2
2
9
6
5
1
3
9
9
2
8
9
4
2
9
8
0
5
1
5
1
3
6
7
3
Q
Q
TEL 13942296513 QQ 376315150 892498299
TEL 13942296513 QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

2
HCD-DZ20
UNLEADED SOLDER
Boards requiring use of unleaded solder are printed with the lead-
free mark (LF) indicating the solder contains no lead.
(Caution: Some printed circuit boards may not come printed with
the lead free mark due to their particular size)
: LEAD FREE MARK
Unleaded solder has the following characteristics.
•Unleaded solder melts at a temperature about 40 °C higher
than ordinary solder.
Ordinary soldering irons can be used but the iron tip has to be
applied to the solder joint for a slightly longer time.
Soldering irons using a temperature regulator should be set to
about 350 °C.
Caution: The printed pattern (copper foil) may peel away if
the heated tip is applied for too long, so be careful!
•Strong viscosity
Unleaded solder is more viscou-s (sticky, less prone to flow)
than ordinary solder so use caution not to let solder bridges
occur such as on IC pins, etc.
•Usable with ordinary solder
It is best to use only unleaded solder but unleaded solder may
also be added to ordinary solder.
Notes on chip component replacement
•Never reuse a disconnected chip component.
•Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing
•Keep the temperature of the soldering iron around 270 °C
during repairing.
•Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
•Be careful not to apply force on the conductor when soldering
or unsoldering.
This appliance is classified as
a CLASS 1 LASER product.
This marking is located on the
rear of the unit.
MODEL IDENTIFICATION
– Rear Panel –
Model Part No.
AEP, UK models 2-892-575-0[]
RU model 2-892-575-1[]
E32 model 2-892-575-2[]
MX model 2-892-575-3[]
E3 model 2-892-575-4[]
E12 model 2-892-575-5[]
AR model 2-892-575-6[]
SP model 2-892-575-7[]
TH model 3-270-984-0[]
•Abbreviation
AR : Argentine model
E3 : 220 – 240 V AC area in E model
E12 :220 – 240 V AC area in E model
E32 :110 – 240 V AC area in E model
MX : Mexican model
RU : Russian model
SP : Singapore model
TH :Thai model
Laser component in this product is capable of emitting radiation
exceeding the limit for Class 1.
CAUTION
Use of controls or adjustments or performance of procedures
otherthanthosespecifiedhereinmayresult in hazardousradiation
exposure.
Parts No.
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS WHOSE
PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR
IN SUPPLEMENTS PUBLISHED BY SONY.
Special Component Notice
