Sony HT-A7000 User guide

5-024-830-62(1)
Continued on back page
續背面
Sound Bar
Startup Guide
入門指南
HT-A7000
GB
CT
2Connect a TV and another device
連接電視機與其他裝置




YES/是NO/否
Is there an HDMI IN jack labeled “eARC” or “ARC” on your TV?
電視機是否有一個標示為“eARC”或“ARC”的HDMI IN插孔？
: Video signal
: 視訊訊號
: Audio signal
: 音訊訊號
: Video signal
: 視訊訊號
: Audio signal
: 音訊訊號
HDMI cable (supplied)
HDMI連接線（附帶）
Blu-ray Disc™ player, set-top box or
gaming console, etc.
Blu-ray Disc™播放器、機上盒或遊戲
機等
HDMI cable (not supplied)
HDMI連接線（無附帶）
HDMI cable (supplied)
HDMI連接線（附帶）
Optical digital cable
(not supplied)
光纖數位線（無附帶）
Blu-ray Disc player, set-top box or
gaming console, etc.
Blu-ray Disc播放器、機上盒或遊戲
機等
HDMI cable (not
supplied)
HDMI連接線（無附
帶）

Connect the HDMI cable (supplied) to the HDMI OUT jack on the speaker system
and the HDMI IN jack on your TV.
If your TV has the S-CENTER SPEAKER IN jack, connect the S-CENTER SPEAKER IN jack on
your TV to the S-CENTER OUT jack on the speaker system using the TV center speaker
mode cable (supplied).

When your TV does not have an HDMI IN jack labeled “eARC” or “ARC,” use an
optical digital cable (not supplied) to connect an optical out jack on your TV and
the TV IN (OPT) jack on the speaker system.
There will be no sound output from the TV if the TV and the speaker system are connected
only using the HDMI cable.

Connect an HDMI cable (not supplied) to the HDMI OUT jack on another device
(a Blu-ray Disc player, set-top box, gaming console, etc.) and the HDMI IN jack on
the speaker system.
You can listen to high quality sound by playing the audio formats such as Dolby Atmos-
Dolby TrueHD or DTS:X.
If your TV is compatible with the eARC function, you can listen to high quality sound by
connecting another device to the HDMI IN jack on the TV and enabling the eARC function
of the TV.

將HDMI連接線（附帶）連接至揚聲器系統上的HDMI OUT插孔和電視機上的HDMI IN
插孔。
如果您的電視機有S-CENTER SPEAKER IN插孔，則使用中心揚聲器模式訊號線（附帶），將電視
機上的S-CENTER SPEAKER IN插孔連接至揚聲器系統上的S-CENTER OUT插孔。

如果您的電視機沒有標示為“eARC”或“ARC”的HDMI IN插孔，請使用光纖數位線（無
附帶）連接電視機的光纖輸出插孔與揚聲器系統的TV IN (OPT)插孔。
如果僅使用HDMI連接線連接電視機與揚聲器系統，電視機就沒有聲音輸出。

將HDMI連接線（無附帶）連接到其他裝置（Blu-ray Disc播放器、機上盒或遊戲機
等）上的HDMI OUT插孔和揚聲器系統上的HDMI IN插孔。
您可以透過播放Dolby Atmos-Dolby TrueHD或DTS:X等音訊格式來聆聽高品質聲音。
如果您的電視機與eARC功能相容，可以將其他裝置連接到電視機上的HDMI IN插孔並啟用電視
機的eARC功能來聆聽高品質聲音。
Note
• Make sure that the connectors are firmly inserted.
• Check the shape of the optical digital cable’s connectors and the jacks on the TV and the speaker system.
Insert the connectors into the jacks in the right directions. If you forcibly insert the connectors in the
wrong directions, the connectors and the jacks may be damaged.
Tip
• Select the appropriate HDMI cable and [HDMI Signal Format] setting according to the video formats
output from the device connected to the speaker system. For details, refer to the Help Guide.
• When you connect the speaker system to a device which supports the 8K video format, refer to
“Connecting an AV Device Compatible with the 8K Video Format” in the Operating Instructions (separate
document).
註
•確定接頭牢固地插入。
•請檢查光纖數位線連接器與電視機及揚聲器系統插孔的形狀。以正確的方向將連接器插入到插孔內。如果您以
錯誤方向強力插入連接器，連接器與插孔可能會損壞。
提示
•根據從連接到揚聲器系統的裝置輸出的視訊格式，選擇適當的HDMI連接線和[HDMI訊號格式]設定。如需詳細資
訊，請參閱說明指南。
•當您將揚聲器系統連接到支援8K視訊格式的裝置時，請參閱使用說明書（另外的文件）中的“連接與8K視訊格
式相容的AV裝置”。
1Choose an installation method
選擇安裝方式
Installing on a shelf/stand
在架子/底座上安裝
or
或
Mounting on a wall
For details, refer to the Operating Instructions (separate document).
在牆壁上安裝
如需詳細資訊，請參閱使用說明書（另外的文件）。
Note
• Before connecting the speaker system, disconnect the AC power cords (mains leads) of the TV and AV
devices from the AC outlets (mains). Reconnect them in step 4.
• Do not place metal objects near the speaker system. Wireless functions may become unstable.
• Do not cover the top of the speaker. It may interrupt the sound output from the top of the speaker.
• There are ventilation holes at the rear of the speaker. Place the speaker away from a TV or a wall at a
distance of 10 mm (13/32 in) or more.
註
•連接揚聲器系統之前，從交流電插座拔出電視機與AV裝置的交流電源線。在步驟4中重新連接。
•請勿將金屬物體放在揚聲器系統附近。無線功能可能不穩定。
•請勿覆蓋揚聲器的頂部。否則可能會中斷揚聲器頂部聲音輸出。
•揚聲器背後有通風孔。請將揚聲器與電視機或牆壁保持10 mm或更大距離。
REAR R
REAR L
To set up with the optional subwoofer and/or rear speakers
The confirm screen for the speaker connection appears on the TV screen in step 5. Connect the optional speakers to the
speaker system by following the screen instructions.
與可選重低音揚聲器和/或後置揚聲器配合使用時的設置
揚聲器連接的確認螢幕出現在步驟5中的電視機螢幕上。按照螢幕指示將可選揚聲器連接至揚聲器系統。
What’s in the box
盒中內容
Bar speaker (1)
主動式揚聲器（1）
Remote control (1) /
R03 (size AAA) battery (2)
遙控器（1）/
R03（AAA大小）電池（2）
AC power cord (mains lead) (1)
(The shape of the plug differs
depending on countries/regions)
交流電源線（1）
（插頭形狀視國家/地區而異）
HDMI cable* (1)
HDMI連接線*（1）
TV center speaker mode cable (1)
中心揚聲器模式訊號線（1）
Wall mounting bracket (2) /
Screw (2)
壁掛式支架（2）/螺絲（2）
Sound Bar Sound Bar
Startup Guide
WALL MOUNT TEMPLATE (1)
壁掛式安裝模板（1）
Operating Instructions
使用說明書
Startup Guide (this document)
入門指南（本文件）
* Supports the transmission of 4K/8K content.
*支援4K/8K內容的傳輸。

© 2021 Sony Corporation Printed in Malaysia
3Set up the remote control
設定遙控器
4Turn on the TV and the speaker system
開啟電視機和揚聲器系統的電源

PLEASE WAIT
HOME

AC power cord (mains lead) (supplied)
交流電源線（附帶）

AC power cord
(mains lead)
交流電源線
Power ON
電源開啟
0h:02m
HELLO
AC power cord (mains lead) (supplied)
交流電源線（附帶）

Connect the TV’s AC power cord (mains lead) to the AC outlet (mains).

Connect the AC power cord (mains lead) to the AC inlet on the bar speaker.

Connect the AC power cord (mains lead) to the AC outlet (mains).
The remote control of the speaker system does not work until [HELLO] in the front panel
display on the speaker system disappears.

Press HOME on the remote control of the speaker system after [HELLO] in the
front panel display disappears.
Wait until [PLEASE WAIT] in the front panel display disappears and next indication appears
in the front panel display.

將電視機的交流電源線連接至交流電插座。

將交流電源線連接至主動式揚聲器上的交流插口。

將交流電源線連接至交流電插座。
在揚聲器系統前顯示面板上的[HELLO]消失之前，揚聲器系統的遙控器沒有作用。

前顯示面板中的[HELLO]消失後，按揚聲器系統遙控器上的HOME。
等待直到前顯示面板中的[PLEASE WAIT]消失且出現下一個指示。
5Perform Initial Settings
執行初始設定
Initial Settings screen
初始設定畫面
HOME
////

Follow the instructions on the screen displayed on the TV to perform initial
settings with ///and .
If the initial setting screen is not displayed, use the TV remote control to switch the input
on the TV to the HDMI input that is connected to the speaker system, then press HOME on
the remote control of the speaker system.

If you use the optional subwoofer/rear speakers, connect them by following the
instructions on the [Checking Wireless Speaker Connection] screen.

Once [Setup is complete.] appears, select [Learn more].

按照電視機上顯示的螢幕指示使用///和 執行初始設定。
若不顯示初始設定螢幕，則使用電視機遙控器將電視機上的輸入切換至揚聲器系統所連接的
HDMI輸入，然後按下揚聲器系統遙控器上的HOME。

若使用可選重低音揚聲器/後置揚聲器，則按照[檢查無線揚聲器連線]螢幕上的指示進
行連線。

一旦出現[設置已完成。]，請選擇[深入了解]。
6Listen to sound
聆聽聲音
TV
HDMI1
HDMI2
TV input switch
電視機輸入開關
To listen to the audio of the TV

Select the desired input to the TV using the TV remote control.
The screen switches to the selected input screen and the TV audio is output from the
speaker system.
If [TV] does not appear in the front panel display on the speaker system, press TV on the
remote control of the speaker system to select the TV input. [TV] appears in the front
panel display on the speaker system.
聆聽電視機的聲音

使用電視機遙控器選擇所要的電視機輸入。
畫面切換為所選輸入畫面，而且揚聲器系統輸出電視機的聲音。
如果揚聲器系統的前顯示面板上沒有出現[TV]，請按下揚聲器系統遙控器上的TV以選擇電視
機輸入。揚聲器系統的前顯示面板上出現[TV]。
To listen to the audio of a device that is connected to the HDMI IN jack
on the speaker system

Turn on the connected device. Then use the TV’s remote control to switch the
TV’s input to the HDMI IN jack to which the speaker system is connected.

Press HDMI1 or HDMI2 on the remote control of the speaker system to switch
to the HDMI input.
[HDMI1] or [HDMI2] appears in the front panel display on the speaker system and the
audio of the connected device is output from the speaker system.
聆聽連接到揚聲器系統HDMI IN插孔的裝置之音訊

開啟連接的裝置之電源。然後使用電視機遙控器將電視機輸入切換為揚聲器系統連
接的HDMI IN插孔。

按下揚聲器系統遙控器的HDMI1或HDMI2，以切換到HDMI輸入。
揚聲器系統的前顯示面板上出現[HDMI1]或[HDMI2]，連接裝置的音訊會從揚聲器系統輸出。
Note
• Depending on the order in which you turn on the TV and speaker system, the speaker system may be
muted and [MUTING] may appear on the front panel display on the speaker system. If this happens,
turn on the TV first, then the speaker system.
• If you select “YES” in “2 Connect a TV and another device,” enable the Control for HDMI function on the
TV. Otherwise, there will be no TV sound output from the speaker system.
註
•依據您開啟電視機與揚聲器系統的順序，揚聲器系統可能會靜音，而且揚聲器系統的前顯示面板上可能會出
現[MUTING]。如果發生這種狀況，請先開啟電視機，然後開啟揚聲器系統。
•如果在“2 連接電視機與其他裝置＂中選擇“是＂，則啟用電視機的HDMI控制功能。否則揚聲器系統不會輸
出電視機聲音。
How to use the speaker system / Troubleshooting
如何使用揚聲器系統/故障排除
Sound Bar
Operating Instructions (booklet)
Describes basic usage such as installation/connection
and playback of connected devices.
Help Guide (Web instruction manual)
Describes all the usage such as the network function
and the detailed setting method, including the contents
of the Operating Instructions.
For troubleshooting when the speaker system does not
operate correctly, see “Troubleshooting” in the Operating
Instructions or Help Guide.
使用說明書（小冊子）
描述基本使用，例如安裝/連接和播放連接裝置。
說明指南（網頁版使用說明書）
描述所有使用，例如網路功能和詳細設定方法，包括使用說
明書的內容。
有關揚聲器系統無法正常操作時的故障排除，請參閱使用說
明書或說明指南中的“故障排除”。
For customers in Americas
對於美洲客戶
https://rd1.sony.net/help/ht/
a7000/h_uc/
For customers in other countries/
regions
對於其他國家/地區客戶
https://rd1.sony.net/help/ht/
a7000/h_zz/
