SRS-D4100/D5100
US Model
AEP Model
SRS-D4100/D5100
Canadian Model
UK Model
Korean Model
SRS-D5100
SERVICE MANUAL
ACTIVE SPEAKER SYSTEM
Sony Corporation
Parsonal Audio Company
Published by Sony Engineering Corporation
9-877-701-02
2004E02-1
© 2004.05
SPECIFICATIONS
Ver 1.1 2004. 05
Subwoofer Satellite
Speaker Control Box
Photo : SRS-D5100
Speaker section
Satellite speaker
Speaker system Full range, magnetically shielded
Speaker units 5.6 cm, cone type
Enclosure type Closed type
Impedance 6 Ω
Cord length 3 m
Subwoofer
Speaker system Woofer
Speaker units 16 cm, cone type
Enclosure type Bass reflex
Impedance 6 Ω
Amplifier section
Rated output 12 W (10% T.H.D., 1 kHz, 6 Ω)
(Satellite speaker)
80 W (10% T.H.D., 100 Hz, 6 Ω)
(Subwoofer)
Input Stereo mini jack x 3
(INPUT 1 for 5.1 channel signal input)
(D5100)
Stereo mini jack x 2
(INPUT 1 for 4 channel signal input)
(D4100)
Stereo mini jack x 1
(INPUT 2 for 2 channel signal input)
Input impedance 4.7 kΩ(at 1 kHz)
Output Stereo mini jack x1 (PHONES)
General
Dimensions (w/h/d) Approx. 166 x 40 x 83 mm
(6 5/8x 1 5/8x 3 3/8in.) (Control box)
Approx. 95 x 135 x 150 mm
(3 3/4x 5 3/8x 6 in.)
(Satellite speaker, on a desk)
Approx. 95 x 100 x180 mm
(3 3/4x 4 x 7 1/8in.)
(Satellite speaker, attached to a wall)
Approx. 285 x 285 x 462 mm
(11 1/4x 11 1/4x 18 1/4in.)(Subwoofer)
Mass Approx. 240 g (8 oz.) (Control box)
Approx. 490 g (1 lb. 1 oz.)
(Satellite speaker)
Approx. 8.7 kg (19 lb. 3 oz.)(Subwoofer)
(D5100)
Approx. 8.6 kg (18 lb. 15 oz.)(Subwoofer)
(D4100)
Cord length 2 m (Control box to subwoofer)
2 m (Power cord)
Power consumptions 42 W (D5100)
41 W (D4100)
Power requirements
Where purchased Operating voltage
US, Canadian model 120 V AC, 60 Hz
AEP, UK, Korean model 220 – 230 V AC, 50 Hz
Supplied accessories
Connecting Cable (for 5.1 channel signal input) (D5100)
Connecting Cable (for 4 channel signal input) (D4100)
Design and specifications are subject to change without notice.

2
SRS-D4100/D5100
TABLE OF CONTENTS
Specifications ............................................................................ 1
1. GENERAL ................................................................... 3
2. DIAGRAMS
2-1. Schematic Diagram – Amp Section–...............................5
2-2. Printed Wiring Boards– Amp Section (Side A)–............. 6
2-3. Printed Wiring Boards– Amp Section (Side B)–............. 7
2-4. Printed Wiring Boards – Control Section (D5100)– .......8
2-5. Printed Wiring Boards – Control Section (D4100)– .......9
2-6. Schematic Diagram – Control Section– .......................... 10
3. EXPLODEDVIEWS
3-1. Subwoofer Section .......................................................... 11
3-2. Control Box, Satellite Speaker Section ........................... 12
4. ELECTRICAL PARTS LIST .................................. 13
SAFETY CHECK-OUT
After correcting the original service problem, perform the following
safety checks before releasing the set to the customer:
Checkthe antennaterminals, metal trim,“metallized” knobs,screws,
and all other exposed metal parts forAC leakage. Check leakage as
described below.
LEAKAGE
The AC leakage from any exposed metal part to earth Ground and
from all exposed metal parts to any exposed metal part having a
return to chassis, must not exceed 0.5 mA (500 microampers).
Leakage current can be measured by any one of three methods.
1. Acommercial leakage tester, such as the Simpson 229 or RCA
WT-540A. Follow the manufacturers’instructions to use these
instruments.
2. Abattery-operatedAC milliammeter. The Data Precision 245
digital multimeter is suitable for this job.
3. Measuring the voltage drop across a resistor by means of a
VOMor battery-operatedAC voltmeter.The“limit” indication
is 0.75 V, so analog meters must have an accurate low-voltage
scale. The Simpson 250 and Sanwa SH-63Trd are examples
of a passive VOM that is suitable. Nearly all battery operated
digital multimeters that have a 2VAC range are suitable. (See
Fig. A)
Fig. A. Using an AC voltmeter to check AC leakage.
0.15µF
To Exposed Metal
Parts on Set
1.5kΩAC
voltmeter
(0.75V)
Earth Ground
SAFETY-RELATED COMPONENT WARNING!!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN THE
PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE
THESE COMPONENTS WITH SONY PARTS WHOSE PART
NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN
SUPPLEMENTS PUBLISHED BY SONY.
ATTENTION AU COMPOSANT AYANT RAPPORT
À LA SÉCURITÉ!!
LES COMPOSANTS IDENTIFIÉS PAR UNE MARQUE 0SUR LES
DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES
SONT CRITIQUES POUR LA SÉCURITÉ DE FONCTIONNEMENT.
NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES
SONY DONT LES NUMÉROS SONT DONNÉS DANS CE MANUEL
OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.

3
SRS-D4100/D5100
SECTION 1
GENERAL This section is extracted
from instruction manual.
LOCATING THE CONTROLS
VOLUME BASS REAR CENTER
PHONE
ON
OFF
POWER
ON
OFF
Dual Stereo
MIN MAX
POWER
VOLUME
PHONES
DUAL STEREO
Control box
VOLUME BASS REAR
PHONE
ON
OFF
POWER
ON
OFF
DUAL STEREO
MIN MAX
POWER
VOLUME
PHONES
DUAL STEREO
Control box
D5100 D4100

4
SRS-D4100/D5100 SECTION 2
DIAGRAMS
For schematic diagrams.
Note:
•All capacitors are in µF unless otherwise noted. pF: µµF 50 WV or
less are not indicated except for electrolytics and tantalums.
•All resistors are in Ωand 1/4W or less unless otherwise specified.
•C: panel designation.
•A: B+ Line.
•B: B– Line.
•Voltages are dc with respect to ground under no-signal conditions.
•no mark : Power on
•Voltages are taken with a VOM (Input impedance 10 MΩ).
Voltage variations may be noted due to normal production toler-
ances.
•Signal path.
F: AUDIO
•Abbreviation
CND : Canadian model
KR : Korean model
THIS NOTE IS COMMON FOR PRINTED WIRING BOARDS AND SCHEMATIC DIAGRAMS.
(In addition to this necessary note is printed in each block.)
Note:
The components identi-
fied by mark 0or dotted
line with mark 0are criti-
cal for safety.
Replace only with part
number specified.
Note:
Les composants identifiés par
une marque 0sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
For printed wiring boards.
Note:
•X: parts extracted from the component side.
•: Pattern from the side which enables seeing.
•Abbreviation
CND : Canadian model
KR : Korean model
Ver 1.1

SRS-D4100/D5100
55
2-1. SCHEMATIC DIAGRAM – AMP SECTION –
C903
C904
C901
C902
R625
R624
R626
R627
R523
R522
R360
R353
R355
R354
R356
R357
R358
R359
R362
R361
R351
R427
C905
R160
C152
C151
R153
R155
R154
R156
R157
R158
R159
R162
R161
R151
R125
R226
C155 R152
FB601
FB602
FB603
FB604
CNP903
R57
R56
R59
R55
C54 C55
R60 R61
R62
R63
R524
D51
D52
R51
R52 R53
R64
R126 R127
R225 R227
R325 R326 R327
R425 R426
R630
R631
R632
R633
R581
R481 R381
R281
C56
R65
CNP901
CN901
CN903
C58
C59
FB101
R623 C638
C632
R622
R621
C666
C667
C910
C663
C664
IC301
C357
C360
C362
IC101
C157
C160
C162
C127
CNP904 CN904
CN601
CN101
C621
C225
C125
C425
C325
C51
R629
C53
C642
C126
C226
C326
C426
C906
CN902
T901
L501
60µH
L602
33µH
33µH
L601
L101
33µH
L301
33µH
C647 C646
C648
C649
C651 C650
C644
C645
C639
C634
C640
C629
C628
C627
C625
C624
C622
C652
C661
C662
C964
C961
C963
C962
C356
C358
C359
C361
C364
C363
C365
C369
C327
C328
C428
C427
C165
C169
C164
C161
C163
C159
C158
C156
C154
C153
C281 C181 C128
C228
C522
C521
C523
C524
C581
C528
C529
C52
JW901
C909
Q58 Q59
Q51
Q57
Q53
Q54
Q55
Q56
C534
R521
IC501
C481 C381
R181
IC601
IC901
R66
C533
C526
C525
J105
C530 C531 C532
FH901 FH902
FH903 FH904
FH910
FH909
F902
F903
F904
FH906
FH905
FH907 FH908
D901
D902
D903 D904
D909
D910
D911 D912
D905
D906
D907
D908
C653 C623
C626
C654
C655 C631
C637
C657
C635 C656
C641 C658
C633
C57
CNP101
CN102
CNP1
C166
C366
R54 CNP102
FB102
F905
C643
C630
C227
C354
C353
C352
C351
F901
Q52
J110
J108
J107
J106
J109
S901
6800
35V
6800
35V
6800
35V
6800
35V
15
1/10W
15
1/10W
22
1W
22
1W
470
1/10W
12k
4.7k
4.7k
68k
10k
22k
130k
22k
68k
6.8
51k
51k
330
1/10W
1000
25V
4.7k
470 35V
470 35V
4.7k
68k
10k
22k
130k
22k
68k
6.8
51k
51k
330
1/10W
330
1/10W
10 50V 30k
0UH
0UH
0UH
0UH
2P
47k
4.7k
100
4.7k
4.7
50V
10
50V
47k 47k
12k
10k
470
1/10W
1SS355TE-17
1SS355TE-17
47k
47k 4.7k
100
330
1/10W
330
1/10W
330
1/10W
330
1/10W
330
1/10W 330
1/10W 330
1/10W
330
1/10W 330
1/10W
15
1/10W
15
1/10W
15
1/10W
15
1/10W
4.7k
4.7k 4.7k
4.7k
22
16V
2.2k
2P
2P
2P
2200p
2200p
0UH
5.6k 0.015
0.015
30k
5.6k
47
35V
47
35V
47
16V
470
35V
470
35V
TDA7490L
24p
0.1
0.1
TDA7490L
24p
0.1
0.1
560p 50V CH
8P 8P
2P
9P
0.47
50V
0.33 50V
0.33 50V
0.33 50V
0.33 50V
0.1
50V
100
100
10V
47
63V
1000p
1000p
1000p
1000p
2200p/250V
0.68 0.68
0.22
0.22
0.015 0.015
560p
560p
0.1
0.1
0.1
0.1
0.47
330p
330p
0.1
0.1
0.01
0.1
0.1
0.047
0.047
0.047
0.047
470p
470p
330p
330p
470p
470p
0.033
0.1
560p
0.68
0.68
560p
0.033
0.1
470p
330p
470p
330p
470p
470p
0.033
0.1
0.001 0.001 0.68
0.68
0.1
560p
0.0047
270p
0.001
0.1
0.1
0.01
DTC144EUA
MUTE DTC144EUA
MUTE
DTC144EUA
AC DETECT
DTC144EUA
MUTE
SWITCH
DTC144EUA
MUTE
DTC144EUA
MUTE
DTA144EUA
MUTE
DTC144EUA
MUTE
0.68
470
1/10W
TDA7481
0.001 0.001
4.7k
TDA8921TH
KIA78S09
1k
470
35V
0.001
0.33
50V
8P
0.1 470
35V 0.1
U15G
U15G
U15G U15G
10E2
10E2
10E2 10E2
U15G
U15G
U15G
U15G
0.1
100V
0.1
100V
0.1100V
0.1100V
0.1
100V 0.1
100V
0.1 100V
0.1 100V
0.1
100V 0.1
100V
0.1
100V 0.1
100V
0.1
100p
9P
0.1
100V
0.1
100V
10k 4P
0UH
47p
0.1
560p
0.033
0.1
470
35V
470
35V
DTC144EUA
MUTE
DRIVE
*
*2
*3
*3
*3
*2
*4
*2
AEP,UK,KR
US,CND
0.1/50V
1/50V
AEP,UK,KR
US,CND
D5100
T901
POWER
TRANSFORMER
SATELLITE
AMP
POWER
+9V REG.
AMP
POWER
AMP
POWER
AMP
POWER
*1 C52
AEP,UK,KR
US,CND
*2 F901,902
5A/125V
T5AL/250V
AEP,UK,KR
US,CND
AEP,UK,KR
US,CND
*4 F905
1A/125V
T1AL/250V
*3 F903,904
6.3A/125V
T6.3AL/250V
D5100
D4100
D5100
SPEAKERS
D4100
D5100
4P
6P
8P
10P
D5100
*2 CNP103
*3 CN102
D5100
AC IN
POWER
Ver 1.1

SRS-D4100/D5100
66
2-2. PRINTED WIRING BOARD – AMP SECTION (SIDE A) –
R624
C529
R630
C633
R631
C629
C166
C634
C630
C226
C635
C628
C631
R621
R381
C528
C369
R521
C622
R522
C624
R623
R157
C643
R625
C627
C652
C632
R622
C638
C645
C639
C641
C640
R633
Q57
R156
R151
R153
C154
C158
Q54
C156
C623
R155
C157
R158
R154
C159
R159
C160 C161
R160
C163
C162
C126
R161
R162
C164
C127
R126
R226
C227
C165
R362
R632
C169
C366
C426
R356
R351 R353
C354
C358 C356
R355
C357
R358
C153
R354
C359
R359
C360
C361
R360
C363
C362
C326
R361
R524
C364
R357
C365
R326
R426
C909
C327
C381
C481
C532
C427
C524
C522
C523
C644
C526
C181
C281
R327
C521
R60 R61
R62
R523
R63
Q58 Q59
C353
R325
R425
R427
R481
R581 C581
R127
R125
R225
R227
C625
Q55
R59
R57
R55
Q56
Q51
R66
Q53
D51
D52
R52
R51
Q52
D5100
R53
R56
R54
R65
C530
R281
R181
C662
R629
C626
C637
C656
C657
C658 C655
C654
C653
C57
C58
C59
C661
C651
C651
R152
R64
AEP,UK,KR
US,CND
11
(11)
21
(21)
1-861-670-
AEP,UK,KR
US,CND
11
(11)
21
(21)
1-861-669-
BOARDAMP
(SIDE A)
BOARDJACK
(SIDE A)
IC601
1
12
13
24
D5100
23 4 5 6 7 89
A
1
B
C
D
E
F
G
Ref. No. Location
D51 G-3
D52 G-3
IC601 B-2
Q51 A-3
Q52 A-3
Q53 A-3
Q54 B-4
Q55 A-4
Q56 A-4
Q57 A-3
Q58 C-8
Q59 C-8
• Semiconductor
Location
Ver 1.1

SRS-D4100/D5100
77
2-3. PRINTED WIRING BOARD – AMP SECTION (SIDE B) –
J106
J107
J108
J109
J110
JW901
C152
C151
C351
C352
C531
C667
C533
C225
C961
FH901 FH902
FH903 FH904
FH909 FH910
FH905 FH906
FH907 FH908
C910
CNP102
L101
C621
C964
C425
C534
C125
CN903
C905
C664
C666
C963
C962
C525
D5100
CNP101
C903
C902
C901
CN902
AC IN
D905
C904
D902
D908
D904
D907
D906
CNP103
F902
F904
F901
F903
F905
D903
D901
CN901
C55
L301
IC501
L501
C54
CN904
C428
C328
C128
C228
C155
C51 C52
C325
C53
CN102
CN101
D909
D912
D910
D911
FB603
FB602
FB604
FB102
FB101
C906
L602
R626
C648
R627
C646
CN601
C649
C647
FB601
C663
C642
L601
JW902
(SIDE B)
BOARDAMP
S901
POWER
AEP,UK,KR
AEP,UK,KR
AEP,UK,KR
US,CND
US,CND
11
(11)
21
(21)
1-861-669-
AEP,UK,KR
US,CND
11
(11)
21
(21)
1-861-670-
T901
POWER TRANSFORMER
J105
87
543
21
6
A
CONTROL
BOARD
(Page 8)
A
CONTROL
BOARD
(Page 9)
87
5
43
216
SATELLITE
SPEAKER
(CENTER)
SATELLITE
SPEAKER
REAR
(L-CH)
SATELLITE
SPEAKER
REAR
(R-CH)
SATELLITE
SPEAKER
FRONT
(L-CH)
SATELLITE
SPEAKER
FRONT
(R-CH)
SPEAKER
(WOOFER)
1
2
14 15
12
24
25
IC301
12
24
25
IC101
IC901
BOARDJACK (SIDE B)
D5100
D5100
D4100
23 4 5 6 7 89 10
A
1
B
C
D
E
F
G
H
Ref. No. Location
D901 E-7
D902 E-7
D903 E-6
D904 E-6
D905 E-9
D906 E-9
D907 E-8
D908 E-8
D909 F-7
D910 F-7
D911 F-7
D912 F-7
IC101 B-7
IC301 B-4
IC501 B-3
IC901 E-7
• Semiconductor
Location
Ver 1.1

SRS-D4100/D5100
88
2-4. PRINTED WIRING BOARD – CONTROL SECTION (D5100) –
R306
R103
C104
R105
R304
C504
R504
R303
R505
R605
R503
R724
R203
R211
C106
C805
C404
R403
R406
R404
R606
R604
R802
C604
R207
C606
R12
R307
R107
R507
R407
C211
C311
R311
R111
C111
R511
C511
C411
R308
R108
R508
R408
R808
R2
R1
R805
R14
C801
C306
R502
R602
R302
R401
R102
R501
R601
R301
R101
R201
C602
C502
C302
C202
C402
R402
R202 C102
R11
JR1
R8
Q704
Q705
R703
R704
R6
R5
R208
C707
R709
R716
R713
R717
R710
R707
R721
R714
R723
C304
R715
R722
R720
R711
C710
C804
R708
Q706
R705
C714
R706
R405
C702
Q703
R7
C103
C716
R506
R204
R106
R104
C406
R718
R305
R206
C715
R205
R411
R603
R712
C803
C204
R719
R9
C206
C203
R10
C4
R607
JW31
JW41
J102
C717
C806
JW39
J101
C8
JW38
J104
RV501
S701
S701
C501
C601
C301
C401
C101
C201
C7
C403
C503
C2
C3
C5
JW37
JW30
C6
C802
C703
CN1
C713
C712
C711
JW6
C704
C705
C706
JW23
JW25
JW35
C505
C405
C105
C305 C605
C205
C303
C603
JW33
JW32
C1
J103
J701
PHONES
BOARDCONTROL
CENTER
RV601
BASS
RV1
VOLUME
POWER
ON OFF
t
D701
POWER
ON
D701
E
E
E
E
FRONT REAR CENTER
/SUBWOOFER
INPUT 2
INPUT 1
11
(11)
1-861-688-
A
JACK
BOARD
(Page 7)
IC701
IC1
IC803
IC802
IC801
87
543
21
6
SW1
SW1
DUAL STEREO
ON OFF
t
RV301
REAR
23 4 5 6 7
A
1
B
C
D
Ref. No. Location
D701 B-5
IC1 B-6
IC701 C-1
IC801 C-3
IC802 C-3
IC803 C-2
Q703 B-5
Q704 B-5
Q705 C-1
Q706 C-1
• Semiconductor
Location

SRS-D4100/D5100
99
Ref. No. Location
D701 B-5
IC1 B-6
IC701 C-1
IC801 C-3
IC802 C-3
IC803 C-2
Q703 B-5
Q704 B-5
Q705 C-1
Q706 C-1
• Semiconductor
Location
2-5. PRINTED WIRING BOARD – CONTROL SECTION (D4100) –
C306
C406
R306
R103
C104
R105
R304
R13
R303
JR3
R605
JR2
R724
R203
R211
C805
C404
R403
R406
R404 R606
R604
R802
C604
C801
R207
C606
R14
R307
R107
JR7
R407
C211
C311
R311
R111
C111
JR4
JR8
C411
R308
R108
R12
R408
R808
R2
R1
R805
R16
JR5
C106
C206
R607
C4
R10
C203
R9
R719
C204
C803
R712
R603
R411
R205
C715
R206
R305
R718
R104
R106
R204
JR6
C716
C103
R7
Q703
C702
R405
R706
C714
R705
Q706
R708
C804
C710
R711
R720
R722
R715
C304
R723
R714
R721
R707
R710
R717
R713
R716
R709
C707
R208
R5
R6
R704
R703
Q705
Q704
R8
JR1
R11
C102
R202
R402
C402
C202
C302
R201
R101
R301
R102
R401
R302
C1
C10
JW26
JW8
JW27
C717
C806
JW39
JW11
JW1
C8
JW38
S701
S701
C301
C401
C101
C201
JW14
C3
C7
C403
C2
JW9
JW7
C603
C303
C205 C605
C305 C105
C405
JW10
C9
JW35
JW25
C706
C705
C704
JW4
JW6
C711
C712
C713
CN1
C703
C802
C6
JW30
JW37
C5
J101
J102
J103
J701
PHONES
BOARDCONTROL
RV301
REAR
RV601
BASS
RV1
VOLUME
POWER
ON OFF
t
SW1
SW1
DUAL STEREO
ON OFF
t
D701
POWER
ON
D701
E
E
E
FRONT REAR
INPUT 2
INPUT 1
21
(21)
1-861-667-
IC701
IC1
IC803
IC802
IC801
AJACK
BOARD
(Page 7)
87
543
21
6
23 4 5 6 7
A
1
B
C
D

SRS-D4100/D5100
1010
2-6. SCHEMATIC DIAGRAM – CONTROL SECTION –
C502
C602
C302
C402
C102
C202
R802
C205
C605
C305
C105
C802
C806 C805 R805
C505
C405
R808
R710
R711
C711
R717
R712
C706 R709
R714
R716
R715
R713
C713
C712
R705
R706
R707 R708
R704
C704
C705
R205
R206
R605
R606
R106
R105
R305
R306
R405
R406
C204 R204
R203
R304
R303
C104
R104
R103
R504
R503
C404 R404
R403
R603 R604
R5
R8
R11
R10
R7
R9
C717
C5
R12
R207
R607
R307
R107
R507
R407
R14
R501
R601
R301
R401
R101
R201
C501
C601
C301
C401
C101
C201
C803
C804
RV501
R703
R718
R721
R719
R720 R722
R723
C203
C103
C304
C504
C606
C7
C8
RV301
C311
C411
C511
C603
C703
R502
R602
R302
R402
R102
R202
R308
R508
R408
C604
R208
R108
R724
R211
C211
R311
R111
C111
C801
C403
C503
C303
R411
C716
C715 C714
C710
C707
C702
C206
C106
C3
C2
C1
C4
R12 R13
C10 C9
R16
R14
R506
R505
R511
Q705
Q706
Q703
Q704
D701
IC701
R2
R1
RV601
SW1
IC1
RV1
IC801
IC802
IC803
C306
C406
C6
R6
CN1
J101
J104
J701
S701
0.0022
0.0022
0.0022
0.0022
0.0022
0.0022
100k
4.7
16V
4.7
16V
4.7
16V
4.7
16V
100
16V
100
16V 0.1
16V 4.7k
4.7
16V
4.7
16V
4.7k
22k
22k
100
16V
68
4.7k
100
16V 4.7k
39k
39k
1k
1k
220 16V
220 16V
10k
10k
1.5k 1.5k
4.7k
4.7
16V
4.7
16V
4.7k
1k
22k
330
1k
4.7k
22k
1k
22k
1k
0.027 47k
100k
47k
330k
0.027
47k
100k
47k
330k
0.015 47k
330k
10k 10k
10k
5.6k
4.7k
4.7k
22k
22k
220
16V
100
16V
100
100
100
100
100
100
100
10k
2.7k
3.3k
2.7k
2.7k
2.7k
2.7k
4.7
16V
4.7
16V
4.7
16V
4.7
16V
4.7
16V
4.7
16V
0.1
16V
0.1
16V
10k
1k
4.7
4.7
4.7
4.7 220
220
0.027
0.027
0.015
0.015
0.47
4.7
16V
4.7
16V
10k/10k
0.0047
0.0047
0.0047
4.7
16V
4.7
16V
10k
2.2k
10k
10k
10k
10k
330k
330k
330k
0.047
68k
68k
1k
1.5k
0.047
15k
1.5k
0.047
0.1
16V
0.015
0.015
0.015
15k
100p
0.22 0.22
0.1
0.1
0.1
100p
100p
10
10
10
0.1
10k 10k
4.7
16V 4.7
16V
10k
100
1k
22k
15k
DTC343TK-T-146
MUTE
DTC343TK-T-146
MUTE
KRA107S
+B SWITCH
KRC107S
+B SWITCH
SLC-22MG3F
NJM4580E-TE2
10k
10k
100p
100p
4.7
16V
10k
9P
*1
*1
D4100
D4100
D4100
D5100
D5100
D5100
AMP
HEADPHONE
AMP
PRE
LPF
PRE
AMP
AMP
PRE
D5100
D5100
D5100
D5100
D5100
D4100
D4100
D5100
D4100
D5100
D4100
D5100
J101
J102
J102
J103
D4100
D5100
*1 R1,2
2.2k
2.7k
ON
OFF
ON
OFF

11
SRS-D4100/D5100
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SECTION 3
EXPLODED VIEWS
3-1. SUBWOOFER SECTION
NOTE:
•-XX, -X mean standardized parts, so they may
have some differences from the original one.
•Color indication of Appearance Parts
Example :
KNOB, BALANCE (WHITE) … (RED)
↑↑
Parts color Cabinet's color
•Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
•The mechanical parts with no reference number
in the exploded views are not supplied.
•Accessories are given in the last of this parts
list.
• Abbreviation
CND : Canadian model
KR : Korean model
The components identified by mark 0or
dotted line with mark 0are critical for
safety.
Replace only with part number specified.
Les composants identifiés par une
marque 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
1
not supplied
#2
#2
2
8
#1
#1
4
4
#2
#2
#2
#4
not supplied not supplied
#4
7
6
5
#3
3
#4
#4
#4 #4 F901
F902
F905
F90
3
F904
T901
not supplied
S901
1X-3384-826-1 WOOFER CABINET MAIN ASSY (US, CND)
1 X-3384-923-1 WOOFER CABINET MAIN ASSY (AEP, UK, KR)
21-825-753-11 SPEAKER UNIT (165mm)
3A-4547-114-A AMP BOARD, COMPLETE (D5100: US, CND)
3A-4547-162-A AMP BOARD, COMPLETE (D4100: US)
3A-4547-341-A AMP BOARD, COMPLETE (D4100: AEP)
3A-4547-343-A AMP BOARD, COMPLETE (D5100: AEP, UK, KR)
43-264-690-01 FOOT, WOOFER
53-264-525-01 PANEL, REAR (D5100: US, CND)
53-264-525-11 PANEL, REAR (D5100: AEP, UK)
53-264-525-31 PANEL, REAR (D5100: KR)
53-264-847-01 PANEL, REAR (D4100: US)
53-264-847-11 PANEL, REAR (D4100: AEP)
061-696-169-12 CORD, POWER (AEP, UK)
061-769-079-32 CORD, POWER (KR)
061-783-531-72 CORD, POWER (US, CND)
74-217-350-11 STOPPER, CORD
8X-2022-446-1 FRONT SUB ASSY, WOOFER (D4100:US,CND)
8X-2022-447-1 FRONT SUB ASSY, WOOFER (D4100:AEP,UK)
8X-2022-453-1 FRONT SUB ASSY, WOOFER (D5100:US,CND)
8X-2022-454-1 FRONT SUB ASSY, WOOFER (D5100:AEP,UK, KR)
0F901 1-532-505-32 FUSE (T5AL/250V) (AEP, UK, KR)
0F901 1-533-420-11 FUSE, GLASS CYLINDRICAL (DIA.5) (5A/125V)
(US, CND)
0F902 1-532-505-32 FUSE (T5AL/250V) (AEP, UK, KR)
0F902 1-533-420-11 FUSE, GLASS CYLINDRICAL (DIA.5) (5A/125V)
(US, CND)
0F903 1-532-506-32 FUSE (T6.3AL/250V) (AEP, UK, KR)
0F903 1-533-310-11 FUSE, GLASS CYLINDRICAL (DIA.5) (6.3A/125V)
(US, CND)
0F904 1-532-506-32 FUSE (T6.3AL/250V) (AEP, UK, KR)
0F904 1-533-310-11 FUSE, GLASS CYLINDRICAL (DIA.5) (6.3A/125V)
(US, CND)
0F905 1-532-463-32 FUSE (T1AL/250V) (AEP, UK, KR)
0F905 1-533-689-11 FUSE, GLASS CYLINDRICAL (DIA.5) (1A/125V)
(US, CND)
0S901 1-762-876-11 SWITCH, AC POWER (AEP, UK, KR)
0T901 1-443-207-11 TRANSFORMER, POWER (US, CND)
0T901 1-443-209-11 TRANSFORMER, POWER (AEP, UK, KR)
#1 7-685-664-79 SCREW +PTP 4X20 TYPE1
#2 7-685-663-71 SCREW +BVTP 4X16 TYPE2 N-S
#3 7-682-550-04 SCREW +B 3X12 (AEP, UK, KR)
#3 7-685-550-04 SCREW +BTP 3X16 TYPE1 (US, CND)
#4 7-685-647-14 SCREW +BVTP 3X10 TYPE2 SLIT
Ver 1.1

12
SRS-D4100/D5100
3-2. CONTROL BOX, SATELLITE SPEAKER SECTION
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
51
52
53
54
55
56
57
58
59
59
59
59
63
64
59
60
61
62
#5
#6
51 3-264-844-01 CABINET, UPPER 4.1 (D4100: US)
51 3-264-844-11 CABINET, UPPER 4.1 (D5100: US, CND, KR)
51 3-264-844-21 CABINET, UPPER 4.1 (D4100: AEP)
51 3-264-844-31 CABINET, UPPER 4.1 (D5100: AEP, UK)
52 3-264-700-01 SWITCH, POWER
53 3-267-311-01 SHIELD (SHEET)
54 A-4547-159-A CONTROL BOARD, COMPLETE (D4100)
54 A-4547-171-A CONTROL BOARD, COMPLETE (D5100)
55 3-264-699-01 CUSHION, CONTROL
56 3-264-701-01 KNOB, VOLUME
57 3-264-843-01 CABINET, LOWER 4.1 (D4100)
57 3-264-843-11 CABINET, LOWER 4.1 (D5100)
58 1-828-481-11 DIN CABLE 9P (US, CND, KR)
58 1-828-481-21 DIN CABLE 9P (AEP, UK)
59 3-254-151-01 SCREW (B2.6), (+) P TAPPING
60 1-825-754-11 SPEAKER UNIT (57mm)
61 1-828-480-11 CORD CONNECTION 2P (US, CND)
61 1-828-480-21 CORD CONNECTION 2P (AEP, UK, KR)
62 3-264-668-11 CABINET, REAR (D4100)
62 3-264-668-21 CABINET, REAR (D5100)
63 X-2022-440-1 FRAME SUB ASSY, SATELLITE
64 X-2022-441-1 FRONT SUB ASSY, SATELLITE
#5 7-685-105-19 SCREW +P 2X8 TYPE2 SLIT
#6 7-682-160-01 SCREW +P 4X6
Ver 1.1

13
SRS-D4100/D5100
SECTION 4
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
NOTE:
•Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
•-XX, -X mean standardized parts, so they
may have some difference from the original
one.
•Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
•CAPACITORS:
uF: µF
•RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
•COILS
uH: µH
•SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
• Abbreviation
CND : Canadian model
KR : Korean model
Les composants identifiés par une
marque 0sont critiques pour la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
The components identified by mark 0
or dotted line with mark 0are critical
for safety.
Replace only with part number specified.
AMP
A-4547-114-A AMP BOARD, COMPLETE (D5100: US, CND)
A-4547-162-A AMP BOARD, COMPLETE (D4100: US)
A-4547-341-A AMP BOARD, COMPLETE (D4100: AEP)
A-4547-343-A AMP BOARD, COMPLETE (D5100: AEP, UK, KR)
*******************
1-533-313-11 FUSE HOLDER
3-264-694-01 SHEET, INSULATING (B)
4-217-354-11 BUSHING, INSULATING (D5100)
7-682-549-04 SCREW +B 3X10 (D4100)
7-682-549-04 SCREW +B 3X10 (D5100)
< CAPACITOR >
C51 1-124-463-00 ELECT 0.1uF 20% 50V
C52 1-124-463-00 ELECT 0.1uF 20% 50V
(US, CND)
C52 1-126-160-11 ELECT 1uF 20% 50V
(AEP, UK, KR)
C53 1-124-584-00 ELECT 100uF 20% 10V
C54 1-126-963-11 ELECT 4.7uF 20% 50V
(D5100)
C55 1-126-964-11 ELECT 10uF 20% 50V
(D5100)
C58 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C59 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C125 1-124-252-00 ELECT 0.33uF 20% 50V
C126 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C127 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C128 1-131-702-11 FILM 0.68uF 5% 50V
C151 1-126-951-11 ELECT 470uF 20% 35V
C152 1-126-951-11 ELECT 470uF 20% 35V
C153 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C154 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C155 1-126-964-11 ELECT 10uF 20% 50V
C156 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C157 1-162-975-11 CERAMIC CHIP 24PF 5% 50V
C158 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C159 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C160 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C161 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C162 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C163 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C164 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C165 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C166 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C169 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C181 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C225 1-124-252-00 ELECT 0.33uF 20% 50V
C226 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C227 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C228 1-131-702-11 FILM 0.68uF 5% 50V
C281 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C325 1-124-252-00 ELECT 0.33uF 20% 50V
C326 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C327 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C328 1-131-702-11 FILM 0.68uF 5% 50V
C351 1-126-951-11 ELECT 470uF 20% 35V
C352 1-126-951-11 ELECT 470uF 20% 35V
C353 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C354 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C356 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C357 1-162-975-11 CERAMIC CHIP 24PF 5% 50V
C358 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C359 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C360 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C361 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C362 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C363 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C364 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C365 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C366 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C369 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C381 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C425 1-124-252-00 ELECT 0.33uF 20% 50V
C426 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C427 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C428 1-131-702-11 FILM 0.68uF 5% 50V
C481 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C521 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
(D5100)
C522 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(D5100)
C523 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(D5100)
C524 1-164-388-91 CERAMIC CHIP 270PF 5% 50V
(D5100)
C525 1-124-252-00 ELECT 0.33uF 20% 50V
(D5100)
C526 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(D5100)
C528 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(D5100)
Ver 1.1

14
SRS-D4100/D5100
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
AMP
C529 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
(D5100)
C530 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(D5100)
C531 1-126-951-11 ELECT 470uF 20% 35V
(D5100)
C532 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
(D5100)
C533 1-126-951-11 ELECT 470uF 20% 35V
(D5100)
C534 1-131-702-11 FILM 0.68uF 5% 50V
(D5100)
C581 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
(D5100)
C621 1-124-465-00 ELECT 0.47uF 20% 50V
C622 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C623 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C624 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C625 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C626 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C627 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C628 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C629 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C630 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C631 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C632 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C633 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C634 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C635 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C637 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C638 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C639 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C640 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C641 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C642 1-128-552-51 ELECT 47uF 20% 63V
C643 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C644 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C645 1-164-739-11 CERAMIC CHIP 560PF 5% 50V
C646 1-131-702-11 FILM 0.68uF 5% 50V
C647 1-131-702-11 FILM 0.68uF 5% 50V
C648 1-131-696-11 FILM 0.22uF 5% 50V
C649 1-131-696-11 FILM 0.22uF 5% 50V
C650 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C651 1-163-023-00 CERAMIC CHIP 0.015uF 10% 50V
C652 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C653 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C654 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C655 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C656 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C657 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C658 1-165-554-91 CERAMIC CHIP 0.1uF 10% 100V
C661 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C662 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C663 1-126-951-11 ELECT 470uF 20% 35V
C664 1-126-951-11 ELECT 470uF 20% 35V
C666 1-126-947-11 ELECT 47uF 20% 35V
C667 1-126-947-11 ELECT 47uF 20% 35V
C901 1-119-939-11 ELECT 6800uF 20% 35V
C902 1-119-939-11 ELECT 6800uF 20% 35V
C903 1-119-939-11 ELECT 6800uF 20% 35V
C904 1-119-939-11 ELECT 6800uF 20% 35V
C905 1-126-942-61 ELECT 1000uF 20% 25V
C906 1-113-920-11 CERAMIC 0.0022uF 20% 250V
(AEP, UK, KR)
C909 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C910 1-126-947-11 ELECT 47uF 20% 35V
C961 1-130-491-00 MYLAR 0.047uF 5% 50V
C962 1-130-491-00 MYLAR 0.047uF 5% 50V
C963 1-130-491-00 MYLAR 0.047uF 5% 50V
C964 1-130-491-00 MYLAR 0.047uF 5% 50V
< CONNECTOR >
CN601 1-564-320-00 PIN, CONNECTOR (3.96mm PITCH) 2P
CN901 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
*CN902 1-564-321-21 PIN, CONNECTOR (3.96mm PITCH) 2P
(AEP, UK, KR)
CN903 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
*CN904 1-564-674-11 PIN, CONNECTOR (3.96mm PITCH) 8P
< DIODE >
D51 8-719-988-61 DIODE 1SS355TE-17
D52 8-719-988-61 DIODE 1SS355TE-17
D901 8-719-902-17 DIODE U15G
D902 8-719-902-17 DIODE U15G
D903 8-719-902-17 DIODE U15G
D904 8-719-902-17 DIODE U15G
D905 8-719-902-17 DIODE U15G
D906 8-719-902-17 DIODE U15G
D907 8-719-902-17 DIODE U15G
D908 8-719-902-17 DIODE U15G
D909 8-719-200-02 DIODE 10E-2
D910 8-719-200-02 DIODE 10E-2
D911 8-719-200-02 DIODE 10E-2
D912 8-719-200-02 DIODE 10E-2
< FERRITE BEAD >
FB101 1-400-160-51 INDUCTOR (SMALL TYPE)
FB102 1-400-160-51 INDUCTOR (SMALL TYPE)
FB601 1-400-160-51 INDUCTOR (SMALL TYPE)
FB602 1-400-160-51 INDUCTOR (SMALL TYPE)
FB603 1-400-160-51 INDUCTOR (SMALL TYPE)
FB604 1-400-160-51 INDUCTOR (SMALL TYPE)
< IC >
IC101 6-704-237-01 IC TDA7490L
IC301 6-704-237-01 IC TDA7490L
IC501 8-759-553-45 IC TDA7481 (D5100)
IC601 6-704-332-01 IC TDA8921TH
IC901 6-700-776-01 IC KIA78S09P-TP
< COIL >
L101 1-456-524-11 INDUCTOR 33uH
L301 1-456-524-11 INDUCTOR 33uH
L501 1-456-720-11 CIL, CHOKE 60uH (D5100)
L601 1-456-790-11 COIL, CHOKE 33uH
L602 1-456-790-11 COIL, CHOKE 33uH
Ver 1.1

15
SRS-D4100/D5100
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
< TRANSISTOR >
Q51 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q52 8-729-029-14 TRANSISTOR DTC144EUA-T106 (D5100)
Q53 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q54 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q55 8-729-028-91 TRANSISTOR DTA144EUA-T106
Q56 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q57 8-729-029-14 TRANSISTOR DTC144EUA-T106
Q58 8-729-029-14 TRANSISTOR DTC144EUA-T106 (D5100)
Q59 8-729-029-14 TRANSISTOR DTC144EUA-T106 (D5100)
< RESISTOR >
R51 1-216-841-11 METAL CHIP 47K 5% 1/10W
R52 1-216-841-11 METAL CHIP 47K 5% 1/10W
R53 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R54 1-216-833-11 METAL CHIP 10K 5% 1/10W
R55 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R56 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R57 1-216-841-11 METAL CHIP 47K 5% 1/10W
R59 1-216-809-11 METAL CHIP 100 5% 1/10W
R60 1-216-841-11 METAL CHIP 47K 5% 1/10W
(D5100)
R61 1-216-841-11 METAL CHIP 47K 5% 1/10W
(D5100)
R62 1-216-834-11 METAL CHIP 12K 5% 1/10W
(D5100)
R63 1-216-833-11 METAL CHIP 10K 5% 1/10W
(D5100)
R64 1-216-809-11 METAL CHIP 100 5% 1/10W
R65 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R66 1-216-821-11 METAL CHIP 1K 5% 1/10W
R125 1-216-815-11 METAL CHIP 330 5% 1/10W
R126 1-216-815-11 METAL CHIP 330 5% 1/10W
R127 1-216-815-11 METAL CHIP 330 5% 1/10W
R151 1-218-331-11 METAL CHIP 51K 5% 1/10W
R152 1-218-882-11 METAL CHIP 30K 0.5% 1/10W
R153 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R154 1-216-833-11 METAL CHIP 10K 5% 1/10W
R155 1-216-843-11 METAL CHIP 68K 5% 1/10W
R156 1-216-837-11 METAL CHIP 22K 5% 1/10W
R157 1-218-743-11 METAL CHIP 130K 0.5% 1/10W
R158 1-216-837-11 METAL CHIP 22K 5% 1/10W
R159 1-216-843-11 METAL CHIP 68K 5% 1/10W
R160 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R161 1-218-331-11 METAL CHIP 51K 5% 1/10W
R162 1-216-795-11 METAL CHIP 6.8 5% 1/10W
R181 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R225 1-216-815-11 METAL CHIP 330 5% 1/10W
R226 1-216-815-11 METAL CHIP 330 5% 1/10W
R227 1-216-815-11 METAL CHIP 330 5% 1/10W
R281 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R325 1-216-815-11 METAL CHIP 330 5% 1/10W
R326 1-216-815-11 METAL CHIP 330 5% 1/10W
R327 1-216-815-11 METAL CHIP 330 5% 1/10W
R351 1-218-331-11 METAL CHIP 51K 5% 1/10W
R353 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R354 1-216-833-11 METAL CHIP 10K 5% 1/10W
R355 1-216-843-11 METAL CHIP 68K 5% 1/10W
R356 1-216-837-11 METAL CHIP 22K 5% 1/10W
R357 1-218-743-11 METAL CHIP 130K 0.5% 1/10W
R358 1-216-837-11 METAL CHIP 22K 5% 1/10W
R359 1-216-843-11 METAL CHIP 68K 5% 1/10W
R360 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R361 1-218-331-11 METAL CHIP 51K 5% 1/10W
R362 1-216-795-11 METAL CHIP 6.8 5% 1/10W
R381 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R425 1-216-815-11 METAL CHIP 330 5% 1/10W
R426 1-216-815-11 METAL CHIP 330 5% 1/10W
R427 1-216-815-11 METAL CHIP 330 5% 1/10W
R481 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R521 1-216-817-11 METAL CHIP 470 5% 1/10W
(D5100)
R522 1-216-834-11 METAL CHIP 12K 5% 1/10W
(D5100)
R523 1-216-817-11 METAL CHIP 470 5% 1/10W
(D5100)
R524 1-216-817-11 METAL CHIP 470 5% 1/10W
(D5100)
R581 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
(D5100)
R621 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R622 1-218-882-11 METAL CHIP 30K 0.5% 1/10W
R623 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R624 1-216-799-11 METAL CHIP 15 5% 1/10W
R625 1-216-799-11 METAL CHIP 15 5% 1/10W
R626 1-215-859-00 METAL OXIDE 22 5% 1W
R627 1-215-859-00 METAL OXIDE 22 5% 1W
R629 1-216-809-11 METAL CHIP 100 5% 1/10W
R630 1-216-799-11 METAL CHIP 15 5% 1/10W
R631 1-216-799-11 METAL CHIP 15 5% 1/10W
R632 1-216-799-11 METAL CHIP 15 5% 1/10W
R633 1-216-799-11 METAL CHIP 15 5% 1/10W
************************************************************
A-4547-159-A CONTROL BOARD, COMPLETE (D4100)
A-4547-171-A CONTROL BOARD, COMPLETE (D5100)
**********************
< CAPACITOR >
C1 1-107-714-11 ELECT 10uF 20% 50V
C2 1-107-714-11 ELECT 10uF 20% 50V
C3 1-107-714-11 ELECT 10uF 20% 50V
C4 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C5 1-126-933-11 ELECT 100uF 20% 16V
C6 1-124-259-11 ELECT 4.7uF 20% 50V
C7 1-124-259-11 ELECT 4.7uF 20% 50V
C8 1-124-259-11 ELECT 4.7uF 20% 50V
C9 1-124-259-11 ELECT 4.7uF 20% 50V
(D4100)
C10 1-124-259-11 ELECT 4.7uF 20% 50V
(D4100)
C101 1-124-259-11 ELECT 4.7uF 20% 50V
C102 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C103 1-104-700-11 CERAMIC CHIP 0.027uF 10% 16V
C104 1-104-700-11 CERAMIC CHIP 0.027uF 10% 16V
C105 1-124-259-11 ELECT 4.7uF 20% 50V
C106 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
AMP CONTROL

16
SRS-D4100/D5100
Ref. No. Part No. Description Remarks Ref. No. Part No. Description RemarksRef. No. Part No. Description Remarks
CONTROL
C111 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C201 1-124-259-11 ELECT 4.7uF 20% 50V
C202 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C203 1-104-700-11 CERAMIC CHIP 0.027uF 10% 16V
C204 1-104-700-11 CERAMIC CHIP 0.027uF 10% 16V
C205 1-124-259-11 ELECT 4.7uF 20% 50V
C206 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C211 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C301 1-124-259-11 ELECT 4.7uF 20% 50V
C302 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C303 1-130-485-00 MYLAR 0.015uF 5% 50V
C304 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C305 1-124-259-11 ELECT 4.7uF 20% 50V
C306 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C311 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C401 1-124-259-11 ELECT 4.7uF 20% 50V
C402 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C403 1-130-485-00 MYLAR 0.015uF 5% 50V
C404 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C405 1-124-259-11 ELECT 4.7uF 20% 50V
C406 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C411 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C501 1-124-259-11 ELECT 4.7uF 20% 50V
(D5100)
C502 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(D5100)
C503 1-130-485-00 MYLAR 0.015uF 5% 50V
(D5100)
C504 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
(D5100)
C505 1-124-259-11 ELECT 4.7uF 20% 50V
(D5100)
C511 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
(D5100)
C601 1-124-259-11 ELECT 4.7uF 20% 50V
(D5100)
C602 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
(D5100)
C603 1-124-259-11 ELECT 4.7uF 20% 50V
C604 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C605 1-124-259-11 ELECT 4.7uF 20% 50V
C606 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C702 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C703 1-124-259-11 ELECT 4.7uF 20% 50V
C704 1-124-259-11 ELECT 4.7uF 20% 50V
C705 1-124-259-11 ELECT 4.7uF 20% 50V
C706 1-126-933-11 ELECT 100uF 20% 16V
C707 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C710 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C711 1-126-933-11 ELECT 100uF 20% 16V
C712 1-126-934-11 ELECT 220uF 20% 16V
C713 1-126-934-11 ELECT 220uF 20% 16V
C714 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C715 1-127-715-91 CERAMIC CHIP 0.22uF 10% 16V
C716 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C717 1-126-934-11 ELECT 220uF 20% 16V
C801 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C802 1-126-933-11 ELECT 100uF 20% 16V
C803 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C804 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C805 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C806 1-126-933-11 ELECT 100uF 20% 16V
< CONNECTOR >
*CN1 1-506-991-11 PIN, CONNECTOR (PC BOARD) 9P
< DIODE >
D701 8-719-077-29 DIODE SLC-22MG3F (POWER ON)
< IC >
IC1 8-759-100-96 IC uPC4558G2
IC701 8-759-385-17 IC NJM4580E (TE2)
IC801 8-759-100-96 IC uPC4558G2
IC802 8-759-100-96 IC uPC4558G2
IC803 8-759-100-96 IC uPC4558G2
< JACK >
J101 1-566-822-51 JACK (INPUT 1)
J102 1-566-822-51 JACK (INPUT 1)
J103 1-566-822-51 JACK (INPUT 1)
J104 1-566-822-51 JACK (INPUT 2) (D5100)
J701 1-815-325-11 JACK (PHONES)
< SHORT >
JR1 1-216-864-11 SHORT CHIP 0
JR2 1-216-864-11 SHORT CHIP 0 (D4100)
JR3 1-216-864-11 SHORT CHIP 0 (D4100)
JR4 1-216-864-11 SHORT CHIP 0 (D4100)
JR5 1-216-864-11 SHORT CHIP 0 (D4100)
JR6 1-216-864-11 SHORT CHIP 0 (D4100)
JR7 1-216-864-11 SHORT CHIP 0 (D4100)
JR8 1-216-864-11 SHORT CHIP 0 (D4100)
< TRANSISTOR >
Q703 8-729-038-58 TRANSISTOR KRA107S
Q704 8-729-038-71 TRANSISTOR KRC107S
Q705 8-729-920-31 TRANSISTOR DTC343TK
Q706 8-729-920-31 TRANSISTOR DTC343TK
< RESISTOR >
R1 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(D4100)
R1 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
(D5100)
R2 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(D4100)
R2 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
(D5100)
R5 1-216-833-11 METAL CHIP 10K 5% 1/10W
R6 1-216-833-11 METAL CHIP 10K 5% 1/10W
R7 1-216-837-11 METAL CHIP 22K 5% 1/10W
R8 1-216-830-11 METAL CHIP 5.6K 5% 1/10W
R9 1-216-837-11 METAL CHIP 22K 5% 1/10W
R10 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R11 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R12 1-216-809-11 METAL CHIP 100 5% 1/10W
(D5100)

17
SRS-D4100/D5100
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
R12 1-216-833-11 METAL CHIP 10K 5% 1/10W
(D4100)
R13 1-216-833-11 METAL CHIP 10K 5% 1/10W
(D4100)
R14 1-216-809-11 METAL CHIP 100 5% 1/10W
(D4100)
R14 1-216-833-11 METAL CHIP 10K 5% 1/10W
(D5100)
R16 1-216-833-11 METAL CHIP 10K 5% 1/10W
(D4100)
R101 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R102 1-216-833-11 METAL CHIP 10K 5% 1/10W
R103 1-216-845-11 METAL CHIP 100K 5% 1/10W
R104 1-216-841-11 METAL CHIP 47K 5% 1/10W
R105 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R106 1-216-821-11 METAL CHIP 1K 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-843-11 METAL CHIP 68K 5% 1/10W
R111 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R201 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R202 1-216-833-11 METAL CHIP 10K 5% 1/10W
R203 1-216-845-11 METAL CHIP 100K 5% 1/10W
R204 1-216-841-11 METAL CHIP 47K 5% 1/10W
R205 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R206 1-216-821-11 METAL CHIP 1K 5% 1/10W
R207 1-216-809-11 METAL CHIP 100 5% 1/10W
R208 1-216-843-11 METAL CHIP 68K 5% 1/10W
R211 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R301 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R302 1-216-833-11 METAL CHIP 10K 5% 1/10W
R303 1-216-851-11 METAL CHIP 330K 5% 1/10W
R304 1-216-841-11 METAL CHIP 47K 5% 1/10W
R305 1-216-837-11 METAL CHIP 22K 5% 1/10W
R306 1-216-821-11 METAL CHIP 1K 5% 1/10W
R307 1-216-809-11 METAL CHIP 100 5% 1/10W
R308 1-216-851-11 METAL CHIP 330K 5% 1/10W
R311 1-216-835-11 METAL CHIP 15K 5% 1/10W
R401 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R402 1-216-833-11 METAL CHIP 10K 5% 1/10W
R403 1-216-851-11 METAL CHIP 330K 5% 1/10W
R404 1-216-841-11 METAL CHIP 47K 5% 1/10W
R405 1-216-837-11 METAL CHIP 22K 5% 1/10W
R406 1-216-821-11 METAL CHIP 1K 5% 1/10W
R407 1-216-809-11 METAL CHIP 100 5% 1/10W
R408 1-216-851-11 METAL CHIP 330K 5% 1/10W
R411 1-216-835-11 METAL CHIP 15K 5% 1/10W
R501 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
(D5100)
R502 1-216-833-11 METAL CHIP 10K 5% 1/10W
(D5100)
R503 1-216-851-11 METAL CHIP 330K 5% 1/10W
(D5100)
R504 1-216-841-11 METAL CHIP 47K 5% 1/10W
(D5100)
R505 1-216-837-11 METAL CHIP 22K 5% 1/10W
(D5100)
R506 1-216-821-11 METAL CHIP 1K 5% 1/10W
(D5100)
R507 1-216-809-11 METAL CHIP 100 5% 1/10W
(D5100)
R508 1-216-851-11 METAL CHIP 330K 5% 1/10W
(D5100)
R511 1-216-835-11 METAL CHIP 15K 5% 1/10W
(D5100)
R601 1-216-827-11 METAL CHIP 3.3K 5% 1/10W
(D5100)
R602 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
(D5100)
R603 1-216-833-11 METAL CHIP 10K 5% 1/10W
R604 1-216-833-11 METAL CHIP 10K 5% 1/10W
R605 1-216-837-11 METAL CHIP 22K 5% 1/10W
R606 1-216-815-11 METAL CHIP 330 5% 1/10W
R607 1-216-809-11 METAL CHIP 100 5% 1/10W
R703 1-216-821-11 METAL CHIP 1K 5% 1/10W
R704 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R705 1-216-833-11 METAL CHIP 10K 5% 1/10W
R706 1-216-833-11 METAL CHIP 10K 5% 1/10W
R707 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R708 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R709 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R710 1-216-837-11 METAL CHIP 22K 5% 1/10W
R711 1-216-837-11 METAL CHIP 22K 5% 1/10W
R712 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R713 1-216-821-11 METAL CHIP 1K 5% 1/10W
R714 1-216-840-11 METAL CHIP 39K 5% 1/10W
R715 1-216-821-11 METAL CHIP 1K 5% 1/10W
R716 1-216-840-11 METAL CHIP 39K 5% 1/10W
R717 1-216-807-11 METAL CHIP 68 5% 1/10W
R718 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R719 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R720 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R721 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R722 1-216-813-11 METAL CHIP 220 5% 1/10W
R723 1-216-813-11 METAL CHIP 220 5% 1/10W
R724 1-216-821-11 METAL CHIP 1K 5% 1/10W
R802 1-216-845-11 METAL CHIP 100K 5% 1/10W
R805 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R808 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< VARIABLE RESISTOR >
RV1 1-227-640-11 RES, VAR CARBON 10K (VOLUME)
(D5100)
RV1 1-227-641-11 RES, VAR CARBON 10K (VOLUME)
(D4100)
RV301 1-227-642-11 RES, VAR CARBON 10K/10K (REAR)
RV501 1-227-643-11 RES, VAR CARBON 10K (CENTER)
(D5100)
RV601 1-227-643-11 RES, VAR CARBON 10K (BASS)
< SWITCH >
S701 1-571-478-11 SWITCH, SLIDE (POWER)
< SWITCH >
SW1 1-786-706-11 SWITCH, SLIDE (DUAL STEREO)
************************************************************
CONTROL

18
SRS-D4100/D5100
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
JACK BOARD
*********
< CAPACITOR >
C57 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
*CN101 1-566-006-11 PIN, CONNECTOR (PC BOARD) 9P
*CN102 1-506-784-11 PLUG, CONNECTOR (2.5mm) 10P
< JACK >
J105 1-817-577-11 JACK, DIN 8P (CONTROL)
J106 1-566-822-51 JACK (FRONT R)
J107 1-566-822-51 JACK (FRONT L)
J108 1-566-822-51 JACK (REAR R)
J109 1-566-822-51 JACK (REAR L)
J110 1-566-822-51 JACK (CENTER) (D5100)
************************************************************
MISCELLANEOUS
*************
21-825-753-11 SPEAKER UNIT (165mm)
061-696-169-12 CORD, POWER (AEP, UK)
061-769-079-32 CORD, POWER (KR)
061-783-531-72 CORD, POWER (US, CND)
58 1-828-481-11 DIN CABLE 9P (US, CND, KR)
58 1-828-481-21 DIN CABLE 9P (AEP, UK)
60 1-825-754-11 SPEAKER UNIT (57mm)
61 1-828-480-11 CORD CONNECTION 2P (US, CND)
61 1-828-480-21 CORD CONNECTION 2P (AEP, UK, KR)
0F901 1-532-505-32 FUSE (T5AL/250V) (AEP, UK, KR)
0F901 1-533-420-11 FUSE, GLASS CYLINDRICAL (DIA.5) (5A/125V)
(US, CND)
0F902 1-532-505-32 FUSE (T5AL/250V) (AEP, UK, KR)
0F902 1-533-420-11 FUSE, GLASS CYLINDRICAL (DIA.5) (5A/125V)
(US, CND)
0F903 1-532-506-32 FUSE (T6.3AL/250V) (AEP, UK, KR)
0F903 1-533-310-11 FUSE, GLASS CYLINDRICAL (DIA.5) (6.3A/125V)
(US, CND)
0F904 1-532-506-32 FUSE (T6.3AL/250V) (AEP, UK, KR)
0F904 1-533-310-11 FUSE, GLASS CYLINDRICAL (DIA.5) (6.3A/125V)
(US, CND)
0F905 1-532-463-32 FUSE (T1AL/250V) (AEP, UK, KR)
0F905 1-533-689-11 FUSE, GLASS CYLINDRICAL (DIA.5) (1A/125V)
(US, CND)
0S901 1-762-876-11 SWITCH, AC POWER (AEP, UK, KR)
0T901 1-443-207-11 TRANSFORMER, POWER (US, CND)
0T901 1-443-209-11 TRANSFORMER, POWER (AEP, UK, KR)
******************************************************
ACCESSORIES
***********
A-4577-254-A BASE ASSY
1-828-477-11 CORD CONNECTION 6P (D5100: US, CND)
1-828-477-21 CORD CONNECTION 6P (D5100: AEP, UK, KR)
1-828-478-11 CORD CONNECTION 4P (D4100: US)
1-828-478-21 CORD CONNECTION 4P (D4100: AEP)
3-264-408-11 MANUAL, INSTRUCTION (ENGLISH, SPANISH)
(D5100: US)
3-264-408-21 MANUAL, INSTRUCTION
(ENGLISH, SPANISH, FRENCH, GERMAN,
ITALIAN, DUTCH, PORTUGUESE, SWEDISH)
(D5100: AEP, CND, UK)
3-264-410-11 MANUAL, INSTRUCTION (ENGLISH, SPANISH)
(D4100: US)
3-264-410-21 MANUAL, INSTRUCTION
(ENGLISH, SPANISH, FRENCH, GERMAN,
ITALIAN, DUTCH, PORTUGUESE, SWEDISH)
(D4100: AEP)
3-264-674-01 BOLT, SATELLITE
7-685-645-79 SCREW +P 3X6 TYPE2 NON-SLIT
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
JACK
Ver 1.1
The components identified by
mark 0or dotted line with mark
0are critical for safety.
Replace only with part number
specified.

19
SRS-D4100/D5100
MEMO

SRS-D4100/D5100
REVISION HISTORY
Clicking the version allows you to jump to the revised page.
Also, clicking the version at the upper right on the revised page allows you to jump to the next revised
page.
Ver. Date Description of Revision
1.0 2004.03 New
1.1 2004.05 Addition of korean model for SRS-D5100.
