170 Watts Total: 85 Watts per Channel x 2 (RMS 10%
THD) Plenty of power for small to large size rooms or offices.
PC/Audio In for Digital Music Players or PC Input An exciting
new feature that takes music playback beyond tape and CD. It
allows simple plug
-
and
-
play integration with a digital music
device or PC via a 2.5mm jack.
5 Disc CD Changer with CD Pop
-
UpLoading
Mechanism Provides a unique way to keep the music going all
day, or all night long. Pop
-
up mechanism ejects CD
’
s vertically
for convenience and style.
3 Way Main Speakers with Woofers A three driver design helps
ensure audio accuracy by providing a greater frequency
range. The speaker's crossover splits the frequency band into
three ranges: bass frequencies go to the woofer, and treble
frequencies go to the tweeter and the middle frequencies are
sent to a third driver commonly referred to as the midrange.
Plays Back CD
-
R/RW Discs For customers who already have
extensive music libraries. Use CD burning software to music
compilations tailored to your listening preference.
S-
Master
®
Digial Amplifier More efficient than traditional
analog amplifiers by using less energy to produce the same
signal. The audio benefits are higher resolution sound quality,
monitored noise reduction and accurate sound reproduction.
Specifications
General
Type of Use: Desktop Micro System
TrayType: 5 Disc CD Changer with CD Pop
-
Up Loading
Mechanism (Semiconductor Laser 780nm)
DiscCapacity: 5
Audio
Digital
-
to
-
AnalogConverter: 1 Bit
FrequencyResponse: CD: 20
-
20000Hz (±0.3db); Cassette: 50
-
13000Hz (±0.5db)
Format(s)Supported: CD
-
DA, CD
-
R/RW, CDs with
MP3/ATRAC3
®
/
ATRAC3 plus™
Audio Playback Capability
Tuning:
Auto Scan Radio
AntennaSystem: AM: Loop Antenna, FM: Lead Antenna
TapeSystem: 4 Track, 2 Channel Stereo Cassette, CD
Synchronized Recording
FrequencyRange: AM: 530
-
1710kHz; FM: 87.5
-
108.0MHz
CD Play Mode(s):
Program, Shuffle, Repeat
StationPreset(s): 30 (10 AM, 20 FM)
SoundEnhancer: DSGX (Dynamic Sound Generator X
-
tra)
Equalizer:
7 Presets (Rock, Jazz, Classic, Hall, Live, Movie, Flat)
TapeOperation: Single Cassette Deck
TunerType: FM/AM Superheterodyne Tuner
Convenience Features
TimerEvents:
Record/Play/Sleep (Wake
-
up or Fall Asleep To
Music
-
Select from 10 Timed Shut Offs)
Power Save Mode: Yes
Hardware
Display: LCD
RemoteControl: Yes (Remote Commander
®
Remote Contorl)
Power
PowerRequirements: AC 120V, 60Hz
OutputPower: 170W Total (85 W + 85 W (6 ohms at 1 kHz, 10%
THD))
PowerConsumption: 145W
BatteryType: Remote: "AA" x 2
Power Handling Capacity: With 6 ohms loads, both channels
driven from 120
-
10000 Hz; rated 85 W per channel
-
minimum
RMS power, with no more than 10% total harmonic distortion
from 250 milliwatts to rated output.
Speaker
SpeakerSystem: 3
-
Way Bass Reflex Type
SpeakerDimensions: 1.6" (4cm), 0.8" (2cm) (Super Tweeter)
WooferSize(s): 5.9" (15cm)
Inputs and Outputs
Analog Audio Input(s): 1 (Rear, Stereo Mini)
HeadphoneInput(s): 1 (Front, Stereo Mini)
Optical Audio Output(s): 1 (Rear)
Antenna Terminal (AM Loop): 1 (Rear)
Antenna Terminal (FM 75 Ohm): 1 (Rear)
Dimensions
Weight: Speaker: 6 lbs 3 oz (2.8 Kg) (each x 2); Main Unit: 16 lbs
12 oz (7.6 Kg)
Measurements: Speaker: 7 1/12 x 11 9/14 x 9 9/14" (180 x 296 x
245mm) (each x 2); Main Unit: 7 4/5 x 10 5/6 x 13 3/7" (198 x
275 x 341mm)
Supplied Accessories
Power Requirements
Instruction Manual
Remote Commander
®
Remote Control (RM
-
SC3)
Batteries x 2
FM Lead Antenna
UPC Code:
027242683587
