Sony CMT-HX7BT User manual

SON~
3-095-51 7-11 (1)
Micro HI-FI
Component System
Operating Instructions
Owner's Record
The model and serial numbers are located on the rear of the unit. Record
these numbers in the space provided below. Refer to
them whenever you call
upon your Sony dealer regarding this product.
Model No. Serial No.
------
[Q]o§@ s-maSTer
DIGITAL AUDIO Dig ita I Amp I i fie r
o Bluetooth
T
•
CMT-HX7BT
©2007 Sony Corporation
SIRlusiI
REA 0 Y
((X!\A»))
REA DY

WARNING
To reduce the risk of fire or
electric shock, do not expose
this apparatus
to rain or
moisture.
Note to CATV system installer:
This reminder is provided to call the
CATV system installer's attention to
Article 820-40
of the NEC that provides
guidelines for proper grounding and, in
particular, specifies that the cable ground
shall be connected to the grounding
system
of the building, as close to the point
of cable entry as practical.
CAUTION
The use ofoptical instruments with this
product will increase eye hazard.
Notice for the customers in the
U.S.A.
The following
FCC statement applies
only
to the version of this model
manufactured for sale in
the U.S.A.
Other versions may not comply with
FCC technical regulations.
NO USER-SERVICEABLE PARTS INSIDE.
WARNING
This equipment has been tested and found
to comply with the limits for aClass B
digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in aresidential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, ifnot installed and used
in accordance with the instructions,
may cause harmful interference to
radio communications. However, there
is no guarantee that interference will
not occur in aparticular installation.
If this equipment does cause harmful
interference to radio or television
reception, which can be determined
by turning the equipment offand on,
the user
is encouraged to try to correct
the interference by one
or more of the
following measures:
-Reorient
or relocate the receiving
antenna.
-Increase the separation between the
equipment and receiver.
-Connect the equipment into an outlet
on acircuit different from that to which
the receiver
is connected.
-Consult the dealer
or an experienced
radio/TV technician for help.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
This symbol is intended
to alert the user to the
presence
of uninsulated
"dangerous voltage"
within the product's
enclosure that may be
of
sufficient magnitude to
constitute arisk
of electric
shock to persons.
This symbol
is intended
to alert the user to the
presence
of important
operating and
maintenance (servicing)
instructions in the
literature accompanying
the appliance.
DO NOT REMOVE COVER (OR BACK).
REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.

CAUTION
You are cautioned that any changes or
modifications not expressly approved in
this manual could void your authority to
operate this equipment.
This equipment must not be co-located or
operated in conjunction with any other
antenna or transmitter.
This equipment complies with FCC
radiation exposure limits set forth for
uncontrolled equipment and meets the
FCC radio frequency (RF) Exposure
Guidelines in Supplement Cto OET65.
This equipment has avery low
RF energy
level that
is deemed to comply with
FCC radio frequency (RF) Exposure
Guidelines in Supplement Cto OET65
without maximum permissive exposure
evaluation (MPE). But it
is desirable that
it should be installed and operated with at
least 20cm and more between the radiator
and person's body (excluding extremities:
hands, wrists, feet and legs).
Note on DualDiscs
ADualDisc is atwo sided disc product
which mates DVD recorded material on
one side with digital audio material on
the other side. However, since the audio
material side does not conform to the
Compact Disc (CD) standard, playback on
this product
is not guaranteed.
Music discs encoded with copyright
protection technologies
This product is designed to playback
discs that conform to the Compact Disc
(CD) standard. Recently, various music
discs encoded with copyright protection
technologies are marketed by some record
companies. Please be aware that among
those discs, there are some that do not
conform to the CD standard and may not
be playable by this product.
•The Bluetooth word
mark and logos
are owned by the Bluetooth SIG, Inc.
and any use of such marks by Sony
Corporation
is under license. Other
trademarks and trade names are those
of their respective owners.
•MPEG Layer-3 audio coding
technology
and patents licensed from
Fraunhofer lIS
and Thomson.
•The XM
name and related logos are
registered trademarks
of XM Satellite
Radio Inc.
•(c) 2006 SIRIUS Satellite Radio Inc.
"SIRIUS"
and the SIRIUS dog logo
are registered trademarks of SIRIUS
Satellite Radio Inc.
• ™ and ®marks are omitted in this
manual.

Table of Contents
Guide to parts and controls 5
Information on
the display 9
Hooking
up the system
securely
10
Setting the clock 13
Playing aCD/MP3 disc 14
Listening
to the radio 15
Using the Bluetooth function 18
Using optional audio
components 24
Adjusting
the sound 24
Changing
the display 25
Creating your own program
(Program
Play) 26
Presetting radio stations
27
Using the Timers 28
Troubleshooting 29
Messages
32
Precautions 33
Specifications 35
Bluetooth wireless technology 36
Playable Bluetooth devices 38

This manual mainly explains operations using the remote) but the same operations can
also be performed using the buttons on the unit having the same or similar names.
15 16 17 11 12
•
10
Top panel
Unit (HCD-HX7/Compact Disc Receiver)
Front panel
1 2
Guide to parts and controls
Continued~

rnJ
Unit: ~ (open/close) button
(page 14)
Remote: OPEN/CLOSE
~ button
(page 14)
Press to open or close the disc tray.
[I]
AUDIO IN jack (page 24)
Connect to an optional audio
component.
rnJ
PHONES jack
Connect the headphones.
[ID
Unit:VOLUME control (page 14,
15, 16, 20, 23, 24)
Remote:VOLUME
+/- button
(page 14, 15, 16, 20, 23, 24)
Turn or press to adjust the volume.
[ID
BLUETOOTH OPR button (page
20, 22, 23)
Press to make aconnection,
disconnection, or pairing with a
Bluetooth device.
~
BLUETOOTH indicator (page 22,
23)
Lights up when the Bluetooth function
is active.
[i]
Remote sensor (page 29)
,-----.....--119
........ -[j]]
............. ~[gQ]
......... _[j]
ff2l
~~--+-- ...
~- .........
~-+--ilioe
~~===;.===...
[2J
STANDBY indicator (page 25, 29)
Lights up when the system is turned off.
W
1/(9 (power) button (page 13, 28,
31 )
Press to turn on the system.
Remote (RM-SCR32)

[1Q]
Playback buttons and function
buttons
Unit: BLUETOOTH ~II (play/
pause)
button (page 19, 20)
Press to select the Bluetooth function.
Press to start
or pause playback of the
music
on the Bluetooth device (Bluetooth
mobile phone, etc.).
Unit: CD ~II (play/pause)
button (page 14)
Press to select the CD function.
Press to start
or pause playback of adisc.
Remote: CD button (page 14)
Press to select the CD function.
Remote: ~ (play) button,
II (pause) button
Press to start or pause playback.
TUNER/BAND button (page 15,
16)
Press to select the TUNER function.
Press to switch among FM, AM, XM
and
SIRIUS band.
AUDIO IN button (page 24)
Press to select the AUDIO IN function.
FUNCTION button (page 22, 23)
Press to select the function.
[1]
Unit: ./CANCEL (stop/cancel)
button (page 14, 15, 19, 20, 22)
Remote: •(stop)
button (page
14, 15, 19, 20, 22)
Press to stop playback.
Press to cancel search.
[12]
SEARCH button (page 14)
Press to enter or exit search mode.
~
ENTER button (page 13, 16, 26,
27, 28)
Press to enter the settings.
Ml
~ /~ (go back/go forward)
button (page 14, 20, 26)
Press to select atrack or file.
Unit:TUNE +/- (tuning) button
(page 15, 16)
Remote: +/- (tuning) button
(page 15, 16, 27)
Press to tune in the desired station.
o +/ -(select folder) button
(page 14, 26)
Press to select afolder.
Unit: CAT +/- (category) button
(page 16)
Remote: CATEGORY +/ - button
(page 16)
Press to select asatellite radio category.
..../~ (rewind/fast forward)
button (page 14, 20)
Press to find apoint in atrack or file.
[1§]
PLAY MODE/TUNING MODE
button (page 14, 15, 16, 26, 27)
Press to select the play mode of aCD or
MP3 disc.
Press to select the tuning mode.
[§]
Sound buttons (page 24)
Unit: DSGX button
Remote: EQ button
Press to select the sound effect.
Continued~

[ZJ
DISPLAY button (page 20, 25)
Press to change the information on the
display.
[j]]
Satellite radio buttons
XM button (page 16)
Press to select XM band.
SIRIUS button (page 16)
Press to select SIRIUS band.
~
TUNER MEMORY button (page
27)
Press to preset the radio station.
[2Q]
FM MODE button (page 15)
Press to select the FM reception mode
(monaural or stereo).
[2]
CLOCKITIMER SELECT button
(page 28)
CLOCKITIMER SET button (page
13, 28)
Press to set the clock and the Play Timer.
~
Battery compartment lid
(page 11)
~
SLEEP button (page 28)
Press to set the Sleep Timer.
~
REPEAT button (page 14)
Press to listen to adisc, asingle track or
file repeatedly.
[2§]
CLEAR button (page 17, 20, 22,
26)
Press to delete a pre-programmed track
or file.
Press to delete aSIRIUS Parental Lock
password entry.
Press
to erase the pairing registration
information of the Bluetooth device.
~
Number buttons (page 14, 16, 19)
Press to select atrack, file or satellite
channel.
Press to
enter aSIRIUS Parental Lock
password.
Press to
enter aBluetooth passcode.

Information on the display
[Z]
Timer (page 28)
[§]
Audio format
[ID
Play mode (page 14)
.~ ~
clJ ~ ~ ~
@]
Text information
~
Tuner reception mode (page 15)
Tuner reception (page 15)
[2J
DSGX (page 24)
[I]
Play/Pause

Hooking up the system securely
... _-
Left speaker
® SiriusConnect Home tuner (not supplied)
@ Satellite Radio Home Antenna (not supplied)*
© AC power adaptor (not supplied)*
@ DIN cable (not supplied)*
® XM Mini-Tuner and Home Dock (not supplied)
® FM lead antenna (Extend it horizontally.)
@ White side for North American model
® Brown side for other regions
CD AM loop antenna
*Supplied with SiriusConnect Home tuner
mSpeakers
G]Power
Connect the power cord to awall socket.
If the plug does not fit the wall socket,
detach the supplied plug adaptor (only
for models equipped with an adaptor).
[i FMlAM antennas
Find alocation and an orientation that
provide good reception, and then set up
the antenna.
Keep the antennas away from the speaker
cords and the power cord to avoid
picking up noise.

DlXMantenna
Connect the XM Mini-Tuner and Home
Dock. For details, see "To receive the
XM
Satellite Radio" (page 12).
Ii SIRIUS Tuner
Connect the SiriusConnect Home tuner.
When you use the SiriusConnect Home
tuner with this system, be sure to connect
the
AC power adaptor supplied with the
tuner to awall socket. For details, see
"To receive the SIRIUS Satellite Radio"
(page 12).
Keep the SiriusConnect Home tuner,
antenna, and
AC power adaptor away
from the speaker cords and the power
cord to avoid picking up noise.
When carrying this system
1Remove adisc to protect the CD
mechanism.
2 Press CD [Q) to select the CD
function.
3Hold down SEARCH [12] on the unit,
and press
1/6 [] on the unit until
IISTANDBY" appears.
4 After IILOCK" appears, unplug the
power cord.
Speaker pads
Attach the supplied speaker pads to
the bottom
of the speakers to prevent
slipping.
To use the remote
Slide and remove the battery
compartment lid
l22l, and insert the two
supplied R6 (size AA) batteries,
CD side
first, matching the polarities shown
below.
Notes
•With normal use, the batteries should last for
about six months.
•
Do not mix an old battery with anew one or
mix different types of batteries.
•
If you do not use the remote for along period
of time, remove the batteries to avoid damage
from batteryleakage
and corrosion.
Continued~

To receive the XM Satellite Radio
ABOUT XM SATELLITE RADIO
XM offers over 170 digital radio channels: the
most commercial-free music channels, premier
news, sports, talk,
and traffic and weather in
21 metro markets. XM's on-air hosts broadcast
live from studios in Washington, D.C., New
York City
and Nashville.
For more information
or to subscribe in the
US, visit xmradio.com or call Listener Care at
1-800-XMRADIO (1-800-967-2346).
XM READY@) LEGAL
XM monthly service subscription sold
separately. XM Mini-Tuner
and Home Dock
required (each sold separately) to receive
XM service. Installation costs
and other fees
and taxes, including aone-time activation
fee may apply. Subscription fee is consumer
only. All fees and programming subject to
change. Channels with frequent explicit
language are indicated with an
XL. Channel
blocking
is available for XM radio receivers by
calling 1-800-XMRADIO (1-800-967-2346).
For afull listing
of the XM commercial-free
channels
and advertising supported channels,
visit lineup.xmradio.com. Subscriptions
subject to Customer Agreement available at
xmradio.com. XM service only available in
the 48 contiguous United States. XM Satellite
Radio
and XM Ready are trademarks of XM
Satellite Radio Inc. (C)2006 XM Satellite Radio
Inc. All rights reserved.
XM READY@) SUBSCRIPTIONS
Once you have installed the XM Mini-Tuner
Dock inserted the XM Mini-Tuner, connected
, ®
the XM Dock to your XM Ready home audio
system, and installed the antenna, you are
ready to subscribe
and begin receiving XM
programming. There are three places to find
your eight character XM Radio ID: on the XM
Mini-Tuner,
on the XM Mini-Tuner package,
and on XM Channel o. Record the Radio ID in
the following eight squares for reference.
DDDDDDDD
Note: The XM Radio ID does not use the
letters "I':
"0': cCS" or cCF". Activate your XM
Satellite Radio service in the
U.S. online at
http://activate.xmradio.com
or call1-800-XM-
RADIO (1-800-967-2346). You will need a
major credit card. XM will send asignal from
the satellites to activate the full channel lineup.
Activation normally takes
10 to 15 minutes,
but during peak busy periods you may need to
keep your XM Ready home audio system
on
for up to an hour. When you can access the full
channel lineup
on your XM Ready home audio
system you are done.
To receive the SIRIUS Satellite Radio
SIRIUS Satellite Radio: The Best Radio
On Radio
SIRIUS brings all your favorite entertainment
including 100% commercial-free music, plus
superior sports coverage, uncensored talk
and
comedy, world-class entertainment, news,
weather
and more for your car, home or office.
Sirius is available in the
US for subscribers
with addresses in the continental US and is
available in Canada for subscribers with a
Canadian address. Required subscription
plus compatible SiriusConnect Home Tuner
with antenna are required
and sold separately.
SIRIUS Programming is subject to change.
Visit sirius.com
or siriuscanada.ca for the most
complete
and up-to-date channel lineup and
product information. "SIRIUS" and the SIRIUS
dog logo
and related marks are trademarks of
Sirius Satellite Radio Inc. All rights reserved.
To Subscribe to SIRIUS Satellite Radio
Purchase and connect aSiriusConnect Home
Tuner to your Sirius Ready home audio system.
You are then ready to activate and subscribe to
Sirius by either calling 1.888.539.SIRIUS (7474)
or log on to sirius.com. It is that easy.

Setting the clock
Use buttons on the remote to set the
clock.
1Press l/c9W to turn on the
system.
2Press CLOCK/TIMER SET !21l.
If the current mode appears on
the display, press ~ /~ [H]
repeatedly to select "CLOCK SET?"
and then press ENTER ~.
3Press ..... /~ 1M] repeatedly
to set the hour, and then press
ENTER ~.
4Use the same procedure to set
the minutes.
The clock settings are lost when you
disconnect the power cord
or if a
power failure occurs.
To display the clock when the system
is off
Press DISPLAY ffZl. The clock is displayed
for about 8seconds.

To Press
Other operation
~/~ lHl (or the
number buttons [2§],
then press ENTER ~).
II [j].
E:J +/-lHl.
Select afolder SEARCH [2]. Press
and file on ~ /~ lHl to select
an MP3 disc the desired folder, then
while viewing press ENTER ~. Press
the folder and ~ /~ lHl to select
file names on the desired file, then
the display press ENTER~.
Select atrack
or file
Pause playback II (or CD ~II on the
unit)
11m. To resume
play, press the button
again.
Select afolder
on anMP3
disc
Stop playback
Playing a (D/MP3 disc
1 Select the CD function.
Press CD 11m.
2Place adisc.
Press OPEN/CLOSE ~ rID, and place
adisc with the label side up on the
disc tray.
To close the disc tray, press OPEN/
CLOSE
~ rID again.
Do
not force the disc tray closed with
your finger,
as this may damage the
unit.
3Start playback.
Press ~ (or CD ~II on the unit)
11m.
4Adjust the volume.
Press VOLUME +/- (or turn the
VOLUME control
on the unit) [§J.
Find apoint in Hold down ~/~
atrack or file lHl during playback, and
release the button at the
desired point.
Select Repeat REPEAT
~ repeatedly
Play until
"REP)) or "REPl))
appears.
To change the play mode
Press PLAY MODE [§ repeatedly while
the player
is stopped. You can select
normal play
(" = *)) for all MP3 files
in the folder
on the disc), shuffle play
("SHUF))
or ,,= SHUF*))), or program
play «(PGM))).
* When playing aCD-DA disc, (SHUF)
Play performs
the same operation as normal
(shuffle) play.
Notes on Repeat Play
•All tracks or files on adisc are played
repeatedly up to five times.
•"REP
1» indicates that asingle track or file is
repeated until you stop it.

Listening to the radio
1Select"FM" or "AM:'
Press TUNER/BAND [1Q] repeatedly.
2Select the tuning mode.
Press TUNING MODE ~ repeatedly
until
'~UTO" appears.
3Tune in the desired station.
Press +/- (or TUNE +/- on
the unit)
Ml. Scanning stops
automatically when astation
is tuned
in, and then "TUNED"
and "ST" (for
stereo programs only) appear.
AUTO
ST
i·:·i i···i ..:: .
: :: : .1 •••
..... .... :
;:::; ( :: .. ..:
TUNED
Notes on playing MP3 discs
•Do not save other types of files or
unnecessary folders on adisc that has MP3
files.
•Folders that have no MP3 files are skipped.
•MP3 files are played back in the order that
they are recorded onto the disc.
•The system can only play MP3 files that have
a
file extension of ".MP3':
•Ifthere are files
on the disc that have the
".MP3"
file extension, but that are not MP3
files, the unit may produce noise or may
malfunction.
•The maximum number
of:
-folders is 255 (including the root folder).
-MP3 files
is 511.
-MP3 files
and folders that can be
contained
on asingle disc is 512.
-folder levels (the tree structure
of files) is
8.
•Compatibility with all MP3 encoding/writing
software, recording device,
and recording
media cannot be guaranteed. Incompatible
MP3 discs may produce noise
or interrupted
audio or may not play at all.
Notes on playing multisession discs
•Ifthe disc begins with aCD-DA (or MP3)
session, it
is recognized as aCD-DA (or
MP3) disc, and other sessions are not played
back.
• A disc with amixed CD format is recognized
as aCD-DA (audio) disc.
4Adjust the volume.
Press VOLUME +/ -(or turn the
VOLUME control
on the unit) [ID.
To stop automatic scanning
Press II [1].
To tune in a station with a weak signal
If "TUNED" does not appear and the
scanning20es not stop, press TUNING
MODE
~ repeatedly until "AUTO" and
"PRESET" disappear,
and then press
+/- (or TUNE +/- on the unit) Ml
repeatedly to tune in the desired station.
To reduce static noise on a weak FM
stereo station
Press FM MODE I2Q] repeatedly until
"MONO" appears to
turn offstereo
reception.
Continued~

You can operate and listen to XM or
SIRIUS satellite radio by connecting an
optional antenna or tuner. Before using
the system, connect the XM Mini-Tuner
and Home Dock or the SiriusConnect
Home
tuner to the system. See "Hooking
up the system securely" (page 10) for
details about connection.
1Select "XM" or "SIRIUS:'
Press XM or SIRIUS Ml (or TUNER/
BAND
[j]] repeatedly).
2Select the All Channel mode.
Press TUNING MODE [1§] repeatedly
until "CAT"
and "PRESET" disappear.
3Tune in the desired channel.
Press +/- (or TUNE +/- on the
unit)
[HJ repeatedly.
4 Adjust the volume.
Press VOLUME +/- (or turn the
VOLUME control
on the unit) [ID.
To select a channel by Category mode
1 Press XM or SIRIUS Ml (or TUNER/
BAND [j]] repeatedly).
2 Press TUNING MODE [1§] repeatedly
until"CAT"appears.
3 Press CATEGORY +/- (or CAT +/- on
the unit)
[HJ repeatedly.
4 Press +/- (or TUNE +/- on the unit)
[HJ repeatedly.
To select a channel using the number
buttons
Enter the 3digits of the desired channel
using the
number buttons [2§1, then press
ENTER~.
To check your XM Radio ID or SIRIUS ID
number
Press the number button 0 [2§1, then press
ENTER ~ to select channel o.
Notes
•Ifyou select achannel using the number
buttons [2§] in Category mode, the tuning
mode changes automatically to All Channel
mode.
•
You cannot select aSIRIUS channel using
+/- (or TUNE +/- on the unit) [H] if the
Parental Lock
is set for the channel.
...........
Ill ...
....
.:
--
_ ... '
...
I" .... ~ ..
.-
_.~.~
-- ._
II
: ~I
~"
!~
.
.. ,.
-Parental Lock
You can restrict access to certain
channels using your own password. The
password
is set to "0000" as the default.
Change the password before you use
this function for the first time (see "To
change the password").
1Select IISIRIUS:'
Press SIRIUS Ml (or TUNER/BAND
[j]] repeatedly).
2Tune in the desired channel (see
"Listening
to satellite radio").
3 Press TUNER MEMORY ~
repeatedly until "Lock?"appears,
then press ENTER [j]].
"Enter Code" appears.
4Enter your 4-digit password
using
the number buttons [g§].
"Complete!" appears and the Parental
Lock
is set.

To delete the numbers you have
entered
Press CLEAR I2§) repeatedly.
To change the password
1 Press SIRIUS [j]] (orTUNER/BAND [IQ]
repeatedly) to select IISIRIUS:'
2 Press TUNER MEMORY ~ repeatedly
untilllEdit Code?"appears, then press
ENTER Ml.
"OLD Code" appears.
3Enter your current 4-digit password
using
the number buttons 12§].
"NEW Code" appears.
4Enter a new 4-digit password using
the number buttons 12§].
5 To confirm your new password, re-
enter it using the number buttons
12§].
"Complete!" appears and the new
password
is set.
To listen to the locked channels
1 Press SIRIUS [j]] (orTUNER/BAND [IQ]
repeatedly) to select IISIRIUS:'
2Select alocked channel you want to
listen to using the number buttons
12§].
"Enter Code" appears.
3Enter your 4-digit password using
the number buttons 12§].
The channel is tuned in.
To remove the Parental Lock
1When the locked channel is tuned in,
press
TUNER MEMORY ~ repeatedly
untiIIlUnlock?"appears.
2 Press ENTER Ml.
"Complete!" appears and the channel
is unlocked.
Notes
• When you select achannel using +/- (or
TUNE +/ - on the unit) [H] in All Channel
mode or Category mode, locked channels are
skipped.
•The display will
return to the original
indication if you press II [j] or if no entry is
made for aset period of time after you have
been
prompted to enter the password.
•
When the system is reset to the factory
settings, the Parental Lock password returns
to the default ("0000"),
but Parental Lock
settings are
not removed.
•
You cannot preset locked channels.
•
If you set the Parental Lock for apreset
channel,
the preset information for that
channel returns to the default.
•
You cannot set the Parental Lock for channels
a or 184.

Using the Bluetooth
function
This system supports Bluetooth A2DP
and AVRCP profiles. For details
on
Bluetooth wireless technology, see
"Bluetooth wireless technology" (page
36).
Check the websites below for the latest
information about compatible devices.
For customers in the
U.S.A.:
<http://www.sony.com/shelfsupport>
For customers in Canada:
English <http://www.sony.ca/
ElectronicsSupport/>
French <http://fr.sony.ca/
ElectronicsSupport/>
For customers in Europe:
<http://sonydigital-Iink.com/dna>
For customers in Latin America:
<http://www.sony-Iatin.com/pa/info>
For customers in Asia
and Oceania:
<http://www.css.ap.sony.com/>
Li~~'~;~9~.,~p~~~p!:a
BI~~tqp~ltmp~;t'.Dhqri'~'
B·.llIltoot.fI •••. ·.·dev·itl
You can listen to music from your
Bluetooth mobile phone
or Bluetooth
device over awireless connection.
Follow the procedure below to listen to
music from Bluetooth devices with this
system.
Pairing this system with aBluetooth
device !
Connecting to registered devices
!
Playing music of aBluetooth device
For details about the operations
of
the Bluetooth device, also refer to the
operation manual supplied with your
Bluetooth device.

Pairing this system with a Bluetooth
device
Pairing is an operation where Bluetooth
devices register with each other
beforehand. Use the procedure below
to pair the system with your Bluetooth
device. Once apairing operation
is
performed, it does not need to be
performed again.
If pairing is already
completed, proceed to "Playing music
of
aBluetooth device" (page 20).
1 Place the Bluetooth device to be
connected
to this system within
1meter of the system.
2Select the Bluetooth function.
Press BLUETOOTH ~II l1Q] on
the unit.
3Operate the Bluetooth device
and perform the pairing
operation.
For details about the operations of
the Bluetooth device, refer to the
operation manual supplied with your
Bluetooth device.
When searching for this system with
the Bluetooth device, alist
of the
devices found may appear in the
Bluetooth device display depending
on the type of Bluetooth device.
This system appears
as "CMT-
HX7BT:'
When establishing aconnection with
this system, select the audio profile
(A2DP, AVRCP) at the Bluetooth
device.
If the Bluetooth device does
not support the AVRCP profile, you
cannot perform playback
or other
operations with the system (page 20).
4Enter the passcode.
Passcode entry may be required
depending on the type
of Bluetooth
device.
When "PIN?" and acountdown
appear, enter the passcode at the
system
as follows:
.... : :" .. :
.:::. :::=
Press the number buttons I2§] (or 0
+/ - and ~ /~ M] on the unit)
to enter the same passcode that was
entered at the Bluetooth device, and
then press
ENTER~.
Once pairing is completed and the
connection
is established, the system
display changes
as follows:
"Connect"
---+ Name of the Bluetooth
device
To cancel passcode entry partway
Press II [IT].
Notes
•"Passcode" may be called "Passkey:' "PIN
code:' "PIN number"
or "Password:' etc.
depending on the device.
•This system only supports numerical
passcodes up to 4digits.
•The pairing standby status
of the system is
cancelled after about 30 seconds. If pairing is
not successful, redo the procedure from step
1.
•While connected to aBluetooth device, this
system cannot be detected and aconnection
cannot be established from another
Bluetooth device.

Other operation
4Adjust the volume.
Press VOLUME +/- (or turn the
VOLUME control
on the unit) lm.
Note
These operations may not be available for
certain Bluetooth devices. In addition, the
actual operations may differ depending
on the
connected Bluetooth device.
II (or BLUETOOTH
~II on the unit) nm.
II [1].
Hold down ~/~
Ml.
Press
Find apoint in
a
file
Pause playback
Select a
file
Stop playback
To
To cancel the connection with a
Bluetooth device
Press and hold BLUETOOTH OPR [ID
on the unit for about 2seconds until
((Disconnect" appears,
or until the
information
on the display (device name,
etc.) disappears.
To check the address of a connected
Bluetooth device
Press DISPLAY [11] while the Bluetooth
device name appears in the system
display.
The Bluetooth device address appears for
8seconds.
3Start playback.
Press ~ (or BLUETOOTH ~II on
the unit) nm.
Depending on the Bluetooth device,
you may need to start up the
AV
software of the Bluetooth device
beforehand.
Playing music of a Bluetooth device
You can operate aBluetooth device by
connecting the system and aBluetooth
device using
AVRCP. If the system is not
connected with aBluetooth device using
AVRCP, ((Not in Use" appears when you
operate the system.
1Select the Bluetooth function.
Press BLUETOOTH ~II nm on
the unit.
2Establish aconnection from the
Bluetooth device.
For details about the operations of
the Bluetooth device, refer to the
operation manual supplied with your
Bluetooth device.
Once the connection
is established,
the system display changes as follows:
((Connect"
---+ Name of the Bluetooth
device
Note
In order to connect with aBluetooth device
after performing this operation, you must enter
the passcode again.
To erase all the pairing registration
information
1Press BLUETOOTH ~II nm on the
unit.
When the system is connected with a
Bluetooth device (when the Bluetooth
device name
or other information
appears in the system display),]?,ress
and hold BLUETOOTH OPR
LQJ on
the unit for about 2seconds to put the
system in Bluetooth standby mode.
2Press CLEAR ~.
((Delete?" appears.
3Press ENTER ~.
((Complete!" appears and all the
pairing information
is erased.
