SERVICE MANUAL
Sony Corporation
Audio Business Group
Published by Sony Techno Create Corporation
HCD-GZR7D/GZR8D/
GZR9D
DVD DECK RECEIVER
9-889-156-01
2008E04-1
© 2008.05
E Model
HCD-GZR7D/GZR8D/GZR9D
Australian Model
HCD-GZR9D
Ver. 1.0 2008.05
• HCD-GZR7D/GZR8D/GZR9D are the
tuner, deck, DVD and amplifier section
in MHC-GZR7D/GZR8D/GZR9D. Photo: HCD-GZR8D
DVD
Section
Model Name Using Similar Mechanism HCD-GNZ777D/GNZ888D
DVD Mechanism Type CDM74HF-DVBU101//C
Optical Pick-up Name KHM-313CAB/C2RP
Tape Deck
Section Model Name Using Similar Machanism HCD-GNZ777D/GNZ888D
SPECIFICATIONS
Amplifier Section
The following measured at AC 120, 220, 240 V, 50/60 Hz
MHC-GZR9D
Power output (rated): 100 W + 100 W (6 Ωat 1 kHz, 1% THD)
RMS output power (reference)
Front speaker: 180 W + 180 W (per channel at 6 Ω, 1 kHz,
10% THD)
Center speaker: 60 W (6 Ωat 1 kHz, 10% THD)
Surround speaker: 60 W + 60 W (per channel at 6 Ω, 1 kHz,
10% THD)
Subwoofer: 180 W (6 Ωat 80 Hz, 10% THD)
MHC-GZR8D
Power output (rated): 100 W + 100 W (6 Ωat 1 kHz, 1% THD)
RMS output power (reference)
Front speaker: 180 W + 180 W (per channel at 6 Ω, 1 kHz,
10% THD)
Center speaker: 60 W (6 Ωat 1 kHz, 10% THD)
Surround speaker: 60 W + 60 W (per channel at 6 Ω, 1 kHz,
10% THD)
MHC-GZR7D
Power output (rated): 100 W + 100 W (6 Ωat 1 kHz, 1% THD)
RMS output power (reference):
180 W+ 180 W (per channel at 6 Ω, 1 kHz,
10% THD)
Inputs
VIDEO/SAT VIDEO IN (phono jack):
1 Vp-p, 75 ohms
VIDEO/SATAUDIO IN L/R (phono jacks):
voltage 250/450 mV, impedance 47 kilohms
MIC 1/MIC 2 (phone jacks):
sensitivity 1 mV, impedance 10 kilohms
– Continued on next page –
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
http://www.xiaoyu163.com
http://www.xiaoyu163.com

HCD-GZR7D/GZR8D/GZR9D
2
SAFETY-RELATED COMPONET WARNING!
COMPONENTS IDENTIFIED BY MARK 0OR DOTTED LINE
WITH MARK 0ON THE SCHEMATIC DIAGRAMS AND IN
THE PARTS LIST ARE CRITICAL TO SAFE OPERATION.
REPLACE THESE COMPONENTS WITH SONY PARTS
WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS
MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY.
Outputs
VIDEO OUT (phono jack):
max. output level 1 Vp-p, unbalanced, Sync
negative, load impedance 75 ohms
S VIDEO OUT (4-pin/mini-DIN jack):
Y: 1 Vp-p, unbalanced, Sync negative,
C: 0.286 Vp-p, load impedance 75 ohms
COMPONENT VIDEO OUT:
Y: 1 Vp-p, 75 ohms
PB/CB: 0.7 Vp-p, 75 ohms
P
R/CR: 0.7 Vp-p, 75 ohms
DVD DIGITAL OUT (MHC-GZR7D only)
(Square optical connector jack, rear panel):
Wavelength 660 nm
PHONES (stereo mini jack):
accepts headphones of 8 ohms or more
SUBWOOFER OUT (MHC-GZR8D/GZR7D only):
Voltage 1 V, impedance 1 kilohms
FRONT SPEAKER:
MHC-GZR9D: Use only the supplied speaker SS-GZR9D.
MHC-GZR8D/GZR7D:
Use only the supplied speaker SS-GZR8D.
SURROUND SPEAKER (MHC-GZR9D/GZR8D only):
Use only the supplied speaker SS-RSX9D.
CENTER SPEAKER (MHC-GZR9D/GZR8D only):
Use only the supplied speaker SS-CTX9D.
SUBWOOFER (MHC-GZR9D only):
Use only the supplied subwoofer SS-WGV9D.
USB section
Supported bit rate MP3 (MPEG 1 Audio Layer-3): 32 – 320 kbps
WMA: 48 – 192 kbps
AAC: 48 – 320 kbps
Sampling frequencies
MP3 (MPEG 1 Audio Layer-3): 32/44.1/48 kHz
WMA: 44.1 kHz
AAC: 44.1 kHz
(USB) port: Maximum current: 500 mA
Disc player section
System: Compact disc and digital audio and video system
Laser Diode Properties
Emission duration: Continuous Laser Output*:
Less than 44.6μW
*This output is the value measurement at a distance
of 200mm from the objective lens surface on the
Optical Pick-up Block with 7mm aperture.
Frequency response DVD (PCM 48 kHz): 2 Hz – 22 kHz (±1 dB)
CD: 2 Hz – 20 kHz (±0.5 dB)
Video color system format
NTSC and PAL
Tape deck section
Recording system: 4-track 2-channel, stereo
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range: 87.5 – 108.0 MHz (50 kHz step)
Antenna: FM lead antenna
Antenna terminals: 75 Ωunbalanced
Intermediate frequency:
10.7 MHz
AM tuner section
Tuning range:
Australian model: 531 – 1,710 kHz (with 9 kHz tuning interval)
530 – 1,710 kHz (with 10 kHz tuning interval)
Other models: 531 – 1,602 kHz (with 9 kHz tuning interval)
530 – 1,610 kHz (with 10 kHz tuning interval)
Antenna: AM loop antenna
Antenna terminals: External antenna terminal
Intermediate frequency:
450 kHz
General
Power requirements
Australian model: AC 230 – 240 V, 50/60 Hz
Thai model: AC 220 V, 50/60 Hz
Other models: AC 120, 220, 230 – 240 V, 50/60 Hz, adjustable
with voltage selector
Power consumption
MHC-GZR9D: 270 W
MHC-GZR8D: 240 W
MHC-GZR7D: 170 W
Dimensions (w/h/d) (excl. speakers)
MHC-GZR9D: Approx. 280 × 325 × 415 mm
MHC-GZR8D/GZR7D:
Approx. 280 × 325 × 382 mm
Mass (excl. speakers)
MHC-GZR9D: Approx. 12 kg
MHC-GZR8D: Approx. 11.5 kg
MHC-GZR7D: Approx. 10.5 kg
Design and specifications are subject to change without notice.
