Sound Tube SMi Series Configuration guide

Box contents
1 Speaker
1 Terminal weather boot
1 Mounting bracket
1 Safety cable
1 Euroblock connector
1 Tension lever screw
1 Paint mask
Install Instructions For:
SM800i&SM890i-WX
3. To replace horn assembly,
insert horn 1/8 turn from nal
position and rotate clockwise to
tighten. Horn is fully engaged
when horn bae throat is aligned
with speaker.
4. Attach grille by pressing down
gently and rotating the retention
knob clockwise to vertical postion.
2. To release the horn, insert hand
into horn throat and twist horn
assembly counter-clockwise.
1. To rotate the horn, disengage
grille by rotating the retention
knob counter-clockwise to
horizontal position while gently
pushing down on the grille.
The SM890i-WX has a rotatable horn for 85° or 110° positioning.
1.435.647.9555 |800.647.TUBE | www.soundtube.com
Grille
Tensionleverandscrew
Terminal
weatherboot
Euroblock
Mountingbracket
Rotatablehorn(SM890i-WX)
Tapswitch
Mountingclip
Strapmount
location
Grilleretentionknob
Speaker ships in the 110º vertical (85º horizontal) position. To change to
85º vertical (110º horizontal), prior to installation, follow these directions: 110º x 85º 85º x 110º
Signalwire

©2011SoundTube Entertainment,Inc. All rightsreserved. PN INS-SM8 Rev08.17.11
SM890i-WX:UL1480(UEAY)listed
1. Unpack speaker and
mounting hardware.
4. Slip terminal weather boot
over signal wire. For environ-
mental applications, put sealant
around nipple and base when
installation is complete.
2. Choose a secure mounting
surface with sucient strength
to reliably hold the speaker.
Mounting bracket accom-
modates screwing, through-
bolting and strapping
installation options.
The max. strap width is
0.73 in / 18.5 mm.
3. Feed speaker wire through
speaker wire hole before
mounting. Thread safety cable
(included) through mounting
screw and securely fasten
mounting plate to surface
(user must supply fasteners).
Mounting bracket may also
be strap-mounted to pole or
appropriate anchor point.
9. Select the desired setting
on the rear-mounted tap switch.
Use table to right to choose
appropriate tap number based on
system voltage, and desired
power draw.
11. Done!
5. Connect signal wire to
four-pin Euroblock plug. Use
inside positive and negative
inputs for either voice coil or
distributed systems. For daisy
chaining, use outside positive
and negative terminals. Tighten
unused terminal screws.
7. Slide speaker into wall mount
plate until it locks into place.
6. Insert four-pin Euroblock jack
on rear of speaker. Connectors
are keyed for polarity.
10. Aim speaker in desired
direction, close tension lever
and insert tension lever screw.
Install Instructions For:
SM800i &SM890i-WX
1.435.647.9555 |800.647.TUBE | www.soundtube.com
Do not spec or install speaker near support beam, ventilation duct or other
structure that may interfere with speaker function or dispersion.
Warning Warning
SoundTube speakers must be installed by a professional audio installer/contractor. For safety and for optimum
audio performance, installer must follow all directions issued by SoundTube Entertainment.
8. Clip snap link with safety
cable to mounting bracket.
speaker
wire holes
SM800i - Tap Setttings
25v 70v 100v
6 direct direct direct
5 15w 120w X
4 8w 60w 120w
3 4w 30w 60w
2 2w 15w 30w
1 1w 8w 15w
SM890i-WX - Tap Setttings
25v 70v 100v
6 direct direct direct
5 19w 150w X
4 10w 75w 150w
3 5w 38w 75w
2 2.5w 19w 38w
1 1.3w 10w 19w
2
1
3
4
