Soundcore Rave Plus User manual

Soundcore Rave+
USER MANUAL

English 01
Čeština 09
Dansk 17
Deutsch 25
Español 33
Suomi 41
Français 49
Italiano 57
Nederlands 65
Norsk 73
Język polski 81
Portugues do Brasil 89
Pусский 97
Slovenský Jazyk 105
Türkçe 113
日本語 121
한국어 129
简体中文 138
繁體中文 146
ةيِبَ رَعل 154
תי ִ רבִע164

1
1 Charging
1.1 Charging Your Speaker
Use the included AC power cord to charge your speaker.
Battery level <25%
Battery level 25% - 50%
Battery level 51% - 75%
Battery level 76% - 95%
Battery level >95%
● Fully charge this speaker before the first use to prolong the lifespan of the built-in battery.
● Disconnect your speaker from the power supply when fully charged. Do not charge for
extended periods.
1.2 Checking Battery Level
Battery level <15%
Battery level 15% - 25%
Battery level 26% - 50%
Battery level 51% - 75%
Battery level 76% - 100%

2
1.3 Charging Your USB Devices
Charge your mobile device through the Power IQ port on the back of this speaker.
2 Powering On/Off
Press and hold for 2 seconds
Power on
Steady white
Press and hold for 2 seconds
Power off
Light off
● Unplug the power cable from the AC mains outlet when not in use for an extended period of
time.
● This speaker will power off automatically after 30 minutes if there is no audio input.

3
3 Using Your Speaker
3.1 Bluetooth Pairing
With this speaker, you can enjoy music through your Bluetooth-enabled devices.
Press
Enter Bluetooth pairing mode
Flashing blue
Bluetooth pairing
Steady blue
Bluetooth connected
● Each time you power on your Soundcore speaker, it will automatically connect to your last
connected device if available within the Bluetooth range. If not, press the Bluetooth button to
enter Bluetooth pairing mode.
3.2 PartyCast Mode
You can wirelessly connect up to 100 Soundcore Rave+ speakers or Soundcore speakers with
PartyCast functions together.
1. Press and hold the Bluetooth button for 2 seconds on the Soundcore Rave+ that’s currently
connected to your device as the primary speaker.
2. Repeat Step 1 on the other Soundcore Rave+ speakers you want to connect and then press the
Bluetooth button twice to make them secondary speakers in PartyCast pairing.
→ The secondary speakers will automatically connect with the primary speaker.

4
Press and hold for 2 seconds
Enter PartyCast mode
Slowly flashing white (Primary speaker)
PartyCast pairing
Rapidly flashing white (Secondary speaker)
Slowly flashing white (Primary speaker)
PartyCast connected
Steady white (Secondary speakers)
When PartyCast mode is successfully entered:
● You can power off, adjust the volume, or switch light modes for all speakers by controlling the
primary speaker only.
● You can power off or switch light modes for each secondary speaker individually.
● You can't adjust the volume for each secondary speaker individually.
● Any secondary speaker can be switched to become the primary speaker by pressing the
Bluetooth button twice and connecting to your smartphone. Any primary speaker can be
switched to become the secondary speaker by pressing the Bluetooth button twice and
searching for an available primary speaker.
● To exit the PartyCast mode, press and hold the Bluetooth button on any speaker for 2
seconds.

5
3.3 AUX/USB Mode
Plug in an audio cable or insert a USB flash drive, then press the source button to switch between
AUX in mode and USB mode (support FAT32 / MP3 / WMA formats).
Press
Switch source
Press and hold for 2 seconds
Exit AUX/USB mode
Steady green
AUX in mode
Steady white
USB mode
● Audio cable or USB flash drive is not provided.
● When using AUX mode, control audio playback via the connected device.
3.4 Wired Party Mode
You can connect multiple Soundcore Rave+ speakers via RCA cables to form a wired party chain.
Then press the source button to enter the wired party mode.

6
3.5 Button Controls
Press
Play/Pause
Press
Previous track
Press
Next track
Rotate
Adjust volume
Press
Turn BassUp on/off
3.6 Light Effects
Your speaker is equipped with light effects for a party mood.
When powered on, the light effects are automatically turned on. Press the light effect button to switch
among multiple music-sync light effects.
To turn off the light effects, press and hold the light effect button for 2 seconds.

7
Press
Switch light effects / Turn light effects on
Press and hold for 2 seconds
Turn light effects off
You can also check all available specific light effects in the Soundcore app.
3.7 Microphone Connection
For the best performance, use the microphone (not provided) when in the wired party chain mode.
Connect the microphone to the MIC port. You can adjust the microphone volume by rotating the MIC
ECHO volume knob.
4 Soundcore App
Download the Soundcore app to enhance your experience.
● Set up Bluetooth connection
● Check product information
● Update firmware
● Indicate battery status
● Customize button controls
● Switch among multiple light effects
● Light DJ mode to support light and sound variation
● Enjoy party games
● Switch BassUp mode
● Switch EQ modes
● Set Auto-power off time

8
5 Specifications
Specifications are subject to change without notice.
Input
100V-240V AC~, 50/60Hz
Charge out
5 V ⎓2.1 A
Audio output power
160W
Battery capacity
4900 mAh / 7.4 V x 2
Charging time
Appr. 5 hours
Playtime (varies by volume level and music content)
Up to 24 hours
Waterproof level
IPX4
USB audio format
.mp3, .wma
Bluetooth version
V5.0
Bluetooth range
20 m / 66 ft
