Southwire MSP-01 Manual

READ AND UNDERSTAND ALL OF THE
INSTRUCTIONS AND SAFETY INFORMATION IN
THIS MANUAL BEFORE OPERATING OR
SERVICING THIS TOOL
03/17
MSP-01 Manual
OPERATING and MAINTENANCE
INSTRUCTIONS
Manual Stud Punch
(MSP-01)

1
TABLE OF CONTENTS
Important Safety Information.................................................2 - 4
Description of Operation.............................................................5
Identification................................................................................6
Setup and Operation...................................................................7
Maintenance...............................................................................8
Warranty...............................................................................9 - 10
SAFETY FIRST
Safety is essential in the use and maintenance of Southwire
Contractor Equipment. This instruction manual and any markings
on the tool provide information for avoiding hazards and unsafe
practices related to the use of this tool. Observe all of the safety
information provided.
SAFETY ALERT SYMBOLS
These symbols are used to call attention to hazards or unsafe
practices related that could result in injury or property damage.
The three safety words defined below indicate the severity of the
hazard. The message after the signal word provides information
for preventing or avoiding the hazard.
2

DANGER: Electrical Shock Hazards.
• Only qualified persons should use the Manual Stud Punch.
• Wear eye protection, hard hat, cut resistant gloves and safety
toe shoes when using this tool.
• Do not use tool while tired or under the influence of drugs,
alcohol, or medication.
• Keep body parts and loose clothing away from moving parts.
• Always follow safety procedures as shown in this manual.
• This is not an insulated tool, contact with live circuits could
result in severe injury or death.
FAILURE TO OBSERVE THESE WARNINGS COULD
RESULT IN SEVERE INJURY OR DEATH.
WARNING - Personal Safety Hazards
WARNING
• Read and understand all instructions and safety information in
this manual before operating or servicing this tool.
3
IMPORTANT SAFETY INFORMATION
FAILURE TO OBSERVE THESE WARNINGS COULD
RESULT IN SEVERE INJURY OR DEATH.
WARNING: Tool Use Hazards
• Use this tool for the manufacturers intended purpose only.
Use other than that described in this manual can result in injury
or property damage.
• Inspect all aspects of the electrical box to ensure safety.
• Only qualified personnel should use knockout equipment.
• Keep all decals clean and legible, and replace when necessary.
CAUTION:
• Read and understand all of the instructions and safety information
in this manual before operating or servicing this tool.
CAUTION: Make sure bystanders are clear of the work area
when drilling and performing knockouts. Nearby personnel can be
injured if there is flying debris.
• Do not use the if dies are damaged as this can cause binding
leading to tool malfunction.
• If tool is in disrepair,
DO NOT USE.
Have tool serviced at an
Authorized Southwire Repair Center
FAILURE TO OBSERVE THESE CAUTIONS CAN RESULT IN
INJURY OR PROPERTY DAMAGE
FAILURE TO OBSERVE THESE CAUTIONS CAN RESULT IN
INJURY OR PROPERTY DAMAGE
4
IMPORTANT SAFETY INFORMATION
WARNING: Entanglement Hazard
• Do not operate this tool while wearing loose fitting clothing.
Retain long hair.
• Keep hands away from cup and dies while operating punch.
Could pinch or crush hands.
• Do not add extensions (cheaters) to the handles. Using excessive
force may result in injury or damage to the tool. If excessive force
is required, check and verify proper set up instructions.
FAILURE TO OBSERVE THESE WARNINGS CAN RESULT
IN SEVERE INJURY OR DEATH.

5
DESCRIPTION OF OPERATION
This manual is intended to familiarize all personnel with the safe
operation and maintenance procedures for the following Southwire
Tools and Equipment: MANUAL STUD PUNCH.
Keep this manual available to all personnel. Replacement manuals
are available upon request at no charge at www.southwiretools.com.
PURPOSE OF THIS MANUAL
Manual Stud Punch is a tool that will punch holes in 20 structural
steel studs. Punch comes with two punch dies in sizes 7/8”
(22.5mm) and 1-11/32” (34.1mm).
6
IDENTIFICATION
Stud Punch Quanty
Unit of Measure
STOCK NO. Manufacturer Stock # DESCRIPTION
Item Number
1 2 Ea.
64-19-53-01 MSP-01 Fixed Handle Grip
2 2 Ea. 64-19-54-01 MSP-02 End Cap
3 1 Ea.
64-19-55-01 MSP-03 Flexible Handle
4 2 Ea.
64-19-56-01 MSP-04 Pin
5 4 Ea. 64-19-57-01 MSP-05 Axial Spring Collar
6 1 Ea.
64-19-58-01 MSP-06 Guide Sleeve
7 6 Ea. 64-19-59-01 MSP-07 Axial Spring Collar
8 2 Ea.
64-19-60-01 MSP-08 Washer
9 1 Ea.
64-19-61-01 MSP-09 Spring
10 1 Ea.
64-19-62-01 MSP-10 Strut
11 1 Ea.
64-19-63-01 MSP-11 Upper Mold 7/8" Cuer
12 1 Ea.
64-19-64-01 MSP-12 Screw
13 1 Ea.
64-19-65-01 MSP-13 Connecng Rod
14 1 Ea.
64-19-66-01 MSP-14 Connecng Rod Pin
15 1 Ea.
64-19-67-01 MSP-15 Main Body Housing
16 1 Ea.
64-19-68-01 MSP-16 Lower Mold 7/8" Cup
17 2 Ea.
64-19-70-01 MSP-17 Screw
18 1 Ea.
64-19-71-01 MSP-18 Fixed Handle Grip
19 1 Ea.
64-19-72-01 MSP-19 Screw
20 1 Ea.
64-19-73-01 MSP-20 Hanger
21 1 Ea.
64-19-74-01 MSP-21 Upper Mold 1-11/32" Cuer
22 1 Ea.
64-19-75-01 MSP-22 Lower Mold 1-11/32" Cup

87
SET UP AND OPERATION
EXCHANGE PUNCH SIZE
1. Position the Manual Stud Punch on the metal stud. Squeeze the
handles together. The slug will fall free when the hole is complete.
NOTE: IF EXCESSIVE FORCE IS REQUIRED, STOP AND
INSPECT THE TOOL AND THE MATERIAL.
Manual Stud Punch includes two sizes, 7/8” and 1-11/32”.
1. Remove cutter by unscrewing hex bolt using a #5 hex
wrench. (Fig. 1)
2. Remove cup by loosening hex bolt closest to cup located on
C-frame. (Fig. 2)
3. Drop in desired cutter and tighten with hex screw.
4. Slide in cup and tighten hex bolt.
MAINTENANCE
1. Lubricate all moving parts with lightweight oil.
SPECIFICATIONS
• Model# MSP-01
• Stock # 57-57-62-01
• Height –18.5”
• Width – 8.55”
• Depth – 2.25”
• Weight – 7.5lbs
• Capacity – 20-gauge Structural Steel Studs
Fig 1 Fig 2
8
NOTE: CUP AND CUTTER SIZES MUST MATCH; THEY WILL
NOT WORK PROPERLY IF INTERCHANGED.
