Southworth PalletPal 360Air User manual

Owner’s Manual
PalletPalTM 360 Air
Level Loader
Southworth Products Corp
P.O. Box 1380 • Portland, Maine 04104-1380
Phone [phone] • 207-878-0700 Fax [phone]
www.SouthworthProducts.com
[email protected]
Serial # ______________________________________________
Placed in Service ______________________________________
OCTOBER 2017
For products shipped after January 2014

2PALLETPAL 360 AIR
This manual was current at the time of printing.
To obtain the latest, most updated version, please contact Southworth's Customer Service Depart-
ment or go to our website: www.SouthworthProducts.com under
Parts & Service you will nd a complete list of current owner’s manuals to print.

PALLETPAL 360 AIR 3
CONTENTS
INTRODUCTION ........................................................................................Page 4
RESPONSIBILITY OF OWNERS AND USERS ................................................... 5
SAFETY .......................................................................................................... 6
INSTALLATION INSTRUCTIONS ...................................................................... 8
Unpacking the Unit .......................................................................... 8
Setup, Overview and Quick Setup Instructions ................................ 8
Operation notes ................................................................................. 9
Specications................................................................................... 10
OPERATING INSTRUCTIONS .......................................................................... 10
Labels and Precautionary Markings ................................................ 10
Loading Manually ............................................................................ 12
Removing Loads Manually .............................................................. 12
Operating Safely – Manual Use....................................................... 12
Loading with a Fork Lift ................................................................... 13
Unloading with a Fork Lift ................................................................ 13
Moving the PalletPal 360 Air............................................................ 13
MAINTENANCE/TROUBLESHOOTING ............................................................ 14
Safe Servicing of Lift........................................................................ 14
Maintenance .................................................................................... 15
Troubleshooting Check List ............................................................. 15
Ordering Replacement Parts.............................................................................. 17
WARRANTY ....................................................................................................... 18
LIST OF FIGURES
Figure A Actuation System............................................................................... 9
Figure 1 Labels and Precautionary Markings ............................................... 10
Figure 2 Loading Manually ............................................................................ 12
Figure 3 Unloading Manually ........................................................................ 12
Figure 4 Warning - Load and Unload in Even Layers .................................... 12
Figure 5 Loading with a Fork Lift ................................................................... 13
Figure 6 Unloading with a Fork Lift ............................................................... 13
Figure 7 Moving the PalletPal 360 Air ........................................................... 13
Figure 8 Safe Servicing of the Lift.................................................................. 14
Figure 9 Recommended Spare Parts ............................................................ 16

4PALLETPAL 360 AIR
INTRODUCTION
The PalletPal 360 Air Level Loader is a simple device that will automatically main-
tain a load at the ideal height for manual loading and unloading. If a palletized load
is placed on the unit, the unit gradually rises as boxes or parts are removed. This
automatically maintains the top of the load at the correct working height.
The unit may also be used for the reverse application. An empty pallet may be placed
on the PalletPal 360 Air. The unit gradually lowers as boxes or parts are added.
Again, this keeps the top of the load at the correct height. Complete pallets may be
loaded or unloaded using a stacker or fork lift. See page 13.
This manual contains information to help you to learn about the safe and proper
installation, use, and upkeep of your PalletPal 360 Air unit. Please be sure that this
manual is available to anyone who uses or services the unit.
PalletPal 360 Air units may be used in a wide variety of industrial settings. The
instructions in this manual are not necessarily all-inclusive, as Southworth cannot
anticipate all conceivable or unique situations.
In the interest of safety, please read this whole manual carefully.
Be familiar with the contents of this manual before you install or
use the PalletPal 360 Air unit. If you are not sure of the proper
procedure to be followed, please call Southworth Products Corp
for more information.
Southworth’s product warranty is shown on the rear cover of this manual. This
instruction manual is not intended to be or to create any other warranty, express or
implied, including any implied warranty of merchantability or tness for a particular
purpose, all of which are hereby expressly excluded. As set forth more specically
in the product warranty, Southworth’s obligation under that warranty is limited to
the repair or replacement of defective components, which shall be the buyer’s sole
remedy, and Southworth shall not be liable for any loss, injury, or damage to persons
or property, nor for any direct, indirect, or consequential damage of any kind resulting
from the PalletPal 360 Air unit.

PALLETPAL 360 AIR 5
Responsibility of Owners and Users
Inspection and Maintenance
The device shall be inspected and maintained in proper working order in accordance with
Southworth’s owner’s manual.
Removal from Service
Any device not in safe operating condition such as, but not limited to, excessive leakage,
missing rollers, pins, or fasteners, any bent or cracked structural members, cut or frayed
pneumatic lines, damaged or malfunctioning controls or safety devices, etc. shall be
removed from service until it is repaired to the original manufacturer’s standards.
Deection
It is the responsibility of the user/purchaser to advise the manufacturer where deection
may be critical to the application.
Repairs
All repairs shall be made by qualied personnel in conformance with Southworth’s in-
structions.
Operators
Only trained personnel and authorized personnel shall be permitted to operate the lift.
Before Operation
Before using the device, the operator shall have:
• Read and/or had explained, and understood, the manufacturer’s operating instruc-
tions and safety rules.
• Inspected the device for proper operation and condition. Any suspect item shall be
carefully examined and a determination made by a qualied person as to whether
it constitutes a hazard. All items not in conformance with Southworth’s specica-
tion shall be corrected before further use of the equipment.
During Operation
The device shall only be used in accordance with this owner’s manual.
• Do not overload.
• Ensure that all safety devices are operational and in place.
Modications or Alterations
Modications or alterations to any Southworth industrial positioning equipment shall be
made only with written permission from Southworth.

6PALLETPAL 360 AIR
SAFETY ALERT SYMBOLS AND SIGNAL WORDS
The safety of all persons operating, maintaining, repairing, or in the vicinity of this equipment is of paramount concern. This is
a powerful machine with moving parts, and is capable of causing personal injury if proper precautions are not taken. Therefore,
throughout this manual, certain hazards have been identied which may occur in the use of the machine, and there are appropriate
instructions or precautions which should be taken to avoid these hazards. In some cases, there are consequences which
may occur if instructions or precautions are not followed. Below are the symbols and signal words along with their denitions
referenced from ANSI Z535.4 - Product Safety Signs and Labels.
4.11 Safety Alert Symbols: A symbol that indicates a hazard. It is composed of an equilateral triangle surrounding
an exclamation mark. The safety alert symbol is only used on hazard alerting signs. It is not used on safety notice and safety
instructions signs.
4.14 Signal Words: The words used in the signal word panel. The signal words for hazard alerting signs are “DANGER,”
“WARNING,” and “CAUTION.” Safety notice signs use the signal word “NOTICE.” Safety instruction signs use signal words that
are specic to the situation.
DANGER indicates a hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
NOTICE is used to address practices not related to physical injury.
SAFETY INSTRUCTIONS (or equivalent) signs indicate specic safety-
related instructions or procedures.
NOTE: DANGER, WARNING or CAUTION should not be considered for property damage accidents unless personal injury risk
appropriate to these levels is involved.
A): for use with DANGER signal word; (safety white triangle, safety red exclamation mark, safety red background)
B): for use with WARNING signal word; (safety black triangle, safety orange exclamation mark)
C): for use with CAUTION signal word; (safety black triangle, safety yellow exclamation mark)
D) and E): for use with DANGER, WARNING, or CAUTION signal word; (D: is a safety yellow triangle with a
black border and safety black exclamation mark; E: is a safety yellow triangle with a safety black exclamation mark and a
safety yellow border around a safety black band)
NOTE: D and E are provided to allow for consistency with certain ISO standards such as ISO 3864-1 and ISO 3864-2.

PALLETPAL 360 AIR 7
WARNING!
Do not inate the system to more than 30 PSI at the fully
raised position with no load. If the actuation system pres-
sure is higher than 65 PSI under any circumstance it may
cause the failure of the air actuation system thus resulting
in severe injury.
WARNING!
Never try to service or troubleshoot the machine without
carefully reading the maintenance section of this manual
and reviewing "Safe Servicing of the Lift", gure 8 on page
14. Otherwise severe personal injury may result.
Figure 1 (beginning on page 10) shows all the labeling on this unit.
Please be sure that all of the labels are in place, and are visible to the
machine operators. Never paint over the labels. If any of the labels
are missing, please contact Southworth for replacements. Labels
and precautionary markings on the machine help to protect your
workers.

8PALLETPAL 360 AIR
INSTALLATION INSTRUCTIONS
Unpacking the Unit
1. Before you put the unit in service, check for local codes and ordinances that may apply. It is your
responsibility to obtain any necessary permits.
2. Please read all of these instructions carefully. Be sure to read and understand all of the warnings.
3. Inspect the shipping pallet carefully for any damage which may have affected the unit. If you see
signs of damage, notify the shipper immediately. Also make a note of this on the shipping papers that
you are asked to sign.
4. Choose the place where you want to set the unit. It is very important that the PalletPal 360 Air be
located on a level, smooth and at surface. Check the oor surface carefully and make sure that it is
free of all loose debris and dirt.
5. Remove the banding that secures the unit to the pallet. Remove all packing material. Shift the unit
to the oor. Support the base as you do this.
6. Check to see that the base frame of the unit is sitting rmly on the oor. Try to move or rock the
frame of the unit. The base frame should be stable, and should not move. Check to see that the base
frame is level. If any part of the base frame is more than 1/2" out of level in relation to any other part,
reposition to a atter, more level surface area.
7. If you have any questions about the steps in the installation process, please call Southworth Cus-
tomer Service at 1-800-743-1000.
Overview
The PalletPal 360 Air can be setup to position pallet loads ranging from approximately 300 lbs to 4500
lbs (140kg to 2025kg). Once air is inated into unit's air actuation system load capacity can be set. The
gauge must never be more than 30 PSI (2.1 BAR) when the unit has no load on it and is in the fully
raised position. The unit will then lower or rise as the load is being added or removed from the unit,
(see quick setup section below), and thus works as an automatic level loader holding the top layer of
goods at a convenient height.
*NOTE: The actuation system of the PalletPal 360 Air contains captive air much like an automotive
tire and may lose small amounts of air over time. Therefore, air may have to be occasionally added to
the system to compensate for the loss.
Quick Setup
Read and understand entire manual before performing quick setup.
With no load on the unit, pressurize the actuation system with 30 PSI (2.1 BAR) of air via the air ll
valve stem, see Figure A on next page. Using a fork lift or stacker place the heaviest, complete pallet
load on the unit, (maximum weight 4,500 lbs). Slowly open the Manual Air Discharge Valve allowing
air to escape. When the unit is fully lowered, close the Air Discharge Valve. The PalletPal 360 Air is
now set for that pallet load.
As the upper layers on the pallet are removed in even layers the unit will rise. When the pallet is near
empty the unit will be at the top of its travel.
Setting the ideal load height is subjective. Some operators prefer to have the load held slightly higher.
If so increase the air pressure slightly. If the load is being held too high slightly discharge some air. Air
pressure must never exceed 30 PSI when the lift is unloaded or 65 PSI when the lift is loaded.

PALLETPAL 360 AIR 9
OPERATION NOTES
WARNING!
Never sit or ride on the turntable or operate the unit if anyone is on it.
WARNING!
Never operate the unit if the load is off center. The load may shift, and you may be injured.
This can also damage the unit.
WARNING!
Keep the area around the unit clean. Do not allow any dirt, debris, spilled oil, or excess
grease to collect. These materials may cause you to slip while the unit is operating, and
you may be injured.
WARNING!
Stay clear of the turntable when it is moving. As the pallet turns, a part of the load may rotate
around and hit you. Never turn the load when anyone is standing beside the unit.
WARNING!
Do not try to use this unit with damaged or broken pallets. Broken pallets may have boards
or nails which hang down below the main part of the pallet. As the pallet is turned, these
boards or nails may catch on the frame of the unit. This can cause the pallet to stop turning
suddenly, causing the load to shift.
You may be injured, and the unit may be damaged. The boards or nails on the bottom of the
pallet should not extend down more than 1/8 inch.
AIR PRESSURE
GAUGE
AIR PRESSURE
RELIEF VALVE
MANUAL AIR
DISCHARGE VALVE
VALVE STEM
FOR AIR FILL
MANIFOLD
VALVE
Figure A

10 PALLETPAL 360 AIR
Imperial Metric
Load capacity 300 to 4500 lbs. 180kg to 2025kg
Load size 50" x 50" l x 72" high 1270mm x 1270mm x 1800mm high
Base frame 36" x 36" 915mm x 915mm
Compressed height 9-1/2 inches 240mm
Extended height 27-3/4 inches 705mm
Air source 80 PSI 5.5 BAR
Maximum system air pressure 30 PSI without load 2.1 BAR
Maximum system air pressure 65 PSI with full load 4.5 BAR
Safety relief valve setting 125 PSI 8.6 BAR
Rotating ring, outer diameter 43-5/8 inches 1,110mm
Rotating ring, inner diameter 40-5/8 inches 1,030mm
Ship weight 375 lbs 170kg
Operating environment indoor indoor
Operating temperature -0F to +120F -18° to 50° c
Specications
Figure 1.
OPERATING INSTRUCTIONS
Labels and Precautionary Markings
Label Location Drawing - #60041394

PALLETPAL 360 AIR 11
Decal 5900191
Item 2990414
Item 10089457
SOUTHWORTH


THIS DRAWING MUST BE AT REVISION: '-'

Item 10089457


Item 10089458

12 PALLETPAL 360 AIR
OPERATING INSTRUCTIONS (continued)
Loading Manually
Add boxes or parts in even layers until the pallet is full.
The unit will gradually lower the pallet until it reaches
the bottom. See Figure 2.
Removing Loads Manually
Remove boxes or parts in even layers until the pallet
is empty. The unit will gradually raise the pallet. See
Figure 3.
Operating Safely -- Manual Use
1. Never push the load off of the side of the unit. If you
do this, the frame of the unit may jump upward.
Figure 2. Loading Manually Figure 3. Unloading Manually
Figure 4. Warning - Load and Unload in
Even Layers
WARNING!
Ensure that loading and unloading of the PalletPal 360 Air is done in even layers.
Loading or unloading a load on one side may cause the load to tip over and you
may be injured. This can also damage the unit. See Figure 4.
2. Never use the unit when anyone is sitting or riding on the turntable.
3. Do not try to use this unit with damaged or broken pallets. Broken pallets may have boards or nails which hang
down below the main part of the pallet. As the pallet is turned, these boards or nails may catch on the frame.
The pallet may stop turning suddenly and this can cause the load to shift. You may be injured and the unit may
be damaged. If the boards or nails on the bottom of the pallet extend down more than 1/8 inch, they will interfere
with the turning action.
4. Stay clear of the turntable when it is moving. As the pallet turns, a part of the load may rotate around and hit you.
5. Keep the area around the unit clean. Do not allow any dirt, debris, spilled oil, or excess grease to collect. These
materials may cause you to slip while the unit is operating and you may be injured.

PALLETPAL 360 AIR 13
Figure 7. Moving the PalletPal 360 Air
Figure 6. Unloading with a Fork Lift
Loading with a Fork Lift
1. Place the evenly layered load on the unit. Be sure
the load is centered on the turntable, then slowly lower
the fork lift.
• Lower the load until the airbag on the PalletPal 360 Air
is fully compressed.
• Be sure the forks on the lift are clear of the inside of
the pallet and ensure unit is carrying the weight - not the
fork lift, see gure 5.
WARNING!
If you skip these steps, the load may drop suddenly when you remove the fork lift. You
may be hurt or the unit or load may be damaged.
WARNING!
Never drop the load on the turntable. If you do this while the turntable is moving, the load
may shift. You may be injured or the unit may be damaged.
WARNING!
If the load is off-center, it may shift when the turntable is turned. You may be hurt or the
unit or load may be damaged.
Unloading with a Fork Lift
1. Insert the forks into the evenly loaded pallet, and
slowly lift the pallet clear of the top of the unit. See
Figure 6.
• Be sure the pallet clears the top of the turntable
before you move the fork lift.
WARNING!
If you skip these steps, the unit may jump up suddenly when you remove the pallet. You
may be hurt or the unit or load may be damaged.
Moving the PalletPal 360 Air
It can be moved loaded or empty. When moving a
loaded PalletPal 360 AIR be sure to secure the load
(stretch lm or strapping) to avoid spillage.
There are three ways to move it.
1. Use a forklift inserting the forks into the pockets in
the base frame, as shown in Figure 7.
Figure 5. Loading with a Fork Lift

14 PALLETPAL 360 AIR
Safe Servicing of the Lift
The two holes in the base roller tracks, one on
each side (see Choked Position image) are
intended for 3/8 inch diameter pins to be utilized
to chock up the lift whenever maintenance or
under lift troubleshooting is performed. When
chocks not in use place in the Stowed Position,
see image on the right.
Note: Earlier designs may not have had these
pins or the stowed position holes. If your unit
was not supplied with these, use two 3/8 x 3''
long bolts.
Figure 8. Safe servicing of the Lift
2 When equipped with the optional Portability Set
release the oor lock and move the unit. Be sure
to engage the oor lock once the PalletPal 360
AIR is re-located.
3. When equipped with the optional leveling feet
the base frame can be raised approximately 3''
from the oor allowing access for a hand (or pow-
ered) pallet jack to be positioned under the center
of the base frame.
Note that certain Southworth supplied and ap-
proved portability kits installed on the PalletPal
360 Air allow the unit to be rolled around on
smooth level surfaces when loaded.
Stowed Position
Chocked
Position
One pin
on each side
Chocked

PALLETPAL 360 AIR 15
Maintenance
• The lack of maintenance may result in catastrophic failure.
• See Figure 8 on page 14: Safe Servicing of the Lift before performing
maintenance.
Routine Periodic Maintenance
Every 90 days -
• Inspect all rollers, pins and bushings for excessive wear.
> 8 Ball bearings supporting the rotator ring.
> 1 center pin on rotator ring
> 2 main axle pins on the leg set
> 4 rollers with bushings on lower ends of leg
> 4 ball bearing rollers on upper ends of legs
> 8 connection points on leg set centering linkages
• Inspect rotating ring, some units have a solid disk rotating platform
• Check for loose hardware and signs of excessive wear.
• Check to be sure that the unit is placed on a rm level surface.
• Ensure labels and precautionary markings are in place and legible.
• Inspect all components of the air actuation system, note the actuation system of the PalletPal
360 Air contains captive air much like an automotive tire and will lose small amounts of air over
time. Therefore, air may have to be occasionally added to the system to compensate for the loss.
Troubleshooting
Troubleshooting Check List
P roblem Possible Cause Check This
The unit lowers too easily (too early) Not enough air pressure See set-up procedure page 8
The unit does not lower
enough (too late) Too much air pressure See set-up procedure page 8
The top of the unit rotates The base frame of the unit may not Move the unit to a level surface or away
from you. be level. install the optional leveling feet.
Excessive “rumble” when One or more worn or broken Remove turntable, replace bearings.
top rotating bearings under turntable.
Wear on underside Normal condition caused by No repair necessary.
of turntable. wear-hardening of metal.
See Figure 8 on page 14: Safe Servicing of the Lift before performing
maintenance or troubleshooting under lift.

16 PALLETPAL 360 AIR
Figure 9. Recommended Spare Parts

PALLETPAL 360 AIR 17
Ordering Replacement Parts
Southworth has carefully chosen the components in your unit to be the best available for the purpose. Replacement
parts should be identical to the original equipment. Southworth will not be responsible for equipment failures
resulting from the use of incorrect replacement parts or from unauthorized modications to the unit.
Southworth can supply all replacement parts for your PalletPal. With your order, please include the model number
and the serial number of the unit. You can nd these numbers on the name plate. This plate is located within
the scissors mechanism.
To order replacement parts, please call the Parts Department at [phone] or [phone]. Parts are
shipped subject to the following terms:
• FOB factory
• Returns only with the approval of our parts department.
• Payment net 30 days (except parts covered by warranty).
• Freight collect (except parts covered by warranty).
• The warranty for repair parts is 30 days from date of shipment.
Parts replaced under warranty are on a “charge-credit” basis. We will invoice you when we ship the replacement
part, then credit you when you return the worn or damaged part, and we verify that it is covered by our warranty.
Labor is not covered under warranty for Parts orders.
Southworth Products Corp
P.O. Box 1380, Portland, ME 04104-1380
www.SouthworthProducts.com
Email: [email protected]
Telephone: [phone] or (207)-878-0700
Fax: [phone]

18 PALLETPAL 360 AIR
SOUTHWORTH PRODUCTS CORP
P.O. Box 1380, Portland, ME 04104-1380
Telephone: [phone] • [phone]
Fax: [phone]
www.SouthworthProducts.com
Southworth Products Corp warrants this product to be free from defects in material
or workmanship for a period of 2 years of single shift usage from date of shipment,
providing claim is made in writing within that time period. The air bag has a lifetime
warranty. This warranty shall not cover modied designs for special applications, failure
or defective operation caused by misuse, misapplication, negligence or accident,
exceeding recommended capacities, failure to perform required maintenance or altering
or repairing, unless alteration is authorized by Southworth Products Corp. Except as set
forth herein, there are no other warranties, express or implied, including the warranties
of merchantability and tness for a particular purpose, all of which are hereby excluded.
Southworth Products Corp makes no warranty or representation with respect to the
compliance of any product with state or local safety or product standard codes, and any
failure to comply with such codes shall not be considered a defect of material or work-
manship under this warranty. Southworth Products Corp shall not be liable for any direct
or consequential damages arising out of such noncompliance.
Southworth Products Corp’s obligation under this warranty is limited to the replace-
ment or repair of defective components at its factory or another location at Southworth
Products Corp’s discretion. The Southworth Warranty is for product sold with in North
America. For products shipped outside of North America the warranty will be for replace-
ment of defective parts only. Labor is not included. This is buyer’s sole remedy. Except
as stated herein, Southworth Products Corp will not be liable for any loss, injury or dam-
age to persons or property, nor for direct, indirect, or consequential damage of any kind,
resulting from failure or defective operation of said product.
This warranty may be altered only in writing by Southworth Products Corp, Portland,
Maine.
2 YEAR WARRANTY
