Speakman CPT-24000 User manual

INSTRUCTIONS FOR MODELS
92-CPT-24000-01
For additional assistance or service please contact:
SPEAKMAN®Company
400 Anchor Mill Road
New Castle, DE 19720
800-537-2107
customerser[email protected]
www.speakman.com
CPT-24000
TOOLS AND SUPPLIES
Phillips
Screwdriver
Measuring
Tape
Hex Key Wrench
(Included)
Additional warranty information can be found at:
www.speakman.com
WARRANTY
MAINTENANCE
Cover your drain to prevent loss of parts.
SAFETY TIPS
IMPORTANT
• Be sure to read instructions thoroughly before
beginning installation.
• Do not over-tighten any connections or damage
may occur.
Your new Speakman Product is designed for years of
trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. The use of harsh
chemicals and abrasives on any of the Speakman custom
finish products may damage the finish and void the
product warranty. Please be sure to only use approved
cleaners. Please contact Speakman for any clarification
of acceptable cleaners.
1Clean wall surface. Place Mounting Base (1) onto the valve, align mounting holes, and secure
with supplied screws (2).
2There are two connectors included to allow for both Shallow Mount (Valve Centerline is 2.5-3.0”
from finished wall surface) and Deep Mount (Valve Centerline is 3.0”-3.5” from finished wall
surface) applications. Please select Connector appropriate for your installation.
For Deep Mount Application For Shallow Mount Application
3Confirm that the valve is in the “OFF” position. Place appropriate Connector (5) onto spindle
of valve making sure to orient the Connector so that one set of splines are perfectly vertical
as shown below.
4
When installed correctly, the Connector (5), should extend beyond the Mounting Base
in-between 1/8” -1/2”. Secure with screw (6). If your installation does not fall within this range,
try swapping Connectors.
IMPORTANT
1/8”-1/2”
5Place Wall Plate (3) onto Mounting Base. Align the flat tabs on the Mounting Base with the cut
outs on the Wall Plate as shown for perfect fit.
6Orient the Handle Assembly (1) as shown below. Place Handle Assembly (1) onto the Mounting
Base while guiding the splines of the Adapter (2) into the Handle Assembly (1). Align the
Mounting Base Tabs (3) into the corresponding recesses of the Handle Assembly (1). Once all
items are aligned, press Handle Assembly (1) inward toward Wall Plate. Secure Handle
Assembly (1) by tightening Set Screw (4) with supplied Allen Wrench.

CPT-24000 REPAIR PARTS SPEAKMAN®
ITEM NO. PART NO. DESCRIPTION
RPG05-0874 MOUNTING HARDWARE
RPG04-104273 HANDLE/ESCUTCHEON/SET SCREW
RPG10-104276 TRIM PLATE
CPT-24000 ROUGH-IN DIAGRAM SPEAKMAN®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
VALVE MOUNTING IS SHOWN FOR REFERENCE ONLY.
VALVE IS NOT INCLUDED WITH CPT-24000
87
16
"
215mm
67
8
"
175mm
13
16
"
21mm
35
16
"
83.80mm
1"
25mm
HOLE FOR
SHOWER ARM
51
2
"
140mm
HOLE FOR
VAVLE ACCESS
513
16
"
147mm
1'-9"
[533mm]
4"
[102mm]
TO TOP OF
TUB LEDGE
4'-6"
[1.4 METERS]
TO FLOOR
(SHOWER INSTALL ONLY)
6'-6"
[2 METERS]
TO FLOOR
1"
25mm
HOLE FOR
TUB SPOUT
A
A
2-1/2" [64mm] MINIMUM
3-1/2" [89mm] MAXIMUM
ROUGH IN DEPTH
37
16
"
87mm
SECTION A-A
