Speakman Sentinel Mark II SLV-3420 Guide

SPEAKMAN®
SPEAKMAN®
½

SPEAKMAN®

INSTRUCTIONS FOR MODELS
92-CPT-3001-01
For additional assistance or service please contact:
SPEAKMAN®
800-537-2107
customerser[email protected]
www.speakman.com
CPT-3001
CPT-3401
TOOLS AND SUPPLIES
IMPORTANT
Warranty information can be found at:
www.speakman.com
MAINTENANCE
WARRANTY
Phillips
Screwdriver
Hex Key Wrench
(included)
• Be sure to read instructions thoroughly before
beginning installation.
• Be sure to have properly adjusted the Temperature
Limiting Stop (TLS) as outlined in the Valve Installation
Manual.
• Cover your drain to prevent loss of parts. Be sure to
wear eye protection while cutting pipe.
Your new Valve Trim is designed for years of
trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. The use of
harsh chemicals and abrasives on any of the Speakman
custom finish products may damage the finish and void
the product warranty. Please be sure to only use
approved cleaners. Please contact Speakman for any
clarification of acceptable cleaners.
1OPTIONAL: If a firm fit is required, insert the O-Ring ❶ onto the Bonnet ❷ of the Shower Valve.
2Verify that the Valve is in the “OFF” position. Install the Wall Plate ❶ to the Valve. If installing a Diverter
model of Trim, align the Diverter Handle to the 12 o’clock position and position the Diverter Drive Tube ❷
over the Diverter Spindle of the Valve. Secure with the included Mounting Screws ❸.

3
* VIEW WITHOUT VALVE
Align the Index Plate ❶ with the Large Slot ❷ and Small Slot ❸ on the Wall Plate. If installing onto a Diverter
Model, align the U shape ❹ under the Diverter Handle and then align to the slots.
4Install the Spindle Adapter ❶ (with appropriate O-ring in its place) onto the Spindle so that the Circular Indent ❷
is pointing downward and is horizontal as shown below. Secure the Spindle Adapter with the included Screw ❸.
5Push the Escutcheon ❶ gently over the O-ring ❷ of Spindle Adapter. Thread the Escutcheon onto the Bonnet ❸
of the Valve. Hand tighten into position.
6Install Retaining Ring ❶. Align the Retaining Ring
with the Large Slot ❷ and Small Slot ❸ on the
Wall Plate. Snap in place.
* BACK OF RETAINING RING
7
* VIEW UNDER THE HANDLE
Orient the Handle ❶ as shown below and
position over the Spindle Adapter ❷. Secure with
the included Set Screw ❸.

CPT-3001/3401 REPAIR PARTS
ITEM NO. PART NO. DESCRIPTION
RPG05-1126 REPAIR PARTS GROUP FOR CPT-3X01 TRIMS
CPT-3001 ROUGH-IN DIAGRAM SPEAKMAN®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
47
16
"
112.5mm
41
8
"
105.4mm
71
16
"
180.0mm
R
7
8
"
22.5mm
TRIM IS SHOWN AT A ROUGH-IN DEPTH OF 3.0in
21
16
"
-
33
16
"
[52.4mm - 81.3mm]
CPT-3401 ROUGH-IN DIAGRAM SPEAKMAN®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
11
16
"
26.8mm
41
8
"
105.4mm
47
16
"
112.5mm
71
16
"
180.0mm
R
7
8
"
22.5mm
TRIM IS SHOWN AT A ROUGH-IN DEPTH OF 3.0in
21
16
"
-
33
16
"
[52.4mm - 81.3mm]

SPEAKMAN®
400 Anchor Mill Rd. New Castle, DE 19720 Phone: [phone] Fax: [phone]
11/06/17 www.speakman.com 92-S-2280-01
SPEAKMAN®
S-2280
Installation, Operation & Maintenance Instructions
ANYSTREAM® SHOWER HEAD
DESCRIPTION
Polished chrome plated ANYSTREAM wall mounted shower head. Rigid brass ball. Spray adjusting T-handle,
2-1/4” face. 4 Lexan® deposit resisting plungers with 32 spray channels. Drilled for but less mounting bolts.
Water conserving pressure compensating AUTOFLO® device reduces flow to 2.5 GPM/9.46LPM maximum, to
meet existing ANSI A112.18.1 Standard. Vandal resistant standard. ½” NPT back inlet.
SPECIFICATIONS Options:
SUPPLY INLET: ½” NPTF
FLOW RATE: 2.5 GPM/9.46LPM MAXIMUM
FLOW CONTROL: VARIABLE
SHIPPING WEIGHT: 2.1 LBS
INSTALLATION
Apply pipe thread tape in a clockwise direction to threads of supply nipple. Pipe joint compound may be
used instead of tape. Turning in a clockwise direction, thread the showerhead on to the supply nipple.
Tighten & position with a strap wrench or a pair of soft jaw pliers. Mark and drill holes for mounting screws
(not provided). Note: If necessary, remove shower head and use proper screw anchors (4) (not provided).
Turn the water supply on and check for leaks. Tighten mounting screws (4).
OPERATION
To adjust the spray pattern of the shower head, simply rotate the handle to the desired spray (needle spray,
gentle rain or full flood).
MAINTENANCE
The gleaming finish of your SPEAKMAN WATERSAVER® shower head can be cleaned by using mild soap and
warm water. Dry immediately with a soft, clean cloth for best results. The flow control device limits water
flow to 2.5 gallons per minute. The small orifice may become clogged with scale and other minerals found in
potable water. To clean the flow regulator, simply loosen the side set screw and remove the shower head
from the flanged elbow, remove the flow control from the brass retainer and clean as necessary.
ROUGH-IN
AP Anchor Plate Assembly with Mounting Screws
BJ Ball Joint
E15 Low Flow Head (1.5 GPM/ 5.7 LPM)
(Ball Joint Only)
E20 Low Flow Head (2.0 GPM/ 7.6 LPM)
(Ball Joint Only)
