Speakman SENTINELPRO COMBINATION SLV-5420 Guide

SPEAKMAN®
400 Anchor Mill Rd. New Castle, DE 19720 Phone: [phone] Fax: [phone]
07/30/18 www.speakman.com 92C-SLV-5420-01
SPEAKMAN®
SLV-5420
Installation, Operation & Maintenance Instructions
SENTINELPRO™ COMBINATION SERIES
DESCRIPTION
Speakman SentinelPro™ Combination, SLV-5420 includes: Trim with integral Volume Control / Diverter
Handle (CPT-5401), and AnyStream® Wall Mounted Shower Head (S-2280). This combination does not
include the Shower Valve.
This combination should be installed with one of the following
Speakman SentinelPro™ Thermostatic/Pressure Balance Diverter Shower Valves
CPV-TP-DV: Thermostatic/Pressure Balance Diverter Shower Valve
Sweat & Thread Connections
CPV-TP-DV-PXC: Thermostatic/Pressure Balance Diverter Shower Valve
PEX F1807 Crimp Inlet Connections
CPV-TP-DV-PXE: Thermostatic/Pressure Balance Shower Valve
PEX F1960 Cold-Expansion Inlet Connections
SPECIFICATIONS
CPT-5401 T/P DIVERTER VALVE TRIM:
FINISH: Polished Chrome
COMPLIANCE: ASME A112.18.1 / CSA B125.1 Standard
S-2280 ANYSTREAM® WALL MOUNTED SHOWER HEAD:
CONNECTIONS: ½” NPT Female Inlet
FLOW RATE: 2.5 gpm (9.5 L/min)
FINISH: Polished Chrome
COMPLIANCE: ASME A112.18.1 / CSA B125.1 Standard
INSTRUCTIONS
See individual products for installation of the components and warranty information.

SPEAKMAN®
400 Anchor Mill Rd. New Castle, DE 19720 Phone: [phone] Fax: [phone]
07/30/18 www.speakman.com 92C-SLV-5420-01
ROUGH-IN

INSTRUCTIONS FOR MODELS
92-CPT-5001-01
For additional assistance or service please contact:
SPEAKMAN®Company
400 Anchor Mill Road
New Castle, DE 19720
800-537-2107
customerser[email protected]
www.speakman.com
CPT-5001 / CPT-5401
TOOLS AND SUPPLIES
Phillips
Screwdriver
Silicone Caulk Gun
Additional warranty information can be found at:
www.speakman.com
WARRANTY
MAINTENANCE
Cover your drain to prevent loss of parts. Be sure to
wear eye protection while cutting pipe.
SAFETY TIPS
IMPORTANT
• Be sure to read instructions thoroughly before
beginning installation.
• Do not over-tighten any connections or damage
may occur.
• This valve has an operating range of 20-80 psi.
Your new Speakman Product is designed for years of
trouble-free performance. Keep it looking new by
cleaning it periodically with a soft cloth. The use of harsh
chemicals and abrasives on any of the Speakman custom
finish products may damage the finish and void the
product warranty. Please be sure to only use approved
cleaners. Please contact Speakman for any clarification
of acceptable cleaners.
1Remove the Handle Button Screw by inserting one of the included Mounting Screws thru the hole in the Handle.
2Insert the T/P Rubber Sleeve with Tabs over
Valve Bonnet.
3Be sure to have properly adjusted the Temperature
Limiting Stop (TLS) as per the Valve Installation
Instructions before installing
Valve Trim. Slide Trim Sleeve
over the Rubber Sleeve.
Ensure the tabs are
properly seated within
the grooves of the
Trim Sleeve.
4Clean wall surface. Orient Wall Plate as shown below. Apply clear silicone sealant to the backside outer flat
surface of the Wall Plate, while leaving a small area open at the bottom. This will allow for any moisture to drain.
5A FOR CPT-5001 - Align the Wall Plate (1) as shown below. Secure to Valve with the included Mounting Screws
(2). Take care to not over tighten Mounting Screws. Remove excess sealant after securing Wall Plate to wall.
5B FOR CPT-5401 - Align the Wall Plate (1) as shown below. Verify the Diverter Valve Stem is in the OFF (vertical)
position. Align the Diverter Drive Tube (3) on the Wall Plate to the Stem (4) of the Diverter Valve. Secure to Valve
with the included Mounting Screws (2). Take care to not over tighten Mounting Screws. Remove excess sealant
after securing Wall Plate to wall.
* VIEW FROM BACK OF WALL PLATE
6Remove protective film from Trim Index Plate.
7
OR
CPT-5001: Slide Index Plate over
the Trim Sleeve. Align Index Plate
with the small Alignment Pin on the
Wall Plate, and hold Index Plate in
place for the next step.
CPT-5401: Slip the upper hole of
the Index Plate over the Diverter
Handle and then align the large hole
of the Index Plate over the Trim
Sleeve. Align Trim Index Plate with
the small Alignment Pin on the Wall
Plate, and hold Index Plate in place
for the next step.

8Ensure the Rubber Gasket is correctly installed to the Retaining
Ring. Align the Retaining Ring with the slots on the Wall Plate.
Press and Rotate the ring clock-wise until it Locks / Seals in place.
Make sure the seal is secure with the Wall Plate.
9Temporarily place Handle over splines and adjust the valve to
the OFF position (as per the Valve Instructions). Then, align Handle
vertically as shown below. Secure Handle to Spindle with the
included #8 Screw.
10 Insert Handle Button into the Handle.
* VIEW FROM BACK UNDERSIDE OF HANDLE
If further adjustments need to be made after
the Handle Button is inserted, there is an
access hole at the back side of the handle.
Use a paper clip to push the Button back out.
CPT-5001 / CPT-5401 REPAIR PARTS SPEAKMAN®
ITEM NO. PART NO. DESCRIPTION
RPG04-0443 HANDLE ASSEMBLY
RPG05-1111 RETAINING RING WITH SEAL
RPG05-1110 TRIM SLEEVE AND RUBBER SLEEVE
RPG41-0286 INDEX PLATE
RPG10-0120 WALL PLATE
RPG10-0121 WALL PLATE WITH DIVERTER
RPG10-0119 MOUNTING HARDWARE (ALL SCREWS)
RPG41-0286-DV DIVERTER MODEL INDEX PLATE

CPT-5001 ROUGH-IN DIAGRAM SPEAKMAN®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
VALVE MOUNTING IS SHOWN FOR REFERENCE ONLY.
VALVE IS NOT INCLUDED WITH CPT-5000
4.31in
110mm
1.53in
39mm
3.75in
95mm
6'-6" [2 METERS]
TO FLOOR
1'-9" [533mm]
4’-6" [1.4 METERS]
TO FLOOR
(SHOWER
INSTALLATION
ONLY)
4" [102mm]
TO TOP OF
TUB LEDGE
1"
25mm
HOLE FOR
SHOWER ARM
1"
25mm
HOLE FOR
TUB SPOUT
A
A
1/2" NPT MALE
1/2" SWEAT
CONNECTION
1/2" NPT MALE
1/2" SWEAT
CONNECTION
1/2" NPT MALE
1/2" SWEAT
CONNECTION
1/2" NPT MALE
1/2" SWEAT
CONNECTION
5-1/2" (140MM) DIA.
HOLE FOR
VALVE ACCESS
2-1/2" MIN
[64mm]
3-1/2" MAX
[89mm]
(ADJUSTMENT)
7.50in
191mm
3.50in
89mm
CPT-5401 ROUGH-IN DIAGRAM SPEAKMAN®
DIMENSIONS SUBJECT TO CHANGE WITHOUT NOTICE.
VALVE MOUNTING IS SHOWN FOR REFERENCE ONLY.
VALVE IS NOT INCLUDED WITH CPT-5400
4.31in
110mm
1.53in
39mm
3.75in
95mm
6'-6" [2 METERS]
TO FLOOR
1'-9" [533mm]
4’-6" [1.4 METERS]
TO FLOOR
(SHOWER
INSTALLATION
ONLY)
4" [102mm]
TO TOP OF
TUB LEDGE
1"
25mm
HOLE FOR
SHOWER ARM
1"
25mm
HOLE FOR
TUB SPOUT
A
A
1/2" NPT MALE
1/2" SWEAT
CONNECTION 1/2" NPT MALE
1/2" SWEAT
CONNECTION
1/2" NPT MALE
1/2" SWEAT
CONNECTION
1/2" NPT MALE
1/2" SWEAT
CONNECTION
5-1/2" (140MM) DIA.
HOLE FOR
VALVE ACCESS
2-1/2" MIN
[64mm]
3-1/2" MAX
[89mm]
(ADJUSTMENT)
7.50in
191mm
3.50in
89mm

SPEAKMAN®
400 Anchor Mill Rd. New Castle, DE 19720 Phone: [phone] Fax: [phone]
11/06/17 www.speakman.com 92-S-2280-01
SPEAKMAN®
S-2280
Installation, Operation & Maintenance Instructions
ANYSTREAM® SHOWER HEAD
DESCRIPTION
Polished chrome plated ANYSTREAM wall mounted shower head. Rigid brass ball. Spray adjusting T-handle,
2-1/4” face. 4 Lexan® deposit resisting plungers with 32 spray channels. Drilled for but less mounting bolts.
Water conserving pressure compensating AUTOFLO® device reduces flow to 2.5 GPM/9.46LPM maximum, to
meet existing ANSI A112.18.1 Standard. Vandal resistant standard. ½” NPT back inlet.
SPECIFICATIONS Options:
SUPPLY INLET: ½” NPTF
FLOW RATE: 2.5 GPM/9.46LPM MAXIMUM
FLOW CONTROL: VARIABLE
SHIPPING WEIGHT: 2.1 LBS
INSTALLATION
Apply pipe thread tape in a clockwise direction to threads of supply nipple. Pipe joint compound may be
used instead of tape. Turning in a clockwise direction, thread the showerhead on to the supply nipple.
Tighten & position with a strap wrench or a pair of soft jaw pliers. Mark and drill holes for mounting screws
(not provided). Note: If necessary, remove shower head and use proper screw anchors (4) (not provided).
Turn the water supply on and check for leaks. Tighten mounting screws (4).
OPERATION
To adjust the spray pattern of the shower head, simply rotate the handle to the desired spray (needle spray,
gentle rain or full flood).
MAINTENANCE
The gleaming finish of your SPEAKMAN WATERSAVER® shower head can be cleaned by using mild soap and
warm water. Dry immediately with a soft, clean cloth for best results. The flow control device limits water
flow to 2.5 gallons per minute. The small orifice may become clogged with scale and other minerals found in
potable water. To clean the flow regulator, simply loosen the side set screw and remove the shower head
from the flanged elbow, remove the flow control from the brass retainer and clean as necessary.
ROUGH-IN
AP Anchor Plate Assembly with Mounting Screws
BJ Ball Joint
E15 Low Flow Head (1.5 GPM/ 5.7 LPM)
(Ball Joint Only)
E20 Low Flow Head (2.0 GPM/ 7.6 LPM)
(Ball Joint Only)
