Speco PVS-CAMB User manual

speco technologies
TM
PVS– CAMB
B/W CCD OBSERVATION CAMERA
WITH VARIFOCAL LENS
speco technologies
200 New Highway
Amityville, NY 11701
Toll Free : 1-800-645-5516
In Metro NY : 631-957-8700
www.specotech.com
OPERATION MANUAL

INSTRUCTION MANUAL
B/W CCD OBSERVATION CAMERA
WITH VARIFOCAL LENS
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE, REFER FOR SERVICE TO QUALIFIED
SERVICE PERSONNEL.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO WATER OR WET LOCATIONS.
1 PVS-CAMB
MEMO
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION

MEMO
DIMENSION
FRONT SIDE
PVS-CAMB 2
GENERAL FEATURES
yDigital signal processing
y0.02 LUX sensitivity
yBack Light Compensation
50mm
50mm
DIGITAL CCD CAMERA
125mm
50mm
BACK
50mm
SPEAKER
OUT OUT
POWER
MONITOR
50mm
SENSOR
TRIGGER G B+
ESC AGC
ON ON
ESC AGC
OFF OFF
SPEAKER
+ GND

3PVS-CAMB
SPECIFICATIONS
Always use discretion when installing video and or audio surveillance
equipment especially when there is perceived privacy or an expectation of
privacy. Inquire regarding federal, state and or local regulations applicable
to the lawful installation of video and or audio recording or surveillance.
Party consent may be required.
PVS-CAMB 4
ITEM PVS-CAMB
Image Sensor Varifocal Lens (3.5mm ~ 8mm)
Effective Pixels 512H ×492V (270K pixels)
Scanning System 525 Lines 2:1 Interlace
Scanning
Frequency 15.734KHz(H), 59.94Hz(V)
Resolution 420TV – Lines
Shutter Speed 1/60 ~ 1/100,000 sec
S/N Ratio More than 50dB (AGC off)
Sync. System Internal
Min. Illumination 0.02LUX (F1.2)
Video Output VBS 1.0 Vp-p (75 ohm load)
Lens C/CS MOUNT
Power Supply DC 9.5V ~ 16V
Power
Consumption 90mA(DC12V)
Operating Temp. -10℃~ +50℃
Operating Humidity 90% RH max.
Weight Approx. 250g
Accessory 60ft cable , stand, wrench
Option : PIR sensor
SPECIFICATIONS
yESC ON/OFF
yAGC ON/OFF
ySPEAKER ON/OFF
yAUDIO
ySENSOR (TRIGGER,G,B+) FOR PIR
50mm
ESC AGC
ON ON SPEAKER
ESC AGC
OFF OFF
OUT IN
POWER
MONITOR
50mm
DIN JACK CONFIGURATION
①DC 12V OUTPUT ② N.C
③ VIDEO INPUT ④ PIR INPUT
⑤AUDIO INPUT ⑥AUDIO OUTPUT
SNESOR CABLE CONFIGURATION
(RED: DC 12V)
(BLACK : GND)
(WHITE : TRIGGER)
SENSOR
TRIGGER G B+
SPEAKER
+ GND
⑥ ⑤
④ ③
② ①
