Spectra 1689 User manual

User Quick Reference Guide
1689 LED Keypad / 1641 LCD Keypad
KEYPAD OVERVIEW
To arm
when leaving...
To arm
when staying...
1689 LED Keypad
PRINTED IN CANADA 10/04
www.paradox.ca
Security Company:
Stay Lights
(for Stay & Instant arming)
ON = area 1 or 2 armed
OFF = area 1 or 2 disarmed
FLASH = area 1 or 2 in alarm
1641 LCD Keypad
Zone Display
The numbers represent zones 1
to 16. When illuminated, the
zones are open or breached.
FNC1 Key
Your system may have one or
more home-automation options.
One of these options may be
triggered directly from the
keypad. Press and hold [FNC1] for
3 seconds to activate:
___________________________
(i.e. reset smoke detector,
activate lights, etc.)
Arrow Keys
Use the arrow keys to scroll
menu or choices.
Arm Lights
(for Regular & Force arming)
ON = area 1 or 2 armed
OFF = area 1 or 2 disarmed
FLASH = area 1 or 2 in alarm
AC Light
(for Stay & Instant Arming)
ON = AC power
OFF = power failure
Status Light
Green
ON = zones closed
OFF = zone(s) open
FLASH = exit delay
Red (1641 only)
ON = system armed
FLASH = stay armed
FAST FLASH = alarm
Made a mistake?
Press [CLEAR]to delete an entry
or revert to last step.
ARMING AND DISARMING
Regular Arm:
Arm entire area when all zones are
closed.
Enter your [ACCESS CODE]*.
(or press and hold [ENTER]for 3
seconds)†.
Force Arm:
Arm area without waiting for all zones to
close.
Press [FORCE]and then enter your
[ACCESS CODE]*.
(or press and hold [FORCE]for 3
seconds)†.
Stay Arm:
Arm area’s perimeter, which allows you to
remain in the protected area.
Press [STAY]* and then enter your [ACCESS
CODE]*.
(or press and hold [STAY]for 3 seconds)†.
Instant Arm:
Area is stay armed, but an alarm occurs
instantly if any armed zones are
breached.
Stay arm and then press and hold [STAY]
for 3 seconds during the Exit Delay.
Disarming:
Enter your [ACCESS CODE]*.
* If needed, press the key(s) corresponding to the desired area(s). For two areas, press the other
key after the confirmation beep.
†The One-Touch Arming feature must be enabled by your installer.
1689_41-EQ00
LCD Screen
Messages on the LCD screen
will guide you through the
operations.
1689_41-EQ00.qxd 10/28/2004 11:33 AM Page 1

ALARM MEMORY DISPLAY
PANIC ALARMS
To send a silent or audible alarm to your
monitoring station, press and hold one of
the key combinations listed below for 3
seconds.
Panic Alarm Type Key Combination
Police Press [1] and [3]
Medical Press [4] and [6]
Fire Press [7] and [9]
To view the alarms that occurred during
the last armed period:
1. Press [MEM].
2. 1689: The light(s) corresponding to the
breached zone(s) will illuminate.
1641: Use [S] and [T]to view the
breached zone(s).
3. Press [CLEAR]to exit.
TROUBLE DISPLAY
When a trouble condition occurs...
1689: the TRBL light flashes.
1641: the message “System Trouble
[TRBL] to view” appears on the
screen.
1. Press [TRBL].
2. 1689: Numbers corresponding to
troubles will illuminate.
1641: Use [S] and [T]to view the
trouble(s).
Please consult the Trouble List in the
user manual or contact your installer
for repairs.
3. Press [CLEAR]to exit.
KEYPAD SETTINGS(1641 ONLY)
You can customize the keypad settings to
suit your needs.
1. Press and hold [6] for 3 seconds.
2. Choose one of the following. Press:
[1] Backlight: keypad’s light (7 is
brightest).
[2] Contrast: character intensity (7 is
lightest).
[3] Scroll Speed: time between
messages (7 is slowest).
3. Press [S] and [T]to modify.
4. Press [ENTER] to save.
5. Return to step 2 or press [CLEAR]to
exit.
BYPASS PROGRAMMING
Bypassed zones are not armed when the
area is armed.
1. Press [BYP]and then enter your
[ACCESS CODE]*.
(or press and hold [BYP]for 3
seconds)**.
2. Enter the zone number.
Or scroll the list and then press [BYP]
when the desired zone appears on the
screen (1641 only).
OR
Press [BYP]to activate Bypass Recall
(bypasses the zones that were
bypassed during the last armed
period).
3. Press [ENTER]to exit.
CHIME PROGRAMMING
The keypad beeps when a chime zone
opens.
1. Press and hold [9] for 3 seconds.
2. Enter the 2-digit zone number.
Or scroll the list and then press [FNC1]
when the desired zone appears on the
screen (1641 only).
3. Press [ENTER](1689) / [CLEAR](1641)
to exit.
CLOCK PROGRAMMING
1689: Set the system clock.
1. Press [ENTER].
2. Enter the [SYSTEM MASTER CODE].
3. Enter [100].
4. Enter the time using the 24h clock (i.e.
6:15 p.m. = 18:15).
5. Press [CLEAR]to exit.
1641: Set the system clock and day.
1. Press [ENTER].
2. Enter the [SYSTEM MASTER CODE].
3. Enter [100].
4. Enter the time.
a. If the keypad is set to follow the 24h
clock (i.e. 18:15), proceed
to step 6.
b. If the keypad is set to follow the 12h
clock (i.e. 6:15 p.m.), proceed to step
5.
5. After entering the time, press [1] to set
the time in a.m. or [2] to set the time in
p.m..
6. Press [S] and [T]to select the day of
the week.
7. Press [ENTER]to exit.
* If needed, press the key(s) corresponding to the desired area(s). For two areas, press the other
key after the confirmation beep.
** The One-Touch Bypass Programming feature must be enabled by your installer.
1689_41-EQ00.qxd 10/28/2004 11:33 AM Page 2

ALARM MEMORY DISPLAY
PANIC ALARMS
To send a silent or audible alarm to your
monitoring station, press and hold one of
the key combinations listed below for 3
seconds.
Panic Alarm Type Key Combination
Police Press [1] and [3]
Medical Press [4] and [6]
Fire Press [7] and [9]
To view the alarms that occurred during
the last armed period:
1. Press [MEM].
2. 1689: The light(s) corresponding to the
breached zone(s) will illuminate.
1641: Use [S] and [T]to view the
breached zone(s).
3. Press [CLEAR]to exit.
TROUBLE DISPLAY
When a trouble condition occurs...
1689: the TRBL light flashes.
1641: the message “System Trouble
[TRBL] to view” appears on the
screen.
1. Press [TRBL].
2. 1689: Numbers corresponding to
troubles will illuminate.
1641: Use [S] and [T]to view the
trouble(s).
Please consult the Trouble List in the
user manual or contact your installer
for repairs.
3. Press [CLEAR]to exit.
KEYPAD SETTINGS(1641 ONLY)
You can customize the keypad settings to
suit your needs.
1. Press and hold [6] for 3 seconds.
2. Choose one of the following. Press:
[1] Backlight: keypad’s light (7 is
brightest).
[2] Contrast: character intensity (7 is
lightest).
[3] Scroll Speed: time between
messages (7 is slowest).
3. Press [S] and [T]to modify.
4. Press [ENTER] to save.
5. Return to step 2 or press [CLEAR]to
exit.
BYPASS PROGRAMMING
Bypassed zones are not armed when the
area is armed.
1. Press [BYP]and then enter your
[ACCESS CODE]*.
(or press and hold [BYP]for 3
seconds)**.
2. Enter the zone number.
Or scroll the list and then press [BYP]
when the desired zone appears on the
screen (1641 only).
OR
Press [BYP]to activate Bypass Recall
(bypasses the zones that were
bypassed during the last armed
period).
3. Press [ENTER]to exit.
CHIME PROGRAMMING
The keypad beeps when a chime zone
opens.
1. Press and hold [9] for 3 seconds.
2. Enter the 2-digit zone number.
Or scroll the list and then press [FNC1]
when the desired zone appears on the
screen (1641 only).
3. Press [ENTER](1689) / [CLEAR](1641)
to exit.
CLOCK PROGRAMMING
1689: Set the system clock.
1. Press [ENTER].
2. Enter the [SYSTEM MASTER CODE].
3. Enter [100].
4. Enter the time using the 24h clock (i.e.
6:15 p.m. = 18:15).
5. Press [CLEAR]to exit.
1641: Set the system clock and day.
1. Press [ENTER].
2. Enter the [SYSTEM MASTER CODE].
3. Enter [100].
4. Enter the time.
a. If the keypad is set to follow the 24h
clock (i.e. 18:15), proceed
to step 6.
b. If the keypad is set to follow the 12h
clock (i.e. 6:15 p.m.), proceed to step
5.
5. After entering the time, press [1] to set
the time in a.m. or [2] to set the time in
p.m..
6. Press [S] and [T]to select the day of
the week.
7. Press [ENTER]to exit.
* If needed, press the key(s) corresponding to the desired area(s). For two areas, press the other
key after the confirmation beep.
** The One-Touch Bypass Programming feature must be enabled by your installer.
1689_41-EQ00.qxd 10/28/2004 11:33 AM Page 2

User Quick Reference Guide
1689 LED Keypad / 1641 LCD Keypad
KEYPAD OVERVIEW
To arm
when leaving...
To arm
when staying...
1689 LED Keypad
PRINTED IN CANADA 10/04
www.paradox.ca
Security Company:
Stay Lights
(for Stay & Instant arming)
ON = area 1 or 2 armed
OFF = area 1 or 2 disarmed
FLASH = area 1 or 2 in alarm
1641 LCD Keypad
Zone Display
The numbers represent zones 1
to 16. When illuminated, the
zones are open or breached.
FNC1 Key
Your system may have one or
more home-automation options.
One of these options may be
triggered directly from the
keypad. Press and hold [FNC1] for
3 seconds to activate:
___________________________
(i.e. reset smoke detector,
activate lights, etc.)
Arrow Keys
Use the arrow keys to scroll
menu or choices.
Arm Lights
(for Regular & Force arming)
ON = area 1 or 2 armed
OFF = area 1 or 2 disarmed
FLASH = area 1 or 2 in alarm
AC Light
(for Stay & Instant Arming)
ON = AC power
OFF = power failure
Status Light
Green
ON = zones closed
OFF = zone(s) open
FLASH = exit delay
Red (1641 only)
ON = system armed
FLASH = stay armed
FAST FLASH = alarm
Made a mistake?
Press [CLEAR]to delete an entry
or revert to last step.
ARMING AND DISARMING
Regular Arm:
Arm entire area when all zones are
closed.
Enter your [ACCESS CODE]*.
(or press and hold [ENTER]for 3
seconds)†.
Force Arm:
Arm area without waiting for all zones to
close.
Press [FORCE]and then enter your
[ACCESS CODE]*.
(or press and hold [FORCE]for 3
seconds)†.
Stay Arm:
Arm area’s perimeter, which allows you to
remain in the protected area.
Press [STAY]* and then enter your [ACCESS
CODE]*.
(or press and hold [STAY]for 3 seconds)†.
Instant Arm:
Area is stay armed, but an alarm occurs
instantly if any armed zones are
breached.
Stay arm and then press and hold [STAY]
for 3 seconds during the Exit Delay.
Disarming:
Enter your [ACCESS CODE]*.
* If needed, press the key(s) corresponding to the desired area(s). For two areas, press the other
key after the confirmation beep.
†The One-Touch Arming feature must be enabled by your installer.
1689_41-EQ00
LCD Screen
Messages on the LCD screen
will guide you through the
operations.
1689_41-EQ00.qxd 10/28/2004 11:33 AM Page 1
